ENGLISH
SIMPLE MANUAL
DVD Home
Theater
System
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
LHD756
*MFL69443604* Copyright © 2017 LG Electronics. All Rights Reserved
www.lg.com
Specication
Power
requirements Refer to main label.
Power
consumption Refer to main label.
Dimensions
(W x H x D)
Approx.
440 mm x 65 mm x 298 mm
Net Weight Approx. 3.2 kg
Bus Power Supply
(USB) 5 V 0 500 mA
Amplier
(Total RMS output
power)
1,200 W
Design and specications are subject to change without
notice.
Replacement of battery
POWER: This unit operates on a mains supply of 200 -
240 V ~, 50 / 60 Hz.
Wiring: This unit is supplied with a BS 1363 approved
main plug. When replacing the fuse, always use of the
same rating approved to BS 1362. Never use this plug
with the fuse cover omitted. To obtain a replacement
fuse cover contact your dealer. If the type of plug
supplied is not suitable for the mains sockets in your
home, then the plug should be removed and a suitable
type tted. Please refer to the wiring instructions below:
Warning: A mains plug removed from the mains lead of
this unit must be destroyed. A mains plug with bared
wires is hazardous if inserted in a mains socket. Do not
connect either wire to the earth pin, marked with the
letter E or with the earth symbol 6or coloured green
or green and yellow. If any other plug is tted, use same
rating of fuse in the plug.
Important: The wires in this mains lead are coloured in
accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE: As the colours of the
wires in the mains lead of this unit may not correspond
with the coloured marking identifying the terminals in
your plug, proceed as follows: The wire which is coloured
blue must be connected to the terminal which is marked
with the letter N or coloured black. The wire which is
coloured brown must be connected to the terminal
which is marked with the letter L or coloured red.
Additional Information
LHD756-FC.DLKALLK_SIM_ENG_MFL69443604.indd 1-2 2017-05-12 �� 1:51:43

Home menu appears on the TV screen. Enjoy various
functions on the player.
TV Connection3Home Menu4
HDMI & Optical Connection
aConnect the Player to the TV using HDMI &
Optical cable.
bSet the input selector to HDMI on the TV.
cSet up [External Speaker (Optical)] on your
TV setting menu.
dFollow the instructions on the TV screen
using remote control.
For more information, download the online owner’s manual. http://www.lg.com
Front Panel Rear Panel
MIC 1/2· · · · · · · · · · · · · · · · · · · · Connect a microphone.
PORT. IN · · · · · · · · · · · · · ·Connect to a Portable device.
USB Port· · · · · · · · · · · · · · · · · · · · Connect a USB device.
R· · · · · · · · · · · · · · · · · · · · · · · · · · Disc Tray Open / Close
T· · · · · · · · · · · · · · · · · · · · · · ·Starts / Pauses playback.
I· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·Stops playback.
F· · · · · · · · · · · · · Changes the input source or function.
- / +· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · Adjusts volume.
1/! · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · Power On / Off
SPEAKERS · · · · · · · · · · · · · · · · · · · Connect to speakers.
ANTENNA FM · · · · · · · · · · Connect to radio antenna.
AUX (L/R) INPUT· · · · · · Connect to analogue device.
VIDEO OUT · · · · · · · · · · · · · · · · · · · · · · · · Connect to TV.
HDMI OUT TO TV· · · · · · · · · · · · · · · · · · · Connect to TV.
OPTICAL IN · · · · · · · · · · · · · · Connect to digital device.
Speaker design and connection method may
be different according to models.
,
Speaker Connection2Speaker Assembling1
Front
(Right)
Front
(Left)
Center
Subwoofer
Unit
Surround
(Left)
Surround
(Right)
Small
screw
Small
screw
Big
screw
