LG 9LS4D User manual

1. Trim Size (Format) : 185 mm x 260 mm
2. Printing Colors : 1 Color (BLACK)
3. Stock (Paper) : Uncoated paper, 백상지 60 g/㎡
4. Printing Method : Off-set
5. Bindery : Saddle stitch
6. Language : EN (1)
7. Number of pages : 20 pages
Changes
3.
REV.
NO. MM/DD/YY SIGNATURE CHANGE NO. CHANGE CONTENTS
1
4
5
6
8
7
9
10
2
3
“This part contain Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,
Details should be followed Eco-SCM management standard[LG(56)-A-2524].
Especially, Part should be followed and controlled the following specification.
(1)Eco-hazardous substances test report should be submitted
when Part certification test and First Mass Production.
(2) Especially, Don’t use or contain lead(Pb) and cadmium(Cd) in ink.
N
O
T
E
S
(1) Origin Notification
* LGEIN : Printed in Indonesia * LGEWA : Printed in U.K. * LGEMA : Printed in Poland
* LGESP : Printed in Brazil * LGEMX : Printed in Mexico
* LGEND : Printed in China * LGEIL : Printed in India
* Other Oversea Factories : NON
Special Instructions3.
담 당 관리자
Model Description
MODEL BRAND
Printing Specification
Part No.
1.
2.
User’s Guide Specification
User’s Guide Specification
SUFFIX
19/22LS4D-ZD, 19/22/26/32/37/42LG3000-ZA,
32/37/42/47/52LG5000-ZA LG MFL34441652
(0810-REV00)
Product Name
UK 19/22LS4D*, 19/22/26/32/37/42LG
30**, 32/37/42/47/52LG50**
SHIN HJ
08.10.17
KIM JO
08.10.17
Ofrecido por www.electromanuales.com

Pagination sheet
Pagination sheet P/NO. MFL34441652
Total pages : 20 pages
Front
Cover
P/NO. 3…192
(UK
only)
Ofrecido por www.electromanuales.com

Please read this manual carefully before operating
your TV.
Retain it for future reference.
Record model number and serial number of the TV.
Refer to the label on the back cover and quote this
information.
To your dealer when requiring service.
Extended Owner’s Manual that contains advanced fea-
tures of these LG TV-sets is located on CD-ROM in
electronic version.
To read it You need to open chosen files by using
Personal Computer (PC) equipped with CD-ROM drive.
PP//NNOO::MMFFLL3344444411665522((00881100--RREEVV0000))
PPrriinntteeddiinnKKoorreeaa
LCD TV
OWNER’S MANUAL
Trade Mark of the DVB Digital Video
Broadcasting Project (1991 to 1996)
LCD TV MODELS
1199LLSS44DD**
2222LLSS44DD**
3322LLGG2200****
3377LLGG2200****
4422LLGG2200****
1199LLGG3300****
2222LLGG3300****
2266LLGG3300****
3322LLGG3300****
3377LLGG3300****
4422LLGG3300****
3322LLGG55******
3377LLGG5500****
4422LLGG5500****
4477LLGG5500****
5522LLGG5500****
IIDDNNuummbbeerr((ss))::5499: 22LS4D-ZD 5507: 19LS4D-ZD
5629: 32LG2000-ZA 5721: 26LG3050-ZA
5630: 37LG2000-ZA 5631: 42LG2000-ZA
5088: 19LG3000-ZA 5090: 22LG3000-ZA
5080: 26LG3000-ZA 5089: 32LG3000-ZA
5087: 37LG3000-ZA 5086: 42LG3000-ZA
5085: 32LG5000-ZA 5084: 37LG5000-ZA
5083: 42LG5000-ZA 5082: 47LG5000-ZA
5081: 52LG5000-ZA 5385: 52LG5010-ZD
5386: 47LG5010-ZD 5387: 42LG5010-ZD
5388: 37LG5010-ZD 5389: 32LG5010-ZD
5390: 52LG5020-ZB 5391: 47LG5020-ZB
5392: 42LG5020-ZB 5393: 37LG5020-ZB
5394: 32LG5020-ZB 5395: 52LG5030-ZE
5396: 47LG5030-ZE 5397: 42LG5030-ZE
5398: 37LG5030-ZE 5399: 32LG5030-ZE
5671: 32LG5700-ZF 5820: 19LG3050-ZA
5818: 22LG3050-ZA 5879: 19LG3060-ZB
5880: 22LG3060-ZB 5878: 32LG5600-ZB
Ofrecido por www.electromanuales.com

