LG 47/55LW9500-TA User manual

담 당 관리자
Model Description
MODEL BRAND
Printing Specification
1. Trim Size (Format) : 182mm x 257 mm
2. Printing Colors
•Cover : 1 COLOR (BLACK)
•Inside : 1 COLOR (BLACK)
3. Stock (Paper)
•Cover : Uncoated paper , 백상지 60 g/㎡
•Inside : Uncoated paper , 백상지 60 g/㎡
4. Printing Method : Off-set
5. Bindery : Saddle stitch
6. Language : English (1)
7. Number of pages : 52 pages
Part No.
1.
2.
User’s Guide Specification
User’s Guide Specification
Changes
4.
REV.
NO. MM/DD/YY SIGNATURE CHANGE NO. CHANGE CONTENTS
SUFFIX
LG MFL62864962
(1111-REV10)
(1) Origin Notification
* LGEIN: Printed in Indonesia * LGEWA : Printed in U.K.
* LGESP : Printed in Brazil * LGEMX : Printed in Mexico
* LGEND/NP : Printed in China * LGEIL : Printed in India
* LGEMA : Printed in Poland
Special Instructions3.
Product Name
For Asia
1
2
3
4
5
7
6
8
This part contains Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,
Details should be followed Eco-SCM management standard[LG(56)-A-2524].
Especially, Part should be followed and controlled the following specification.
(1) Eco-hazardous substances test report should be submitted when Part certification test and First Mass Production.
(2) Especially, Don’t use or contain lead(Pb) and cadmium(Cd) in ink.
Notes
47/55LW9500-TA
47/55LW95**
JS Song
11.01.24 JO Kim
11.01.24
EH Hong
11.01.24
Feb./07/11 Song Ju Seok S1-19921 Updated the contents.
Feb./18/11 Song Ju Seok S1-21863 Deleted the cable holder by meterial request.
Mar./24/11 Song Ju Seok S1-26863 Changed the specifications of some models.
Apr./19/11 Song Ju Seok S1-30374 Added the Motion remote control of LW57**/LW65** series.
Jun./17/11 Go Woon Lee S1-35767 Updated the NSU contents.
Jul./20/11 Go Woon Lee S1-40722 Changed the specifications of 47/55LW98** model.
Aug./19/11Go Woon Lee S1-43710 Added the accessory for Skype.
Sept./19/11Go Woon Lee EKLB900133 Added the 3D disclaimer.

REV.
NO. MM/DD/YY SIGNATURE CHANGE NO. CHANGE CONTENTS
9
10
11
12
13
15
14
16
Go Woon Lee
Oct./12/11 EKLBA00524 Added the model 72LW9900-TA.
Go Woon Lee
Nov./15/11 EKLBB01228 Updated the contents of swivel.

Pagination sheet
Pagination sheet P/NO. MFL62864962
Total pages : 52 pages
LG(EN)
P/no 51
Front cover 50……32
LG(EN)
Back cover

www.lg.com
OWNER’S MANUAL
LED LCD TV
Please read this manual carefully before operating your
set and retain it for future reference.
P/NO : MFL62864962 (1111-REV10)
Printed in Korea

