LG LHD657M Specification sheet

www.lg.com
Copyright © 2019 LG Electronics Inc. All Rights Reserved.1903_Rev01
MFL71385102
SIMPLE MANUAL
DVD Home
Theater
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit http://www.lg.com and
then download Owner’s Manual. Some of the content in this manual may
differ from your unit.
MODEL
LHD657M
ENGLISH FRANÇAIS PORTUGUÊS
LHD657M-FC.DGHALLK_SIM_ENG_MFL71385102.indd 1 2019-03-08  9:32:38

Front Panel Rear Panel
MIC 1/2···················· Connect a microphone.
PORT. IN ··············Connect to a Portable device.
USB Port····················Connect a USB device.
R··························Disc Tray Open / Close
T·······················Starts / Pauses playback.
I·································Stops playback.
F············· Changes the input source or function.
- / +·······························Adjusts volume.
1/! ······························Power On / Off
SPEAKERS ··················· Connect to speakers.
HDMI OUT TO TV··················· Connect to TV.
AUX (L/R) INPUT······ Connect to analogue device.
VIDEO OUT ························ Connect to TV.
OPTICAL IN ·············· Connect to digital device.
ANTENNA FM ·········· Connect to radio antenna.
Speaker Assembling1 Speaker Connection2
Speaker design and connection method may
be different according to models.
,
Front
(Right)
Front
(Left)
Center
Subwoofer
Unit
Surround
(Left) Surround
(Right)
LHD657M-FC.DGHALLK_SIM_ENG_MFL71385102.indd 2 2019-03-08  9:32:40

TV Connection3
HDMI & Optical Connection
aConnect the Unit to the TV using HDMI & Optical
cable.
bSet the input selector to HDMI on the TV.
cSet up [External Speaker (Optical)] on your TV
setting menu.
dFollow the instructions on the TV screen using
remote control.
For more information, download the online owner’s manual. http://www.lg.com
Home menu appears on the TV screen. Enjoy various
functions on the unit.
Home Menu4
Front
(Right)
LHD657M-FC.DGHALLK_SIM_ENG_MFL71385102.indd 3 2019-03-08  9:32:41

Specication
Power
requirements Refer to main label.
Power
consumption Refer to main label.
Dimensions
(W x H x D)
Approx. 360 mm x 58 mm x
298.5 mm
Bus Power Supply
(USB) 5 V 0 500 mA
Amplier
(Total RMS output
power)
1,000 W RMS
Design and specications are subject to change without
notice.