2
CONNECTING YOUR UNIT
■
Image shown may differ from your TV.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
* To connect an additional equipment, see the
EExxtteerrnnaalleeqquuiippmmeennttSSeettuupp
section in CD Manual.
COMPONENT
IN
VIDEO AUDIO
RGB IN (PC)
OPTICAL
DIGITAL
AUDIO OUT
AV 1 AV 2
AV 1 AV 2
ANTENNA IN
RS-232C IN
(CONTROL & SERVICE)
AUDIO IN
(RGB/DVI)
HDMI/DVI IN
2
1(DVI)
COMPONENT
IN
VIDEO AUDIO
ANTENNA IN
USB IN
SERVICE ONLY
DVD/STB
VCR Connection
2
Power Cord
3
1
Antenna Connection
2
Ofrecido por www.electromanuales.com

3
ENGLISH
■
Image shown may differ from your TV.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
* To connect an additional equipment, see the
EExxtteerrnnaalleeqquuiippmmeennttSSeettuupp
section in CD Manual.
AUDIO IN
(RGB/DVI)
Y PB P R LR
VIDEO
COMPONENT IN
AUDIO
EJECTPCMCIA
CARD SLOT
RS-232C IN
(CONTROL & SERVICE)
SERVICE
ONLY
RGB (PC) IN
HDMI/DVI IN
AV 1 AV 2
ANTENNA IN
ANTENNA IN
Y PB P R LR
VIDEO
COMPONENT IN
AUDIO
AV 1 AV 2
VCR Connection
2
Power Cord
3
1
Antenna Connection
DVD/STB
2
Ofrecido por www.electromanuales.com

4
SAFETY INSTRUCTIONS
ENGLISH
• Please read these safety precautions carefully before using the product.
• In this manual, the illustration may be somewhat different from your product because it is just example to help the instruction.
If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death.
If you ignore the caution message, you may be slightly injured or the product may be damaged.
PPrreeccaauuttiioonniinnIInnssttaalllliinnggtthheePPrroodduucctt
WARNING
WARNING
CAUTION
Keep away from heat sources like electrical heaters.
- Electrical shock, fire, malfunction or deformation may occur.
If you can smell smoke or other odors or hear a strange
sound unplug the power cord and contact the service
center.
- If you continue to use without taking proper measures, elec-
trical shock or fire can occur.
Do not use the product in damp place such as a bath-
room or any place where it is likely to get wet.
- This may cause a fire or could give an electric shock.
Install the product on a flat and stable place that
has no risk of dropping the product.
- If the product is dropped, you may be injured or the
product may be broken.
Keep the product away from direct sunlight.
- The product can be damaged.
Do not place the product in a built-in installation
such as bookcase or rack.
- Ventilation required.
EElleeccttrriiccaallPPoowweerrRReellaatteeddPPrreeccaauuttiioonnss
Make sure to connect the power cable to the ground-
ed current.
- You may be electrocuted or injured.
Do not touch the power plug with wet hands.
Additionally, it the cord pin is wet or covered with
dust, dry the power plug completely or wipe dust off.
- You may be electrocuted due to excess moisture.
During a thunder or lightning storm, unplug the
power cable or signal cable.
- You may be electrocuted or a fire can break out.
Protect the power cord from physical or mechanical
abuse, such as being twisted, kinked, pinched, closed in
a door, or walked upon. Pay particular attention to plugs,
wall outlets, and the point where the cord exits the
appliance.
PPrreeccaauuttiioonnssiinnMMoovviinnggtthheePPrroodduucctt
Do not shock the product when moving it.
- You may be electrocuted or the product can be damaged.
Make the panel face forward and hold it with both
hands to move.
- If you drop the product, the damaged product can cause elec-
tric shock or fire. Contact with the service center for repair.
Make sure to turn off the product.
Make sure to remove all cables before moving the
product.
- You may be electrocuted or the product can be dam-
aged.
PPrreeccaauuttiioonnssiinnUUssiinnggtthheePPrroodduucctt
Do not disassemble, repair or modify the product at
your own discretion.
- Fire or electric shock accident can occur.
- Contact the service center for check, calibration or
repair.
To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug
is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normal-
ly, or has been dropped.
WARNING
WARNING
CAUTION
CAUTION
CAUTION
CAUTION
WARNING
Do not keep a still image on the screen for an
extended period (e.g. by pausing a video) as the fixed
image may remian visible on the screen. This is known
as image burn. Image burn is not covered under the
manufacturer’s warranty.
Ofrecido por www.electromanuales.com