SAFETY INSTRUCIONS
2
ENG
ENGLISH
 Pleasereadthesesafetyprecautionscarefullybeforeusingtheproduct.
 Inthismanual,theillustrationmaybesomewhatdifferentfromyourproductbecauseitis
justexampletohelptheinstruction.
PRECAUTION IN INSTALLING THE PRODUCT
Keepawayfromheatsourceslikeelectrical
heaters.
-Electricalshock,fire,malfunctionor
deformationmayoccur.
Ifyoucansmellsmokeorotherodoursorhear
astrangesoundunplugthepowercordand
contacttheservicecenter.
-Ifyoucontinuetousewithouttakingproper
measures,electricalshockorfirecanoccur.
Donotusetheproductindampplacesuch
asabathroomoranyplacewhereitislikely
togetwet.
-Thismaycauseafireorcouldgivean
electricshock.
Installtheproductonaflatandstableplace
thathasnoriskofdroppingtheproduct.
-Iftheproductisdropped,youmaybeinjured
ortheproductmaybebroken.
Keeptheproductawayfromdirectsunlight.
-Theproductcanbedamaged.
Donotplacetheproductinabuilt-in
installationsuchasbookcaseorrack.
-Ventilationrequired.
ELECTRICAL POWER RELATED
PRECAUTIONS
Makesuretoconnectthepowercabletoa
properlyearthedoutlet.
-Youmaybeelectrocutedorinjured.
Donottouchthepowerplugwithwethands.
Additionally,itthecordpiniswetorcovered
withdust,drythepowerplugcompletelyorwipe
dustoff.
-Youmaybeelectrocutedduetoexcess
moisture.
Duringathunderorlightningstorm,unplugthe
powercableorsignalcable.
-Youmaybeelectrocutedorafirecanbreak
out.
Protectthepowercordfromphysicalor
mechanicalabuse,suchasbeingtwisted,
kinked,pinched,closedinadoor,orwalked
upon.Payparticularattentiontoplugs,wall
outlets,andthepointwherethecordexits
theappliance.
PRECAUTIONS WHEN MOVING THE PRODUCT
Donotimpacttheproductwhenmovingit.
-Youmaybeelectrocutedortheproduct
canbedamaged.
Makethepanelfaceforwardandholdit
withbothhandstomove.
-Ifyoudroptheproduct,thedamaged
productcancauseelectricshockorfire.
Contactyournearestservicecenterfor
repair.
Makesuretoturnofftheproduct.
Makesuretoremoveallcablesbefore
movingtheproduct.
-Youmaybeelectrocutedortheproduct
canbedamaged.
PRECAUTIONS WHEN USING THE PRODUCT
Donotdisassemble,repairormodifythe
productatyourowndiscretion.
-Fireorelectricshockaccidentcanoccur.
-Contacttheservicecenterforcheck,
calibrationorrepair.
Toreducetheriskoffireorelectricshock,
donotexposethisapparatustorainor
moisture.
Apparatusshallnotbeexposedto
drippingorsplashingandnoobjects
filledwithliquids,suchasvases,shallbe
placedontheapparatus.
Referallservicingtoqualifiedservice
personnel.Servicingisrequiredwhen
theapparatushasbeendamagedinany
way,suchaspowersupplycordorplug
isdamaged,liquidhasbeenspilledor
objectshavefallenintotheapparatus,the
apparatushasbeenexposedtorainor
moisture,doesnotoperatenormally,or
hasbeendropped.
IMPORTANT INFORMATION TO PREVENT “IMAGE BURN /
BURN-IN” ON YOUR TELEVISION SCREEN
- Whenafixedimage(e.g.logos,screenmenus,videogame,
computerdisplayorteletextpages)isdisplayedonthe
televisionforanextendedperioditcanbecomepermanently
imprintedonthescreen.Thisphenomenonisknownas“image
burn”or“burn-in”.Imageburnisnotcoveredunderthe
manufacturer’swarranty.
- Inordertopreventimageburn,avoiddisplayingafixed
imageonyourtelevision’sscreenforaprolongedperiod(2or
morehoursforLCD,1ormorehoursforPlasma).
- Imageburncanalsooccurontheletterboxedareasof
yourtelevisionifyouusethe4:3aspectratiosettingforan
extendedperiod.
AslongasthisunitisconnectedtotheACwalloutlet,itis
notdisconnectedfromtheACpowersourceevenifyou
turnoffthisunitbySWITCH.
 Ifyouignorethewarningmessage,youmaybeseriouslyinjuredorthereisa
possibilityofaccidentordeath.
 Ifyouignorethecautionmessage,youmaybeslightlyinjuredortheproductmay
bedamaged.
CAUTION
WARNING
WARNING
CAUTION
WARNING
CAUTION
WARNING
CAUTION
WARNING

