LG 42LF5809 User manual

Please read this manual carefully before operating your set and
retain it for future reference.
Safety and Reference
OWNER’S MANUAL
www.lg.com
P/NO : MFL68662432 (1502-REV00)
Printed in Korea
*MFL68662432*

2
ENGLISH
Safety instructions
Please read these safety precautions carefully before
using the product.
WARNING
Do not place theTV and/or remote control in the following
environments:
• A location exposed to direct sunlight
• An area with high humidity such as a bathroom
• Near any heat source such as stoves and other devices that
produce heat
• Near kitchen counters or humidiers where they can easily be
exposed to steam or oil
• An area exposed to rain or wind
• Near containers of water such as vases
Otherwise, this may result in re, electric shock, malfunction or product
deformation.
Do not place the product where it might be exposed to dust. This may
cause a re hazard.
Mains Plug is theTV connecting/disconnecting device to AC mains
electric supply. This plug must remain readily attached and operable
whenTV is in use.
Do not touch the power plug with wet hands. Additionally, if the cord
pin is wet or covered with dust, dry the power plug completely or wipe
dust o. You may be electrocuted due to excess moisture.
Make sure to connect Mains cable to compliant AC mains socket with
Grounded earth pin. (Except for devices which are not grounded on
earth.) Otherwise possibility you may be electrocuted or injured.
Insert power cable plug completely into wall socket otherwise if not
secured completely into socket, re ignition may break out.
Ensure the power cord does not come into contact with hot objects
such as a heater. This may cause a re or an electric shock hazard.
Do not place a heavy object, or the product itself, on power cables.
Otherwise, this may result in re or electric shock.
Bend antenna cable between inside and outside building to prevent
rain from owing in. This may cause water damaged inside the Product
and could give an electric shock.
When mountingTV onto wall make sure to neatly install and isolate
cabling from rear ofTV as to not create possibility of electric shock /
re hazard.
Do not plug too many electrical devices into a single multiple electrical
outlet. Otherwise, this may result in re due to over-heating.

ENGLISH
3
Do not drop the product or let it fall over when connecting external
devices. Otherwise, this may result in injury or damage to the product.
Desiccant
Keep the anti-moisture packing material or vinyl packing out of the
reach of children. Anti-moisture material is harmful if swallowed. If
swallowed by mistake, force the patient to vomit and visit the nearest
hospital. Additionally, vinyl packing can cause suocation. Keep it out
of the reach of children.
Do not let your children climb or cling onto the TV.
Otherwise, theTV may fall over, which may cause serious injury.
Dispose of used batteries carefully to ensure that a small child does not
consume them. Please seek Doctor- Medical Attention immediately if
child consumes batteries.
Do not insert any metal objects/conductors (like a metal chopstick/
cutlery/screwdriver) between power cable plug and inputWall Socket
while it is connected to the input terminal on the wall. Additionally,
do not touch the power cable right after plugging into the wall input
terminal.You may be electrocuted. (Depending on model)
Do not put or store inammable substances near the product. There is a
danger of combustion/explosion or re due to careless handling of the
inammable substances.
Do not drop metallic objects such as coins, hair pins, chopsticks or wire
into the product, or inammable objects such as paper and matches.
Children must pay particular attention. Electrical shock, re or injury
can occur. If a foreign object is dropped into the product, unplug the
power cord and contact the service centre.
Do not spray water on the product or scrub with an inammable
substance (thinner or benzene). Fire or electric shock accident can
occur.
Do not allow any impact, shock or any objects to fall into the unit,
and do not drop anything onto the screen.You may be injured or the
product can be damaged.
Never touch this product or antenna during a thunder or lighting storm.
You may be electrocuted.
Never touch the wall outlet when there is leakage of gas, open the
windows and ventilate. It may cause a re or a burn by a spark.
Do not disassemble, repair or modify the product at your own
discretion. Fire or electric shock accident can occur.
Contact the service centre for check, calibration or repair.