5
ENGLISH
PREPARATION
LCD TV Models :
32/37/42LG20**, 26/32/37/42LG30**, 32/37/42/47/52LG5***
P
MENU
INPUT
OK
+
-
PROGRAMME
VOLUME
OK
MENU
INPUT
FRONT PANEL CONTROLS
■
Image shown may differ from your TV.
■
If your TV has a protection film attached, remove the film and then wipe the TV with a polishing cloth.
Intelligent Sensor
Adjusts picture according to
the surrounding conditions.
(32/37/42/47/52LG5***
only)
POWER
Remote Control Sensor
Power/Standby Indicator
• illuminates red in standby mode.
• illuminates blue when the TV is switched on.
Note: You can adjust PPoowweerrIInnddiiccaattoorr
in the OPTION menu.
INPUT MENU P-+OK
PROGRAMME
VOLUME
MENU OK
INPUT
INPUT MENU VOL PR
/I OK
PROGRAMMEVOLUME
MENU
OKINPUT
POWER
Remote Control Sensor
Power/Standby Indicator
• illuminates red in standby mode.
• illuminates green when the TV is switched on.
LCD TV Models : 19/22LS4D*
LCD TV Models : 19/22LG30**
Ofrecido por www.electromanuales.com

6
ENGLISH
PREPARATION
RGB IN (PC)
OPTICAL
DIGITAL
AUDIO OUT
AV 1 AV 2
ANTENNA IN
RS-232C IN
(CONTROL & SERVICE)
AUDIO IN
(RGB/DVI)
HDMI/DVI IN
2
1(DVI)
COMPONENT
IN
VIDEO AUDIO
AV IN 3
H/P
L/ MONO
R
AUDIO
HDMI IN 3 PCMCIS CARD SLOT
VIDEO
S-VIDEO
USB IN
SERVICE ONLY
Power Cord Socket
This TV operates on an AC power. The voltage is
indicated on the Specifications page. Never
attempt to operate the TV on DC power.
RGB/DVI Audio Input
Connect the audio from a PC or DTV.
DIGITAL AUDIO OUT OPTICAL (Except for 19/22LS4D*)
Connect digital audio from various types of equipment.
Note: In standby mode, these ports do not work.
Euro Scart Socket (AV1/AV2)
Connect scart socket input or output from an
external device to these jacks.
HDMI Input
Connect a HDMI signal to HDMI IN. Or DVI (VIDEO)
signal to HDMI/DVI port with DVI to HDMI cable.
RGB IN (PC)
Connect the output from a PC.
RS-232C IN (CONTROL & SERVICE) PORT
Connect to the RS-232C port on a PC.
Component Input
Connect a component video/audio device to
these jacks.
Antenna Input
Connect RF antenna to this jack.
PCMCIA (Personal Computer Memory Card
International Association) Card Slot
(This feature is not available in all countries.)
Audio/Video Input
(Except for 19/22LS4D*)
Connect audio/video output from an external
device to these jacks.
S-VIDEO
(Except for 19/22LS4D* , 32/37/42LG20** )
Connect S-Video out from an S-VIDEO device.
Headphone Socket
(Except for 19/22LS4D* ,
32/37/42LG20**
)
Connect the headphone plug to this socket.
SERVICE ONLY PORT
1
2
3
4
5
6
7
8
9
10
11
12
13
2
13 43
AV IN 3
H/P
L/MONO
R
AUDIO
AUDIO
HDMI IN 3
HDMI IN 3
PCMCIA CARD SLOT
PCMCIA CARD SLOT
VIDEO
VIDEO
S-VIDEO
95 6 7 8
10
5
11
12
BACK PANEL INFORMATION
A
Image shown may differ from your TV.
AUDIO IN
(RGB/DVI)
Y P B P R LR
VIDEO
COMPONENT IN
AUDIO
EJECTPCMCIA
CARD SLOT
RS-232C IN
(CONTROL & SERVICE)
SERVICE
ONLY
RGB (PC) IN
HDMI/DVI IN
AV 1 AV 2
ANTENNA IN
10
2 59
7 8 13
46
1
Except for
32/37/42LG20**
Ofrecido por www.electromanuales.com