3
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Remotecontrolandbatteries
(AAA)
NeroMediaHome4EssentialsCD Owner’smanual
Polishingcloth1
(Dependingonmodel)
CleansingCloths(Mitt)2
(Dependingonmodel)
Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal
dealerwhereyoupurchasedyourproduct.
Theillustrationsinthismanualmaydifferfromtheactualproductanditem.
1 Gentlywipethespotsonthecabinetwiththepolishingcloth.
Water
2 Wipespotsontheexterioronlywiththecleansingcloths.
Donotwiperoughlywhenremovingstains.Excessivepressure
maycausescratchesordiscolouration.
Forcleaningfrontframe,pleaseslowlywipeinonedirection
aftersprayingwater1-2timesoncleansingcloths.Please
removeexcessivemoistureaftercleaning.Excessivemoisture
maycausewaterstainsontheframe.
Only32/37/42/47/55LV37**
Screwforassembly Screwforfixing
(Only32/37LV37**)
M4x12
x8
 ImageshownmaydifferfromyourTV.
 YourTV'sOSD(OnScreenDisplay)maydifferslightlyfromthatshowninthismanual.
 Theavailablemenusandoptionsmaydifferfromtheinputsourceorproductmodelthatyouare
using.
NOTE

4
ENG
ENGLISH
ASSEMBLING AND PREPARING
1Thenumberof3Dglassesmaydifferdependingonthecountry.
Only32/37/42/47/55LV55**,32/42/47/55LW57**,42/47/55/65LW65**,47/55LW77**,47/55LW95**,
47/55LW98**,72LW99**
Screwforassembly
MagicMotionRemote
Control,
Strap,Batteries(AA)
(Only47/55LW77**,
47/55LW95**,
47/55LW98**,72LW99**)
Compositegendercable
Componentgendercable
Compositegendercable
Componentgendercable
(Only72LW99**)
FPR3DGlasses1
(Only32/42/47/55LW57**,
42/47/55/65LW65**,
47/55LW98**,72LW99**)
3DGlasses(AG-S250)
(Only47/55LW77**)
Screwforfixing
(Only32/37LV55**,
32LW57**)
Cableholder
(Dependingonmodel)
Cableholder
(Only72LW99**)
WirelessLANforBroad-
band/DLNAAdaptor
(AN-WF100)
(Only72LW99**)
PowerCord
(Only72LW99**)
PowerCordholder
(Only72LW99**)
Ferritecore
(Only72LW99**)
x8
M4x16
x8
M4x12
(Exceptfor
47/55LW95**,
65LW65**,
47/55LW98**)
(Only47/55LW95**,
47/55LW98**)
x9
M4x16
(Only65LW65**)
Home
OK
P
MUTE
FREEZE
RATIO
L/R SELECT
ENTER
BACK EXIT
Q.MENU
INFO
MENU
CHVOL
P
A
G
E
FAV
3D
MUTE
1 2 3
4 5 6
7 8
0
9
MARK
LIST
FLASHBK
ENERGY
SAVING
TV
AV MODE INPUT
M5x35
M4x20
(Only72LW99**)
x2
x2
x4
x4