4
ENGLISH
If any of the following occur, unplug the product immediately and
contact your local service centre.
• The product has been impacted by shock
• The product has been damaged
• Foreign objects have entered the product
• The product produced smoke or a strange smell
This may result in re or electric shock.
Unplug theTV from AC mains wall socket if you do not intend to use the
TV for a long period of time. Accumulated dust can cause re hazard
and insulation deterioration can cause electric leakage/shock/re.
Apparatus shall not be exposed to dripping or splashing and no objects
lled with liquids, such as vases, shall be placed on the apparatus.
Do not install this product on a wall if it could be exposed to oil or oil
mist.This may damage the product and cause it to fall.
If water enters or comes into contact withTV, AC adapter or power
cord please disconnect the power cord and contact service centre
immediately. Otherwise, this may result in electric shock or re.
Only use an authorized AC adapter and power cord approved by
LG Electronics. Otherwise, this may result in re, electric shock,
malfunction or product deformation.
Never Disassemble the AC adapter or power cord.This may result in re
or electric shock.
CAUTION
Install the product where no radio wave occurs.
There should be enough distance between an outside antenna and
power lines to keep the former from touching the latter even when the
antenna falls. This may cause an electric shock.
Do not install the product on places such as unstable shelves or inclined
surfaces. Also avoid places where there is vibration or where the
product cannot be fully supported. Otherwise, the product may fall or
ip over, which may cause injury or damage to the product.
If you install theTV on a stand, you need to take actions to prevent the
product from overturning. Otherwise, the product may fall over, which
may cause injury.
If you intend to mount the product to a wall, attachVESA standard
mounting interface (optional parts) to the back of the product.When
you install the set to use the wall mounting bracket (optional parts), x
it carefully so as not to drop.
Only use the attachments / accessories specied by the manufacturer.
When installing the antenna, consult with a qualied service
technician. If not installed by a qualied technician, this may create a
re hazard or an electric shock hazard.

ENGLISH
5
We recommend that you maintain a distance of at least 2 to 7 times
the diagonal screen size when watchingTV. If you watchTV for a long
period of time, this may cause blurred vision.
Only use the specied type of battery. This could cause damage to the
remote control.
Do not mix new batteries with old batteries.This may cause the
batteries to overheat and leak.
Batteries should not be exposed to excessive heat. For example, keep
away from direct Sunlight , open replace and electric heaters.
Do not place non-rechargeable batteries in charging device.
Make sure there are no objects between the remote control and its
sensor.
Signal from Remote Control can be interrupted due to external/internal
lighting eg Sunlight, uorescent lighting. If this occurs turn o lighting
or darken viewing area.
When connecting external devices such as video game consoles, make
sure the connecting cables are long enough. Otherwise, the product
may fall over, which may cause injury or damage the product.
Do not turn the product On/O by plugging-in or unplugging the power
plug to the wall outlet. (Do not use the power plug for switch.) It may
cause mechanical failure or could give an electric shock.
Please follow the installation instructions below to prevent the product
from overheating.
• The distance between the product and the wall should be more
than 10cm.
• Do not install the product in a place with no ventilation (e.g., on a
bookshelf or in a cupboard).
• Do not install the product on a carpet or cushion.
• Make sure the air vent is not blocked by a tablecloth or curtain.
Otherwise, this may result in re.
Take care not to touch the ventilation openings when watching the TV
for long periods as the ventilation openings may become hot.This does
not aect the operation or performance of the product.
Periodically examine the cord of your appliance, and if its appearance
indicates damage or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an exact replacement part
by an authorized servicer.
Prevent dust collecting on the power plug pins or outlet.This may cause
a re hazard.
Protect the power cord from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and the point where the cord
exits the appliance.

6
ENGLISH
Do not press strongly upon the panel with a hand or sharp object such
as nail, pencil or pen, or make a scratch on it, as it may causedamage
to screen.
Avoid touching the screen or holding your nger(s) against it for long
periods of time. Doing so may produce some temporary or permanent
distortion/damage to screen.
When cleaning the product and its components, unplug the power
rst and wipe it with a soft cloth. Applying excessive force may cause
scratches or discolouration. Do not spray with water or wipe with a wet
cloth. Never use glass cleaner, car or industrial shiner, abrasives or wax,
benzene, alcohol etc., which can damage the product and its panel.
Otherwise, this may result in re, electric shock or product damage
(deformation, corrosion or breakage).
As long as this unit is connected to the AC wall outlet, it is not
disconnected from the AC power source even if you turn o this unit
by SWITCH.
When unplugging the cable, grab the plug and unplug it, by pulling at
the plug.
Don’t pull at the cord to unplug the power cord from the power board,
as this could be hazardous.
When moving the product, make sure you turn the power o rst.Then,
unplug the power cables, antenna cables and all connecting cables.
TheTV set or power cord may be damaged, which may create a re
hazard or cause electric shock.
When moving or unpacking the product, work in pairs because the
product is heavy. Otherwise, this may result in injury.
Contact the service centre once a year to clean the internal parts of the
product.
Accumulated dust can cause mechanical failure.
Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
If the product feels cold to the touch, there may be a small“icker”
when it is turned on.This is normal, there is nothing wrong with
product.
The panel is a high technology display product with resolution of two
million to six million pixels. You may see tiny black dots and/or brightly
coloured dots (red, blue or green) at a size of 1ppm on the panel.This
does not indicate a malfunction and does not aect the performance
and reliability of the product.
This phenomenon also occurs in third-party products and is not subject
to exchange or refund.

