TCL LCD32E9A-MS91LA User manual

TCL
SERVICE MANUAL
LCD32E9A-MS91LA
1. Caution…………………………………………………………………………2
2. specification……………………………………………………………………6
3. Alignment Procedure……………………………………………………………7
4．Block of Diagram ……………………………………………………………13
5．Scheme Diagram ……………………………………………………………14
6. Troubleshooting………………………………………………………………26
7. PCB Layout …………………………………………………………………32
8. Explode Diagram ……………………………………………………………38
9. Main IC specification…………………………………………………………39
10．BOM List ……………………………………………………………………43
This manual is the latest at the time of printing, and does not
include the modification which may be made after the printing, by
the constant improvement of product

CA UTION: TO RE DUCE THE RIS K OF
ELECTR ICA L SHOCK, DO NOT RE MOVE
COVER (OR BACK). NO USER SERVICEABLE
PAR TS INS IDE . RE FER SER VIC ING TO
QUALIFIE D SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
CA U T ION
RISK
RISK
OF ELECTRI
ELECTRI
C
SHOCK
SHOCK
DO NOT
NOT
OPEN.
OPEN.
2
dangerous
WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
SCHNEIDER ELECTRONICS GMBH-GERMANY
1. CAUTION
2

1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.
4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.
6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.
7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.
9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance. Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.
10.2. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
CAUTION:
Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and
Instructions marked on the audio equipment.
1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated.
2. Retain Instructions- The safety and operating instructions should be retained for future reference.
3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions- All operating and use instructions should be followed.
3
SCHNEIDER ELECTRONICS GMBH-GERMANY
IMPORTANT SAFETY INSTRUCTIONS
FOR YOUR PERSONAL SAFETY
3

11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.
12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.
13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.
14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.
Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.
15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.
15.2. Note to CATV system installer : (Only for the television set with CATV reception)
This reminder is provided to call the CATV system attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.
ANTENNA
LEAD- IN WIRE
ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMP
NEC-NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS
a built-in
installer s
4
SCHNEIDER ELECTRONICS GMBH-GERMANY
PROTECTION AND LOCATION OF YOUR SET
PROTECTION AND LOCATION OF YOUR SET
4

18. This television set should be operated only from the type of power source indicated on the marking label.If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.
19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.
20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.
21. If you are unable to restorenormal operation by followingthe detailedprocedurein your operatinginstructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.
22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.
23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.
24. Do not use attachments not recommendedby the television set manufacturer as they may cause hazards.
25. When replacementparts are required, be sure the service technicianhas used replacementparts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.
off
5
SCHNEIDER ELECTRONICS GMBH-GERMANY
OPERATION OF YOUR SET
IF THE SET DOES NOT OPERATE PROPERLY
FOR SERVICE AND MODIFICATION
5

EM BUSINESS CENTER
FTV PRODUCT MANAGEMENT DEPT.
SPECIFICATION RELEASE
Version: V1.0 Issued Date: 2008.06.03
Panel Size (inch) 32"
Category LCDTV
Aspect Ratio 16:9
Color Temperature Cool/ Normal / Warm SIGNAL FORMAT CAPABILITY
Backlight Adjustable Yes,Manual Adjustable & DBC(Dynamic Backlight Control ）Component Video Format Y,Pb/Cb,Pr/Cr:up to 1080P
Scaler Mode 4:3,14:9,16:9 ,FULL DVI Video Format --
Picture Effect 4 picture effects preset (Bright,Soft,Personal,Natural) HDMI Video Format Up to up to 1080P
Film Mode (3:2 pull down) Yes PC Compatibility VGA,SVGA,XGA etc.
Picture Enhancement TERMINALS
Comb Filter 3D Audio/CVBS Input (Composite) 3 R/L+3 Video: AV1,AV2,AV3(side)
Core Technology High-quality scaling engine&3-D video de-interlacer S-Video Input 1
DCC(Dynamic Contrast Control) Yes Audio Input for S-Video Share with Audio for AV2
DCDiTM Edge-oriented adaptive algorithm for smooth low-angle edges YPbPr Input 1
Blue Stretch Yes Audio Input for YPbPr 1
Black Stretch Yes YCbCr Input Share with "YPbPr"
Motion Compensation Yes Audio Input for YCbCr Share with Audio for "YPbPr"
DLTI Yes VGA Input(RGB) 1 (D-Sub,15 Pins)
DCTI Yes Audio Input for RGB Share with Audio for "YPbPr"
Dynamic Skin Correction Yes DVI --
DNR Yes Audio Input for DVI --
Panel Specification HDMI 2
Panel supplier SAMSUNG Audio/CVBS Output (Composite) 1 (R/L+CVBS) (RCA)
Viewing Technology PVA SPDIF Output 1 (Optical sound out,RCA)
Display Resolution 1366*768 Headphone Output 1 (Φ3.5mm )
Brightness (cd/m2) 450 RF Input(Antenna) 1 ("F" Type)
Contrast Ratio 2000:1 USB 1 (Standard)
Response Time 8ms (G to G) BASIC INFO.
Viewing Angle (H/V) 176°/176° TV System NTSC-M,PAL M,N
Life Time 60,000hrs AV System PAL,NTSC
Color 16.7M Channels 181
SOUND Chassis MS91-LA
Speakers Integrated speakers (Two mediant and one woofer) Certification CB
Audio Power Output 5W×2+8W(Woofer) Power Supply AC 100V-240V 50/60Hz
Sound Processing BTSC;SAP;Stereo Power Consumption-TV on 130W
DVSS (Dolby Virtual Surround) -- Power Consumption-Standby ＜3W
DDAS (Digital Dynimic Audio System) Yes Default Color of Front Cabinet Black
AVC (Auto Volume Control) Yes Keyboard Position Touch keyboard on the left side
BBE -- Base Stand Detachable Yes
SRS Yes Unpackaged Dimension for Main Body (L*H*D) (mm)
With Base Stand (mm) 796*584*231
Without Base Stand (mm) 796*534*104
Packaged Dimension (L*H*D)
Main Body (mm) 915*652*260
FUNCTION Speaker Box --
V-Chip Yes Base Stand Packaged with Main Body
CCD (Closed Caption) Yes Net Weight (Kg) 13.3
Teletext -- Gross Weight (Kg) 16
PIP/POP Yes see note 1 Container Loading
Macro Vision Yes 20 feet 188
Calendar -- 40 feet 396
Clock/Timers Yes 40 feet high 440
Lock Yes(Child Lock to lock keys) ACCESSORIES
OSD Language English,French,Portuguese,Spanish Operation Manual English(Default)
OSD Features Transparent adjustable(Off,Low,Mid,High) Remote Control For TV control (with two 7# batteries)
Card Reader -- Base Stand Integrated Packaging
AIS (Auto Input Switch) Yes Speaker Box Integrated
USB Connection Yes. Support Mp3,JPEG Wall Mount Optional
Game -- Others AC Power cord
Screen Saver --
Demo Function --
Picture Freeze Yes,and can save to peripheral equipment,such as HD.
Design and specifications are subject to change without notice! Page 1 of 1
Note:
1. PiP POP
Model: L32E9A/MS91-LA
AV Stereo,AVC,
BTSC, Equalizer
Approved by:
Sound Control
In PIP/POP mode,all the sources are divided into two groups. Group 1 includes TV,AV1~AV3,S-Video,Group 2 includes Y/Pb/Pr,VGA,HDMI1,HDMI2. If the Main window
display one of the source in Group 1, the Sub window can only display one of the source in Group 2, vice versa. The source in different group displayed at the same time
can not be supported.
Sound Features
Drafted by: 张勇 2008-06-03
Volume, Balance, 5 mode
presets(Stereo;Movie;News;Music;Personal)