5
ENG
ENGLISH
ASSEMBLING AND PREPARING
Only47/55LZ96** 
M3x6 M4x7 M4x14
Boltsforstandandwallmountingbracketassembly
MagicMotionRemote
Control,Strap,Batteries(AA)
3DGlasses(AG-S250)
Compositegendercable
Componentgendercable
Cableholder StandBase StandBody
StandRearCover DisplayLinkCableCover DisplayLinkCable
(standtypeandwall
mountingtype)
WallMountingBracket
(oneforthesetandone
forthewall)
WallMountingBracket
Pushpin
SetProtectionBracket WallAnchor Screw
x2
x2
Thisfeatureisnotavailableforallcountry.
Only32/37/42/47/55LV37**,32/37/42/47/55LV55**,32/42/47/55LW57**,42/47/55/65LW65**
MagicMotionRemoteControl,
Strap,Batteries(AA)
RFDongle RFDongleaCable Velcro
Home
OK
P
MUTE
FREEZE
RATIO
L/R SELECT
ENTER
BACK EXIT
Q.MENU
INFO
MENU
CHVOL
P
A
G
E
FAV
3D
MUTE
1 2 3
4 5 6
7 8
0
9
MARK
LIST
FLASHBK
ENERGY
SAVING
TV
AV MODE INPUT
x6 x6
Home
OK
P
MUTE
FREEZE
RATIO
L/R SELECT
ENTER
BACK EXIT
Q.MENU
INFO
MENU
CHVOL
P
A
G
E
FAV
3D
MUTE
1 2 3
4 5 6
7 8
0
9
MARK
LIST
FLASHBK
ENERGY
SAVING
TV
AV MODE INPUT
x2 x2
x4

6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Additional information
Viewing the owner’s manual
Theowner’smanualinPDFfileformatissuppliedontheenclosedCD.InstalltheAdobeAcrobatReaderto
viewtheowner’smanualonyourPC.
1 InsertthesuppliedCD.
Thewebpageappearsautomatically.
2 ClickOwner’sManualonthewebpage.
3 Viewtheowner’smanual.
Ifthewebpagedoesnotappearautomatically,accessMycomputerandthenclickLGandindex.
htmltoviewtheowner’smanual.
NOTE
 Donotuseanyunapproveditemstoensurethesafetyandproductlifespan.
 Anydamagesorinjuriesbyusingunapproveditemsarenotcoveredbythewarranty.
CAUTION
 Foranoptimalconnection,HDMIcablesandUSBdevicesshouldhavebezelslessthan10mmthick
and18mmwidth.(Dependingonmodel)
B
AA
B
*A 10mm
*B 18mm
 Theitemssuppliedwithyourproductmayvarydependingonthemodel.
 Productspecificationsorcontentsofthismanualmaybechangedwithoutpriornoticeduetoupgrade
ofproductfunctions.
NOTE
 Howtousetheferritecore(Only72LW99**)
-Installtheferritecoreasshowninthefollowingpicture.
-Theferritecorecanbeusedtoreducetheelectromagneticwavesinthecompositegendercable
(AVIN1only).

7
ENG
ENGLISH
ASSEMBLING AND PREPARING
Separate purchase
Separatepurchaseitemscanbechangedormodifiedforqualityimprovementwithoutanynotification.
Contactyourdealerforbuyingtheseitems.
ThesedevicesonlyworkwithcompatibleLGLEDLCDTV.
WirelessMediaBox
(AN-WL100W)
(Exceptfor32/37/42/47/55LV37
**
)
3DGlasses
(AG-S230,AG-S250,AG-S270)
(Only47/55LW77**, 47/55LZ96** )
FPR3DGlasses1
(AG-F2**)
(Only32/42/47/55LW57**,
42/47/55/65LW65** ,
47/55LW98**,72LW99** )
WirelessLANforBroadband
/DLNAAdaptor
(AN-WF100)
(Exceptfor47/55LW95**,
47/55LW98**)
MagicMotionRemoteControl
(AN-MR200)
VideoCallCamera2
(AN-VC300)
(Dependingonmodel)
Home
OK
P
MUTE
Parts and buttons
 ImageshownmaydifferfromyourTV.
 TVcanbeplacedinstandbymodeinordertoreducethepowerconsumption.AndTVshouldbe
turnedoffifitwillnotbewatchedforsometime,asthiswillreduceenergyconsumption.
 Theenergyconsumedduringusecanbesignificantlyreducedifthelevelofbrightnessofthepicture
isreduced,andthiswillreducetheoverallrunningcost.
NOTE
 Donotstepontheglassstandorsubjectittoanyimpact.Itmaybreak,causingpossibleinjuryfrom
fragmentsofglass,ortheTVmayfall.
 DonotdragtheTV.Thefloorortheproductmaybedamaged.
 Incaseofsomemodel,thethinfilmonscreenisapartofTV,sodon’ttakeitoff.
CAUTION
1 Themodelnameordesignmaybechangeddependingontheupgradeofproductfunctions,
manufacturer'scircumstancesorpolicies.
2 VideoCallCameracanbeusedwithsomeLGTVs.
 VideoCallCameraisnotavailableineverycountry.