ENGLISH
7
You may nd dierent brightness and color of the panel depending on
your viewing position(left/right/top/down).
This phenomenon occurs due to the characteristic of the panel. It is not
related with the product performance, and it is not malfunction.
* LG LED TVs are LCD TVs with LED backlighting.
Displaying a still image (e.g., broadcasting channel logo, on-screen
menu, scene from a video game) for a prolonged time may cause
damage to the screen, resulting in retention of the image, which is
known as image sticking.The warranty does not cover the product for
image sticking.
Avoid displaying a xed image on your television’s screen for a
prolonged period (2 or more hours for LCD, 1 or more hours for Plasma).
Also, if you watch the TV at a ratio of 4:3 for a long time, image sticking
may occur on the borders of the panel.
This phenomenon also occurs in third-party products and is not subject
to exchange or refund.
Generated sound
“Cracking”noise: A cracking noise that occurs when watching or turning
o theTV is generated by plastic thermal contraction due to tempera-
ture and humidity.This noise is common for products where thermal
deformation is required. Electrical circuit humming/panel buzzing:
A low level noise is generated from a high-speed switching circuit,
which supplies a large amount of current to operate a product. It varies
depending on the product.
This generated sound does not aect the performance and reliability
of the product.
Do not use high voltage electrical goods near the TV (e.g. electric
mosquito-swatter).This may result in product malfunction.
Preparing
NOTE
• Image shown may dier from yourTV.
• Your TV’s OSD (On Screen Display) may dier slightly from that
shown in this manual.
• The available menus and options may dier from the input source
or product model that you are using.
• New features may be added to thisTV in the future.
• TheTV can be placed in standby mode in order to reduce the power
consumption. And theTV should be turned o if it will not be
watched for some time, as this will reduce energy consumption.
• The energy consumed during use can be signicantly reduced if the
level of brightness of the picture is reduced, and this will reduce
the overall running cost.
• The items supplied with your product may vary depending on the
model.
• Product specications or contents of this manual may be changed
without prior notice due to upgrade of product functions.
• For an optimal connection, HDMI cables and USB devices should
have bezels less than 10 mm thick and 18 mm width. Use an
extension cable that supports USB 2.0 if the USB cable or USB
memory stick does not t into your TV’s USB port.
A
B
A
B
*A
<
=
10 mm
*B
<
=
18 mm
• Use a certied cable with the HDMI logo attached.
• If you do not use a certied HDMI cable, the screen may not display
or a connection error may occur. (Recommended HDMI CableTypes)
- High-Speed HDMI®/TM Cable (3 m or less)
- High-Speed HDMI®/TM Cable with Ethernet (3 m or less)
CAUTION
• Do not use any unapproved items to ensure the safety and product
life span.
• Any damage or injuries caused by using unapproved items are not
covered by the warranty.
• Some models have a thin lm attached on to the screen and this
must not be removed.

8
ENGLISH
Separate purchase
Separate purchase items can be changed or modied for quality
improvement without any notication. Contact your dealer to buy these
items.These devices only work with certain models.
The model name or design may be changed depending on the upgrade
of product functions, manufacturer’s circumstances or policies.
(Depending on model)
AN-VC5**
Smart camera
AN-MR500
Magic Remote
AN-WF500
Wi-Fi/Bluetooth Dongle
LG Audio Device
* You can use the Magic Remote and LG Audio Device(Wireless) only
when you are using the Wi-Fi/Bluetooth Dongle.
Maintenance
Cleaning your TV
Clean yourTV regularly to keep the best performance and to extend the
product lifespan.
• Make sure to turn the power o and disconnect the power cord and
all other cables rst.
• When theTV is left unattended and unused for a long time,
disconnect the power cord from the wall outlet to prevent possible
damage from lightning or power surges.
Screen, frame, cabinet and stand
To remove dust or light dirt, wipe the surface with a dry, clean, and
soft cloth.
To remove major dirt, wipe the surface with a soft cloth dampened in
clean water or a diluted mild detergent. Then wipe immediately with
a dry cloth.
• Avoid touching the screen at all times, as this may result in damage
to the screen.
• Do not push, rub, or hit the screen surface with your ngernail or a
sharp object, as this may result in scratches and image distortions.
• Do not use any chemicals as this may damage the product.
• Do not spray liquid onto the surface. If water enters theTV, it may
result in re, electric shock, or malfunction.
Power cord
Remove the accumulated dust or dirt on the power cord regularly.
Lifting and moving the TV
Please note the following advice to prevent theTV from being scratched
or damaged and for safe transportation regardless of its type and size.
• It is recommended to move theTV in the box or packing material
that theTV originally came in.
• Before moving or lifting theTV, disconnect the power cord and
all cables.
• When holding theTV, the screen should face away from you to
avoid damage.
• Hold the top and bottom of theTV frame rmly. Make sure not to
hold the transparent part, speaker, or speaker grill area.
• When transporting a largeTV, there should be at least 2 people.
• When transporting the TV by hand, hold the TV as shown in the
following illustration.
• When transporting the TV, do not expose theTV to jolts or
excessive vibration.
• When transporting the TV, keep theTV upright, never turn theTV
on its side or tilt towards the left or right.
• Do not apply excessive pressure to cause exing /bending of frame
chassis as it may damage screen.
• When handling theTV, be careful not to damage the protruding
joystick button.
CAUTION
• Avoid touching the screen at all times, as this may result in damage
to the screen.
• Do not move theTV by holding the cable holders, as the cable
holders may break, and injuries and damage to theTV may occur.