TCL Multimedia Technology Holdings Ltd.
R&D Center
Alignment Procedure
MODEL
： L42E77F/MS91AP LCDTV
Version 1.0
PREPARED BY : Wise Zhang DATE : 2008-5-7
APPROVEDBY: DATE:

O verview：
L CDTV features by its small size, low weight, perfect display effects as well
as energy saving and low radiation. It can not only be used to receive TV program,
but also as PC monitor.
Note:
Factory Menu(FM) is designed for factory. R&D Menu (RDM) is for R&D purpose and
should not be changed in the process of production.
H ow to access to Factory Menu?
1. Firstly, in TV mode, press MUTE button of remote control to mute the set.
Secondly, press MENU button to enter user main menu. Then choose CONTRAST item in
PICTURE menu and press 9,7,3,5 buttons in series. Factory Menu will appear in the
left top of screen.
2. Press RETURN button when FACHOTKEY is enabled (ON).
Note: After upgrading the software for the first time. Restart the set (power off
then power on) should be made to ensure the correct EEPROM data.
F M(Factory Menu) menu
Item Default Description Status
FAC HOTKEY OFF Shortcut button to enter Factory Menu.（OFF：disable；ON：
enable），After production, the item must be disabled.
OK
WARM UP OFF OFF：normal mode，the set will turn to standby mode
when no signal inputted
ON：Aging mode，the set will display blue screen
when no signal inputted. Usually the value should
be set to off when aging test.
OK
ADC Calibration of ADC data OK
WHITE
BALANCE
White balance data adjustment OK
SHOP DO Reset the set after production to remove all unnecessary
factory debug information and the Factory Menu will can
not access for users.
OK
NVM RESET DO Restore the system to default value. This operation
will remove the white balance data. This function
only designed for R&D.
OK

SET FAC CH DO Preset the channel list of factory to provide convenience
for production.
OK
Power on LAST STB: The set will turn to standby mode when switch on.
LAST：remember the status of last switch off.
ON: power on when switch on.
OK
PVR UPGRADE DO OK
VERSION Display the version of software. OK
PVR VERSION OK
ADC calibration：
Item Default Description Status
SOURCE Current source OK
R OFFSET 127 R offset, manually adjustable. Should not be changed
after automatic adjustment.
OK
G OFFSET 127 G offset, manually adjustable. Should not be changed
after automatic adjustment.
OK
B OFFSET 127 B offset, manually adjustable. Should not be changed
after automatic adjustment.
OK
R GAIN 127 R gain, manually adjustable. Should not be changed after
automatic adjustment.
OK
G GAIN 127 G gain, manually adjustable. Should not be changed after
automatic adjustment.
OK
B GAIN 127 B gain, manually adjustable. Should not be changed after
automatic adjustment.
OK
AUTO TUNE Before calibration, first, please input
corresponding pattern according to the
instruction at the bottom of the menu. Second,
select AUTO TUNE, Then press vol- button in remote
control to calibrate ADC automatically. The result will
be displayed.
OK
WHITE BALANCE adjustment:
Item Default Description Status
SOURCE AV1 current source. Only AV1, HDTV, VGA need be
adjusted.
OK