8
ENG
ENGLISH
ASSEMBLING AND PREPARING
1 Intelligentsensor-Adjuststheimagequalityandbrightnessbasedonthesurroundingenvironment.
2 Allofthebuttonsaretouchsensitiveandcanbeoperatedthroughsimpletouchwithyourfinger.
Touch button2Description
/ITurnsthepoweronoroff.
INPUT Changestheinputsource.
HOME AccessestheHomemenu,orsavesyourinputandexitsthemenus.
OKꔉSelectsthehighlightedmenuoptionorconfirmsaninput.
 Adjuststhevolumelevel.
v P
^
Scrollsthroughthesavedprogrammes.
NOTE
 YoucansetthepowerindicatorlighttoonoroffbyselectingOPTIONintheHomemenu-SETUP.
Only42/47/55/65LW65**,47/55LW95**,47/55LW98**
RS-232C IN (CONTROL&SERVICE)
IN 1(ARC) IN 2 IN 3 IN 4
LAN RGB IN (PC)
OPTICAL DIGITAL
AUDIO OUT
AUDIO IN
(RGB/DVI)
ANTENNA/
CABLE IN
AV IN 2
AUDIO / VIDEO
COMPONENT IN 2
AUDIO / Y P B P R
H/P
WIRELESS
CONTROL
AUDIO
VIDEO
L/MONO
R
AV IN 1
COMPONENT
IN 1
AUDIO
RL
Y
P
B
P
R
VIDEO
/DVI /DVI /DVI /DVI
HDD IN USB IN 1
USB Apps USB IN 2
INPUT
HOME
P
OK
H
INPUT
HOME
H
OK
P
Touch
buttons2
Rear Connection panel
Speakers Remote control and intel-
ligent1 sensors
Power indicator
Screen
Only42/47/55/65LW65**
Only47/55LW95**,47/55LW98**

9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Only32/37/42/47/55LV55**
1 Intelligentsensor-Adjuststheimagequalityandbrightnessbasedonthesurroundingenvironment.
2 Allofthebuttonsaretouchsensitiveandcanbeoperatedthroughsimpletouchwithyourfinger.
RS-232C IN (CONTROL&SERVICE)
IN 1(ARC) IN 2 IN 3 IN 4
LAN RGB IN (PC)
AV IN 2
AUDIO / VIDEO
COMPONENT IN 2
AUDIO / Y P B P R
H/P
WIRELESS
CONTROL
AUDIO
VIDEO
L/MONO
R
AV IN 1
COMPONENT
IN 1
AUDIO
RL
YPBPR
VIDEO
/DVI /DVI /DVI /DVI
HDD IN USB IN 1
USB Apps USB IN 2
INPUT
HOME
H
P
OK
OPTICAL DIGITAL
AUDIO OUT
AUDIO IN
(RGB/DVI)
ANTENNA/
CABLE IN
Touch buttons2
Touch button2Description
/ITurnsthepoweronoroff.
INPUT Changestheinputsource.
HOME AccessestheHomemenu,orsavesyourinputandexitsthemenus.
OKꔉSelectsthehighlightedmenuoptionorconfirmsaninput.
 Adjuststhevolumelevel.
v P
^
Scrollsthroughthesavedprogrammes.
Screen
Speakers
NOTE
 YoucansetthepowerindicatorlighttoonoroffbyselectingOPTIONintheHomemenu-SETUP.
Rear Connection
panel
Power indicator
Remote control and intelligent1 sensors