ENGLISH
9
Using the joystick button
(Image shown may dier from yourTV.)
You can simply operate theTV functions, pressing or moving the joystick
button up, down, left or right.
Joystick Button
Basic functions
Power On
When theTV is turned o, place your
nger on the joystick button and
press it once and release it.
Power O
When theTV is turned on, place your
nger on the joystick button and
press it once for a few seconds and
release it. (However, if the Menu
button is on the screen, pressing and
holding the joystick button will let
you exit the Menu.)
Volume
Control
If you place your nger over the
joystick button and move it left or
right, you can adjust the volume level
you want.
Programmes
Control
If you place your nger over the
joystick button and move it up or
down, you can scrolls through the
saved programmes you want.
Adjusting the menu
When theTV is turned on, press the joystick button one time. You can
adjust the Menu items moving the joystick button up, down, left or
right.
Turns the power o.
Clears on-screen displays and returns toTV viewing.
Changes the input source.
Accesses the main menu.
NOTE
• When your nger over the joystick button and push it to the up,
down, left or right, be careful not to press the joystick button. If you
press the joystick button rst, you may not be able to adjust the
volume level and saved programmes.
Mounting on a table
(Depending on model)
1 Lift and tilt the TV into its upright position on a table.
• Leave a 10 cm (minimum) space from the wall for proper
ventilation.
10 cm
10 cm
10 cm
10 cm
10 cm
2 Connect the power cord to a wall outlet.
CAUTION
• Do not place theTV near or on sources of heat, as this may result in
re or other damage.
Securing the TV to a wall
(This feature is not available for all models.)
1 Insert and tighten the eye-bolts, orTV brackets and bolts on the back
of theTV.
• If there are bolts inserted at the eye-bolts position, remove the
bolts rst.
2 Mount the wall brackets with the bolts to the wall.
Match the location of the wall bracket and the eye-bolts on the rear
of theTV.
3 Connect the eye-bolts and wall brackets tightly with a sturdy rope.
Make sure to keep the rope horizontal with the at surface.
CAUTION
• Make sure that children do not climb on or hang on theTV.
NOTE
• Use a platform or cabinet that is strong and large enough to
support the TV securely.
• Brackets, bolts and ropes are not provided.You can obtain
additional accessories from your local dealer.

10
ENGLISH
Mounting on a wall
Attach an optional wall mount bracket at the rear of the TV carefully
and install the wall mount bracket on a solid wall perpendicular to
the oor. When you attach theTV to other building materials, please
contact qualied personnel. LG recommends that wall mounting be
performed by a qualied professional installer.We recommend the
use of LG’s wall mount bracket. When you do not use LG’s wall mount
bracket, please use a wall mount bracket where the device is adequately
secured to the wall with enough space to allow connectivity to external
devices.
10 cm
10 cm
10 cm
10 cm
Make sure to use screws and wall mount bracket that meet theVESA
standard. Standard dimensions for the wall mount kits are described in
the following table.
Separate purchase (Wall mounting bracket)
Model 22LF49** 28LF49**
VESA (A x B) 75 x 75 100 x 100
Standard screw M4 X L10 M4 X L10
Number of screws 4 4
Wall mount bracket LSW140B LSW140B
Model 32LF58** 42/50/55LF58**
VESA (A x B) 200 x 200 400 x 400
Standard screw M6 M6
Number of screws 4 4
Wall mount bracket LSW240B
MSW240
LSW440B
MSW240
A
B
CAUTION
• Disconnect the power rst, and then move or install theTV.
Otherwise electric shock may occur.
• Remove the stand before installing theTV on a wall mount by
performing the stand attachment in reverse.
• If you install theTV on a ceiling or slanted wall, it may fall and
result in severe injury. Use an authorised LG wall mount and
contact the local dealer or qualied personnel.
• Do not over tighten the screws as this may cause damage to theTV
and void your warranty.
• Use the screws and wall mounts that meet theVESA standard. Any
damages or injuries by misuse or using an improper accessory are
not covered by the warranty.
• Screw length from outer surface of back cover should be under
8 mm. (Only LF49**)
Wall mount Pad
Back Cover
Standard screw
: M4 x L10
Wall mount Pad
Back Cover
Max. 8 mm
NOTE
• Use the screws that are listed on theVESA standard screw
specications.
• The wall mount kit includes an installation manual and necessary
parts.
• The wall mount bracket is not provided.You can obtain additional
accessories from your local dealer.
• The length of screws may dier depending on the wall mount.
Make sure to use the proper length.
• For more information, refer to the manual supplied with the wall
mount.
• When attaching a wall mounting bracket to theTV, insert the wall
mount spacers into the TV wall mount holes to adjust the vertical
angle of theTV. (Only when the item of the following form is
provided)
Provided Item
Wall Mount Spacer