COLOR TEMP NORMAL NORMAL/COOL/WARM OK
R GAIN 129 R offset, manually adjustable. Should not be changed
after automatic adjustment.
OK
G GAIN 128 G offset, manually adjustable. Should not be changed
after automatic adjustment.
OK
B GAIN 126 B offset, manually adjustable. Should not be changed
after automatic adjustment.
OK
R OFFSET 126 R gain, manually adjustable. Should not be changed
after automatic adjustment.
OK
G OFFSET 126 G gain, manually adjustable. Should not be changed
after automatic adjustment.
OK
B OFFSET 128 B gain, manually adjustable. Should not be changed
after automatic adjustment.
OK
H ow to access to R&D Menu?
1. Firstly, in TV mode, press MUTE button of remote control to mute the set.
Secondly, press MENU button to enter user main menu. Then choose CONTRAST item in
PICTURE menu and press 1,9,5,0 buttons in series. R&D Menu will appear in the left
top of screen.
2. Press RETURN button when Design Menu->DESIGNKEY is enabled (ON).
3. Press MENU button of remote control under FM.
R&D Menu(RDM)
Item Default Description Status
DESING KEY OFF Shortcut key control switch of Design Menu
(ON: enable, OFF: disable)
OK
FAC MENU To enter Factory Menu OK
SHOP INIT Should not be adjusted by factory. OK
OTHERE Other settings. NG
SERVICER
MENU
Product information NG

PARAM
SETTING
Parameter settings OK
HOTEL MENU Hotel menu NG
SHOP INIT Function
Item Default Description Status
VOLUME 30 Volume default value(0~100) OK
PIC MODE STANDARD Picture mode(Soft, Standard, Bright, User) OK
SOUND MODE STEREO Sound Effect（Stereo，Movie，News，Music Hall，Personal） OK
CH NUMBER 199 Channel number（0-199） OK
LANGUAGE ENGLISH Language（English/French/Farsi/Russian） OK
COLOR SYS AUTO TV Color system（AUTO, PAL, SECAM） OK
SOUND SYS D/K Sound system（D/K,B/G,I） OK
PRESET CH 1 Channel preset（0-199） OK
COLOR TEMP NORMAL Color temperature（NORMAL，WARM，COOL） OK
PARAM SETTING
Item Default Description Status
VOLUME Sound curve adjustment OK
BRIGHTNESS Luminance curve adjustment OK
CONTRAST Contrast curve adjustment OK
SATURATION Saturation curve adjustment OK
SHARPNESS Sharpness curve adjustment OK
DEBUG BOARD:
During production the Debug Board will be used to upgrading software, adjust White
Balance. The function of the board is transfer TTL Voltage to 232 Voltage. 12V DC
power supply should be provided through CON1/CON2.

T he steps of debug during production:
Manually adjustment of White Balance and ADC calibration:
1) ADC calibration
Input dual 16 grey scale signal 1024*768/60Hz(Chroma2225 Pattern47,Timing38 or
Chroma2327 Pattern47, Timing14) from VGA socket
Input 8 color bar with 100% saturation(2327 Pattern37, Timing33 or BSG360A Timing79,
Pattern85), PAL system from Y,Pb,Pr socket.
Enter ADC item of Factory Menu, select the source which you are going to calibrate.
Then select AUTO TUNE and press Vol- button in remote control.
Note: First confirm the input signal pattern and format are correct. After
calibration, If the grey scale can not be distinguished, calibrate again until it
is distinguished.
Color Temperature adjustment.
Before adjustment you should confirm the color analyzer has been calibrated. During
the process, only AV1 Y,Pb,Pr,VGA source should be adjusted. We recommend you use
CA210 color analyzer(0 channel),because it is more accurate.
Connection of devices:
1) connect CON3 of Debug Board to CA210(input VGA signal to CON6 when adjust VGA
source. Connect CON5 of Debug Board to the set through VGA cable. Input
corresponding pattern required, then select GAIN AUTO,press Vol+ button of
remote control.
2) Input 8 grey scale signal of 5418 from AV1/Y,Pb,Pr/VGA source. Point the optical
lens to the fourth brightest scale. Then enter Factory Menu and select WHITE
BALANCE page, select GAIN AUTO, press Vol+ button of remote control.
Note: In the process of adjustment, you can press MUTE button of remote control
to cancel.

