LG LHD655W Specification sheet

SIMPLE MANUAL
DVD Wireless
Home Theater
System
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
LHD655W
*MFL69400850* www.lg.com
ENGLISH
LHD655W-FC.DEGYLLC_SIMPLE_ENG_0850.indd 1 2015-09-17  9:28:49

Front Panel Rear Panel
MIC 1/2···················· Connect a microphone.
PORT. IN ··············Connect to a Portable device.
USB Port····················Connect a USB device.
R··························Disc Tray Open / Close
T·······················Starts / Pauses playback.
I·································Stops playback.
F············· Changes the input source or function.
- / +·······························Adjusts volume.
1/! ······························Power On / Off
SPEAKERS ··················· Connect to speakers.
HDMI OUT TO TV··················· Connect to TV.
AUX (L/R) INPUT······ Connect to analogue device.
VIDEO OUT ························ Connect to TV.
OPTICAL IN ·············· Connect to digital device.
ANTENNA FM ·········· Connect to radio antenna.
Speaker Assembling1
About Ferrite Core (Optional)
Speaker design and connection method may
be different according to models.
,
Speaker Connection2
twice
Front
(Left)
Center
Subwoofer
Unit
Surround
(Left)
Wireless
Receiver
Front
(Right)
Surround
(Right)
LHD655W-FC.DEGYLLC_SIMPLE_ENG_0850.indd 2 2015-09-17  9:28:52

Home menu appears on the TV screen. Enjoy various
functions on the player.
TV Connection4
Home Menu5
HDMI & Optical Connection
aConnect the Player to the TV using HDMI &
Optical cable.
bSet the input selector to HDMI on the TV.
cSet up [External Speaker (Optical)] on your TV
setting menu.
dFollow the instructions on the TV screen using
remote control.
For more information, download the online owner’s manual. http://www.lg.com
LG Sound Sync
(Wireless)
aConnect the rear speakers to the wireless
receiver.
bConnect the power cord of wireless receiver to
the outlet.
cTurn on the player :
The player and wireless receiver will be
automatically connected. A yellow-green LED on
the wireless receiver will light on.
If no sound is heard from the rear speakers
connected to wireless receiver, please follow as
below.
i. Adjust volume level of player to minimum.
“VOL MIN” appears on display window.
ii. Press and hold (Mute) button on the
remote control about 3 seconds.
The red LED will icker.
iii. Press and hold PAIRING on the rear of
wireless receiver for more than 5 seconds
using point of a pen.
iv. Disconnect the power cord of the player and
the wireless receiver. Connect them again.
Pair Up with Wireless Receiver3
TV
LHD655W-FC.DEGYLLC_SIMPLE_ENG_0850.indd 3 2015-09-17  9:28:53

Specication
Power
requirements Refer to main label.
Power
consumption
Refer to main label.
Networked standby : 0.4 W
(If all network ports are
activated.)
Dimensions
(W x H x D)
Approx. 360 mm x 60.5 mm x
299 mm
Net Weight Approx. 2.69 kg
Bus Power Supply
(USB) 5 V 0 500 mA
Amplier
(Total RMS output
power)
1,000 W
Design and specications are subject to change without
notice.
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
Additional Information