ENGLISH
11
Connections (notications)
Connect various external devices to the TV and switch input modes to
select an external device. For more information of external device’s
connection, refer to the manual provided with each device.
Available external devices are: HD receivers, DVD players,VCRs, audio
systems, USB storage devices, PC, gaming devices, and other external
devices.
NOTE
• The external device connection may dier from the model.
• Connect external devices to theTV regardless of the order of the
TV port.
• If you record aTV program on a DVD recorder orVCR, make sure to
connect the TV signal input cable to the TV through a DVD recorder
orVCR. For more information of recording, refer to the manual
provided with the connected device.
• Refer to the external equipment’s manual for operating
instructions.
• If you connect a gaming device to theTV, use the cable supplied
with the gaming device.
• In PC mode, there may be noise associated with the resolution,
vertical pattern, contrast or brightness. If noise is present, change
the PC output to another resolution, change the refresh rate to
another rate or adjust the brightness and contrast on the PICTURE
menu until the picture is clear.
• In PC mode, some resolution settings may not work properly
depending on the graphics card.
Antenna connection
Connect theTV to a wall antenna socket with an RF cable (75 Ω).
• Use a signal splitter to use more than 2TVs.
• If the image quality is poor, install a signal amplier properly to
improve the image quality.
• If the image quality is poor with an antenna connected, try to
realign the antenna in the correct direction.
• An antenna cable and converter are not supplied.
• Supported DTV Audio: MPEG, Dolby Digital, Dolby Digital Plus,
HE-AAC
Satellite dish connection
(Only satellite models)
Connect theTV to a satellite dish to a satellite socket with a satellite RF
cable (75 Ω).
Adapter connection
(Depending on model)
• Please be sure to connect theTV to the AC-DC power adapter
before connecting theTV’s power plug to a wall power outlet.
Euro scart connection
(Depending on model)
Transmits the video and audio signals from an external device to the
TV set. Connect the external device and theTV set with the euro scart
cable.
Output Type
Current
input mode
AV1
(TV Out1)
DigitalTV Digital TV
AnalogueTV, AV
AnalogueTVComponent
HDMI
1 TV Out : Outputs AnalogueTV or Digital TV signals.
• Any Euro scart cable used must be signal shielded.
CI module connection
(Depending on model)
View the encrypted (pay) services in digitalTV mode.
• Check if the CI module is inserted into the PCMCIA card slot in the
right direction. If the module is not inserted properly, this can
cause damage to theTV and the PCMCIA card slot.
• If theTV does not display any video and audio when CI+ CAM is
connected, please contact to theTerrestrial/Cable/Satellite Service
Operator.
Other connections
Connect yourTV to external devices. For the best picture and audio
quality, connect the external device and theTV with the HDMI cable.
Some separate cable is not provided.

12
ENGLISH
Remote control
The descriptions in this manual are based on the buttons on the remote
control. Please read this manual carefully and use theTV correctly.
To replace batteries, open the battery cover, replace batteries (1.5
V AAA) matching the and ends to the label inside the
compartment, and close the battery cover.To remove the batteries,
perform the installation actions in reverse.
CAUTION
• Do not mix old and new batteries, as this may damage the remote
control.
• The remote control will not be included for all sales market.
Make sure to point the remote control toward the remote control sensor
on theTV.
(Depending on model)
FAV
P
PAGE
A
B
A
(POWER) Turns the TV on or o.
Selects Radio,TV and DTV programme.
Recalls your preferred subtitle in digital mode.
Accesses the quick menus.
Shows programme guide.
By Pressing AD button, audio descriptions function will be
enabled.
Changes the input source.
Number buttons Enters numbers.
Accesses the saved programme list.
(Space) Opens an empty space on the screen keyboard.
Returns to the previously viewed programme.
B
Adjusts the volume level.
Accesses your favourite programme list.
Views the information of the current programme and screen.
Mutes all sounds.
Scrolls through the saved programmes.
Moves to the previous or next screen.
Accesses the main menus.
Accesses the Home menu.
Shows the list of Apps.
FAV
P
PAGE
C
C
Teletext buttons ( / ) These buttons are used for
teletext.
Navigation buttons (up/down/left/right) Scrolls through menus
or options.
Selects menus or options and conrms your input.
Returns to the previous level.
Clears on-screen displays and returns toTV viewing.
Selects the MHP TV menu source. (Depending on model)
Starts to record and displays record menu. (OnlyTime
MachineReady supported model) (Depending on model)
Returns to LIVE TV.
Control buttons () Controls the Premium
contents,Time MachineReady or SmartShare menus or the SIMPLINK
compatible devices (USB or SIMPLINK orTime MachineReady).
Coloured buttons These access special functions in some menus.
(: Red, : Green, :Yellow, : Blue)