U303
13-EN25B1-6TB (EN25B16)
16Mbit serial flash memory
AP market use:
13-MST6E1-9GBS1
Ordering: MST6E19GL-
LF-S1
LA market use:
13-MST6M1-9GBS1
Ordering: MST6M19GL-
LF-S1
The MST6*19GL is a
high performance and
fully integrated IC for
multi-function LCD
monitor/TV with
resolutions up to full HD
(1920x1080). It is
configured with an
integrated triple-ADC/
PLL, an integrated DVI/
HDCP/HDMI receiver, a
multi-standard TV video
and audio decoder, two
video de-interlacers, two
scaling engines, the
MStarACE-3 color
engine, an on-screen
display controller, an 8-
bit MCU and a built-in
output panel interface.
By use of external frame
buffer, PIP is provided
for multimedia
applications.
Furthermore, 3-D video
decoding and processing
are fulfilled for high-
quality TV applications.
To further reduce system
costs, the MST6*19GL
also integrates intelligent
power management
control capability for
green-mode
requirements and
spread-spectrum support
for EMI management.
Q400
Q401
Q402
U301
EEPROM
24C64
U305(NC)
EEPROM
24C64
U305
HDCP KEY
24C02 I2 C
I2 S
RESET
IR
KEY
PH-L/PH-R
U301
13-281622-FTB4
HY5DU281622FTP-4
DDR,8Mx16, Max clock is 250MHz
STA333BW Power on sequence U700
13-STA333-BWB
STA333BW
2.1 channels high
efficiency digital
audio system
OUT1A
OUT1B
LC
Low Pass Filter
OUT2A
OUT2B
LC
Low Pass Filter
PLL
P300
ISP
PORT `
P1
VGA PORT
UART (RXD TXD)
U400
VGA DDC
24C02
ISP SW
R G B HS VS
U503(NC)
EDID
24C02
U509(NC)
EDID
24C02
`
DDC2
DDC2
TMDS2
HDMI HPD CONTROL
HDMI DDC I2C
HDMI TMDS
Q501
DDC1
TMDS1
U507
13-0PS321-
00B
PS321 is
integrates
3-to-1
HDMI/DVI
switch
DDC1
YPBPR L4/R4(Share with VGA)
MS91-EM Chassis Block Diagram
U702
13-TDA130-8TB
USB D+/D-
CH1—5VSTB
CH2— HWRESET
CH3— VCC_1.26V
CH1—12V
CH2— 5VSTB
CH3— HWRESET
CH4— +5V
47-EAR005-XX0
Or 47-EAR002-XX0
47-USB002-XX0
P500
P501
SIF
TUNER I2 C
Z600
AP market use:
07-380FI5-NA7G
AP market use:
07-457FF5-NA1G
Z602
SAWF (Picture)
AP: 45-SAWK62-74D
LA: 45-SAWF39-530
Z601
SAWF (Sound)
AP: 45-SAWK93-52M
LA: 45-SAWF93-700
U600
AP market: 13-TDA988-TSB
TDA9886,support PAL,SECAM and
NTSC
LA market: 13-TDA988-5TBS
TDA9885,support PALand NTSC
I2C-bus controlled single and
multistandardalignment-free IF-PLL
demodulators
For LA market
For AP market
Q601
MONO--SET NC FOR EM
TV-V
Q605
SIF 4M5 Trap
Odd Pixel LVDS Signal
Even Pixel LVDS Signal
12V or 5V
LVDS_SEL
RPF(CMO)
TV CVBS、L/R Output
SPDIF
P203
P210
X300 14M3
HWRESET
45-OSC14M-3Y2
Y/C Audio share with L1/R1
AV3 L3/R3
AV2 L2/R2
AV1 L1/R1
P200
P200
Side AV
Board P5
P202
P203
P204
First Issued V1.0
ZCX 2008-07-07
DC/DC
L800
C886
U804
12-13N03L-0BX
PHKD13N03LT
U805
13-RT8110-00B
RT8110
12V
U601
LD0
13-LD1117-50B
5V-IF For Tuner,U600
For LCD Panel TCON,Use F801
12V(or 18V) For U700, Audio Power Supply
U800
LD0
13-IC1084-CMB
3.3VSTB For U300,Such as
AVDD_AU,AVDD_3
3,VDDP,PLL etc.
U803
DC/DC
13-MP1411-DHB
VCC_1.26V For U300 VDDC
U802
LDO
13-LD1117-25B
U801
LD0
13-LD1117-33B
+3.3AVDD
2.6VM
For I/O
AVC33,For U507
For DDR
For USB Module
For LCD Panel TCON,Use F800
5VSTB
24V For Panel Inverter Board
+5V
+5V
+5V
Power Supply Block Diagram
D806
D805
LCD Panel
DC Power On Sequencie MST6*19GL Power On Sequence