10
ENG
ENGLISH
ASSEMBLING AND PREPARING
1 Intelligentsensor-Adjuststheimagequalityandbrightnessbasedonthesurroundingenvironment.
Button Description
/ITurnsthepoweronoroff.
INPUT Changestheinputsource.
HOME AccessestheHomemenu,orsavesyourinputandexitsthemenus.
OKꔉSelectsthehighlightedmenuoptionorconfirmsaninput.
 Adjuststhevolumelevel.
 P Scrollsthroughthesavedprogrammes.
NOTE
 YoucansetthepowerindicatorlighttoonoroffbyselectingOPTIONintheHomemenu-SETUP.
Only32/42/47/55LW57**,47/55LW77**,72LW99**
Speakers Remote control and intelligent1
sensors, Power indicator
Screen
Buttons
Rear Connection panel
Only72LW99**
Only32/42/47/55LW57**,47/55LW77**

11
ENG
ENGLISH
ASSEMBLING AND PREPARING
Only32/37/42/47/55LV37**
1 Intelligentsensor-Adjuststheimagequalityandbrightnessbasedonthesurroundingenvironment.
2 Allofthebuttonsaretouchsensitiveandcanbeoperatedthroughsimpletouchwithyourfinger.
H/P
IN 1 (ARC)
/DVI
IN 2
/DVI
IN 3
/DVI USB Apps
USB IN
P
INPUT
HOME
OK
RS-232C IN (CONTROL & SERVICE)
ANTENNA / CABLE IN
RGB IN (PC)
LAN
VIDEO
AUDIO
L R
COMPONENT
IN
AUDIO IN (RGB/DVI)
OPTICAL DIGITAL
AUDIO OUT
AV IN
L/MONO R
AUDIO
VIDEO
2 1
RS-232C IN (CONTROL & SERVICE)
ANTENNA
/ CABLE IN
13/18V
700mA Max
LNB IN
Satellite
RGB IN (PC)
LAN
VIDEO
AUDIO
L R
COMPONENT
IN
AUDIO IN (RGB/DVI)
OPTICAL DIGITAL
AUDIO OUT
AV IN
L/MONO R
AUDIO
VIDEO
2 1
Remote control and
intelligent1 sensors
Power indicator
Touch buttons2
Rear Connection panel
Touch button2Description
/ITurnsthepoweronoroff.
INPUT Changestheinputsource.
HOME AccessestheHomemenu,orsavesyourinputandexitsthemenus.
OKꔉSelectsthehighlightedmenuoptionorconfirmsaninput.
 Adjuststhevolumelevel.
v P
^
Scrollsthroughthesavedprogrammes.
Speakers
NOTE
 YoucansetthepowerindicatorlighttoonoroffbyselectingOPTIONintheHomemenu-SETUP.
Screen
Exceptfor32/42/47LV370S Only32/42/47LV370S

12
ENG
ENGLISH
ASSEMBLING AND PREPARING
Only47/55LZ96**
1 Intelligentsensor-Adjuststheimagequalityandbrightnessbasedonthesurroundingenvironment.
2 Allofthebuttonsaretouchsensitiveandcanbeoperatedthroughsimpletouchwithyourfinger.
INPUT
HOME
P
OK
AC IN
USB IN
Y P B P R / AUDIO
VIDEO/AUDIO
AV IN
ANTENNA/CABLE IN
/DVI IN
/DVI
IN3
DISPLAY LINK
HDD IN
USB Apps
1(ARC)
H
Remote control and intel-
ligent1 sensors
Screen
Speakers
Button Description
/ITurnsthepoweronoroff.
INPUT Changestheinputsource.
HOME AccessestheHomemenu,orsavesyourinputandexitsthemenus.
OKꔉSelectsthehighlightedmenuoptionorconfirmsaninput.
 Adjuststhevolumelevel.
 P Scrollsthroughthesavedprogrammes.
NOTE
 YoucansetthepowerindicatorlighttoonoroffbyselectingOPTIONintheHomemenu-SETUP.
Rear Connection panel
Power indicator and
Touch buttons2