ENGLISH
13
(Depending on model)
B
A
P
A
G
E
FAV
MUTE
1 .,;@ 2 abc 3 def
4 ghi 5 jkl 6 mno
7
pqrs
8
tuv
0
9
wxyz
A
(POWER) Turns the TV on or o.
Recalls your preferred subtitle in digital mode.
Resizes an image.
Changes the input source.
Selects Radio,TV and DTV programme.
Number buttons Enters numbers.
Accesses the saved programme list.
(Space) Opens an empty space on the screen keyboard.
Returns to the previously viewed programme.
B
Adjusts the volume level.
Accesses your favourite programme list.
Shows programme guide.
Mutes all sounds.
Scrolls through the saved programmes.
Moves to the previous or next screen.
C
D
P
A
G
E
FAV
MUTE
1 .,;@ 2 abc 3 def
4 ghi 5 jkl 6 mno
7 pqrs 8 tuv
0
9
wxyz
C
Views the information of the current programme and screen.
Accesses the Home menu.
Shows the list of Apps.
Navigation buttons (up/down/left/right) Scrolls through menus
or options.
Selects menus or options and conrms your input.
Returns to the previous level.
Accesses the main menus.
Clears on-screen displays and returns toTV viewing.
D
Coloured buttons These access special functions in some menus.
( : Red, : Green, :Yellow, : Blue)
Teletext buttons ( / ) These buttons are used for
teletext.
Accesses the quick menus.
Returns to LIVE TV.
Control buttons () Controls the Premium
contents,Time MachineReady or SmartShare menus or the SIMPLINK
compatible devices (USB or SIMPLINK orTime MachineReady).
Starts to record and displays record menu. (OnlyTime
MachineReady supported model) (Depending on model)
Sets the sleep timer.
By Pressing AD button, audio descriptions function will be
enabled.
Selects the MHP TV menu source. (Depending on model)

14
ENGLISH
Licenses
Supported licenses may dier by model. For more information about
licenses, visit www.lg.com.
Open source software
notice information
To obtain the source code under GPL, LGPL, MPL, and other open source
licenses, that is contained in this product, please visit http://opensource.
lge.com.
In addition to the source code, all referred license terms, warranty
disclaimers and copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM
for a charge covering the cost of performing such distribution (such
as the cost of media, shipping, and handling) upon email request to
[e-mail] oer is valid for three (3) years from the date
on which you purchased the product.
External control device
setup
To obtain the external control device setup information, please visit
www.lg.com.
Troubleshooting
Cannot control theTV with the remote control.
• Check the remote control sensor on the product and try again.
• Check if there is any obstacle between the product and the remote
control.
• Check if the batteries are still working and properly installed (
to , to ).
No image display and no sound is produced.
• Check if the product is turned on.
• Check if the power cord is connected to a wall outlet.
• Check if there is a problem in the wall outlet by connecting other
products.
TheTV turns o suddenly.
• Check the power control settings.The power supply may be
interrupted.
• Check if the Automatic Standby (Depending on model) / Sleep
Timer / Off Time is activated in the TIME settings.
• If there is no signal while theTV is on, the TV will turn o
automatically after 15 minutes of inactivity.
When connecting to the PC (HDMI),‘No signal’or‘Invalid Format’is
displayed.
• Turn the TV o/on using the remote control.
• Reconnect the HDMI cable.
• Restart the PC with the TV on.

ENGLISH
15
Specications
Wireless LAN module specication
• Because band channel used by the country could be dierent, the
user can not change or adjust the operating frequency and this
product is set for the regional frequency table.
• This device should be installed and operated with minimum
distance 20 cm between the device and your body. And this phrase
is f or the general statement for consideration of user environment.
0197
0197
Wireless LAN module (TWFM-B006D) specification
Standard IEEE802.11a/b/g/n
Frequency Range
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz (for Non EU)
Output Power (Max.)
802.11a: 11 dBm
802.11b: 14 dBm
802.11g: 10.5 dBm
802.11n - 2.4 GHz: 11 dBm
802.11n - 5 GHz: 12.5 dBm

Bitte lesen Sie dieses Handbuch aufmerksam durch, bevor
Sie Ihr Gerät zum ersten Mal verwenden und bewahren Sie
es zur späteren Verwendung auf.
Sicherheit und Hinweise
BENUTZERHANDBUCH
www.lg.com