L42E77F(MS91-AP) 原理图
版本：V1.0
制作日期：2008-4-17
制作：张睿 批准：

AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
VDD_DIG2
GND_DIG
SCL
SDA
INT_LINE
RESET
SDI
LRCKL
BICKL
XT1
PLLGND
PLL_FILTER
PLL_VDD
POWERDN
VSS_DIG
VDD_DIG
OUT4B
OUT3A
OUT3B
CONFIG
VDD
GND_REG
OUT1A
GND1
VCC1
OUT1B
OUT2A
VCC2
GND2
OUT2B
VCC_REG
VSS
TESTMODE
SA
GND_SUB
OUT4A
AGND
AGND
Single point to DGND
Single point to DGND
Single point to GND
As close as possible to the pin
loudspeaker circuit
headphone circuit
SPR+
SPR-
SPL+
SPL-
OUT1B
OUT2A
PLLGND
+3.3VSTB
6R8
R724
R725
22R
R723
22R
HP_AMUTE
HP_DET
HP_DET
HP_AMUTE
R720
10K
10K
R717
R733
4K7
AMP-MUTE
R726
6R8
6R8
R727
R728
6R8
R747
22R
RESET#
C723
4700P
C755
0.1U
R707
10K
RESET
C744
4U7
25V
C447U
25V
C709
47U
25V
R746
0R R748
0R
C754
330P
C734
330P C702
0.47U
1000P/100N
C748 C747
1000P
1000P/470N
C749
R730
3K3
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
19
U700
STA333BW
C745
1U
R715
33K
C710
100U
16V
33K
R714 100R
R739
C713
100U
16V
C712
47U
16V
C731
0.1U
3V3
C746
1U
C718
0.1U
C717
0.1U
C700
220U
25V
C701
220U
25V
PLL_FILT
L713
120R
L701
22UH
L705
30R
AGND
AMP_12V
R1051
1R
2W
AMP_+12V
C708
470U
25V
C707
470U
25V
C705
470U
25V
C706
470U
25V
C704
10U
E
C
B
C144ET
Q981
R731
3K3
AMP_+12V
AMP_+12V
AMP_+12V
AMUTE1
AMUTE1
AGND
AGND
2U2
C1011
E
C
B
C144ET
Q980
2U2
C1010
2U2
C726
5V-IF
5V-IF
AMP_+12V
AMP_+12V
L712
120R
R1050
1R
2W
C743
0.1U
R735
330
R734
2K
R963
1K
D702
LL4148
R962
10K
B
C
E
Q915
BT3906
R960
10K
12V_IN
B
C E
Q701
BT3906
1
2
3
4
5
6
7
P700
1
2
3
4
5
6
P702
AOMCLK
R706
2K2
OUT1A
L702
22UH
L700
22UH
L703
22UH
R745
0R NC
R722
0R
10K
R711
B
C
E
Q700
BT3904
C725
2200P
NC
C724
2200P
NC
16V
47U
C711
100P
C728
C732
100P
R718
10K
C727
0.1U
C729
2U2
220R
L50
L49
220R
3V3
3V3
NC
R743
0R
R741
0R
0R
R742
NC
R740
100K
I2C_SCL
I2C_SDA
C703
0.47U
3V3
3V3
3V3
3V3
AOSDATA
AOLRCLK
AOLRCLK
3V3
4K7
R738
PH-R
PH-L
I2C_SCL
I2C_SDA
AOSDATA
AOBCLK
AOMCLK
C722
680P
R705
33R
C721
1000P
C720
0.1U
D700
LL4148
L711
600R
L710
600R
R704
3R3
R703
3R3
C719
0.1U
R702
33R
R701
33R
R700
33R
C716
0.1U
C715
0.1U
AOBCLK
OUT1A
OUT1B
OUT2A
OUT2B
PWDN
PHONE_L
8
7
6
45
3
2
1
U701
TDA1308T
R719
10K
C730
0.1U
PHONE_R
R710
2K2
R709
10K
R708
2K2
PHONE_R
PHONE_L
R721 0R
PHONE_L
PHONE_R
R732
3K3
R729
3K3
C742
0.1U
C741
0.1U
C740
0.22U
C739
0.1U
C738
0.22U
C737
0.22U
C736
0.1U
C735
0.22U
C733
330P
R737
10K
R736
10K
D701
LL4148
PWDN
3V3
AGND
AGND
AGND
AGND
AGND
AGND
AGND
0RR744
3V3
3V3
PH-L
PH-R
PH-LIN
PH-RIN
PHONE_L
PHONE_R
1000P
C752 C751
1000P
1000P
C750
C753
0.47U
R749
0R
OUT2B
R750 0R

AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
NC
TAGC
REF
VAGC
VIF1 VIF2 OP1 FMPLL DEEM AFD DGND AUD CVBS
AGND VPLL
VP
AFC
SIF1 SIF2
OP2
TOP SDA SCL SIOMAD
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
4
AGND
BP
BT
IF1
AGC
SCL
AS
SDA
NC
oscillate frequency is about 440Khz
Pre IF amplify
6
7
8
1
3
2
4
5
Z600
R625
NC
R609
39R
L602
1UH
12V_IN
C652
0.01U
C653
0.01U
R608
680R
L603
0.82UH
R603
4K7
R607
56R
R604
1K
R605
56R
R606
1K2
C654
0.01U
B
C
E
Q604
SC3779
C624
0.01U
0.1U C648
C639
10U
16V
R631
0R
NC
4
1 2 3
U601
LD1117S50
R600
15R
2W
R670
0R TAGC
5V-IF
5V-IF
R637
0R
NC
R633
0R
NC
R632
0R
NC
10K
R623
560P
C604
SIFM
C627
0.1U
C625
0.1U SIFP
R664
100R
NC
C623
0.01U
L611
1UH
R669
51R
6K8
R656
R658
10K
R657
10K
D603
LL4148
D601
BA982
R628
12K
SIF_SW
SIFM
SIFP
VIFM
VIFP
L613
1UH
L612
1UH
R629
NC
312 45
Z602
SAW-K6274D
312 45
Z601
SAW-K9352M
E
C
B
C144ET
Q602
R610
NC
R611
0R
L607
1000U
5V-IF
C626
4.7U
16V
C601
4.7U
16V
330P
C605
0R
R622
TAGC
C650
0.1U
R672
2.2K L606 1000U
R667
5K6
R666
2K
NC
R662
100R
R661
100R
TUNER_SDA
TUNER_SCL
TV1-V
R649
75R
R647
220R
R645
22K
R644
22K
R643
22K
R641
330R
R640
100K
5V-IF
12V_IN
C621
0.1U
10U
C638
0.1U C635
16V
10U
C647
0.1U
C646
470NFC640
0.01UFC641
C613
0.1U
R634
22K
C614
0.01U
R636
47K
1
3
2
D604
0BAV99
C612
0.1U
C610
270P
C609
4700P
B
C
E
Q600
BC846B
C611
200P
R635
100K
600R
L601
5V-IF
470NF
C619
13 14 15 16
1 2 3 4 5 6 7 817
18 19 20 21 23 24 22
9
10 11 12
TDA9885T
U600
X600
4M
22PF
C618
SIF_SW
NC
R639
1.5NF
C617
220NF
C616
1K
R663
NC
C649
1NF
B
C
E
Q601
BT3904
TUNER_SDAR627 100R
R626
100R
5V-IF
600R
L610
C642
390PF
C643
0.01UF
C622
0.1U
C602
47U
16V
5V-IF
0.1U
C620
TUNER_SCL
100P C636 100P C637
L605
1000UR
D600
33V
33V
33V
SIFPOUT
R614
10K
R612
2K2
6K8
R1013
R613
10K
47R
R620
330P
C606
TV1-VIN-
75R
R621
47R
R619
TV1-V
TV1-L/RIN
TV1-VIN+
12K
R624
312 45
Z604
SAW-K6274D
312 45
Z603
SAW-K9352M
D602
BA982
E
C
B
C144ET
Q603
R630
0R
R638
2K2
R648
0R
R602
100R
C651
10U
16V