13
ENG
ENGLISH
ASSEMBLING AND PREPARING
Lifting and moving the TV
WhenmovingorliftingtheTV,readthefollowingto
preventtheTVfrombeingscratchedordamaged
andforsafetransportationregardlessofitstype
andsize.
 ItisrecommendedtomovetheTVinthebox
orpackingmaterialthattheTVoriginallycame
in.
 BeforemovingorliftingtheTV,disconnectthe
powercordandallcables.
 WhenholdingtheTV,thescreenshouldface
awayfromyoutoavoiddamage.
 HoldthetopandbottomoftheTVframefirmly.
Makesurenottoholdthetransparentpart,
speaker,orspeakergrillarea.
 WhentransportingalargeTV,thereshouldbe
atleast2people.
 WhentransportingtheTVbyhand,holdthe
TVasshowninthefollowingillustration.
 WhentransportingtheTV,donotexposethe
TVtojoltsorexcessivevibration.
 WhentransportingtheTV,keeptheTV
upright,neverturntheTVonitssideortilt
towardstheleftorright.
 Avoidtouchingthescreenatalltimes,asthis
mayresultindamageonthescreen.
CAUTION
Setting up the TV
Attaching the stand
Only47/55LW95**,47/55LW98**
1 LaytheTVwiththescreensidedownonaflat
surface.
 Layafoammatorsoftprotectiveclothonthe
surfacetoprotectthescreenfromdamage.
Makesurenoobjectspressagainstthe
screen.
CAUTION
2 AssemblethepartsoftheStand Bodywiththe
Stand BaseoftheTV.
Stand Body
Stand Base
Screw for assembly Number of screws
M4x16 4
IfyouarenotmountingtheTVtoawall,usethe
followinginstructionstoattachthestand.
PutyourTVonapedestalstandandmounttheTV
onatableorwall.
 TightenthescrewsfirmlytopreventtheTV
fromtiltingforward.Donotovertighten.
CAUTION
3 AssemblethepartsoftheStand Rear Cover
withtheTV.
Stand Rear Cover

14
ENG
ENGLISH
ASSEMBLING AND PREPARING
Stand Body
Only32/37/42/47/55LV37**,
32/37/42/47/55LV55**,32/42/47/55LW57**,
42/47/55/65LW65**,47/55LW77**
1 LaytheTVwiththescreensidedownonaflat
surface.
2 AssemblethepartsoftheStand Bodywiththe
Stand BaseoftheTV.
4 SecuretheTVandthestandwiththe4screws.
 Layafoammatorsoftprotectiveclothonthe
surfacetoprotectthescreenfromdamage.
Makesurenoobjectspressagainstthe
screen.
CAUTION
4 SecuretheTVandthestandwiththe4screws.
Screw for assembly Number of screws
M4x16 4
Stand Base
Stand Body
3 AssembletheTVasshown.
Model Screw for
assembly
Number of
screws
32/37/42/47/55LV37**,
32/37/42/47/55LV55**,
32/42/47/55LW57**,
42/47/55LW65**,
47/55LW77**
M4x12 4
65LW65** M4x16 4
Model Screw for
assembly
Number of
screws
32/37/42/47/55LV37**,
32/37/42/47/55LV55**,
32/42/47/55LW57**,
42/47/55LW65**,
47/55LW77**
M4x12 4
Model Screw for
assembly
Number of
screws
65LW65** M4x16 5