2
DEUTSCH
Sicherheitshinweise
Bevor Sie das Produkt zum ersten Mal verwenden,
lesen Sie diese Sicherheitshinweise bitte
aufmerksam durch.
WARNUNG
Stellen Sie dasTV-Gerät mit Fernsteuerung nicht in folgenden
Umgebungen auf:
• Unter direkter Sonneneinstrahlung
• In Bereichen mit hoher Luftfeuchtigkeit, wie z.B. einem
Badezimmer
• In der Nähe von Hitzequellen, wie z.B. Öfen und anderen
hitzeerzeugenden Geräten
• In der Nähe von Küchenzeilen oder Befeuchtern, wo das Gerät
leicht Dampf oder Öl ausgesetzt sein kann
• In Bereichen, die Regen oderWind ausgesetzt sind
• In der Nähe von Behältern mitWasser, wie z.B.Vasen
Andernfalls kann es zu Bränden, Stromschlägen, Fehlfunktionen oder
Produktverformungen kommen.
Schützen Sie das Gerät vor Staub. Es besteht Brandgefahr.
Wenn Sie das Gerät vom Stromnetz trennen möchten, müssen Sie den
Netzstecker aus der Steckdose ziehen. Dieser Stecker muss jederzeit gut
zugänglich sein.
Berühren Sie den Netzstecker nicht mit nassen Händen.Wenn die
Kontaktstifte nass oder verstaubt sind, trocknen Sie den Netzstecker
vollständig ab, bzw. befreien Sie ihn von Staub. Feuchtigkeit erhöht die
Gefahr eines tödlichen Stromschlags.
Stellen Sie sicher, dass das Stromkabel geerdet ist. (Außer bei Geräten,
die nicht geerdet sind.) Bei Nichtbeachtung besteht die Gefahr von
Verletzungen oder eines tödlichen Stromschlags.
Das Stromkabel muss vollständig in die Steckdose eingesteckt werden.
Ist das Stromkabel nicht fest in die Steckdose eingesteckt, besteht
Brandgefahr.
Das Stromkabel darf nicht mit heißen Gegenständen wie einem
Heizkörper in Berührung kommen. Andernfalls bestehen Brandgefahr
und die Gefahr von Stromschlägen.
Stellen Sie keinen schweren Gegenstand oder das Gerät selbst auf
das Stromkabel. Andernfalls kann es zu Bränden und Stromschlägen
kommen.
Platzieren Sie das Antennenkabel zwischen dem Innen- und
Außenbereich des Gebäudes so, dass kein Regen hereinießen kann.
EtwaigerWassereintritt kann zu Schäden am Gerät und Stromschlag
führen.
Falls dasTV-Gerät an derWand montiert wird, darf es nicht an
den Strom- und Signalkabeln auf der Rückseite desTV-Gerätes
aufgehängt werden. Anderenfalls besteht die Gefahr von Bränden oder
Stromschlägen.
Schließen Sie nicht zu viele Elektrogeräte an einer einzelnen Steckdose
an. Andernfalls kann es aufgrund von Überhitzung zu Bränden
kommen.

DEUTSCH
3
Lassen Sie das Gerät beim Anschluss eines externen Gerätes nicht
fallen. Andernfalls könnenVerletzungen verursacht oder das Gerät
beschädigt werden.
Desiccant
Bewahren Sie dasTrockengranulat und dieVinyl-Verpackung außerhalb
der Reichweite von Kindern auf.Trockengranulat ist beiVerschlucken
gesundheitsschädlich. Falls es verschluckt wurde, Erbrechen
herbeiführen und die Person ins nächste Krankenhaus bringen.
Außerdem besteht Erstickungsgefahr durch dieVinyl-Verpackung.
Bewahren Sie sie außerhalb der Reichweite von Kindern auf.
Achten Sie darauf, dass sich Kinder nicht an das TV-Gerät hängen oder
daran hochklettern. Andernfalls kann das Gerät umfallen, wodurch
schwereVerletzungen hervorgerufen werden können.
Leere Batterien müssen sicher entsorgt werden, um zu verhindern, dass
Kinder sie verschlucken. Wenn ein Kind eine Batterie verschluckt hat,
sofort den Arzt aufsuchen.
Berühren Sie das Ende des Netzkabels nicht mit einem leitenden
Gegenstand (wie einer Gabel), während das Netzkabel mit der
Steckdose verbunden ist. Berühren Sie das Netzkabel nicht, kurz
nachdem Sie es mit der Steckdose verbunden haben.
Es besteht die Gefahr eines tödlichen Stromschlags.
(Abhängig vom Modell)
Bringen Sie keine entammbaren Stoe in die Nähe des Gerätes.
Bei unsachgemäßem Umgang mit entammbaren Stoen besteht
Explosionsgefahr.
Es dürfen keine Metallgegenstände wie Münzen, Haarnadeln,
Besteck oder Draht bzw. entzündliche Gegenstände wie Papier oder
Streichhölzer in das Gerät gelangen. Achten Sie insbesondere auf
Kinder. Es besteht die Gefahr von Stromschlag, Brand oderVerletzung.
Wenn ein Gegenstand in das Gerät gelangt, ziehen Sie das Stromkabel,
und wenden Sie sich an den Kundendienst.
Sprühen Sie keinWasser auf das Produkt, und bringen Sie es nicht mit
entzündlichen Stoen (Verdünnungsmittel oder Benzol) inVerbindung.
Es besteht Stromschlag- und Brandgefahr.
Setzen Sie das Produkt keinen Schlägen und Stößen aus. Sorgen Sie
dafür, dass keine Gegenstände auf das Gerät oder den Bildschirm fallen.
Es bestehtVerletzungsgefahr. Außerdem kann das Produkt beschädigt
werden.
Berühren Sie das Produkt oder die Antenne nicht während eines
Gewitters. Es besteht die Gefahr eines tödlichen Stromschlags.
Im Falle eines Gasaustritts berühren Sie keinesfalls die Steckdose.
Önen Sie zum Lüften die Fenster. Durch Funken können ein Brand
oderVerbrennungen hervorgerufen werden.
Sie dürfen das Gerät nicht eigenmächtig auseinanderbauen, reparieren
oder verändern. Es besteht Stromschlag- und Brandgefahr. Wenden
Sie sich zur Überprüfung, Kalibrierung oder Reparatur an den
Kundendienst.

