Front
(Right)
Front
(Left)
Center
Subwoofer
Unit
Surround
(Left) Surround
(Right)
Front Panel Rear Panel
MIC 1/2···················· Connect a microphone.
PORT. IN ··············Connect to a Portable device.
USB Port····················Connect a USB device.
R··························Disc Tray Open / Close
T·······················Starts / Pauses playback.
I·································Stops playback.
F············· Changes the input source or function.
- / +·······························Adjusts volume.
1/! ······························Power On / Off
SPEAKERS ··················· Connect to speakers.
HDMI OUT TO TV··················· Connect to TV.
AUX (L/R) INPUT······ Connect to analogue device.
VIDEO OUT ························ Connect to TV.
OPTICAL IN ·············· Connect to digital device.
ANTENNA FM ·········· Connect to radio antenna.
Speaker Assembling1
Speaker design and connection method may
be different according to models.
,
Speaker Connection2