15
ENG
ENGLISH
ASSEMBLING AND PREPARING
1 Placethestandbasefacingdownonatable
orflatsurface.AssembletheStand Bodywith
theStand Baseusingthescrewsprovided
withtheTVset.
Only47/55LZ96**
Screw for assembly Number of screws
M4x7 4
2 CarefullyplacetheTVscreensidedownona
cushionedsurfacetoprotectthescreenfrom
damage.
3 MountthestandtotheTVsetfittinginto
groovesindirectionofthearrowsasshownin
thefigure.HavetheTVsetalignwiththeholes
forinsertingscrews.AssembletheStand Body
withtheTVsetusingthescrewsprovidedwith
theTVset.
Screw for assembly Number of screws
M4x14 4
4 UsetheDisplay Link Cable(forstand;the
shorterone)toconnecttheStand Baseand
thedisplaylinkinputontheTV.Afterconnec-
tion,fastenthescrewswithadrivertomount
thecabletightly.
5 PlacetheStand Rear Cover properly.
6 PlacetheDisplay Link Cable Coverandcon-
nectitwiththeStand Bodyusingthescrews
providedwiththeTVset.
Screw for assembly Number of screws
M3x6 4
Stand Body
Stand
Base

16
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a table
1 LiftandtilttheTVintoitsuprightpositionona
table.
-Leavea10cm(minimum)spacefromthe
wallforproperventilation.
 DonotplacetheTVnearoronsourcesof
heat,asthismayresultinfireorotherdam-
age.
CAUTION
2 Connectthepowercordtoawalloutlet.
10cm
10cm 10cm
10cm
Exceptfor47/55LZ96**
10cm
10cm 21cm
10cm
Only47/55LZ96**
Only72LW99**
1 LaytheTVwiththescreensidedownonaflat
surface.
2 AssemblethepartsoftheStand Bodywiththe
Stand BaseoftheTV.
 Layafoammatorsoftprotectiveclothonthe
surfacetoprotectthescreenfromdamage.
Makesurenoobjectspressagainstthe
screen.
CAUTION
3 SecuretheTVandthestandwiththe4screws.
Screw for assembly Number of screws
M4x20 4
Stand Body
Stand Base
Screw for assembly Number of screws
M5x35 4

17
ENG
ENGLISH
ASSEMBLING AND PREPARING
Securing the TV to a table
(Only32/37LV55**,32/37LV37**,32LW57** )
FixtheTVtoatabletopreventfromtiltingforward,
damage,andpotentialinjury.
MounttheTVonatable,andtheninsertand
tightenthesuppliedscrewontherearofthestand.

 TopreventTVfromfallingover,theTV
shouldbesecurelyattachedtothefloor/wall
perinstallationinstructions.Tipping,shaking,
orrockingtheTVmaycauseinjury.
WARNING
Securing the TV to a wall
(Thisfeatureisnotavailableforallmodels.)
1 Insertandtightentheeye-bolts,orTVbrackets
andboltsonthebackoftheTV.
-Ifthereareboltsinsertedattheeye-bolts
position,removetheboltsfirst.
2 Mountthewallbracketswiththeboltstothe
wall.
Matchthelocationofthewallbracketandthe
eye-boltsontherearoftheTV.
3 Connecttheeye-boltsandwallbracketstightly
withasturdyrope.
Makesuretokeeptheropehorizontalwiththe
flatsurface.
 Useaplatformorcabinetthatisstrongand
largeenoughtosupporttheTVsecurely.
NOTE
 Makesurethatchildrendonotclimbonor
hangontheTV.
CAUTION
Adjusting the angle of the TV to suit view
Exceptfor47/55LZ96**
Swivel20degreestotheleftorrightandadjustthe
angleoftheTVtosuityourview.
2020
CAUTION
 Whenadjustingtheangleoftheproduct,
watchoutforyourfingers.