RED
GREEN
BLUE
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
RED
RED
YELLOW
YELLOW
WHITE
WHITE
GREEN
RED
BLUE
RED
GREEN
BLUE
AGND
signal is 1Vp-p, so
0.5Vp-p when input
CVBSOUT level is
Location
Near RCA.
input,R339(net SC_SOG,from AV input)must
Note: The IC's
Near RCA.
0.5Vp-p when input
S-VIDEO
SCB+ as HDTV input, R305(net SC_SOG,from
Note:when SCR+，SCG+，SCB+ as scart RGB
be 470ohm,R305must be NC,else SCR+，SCG+，
HDTV input)must be 470ohm,R339 must be NC.
AVOUT AND YPBPR CIRCUIT
AV2 AND AV1 CIRCUIT
X 4) for 2Vp-p output
signal by four (GAIN
signal is 1Vp-p, so
Note: The IC's
signal is 1Vp-p, so
0.5Vp-p when input
CVBSOUT level is
NOTE: THE IC'S CVBSOUT LEVEL IS 0.5VP-P WHEN INPUT SIGNAL IS 1VP-P, SO IT MUST MULTIPLYSIGNAL BY FOUR (GAINX 4) FOR 2VP-P OUTPUT
it must multiply
Location
BACKUP FOR P200 and TCL#ON is 47-RCA248-XX1G
R244
NC
AV1-R
1
3
2
D2
D5V0S2
2
3
1
D5V0S2
D5
D8
D5V0S1
D7
D5V0S1
D3
D5V0S1
D1
D5V0S1
2
3
1
D5V0S2
D4
1
3
2
D9
D5V0S2
1
3
2
D6
D5V0S2
1
4
2
5
3
6
7
8
9
P203
1
4
2
5
3
6
7
8
9
P200
R212
75R
75R
R201
R200
220R
B
E
C
Q203
BT3906
B
C
E
Q200
BT3904
DVD/R
DVD/L
0R
R243
0R
R242
0R
R241
AV1-L
AV2-RIN
AV2-LIN
AV1-RIN
R227
47R
E
C
B
BT3904
Q202
B
C
E
Q201
BT3904
47R R222
SCART2_L
SCART2_L
R207
0R
R206
75R
C222
330P
NC
C229
2U2
R217
100R
R215
100R
C227
2U2
AV1-LIN
R267
0R
R266
47R
C237
330P
NC
AV1-VIN+
AV2-VIN-AV2-VIN-
AV2-LIN
AV2-VIN+
47R R228
SC2-R
2U2
C233
SC2-R
SC2-L
C230
2U2
SC2-L
R224
10K
R223
8K2 47K
R221
R220
47R
R218
0R
C231
0.1U
12V_IN
R237
0R
R236
47R
R234
0R
R233
47R
C234
330P
NC
SV1-YIN
4
3
1
7
5
2
6
P202
C225 0.1U
R203
68K
C255
47U
16V
C200
10U
16V
R213
22K C221
47P
NC
CVBSOUT
C203
10U
R202
330R
470R
R12
PR+ PR+
47R
R11
R252
47R
PB+
PB+
5V-IF
R214
10K
SV1-CIN
SV1-CIN
AV2-RIN
SV1-YIN
AV1-RIN
12V_IN
AV1-LIN
AV1-VIN+
R271
10K
R269
12K
C239
560P
16V
10U
C201
R216
10K
R204
47R
R219
4K7
C226
1000P
R211
10K
R208
10K
R209
12K
C223
560P
R210
12K
C224
560P
C228
1000P
0R
R231
4K7
R230
47K
R229
8K2
R226
10K
R225
0.1U
C232
R232
75R
C235
330P
NC
R235
75R
R240
75R
R239
75R
R238
75R
0R
R247
R265
75R
47R
R268
R272
10K
R270
12K
C238
560P
AV2-VIN+
SCART2_R
SCART2_R
SOY
Y+
47R
R253 SOY
Y+
AV1-R
AV1-L
AV1-V
HD1_PR1
SCART2_ROUT
HD1_PB1
SCART2_LOUT
HD1_Y
SCART2_VOUT
AV2-L
HD1_PB1 HD1_PB1 HD1_PB1
HD1_PR1HD1_PR1HD1_PR1
SCART2_LOUT
SCART2_ROUT
AV1-V
AV2-V
HD1_Y HD1_YHD1_Y
SCART2_VOUT
AV2-R
AV2-R
AV2-L
AV2-V
1
4
2
5
3
6P2