4
DEUTSCH
Ziehen Sie in jedem der folgenden Fälle sofort den Netzstecker, und
setzen Sie sich mit Ihrem Kundendienst vor Ort in Verbindung.
• Das Gerät wurde einer Erschütterung ausgesetzt
• Das Gerät wurde beschädigt
• Fremdkörper sind in das Gerät gelangt
• Vom Gerät sind Rauch oder ungewöhnliche Gerüche ausgegangen
Dies kann Brand oder Stromschlag verursachen.
Ziehen Sie das Stromkabel aus der Steckdose, wenn das Gerät für
längere Zeit nicht verwendet wird.Wenn das Gerät eingestaubt ist,
besteht Brandgefahr. EinVerschleiß der Isolation kann zu Kriechverlust,
Stromschlag oder Brand führen.
Achten Sie darauf, dass keine Flüssigkeit auf das Gerät spritzt oder
tropft. Stellen Sie keine Gegenstände, die Flüssigkeiten enthalten (z.B.
Vasen), auf dem Gerät ab.
Installieren Sie dieses Produkt nicht anWänden, falls es dadurch Öl oder
Ölnebel ausgesetzt werden könnte. Dies kann zu Schäden am Produkt
führen oder das Produkt könnte sich lösen.
WennWasser oder eine andere Substanz in das Produkt (z.B.
Netzadapter, Netzkabel,TV-Gerät) eindringen, unterbrechen Sie
zuerst die Stromzufuhr (Hauptsicherung), ziehen Sie anschließend das
Netzkabel ab und kontaktieren Sie unverzüglich den Kundendienst.
Andernfalls kann es zu einem Brand oder Stromschlag kommen.
Verwenden Sie nur autorisierte Netzadapter und Netzkabel, die von
LGElectronics genehmigt wurden. Andernfalls kann es zu Bränden,
Stromschlägen, Fehlfunktionen oder Produktverformungen kommen.
Nehmen Sie den Netzadapter und das Netzkabel nicht auseinander.
Andernfalls kann es zu einem Brand oder Stromschlag kommen.
VORSICHT
Stellen Sie das Gerät nicht in der Nähe von Funkwellen auf.
Der Abstand zwischen einer Außenantenne und Stromleitungen muss
groß genug sein, um eine Berührung der beiden zu verhindern, selbst
wenn die Antenne herunterfällt. Andernfalls besteht die Gefahr von
Stromschlägen.
Stellen Sie das Produkt nicht auf unstabilen Regalen oder geneigten
Oberächen auf. Vermeiden Sie außerdem Stellplätze, die vibrieren
oder auf denen das Produkt keinen sicheren Halt hat. Andernfalls
kann das Gerät herunter- oder umfallen, wodurchVerletzungen oder
Beschädigungen am Gerät verursacht werden können.
Wenn Sie das TV-Gerät auf einem Standfuß aufstellen, müssen Sie
durch vorbeugende Maßnahmen ein Umkippen verhindern. Andernfalls
kann dasTV-Gerät umfallen, wodurchVerletzungen hervorgerufen
werden können.
Wenn Sie das TV-Gerät an derWand montieren, befestigen Sie eine
VESA-Standardwandhalterung (optional) an der Rückseite des Gerätes.
Wenn Sie das TV-Gerät mit der optionalenWandhalterung montieren
möchten, befestigen Sie diese sorgfältig, um ein Herunterfallen zu
vermeiden.
Verwenden Sie nur vom Hersteller empfohlenes Zubehör.
Konsultieren Sie bei der Installation der Antenne eine qualizierte
Fachkraft. Andernfalls besteht Brandgefahr bzw. die Gefahr von
Stromschlägen.