AGND
AGND
AGND
AGND
AGND
WHITE
RED
AGND
AV3 IN
VGA AUDIO IN
2
3
1
D5V0S2 D10
D11
D5V0S1
AV3-V
2
3
1
D5V0S2 D12
R286
47R
R287
0R
3
1
2
P204
C245
560P
AV3-VIN+
MUX-RIN
MUX-LIN
PC-RIN
PC-LIN
1
2
3
4
5
6
P206
MUX-RIN
MUX-LIN
PC-RIN
PC-LIN
R278
10K
C243
560P
R277
12K
R280
10K
C244
560P
R279
12K
R282
10K
R281
12K
R284
10K
C246
560P
R283
12K
C247
330P
NC
R285
75R
AV3-VIN+

AGND
AGND
AGND
AGND
AGND
SDA
SCL
WC
VCC
VSS
E2/NC
E1/NC
E0/NC
AGND
AGND
AGND
AGND
D15
D5V0S1
1
3
2
D16 D5V0S2
2
3
1
D5V0S2 D14
1
3
2
D13 D5V0S2
VGA-HS
R
G
6
4
11
14
15
7
12
8
5
13
3
10
9
1
2
17
16
P1
VGA-SCL
B
C
E
Q400
C143ZT
PWM0
5VSTB
5VSTB
0R
R409
R407
0R
0R
R438
5VSTB
C414
2U2
VGA-HS
VGA-SDA
VGA-SCL
PRO
VGA-VS
G
VGA/5V
B
R
1
10
11
12
2
3
4
5
6
7
8
9
P401
R442 NC
R439 NC
SOG
RIN+
GIN+
BIN+
PROTECT
R980 4K7
NC
R403 4K7
R441
NC/1K
R408
1K
B
C
E
Q402
C143ZT
C410
0.1U
B
C
E
Q401
C143ZT
+3.3VSTB
R410
10K
R406
10R
R405
10R
VGA-DDC-5V
R404
4K7
R402
4K7
R401
2K2
R400
2K2
0R
R437
TXD0 TXD0
RXD0
RXD0
TXD0
TXD0
R440
NC
HS_RGB
VS_RGB
0R
R414
R431
0R
5
6
7
8
4
3
2
1
U400
M24C02MN
C409
0.1U
+5V
R430
10K
R429
1K
R428
1K
C408 0.1U
C407 0.1U
0R
R416
0R
R419
PROTECT
R427
100R
10R
R421
R420
10R
10R
R422
0R
R417
0R
R415
R412
0R
R423
75R 75R
R424
75R
R425
R426
330R
NC
R432
D404
LL4148
D405
LL4148
RXD0
RXD0
R411
10K
PROTECT
R443 NC
VGA-SCL
VGA-SDA
B
VGA-SDA
VGA/5V
VGA-VS

AGND
AGND AGND AGND AGND
AGND
AGND
AGND
AGND
AGND
AGND
TT
AGND
AGND
AGND
AGND
AGND
AGND
SDA
SCL
WC
VCC
VSS
E2/NC
E1/NC
E0/NC
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND AGND
4
SDA
SCL
WC
VCC
VSS
E2/NC
E1/NC
E0/NC
AGND
RX2+
GND1
RX2-
RX1+
GND2
RX1-
RX0+
GND3
RX0-
RXC+
GND4
RXC-
NC1
NC2
DDCCLK
DDCDA
GND5
VCC
HPD
RX2+
GND1
RX2-
RX1+
GND2
RX1-
RX0+
GND3
RX0-
RXC+
GND4
RXC-
NC1
NC2
DDCCLK
DDCDA
GND5
VCC
HPD
PC0/I2C_RST SDA1 SCL1 GND B11 A11 VCC B12 A12 GND1 B13 A13 VCC1 B14 A14 GND2 VCC2 REXT NC PC1/POWDN
S1/SDA_CTL
S2/SCL_CTL
S3/I2C_ADDR
GND3
Y4
Z4
VCC3
Y3
Z3
GND4
Y2
Z2
VCC4
Y1
Z1
GND5
GND/I2C_CTL_EN
SCL_SINK
SDA_SINK
HPD_SINK
NC/POW_SINK
OE#
VCC/POW3
HPD3 SDA3 SCL3 GND6
B31 A31
VCC5
B32 A32
GND7
B33 A33
VCC6
B34 A34
GND8 CEXT
HPD2
SDA2
SCL2
GND/EDID_BRG_EN
GND9
B21
A21
VCC7
B22
A22
GND10
B23
A23
VCC8
B24
A23_1
GND11
HPD1
VCC/POW1
VCC/POW2
AGND
For CEC Leakage Protect
24C02=>EDID code must be upto 256byte space for hdmi interface
24C02=>EDID code must be upto 256byte space for hdmi interface
HDMI_VCC2
HDMI5V2
R2X2-
R544
500R
DSDA_1
AVCC33
R566
37K RPWR1
R3XC- R3X0+
HDMI-DDC-SDA
HDMI-DDC-SDA
AVCC33
G1_TX1-
G1_TX1-
TX1CLK+
TX1CLK+
HDMI-DDC-SCL
61
79
80
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20 19 18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1
U507 PS321
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
P501
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
P500
R569
0R
HDMI_VCC3
HDMI5V3
0R
R570
R510
0R
HDMI5V3
HDMI5V2
HDMI_VCC2
NC
R527
C511
2U2
B203
NC
R567
4K7
R549
4K7
NC
R550
4K7
NC
R552
100R
NC
R551
100R NC
R506
4K7
NC
R504
100R NC
R503
100R NC
5
6
7
8
4
3
2
1
U503
M24C02MN
R505
4K7
NC
AVCC33
R545
4K7
NC
R543
4K7
NC
1
3
2
D508 1
3
2
D501
2N7002
Q503
C507
0.1U
L501
30R
1 2 3
4
U508
LD1117S33
12
3
D503
BAT54C
R555
37K
R1X2-
CEC
DSCL_1
DSDA_1
HPD1
HDMI_VCC1
R1XC+
AVCC33
R1X0-
R1X0+
R1X1-
R1X1+
R1X2+
R1XC-
12
4
6
8
12
14
16
18
10
3
5
7
9
11
13
15
17
P503
C516
0.1U
C517
0.1U
C518
0.1U
C519
0.1U C520
0.1U
C515
0.1U
C514
0.1U
C512
0.1U
C513
0.1U
DSDA_1
DSCL_1
HDMI_VCC1
R554
4K7
R553
4K7
HDMI_VCC1
R502
4K7
R501
4K7
R507
1K
NC
R558 1K
NC
DSCL_3
R565
10K
R556
10K
12
3
D511
BAT54C
DSCL_2 EDID_BRG_EN
EDID_BRG_EN
+5V
R512
27K
R531 NC
NCR530
NCR529
NCR528
DSDA_3
B1_TX0-
B1_TX0+
R3X1+
C509
0.1U
1
3
2
D509 1
3
2
D510
R3XC-R3XC+
R3X0-R3X0+
R3X1-R3X1+
R3X2-R3X2+
R2XC-R2XC+
R2X0-R2X0+
R2X1-R2X1+
R2X2-R2X2+
+5V+5V+5V+5V
5
6
43
2
1
U506
PRTR5V0U4D
5
6
43
2
1
U505
PRTR5V0U4D
5
6
43
2
1
U502
PRTR5V0U4D
5
6
43
2
1
U501
PRTR5V0U4D
5
6
7
8
4
3
2
1
U509
M24C02MN
DSDA_2
DSCL_2
DSCL_2
DSDA_2
CEC
AVCC33
AVCC33
R557
1K
+5V
+5V
CEC
AVCC33
R541
NC
4K7
R534
47K
HDMI_HPDCTRL
AVCC33
R509
1K
AVCC33
40-LTV522-MAB4XG
FAMILY
30-07-2007
TIGER&MARCUS
FPD DESIGN CENTER
29
2TV522
HDMI INTERFACE
1-14-2008_21:08
R538
10K
NC
R536
4K7
R535
4K7 R537
4K7
AVCC33
R564
37K
R532
4K7
HOT-PLUG
AVCC33
R533
47K
+3.3AVDD
R1_TX2+
R1_TX2-
G1_TX1+
B1_TX0+
B1_TX0-
TX1CLK-
AVCC33
AVCC33
AVCC33
HDMI-DDC-SCL
R539 0R
R540 0R I2C_SCL
I2C_SDA
AVCC33
AVCC33
HDMI_CEC
CEC
+3.3VSTB5VSTB
R511
27K
B
C
E
Q501
C144ET
R559
1K
R508 1K
C510
47U
10V
C508
22U
10V
Z814
Z816
C503
0.1U
C502
0.1U
C505
0.1U
C506
0.1U
C501
0.1U
D504 RLZ5B6 D505 RLZ5B6
RPWR1
RPWR3
RPWR2
R2XC-
R2XC+
HPD3
R2X2+
HOT-PLUG
HOT-PLUG
TX1CLK-
R1_TX2+
I2C_SDA
I2C_SCL
DSCL_1
RPWR3
RPWR3
HPD3
DSDA_3 DSCL_3
R3XC+ R3X0- R3X1- R3X2- R3X2+
R1X1- R1X2+ R1X2- R1X1+ R1X0+ R1X0-
R1XC+ R1XC-
HPD1
R2X1+
R2X1-
R2X0+
HPD2
RPWR2
G1_TX1+
R1_TX2-
DSDA_2
HPD2
R2X2+
R2XC-
R2X2-
R2X1+
R2X1-
R2X0+
R2X0-
R2XC+
RPWR2
R3XC-
R3XC+
R3X0-
R3X0+
R3X1-
R3X1+
R3X2-
R3X2+
HDMI_VCC3
C504
0.1U
D507 RLZ5B6 D506 RLZ5B6
DSCL_3
DSDA_3
R2X0-
R568
4K7