7
ENGLISH
1 3
4
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
2Assemble the parts of the SSttaannddBBooddyywith
the CCoovveerrBBaasseeof the TV.
Assemble the TV as shown.
Fix the 4 bolts securely using the holes in the
back of the TV.
Stand Body
Cover Base
STAND INSTALLATION
(LCD TV Models:
32/37/42LG20**, 26/32/37/42LG30**, 32/37/42LG5***
)
A When assembling the desk type stand, check whether the bolt is fully tightened. (If not tightened fully, the
product can tilt forward after the product installation.) If you tighten the bolt with excessive force, the bolt
can deviate from abrasion of the tightening part of the bolt.
(Only 19/22LG30**)
Carefully place the TV screen side down on a cushioned surface to protect the screen from damage.
Assemble the parts of the SSTTAANNDDBBOODDYYwith CCOOVVEERRBBAASSEEof the TV. Insert the SSTTAANNDDBBOODDYYinto a
CCOOVVEERRBBAASSEEuntil clicking sound.
Assemble the TV as shown.
1
2
3
Stand Body
Cover Base
Ofrecido por www.electromanuales.com

8
ENGLISH
PREPARATION
STAND INSTALLATION
(Only 19/22LS4D*)
■
Image shown may differ from your TV.
1
2
3
4
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
Hold the HHiinnggeeBBooddyyand bend it upward.
Hinge Body
Insert the SSttaannddBBooddyyinto the TV until clicking
sound.
Assemble the parts of the SSttaannddBBooddyywith
the
CCoovveerrBBaasseeof the TV.
Cover Base
Stand Body
DETACHING STAND
(Only 19/22LS4D*)
1
2
3
Place the tv with its front facing downward on a
cushion or soft cloth.
Pull
the
CCoovveerrBBaasseebackward during pressing
a button on the SSttaannddBBooddyy.
Hold
the
CCoovveerrBBaasseeand pull with shake it
backward to separate from the SSttaannddBBooddyy.
4Hold the SSttaannddBBooddyyand bend it upward.
5Pull stand body to separate from the TV during
pressing 2 latches.
Ofrecido por www.electromanuales.com

9
ENGLISH
BACK COVER FOR WIRE ARRANGEMENT
LCD TV Models:
32/37/42LG20**, 26/32/37/
42LG30**, 32/37/42/47/52LG5***
Connect the cables as neces-
sary.
To connect additional equip-
ment, see the External
Equipment Setup section of
the manual.
1
Open the CCAABBLLEEMMAANNAAGGEEMMEENNTTCCLLIIPPas
shown and manage the cables.
2
CABLE MANAGEMENT CLIP
Fit the CCAABBLLEEMMAANNAAGGEEMMEENNTTCCLLIIPPas
shown.
3
Connect the cables as necessary.
To connect additional equipment, see the
External Equipment Setup section.
1
Install the CABLE MANAGEMENT CLIP as shown.
(Only 19/22LS4D*)
(Only 19/22LG30**)
2
First, press the cable management. Hold the CCAABBLLEE
MMAANNAAGGEEMMEENNTTCCLLIIPPwith both hands and pull it
upward.
NOTE
!
GGDo not use the CABLE MANAGEMENT CLIP to lift the TV.
- If the TV is dropped, you may be injured or the TV may be damaged.
How to remove the cable management clip
LCD TV Models :
19/22LS4D*, 19/22LG30**
(Only 19/22LS4D*)
Hold the CABLE MANAGEMENT CLIP with both
hands and pull it backward.
(Only 19/22LG30**)
Ofrecido por www.electromanuales.com

10
ENGLISH
PREPARATION
PLEASE SET IT UP CAREFULLY SO THE PRODUCT DOES NOT FALL OVER.
■You should purchase necessary components to fix the TV to the wall on the market.
■Position the TV close to the wall to avoid the possibility of it falling when pushed.
■The instructions shown below are a safer way to set up the TV, which is to fix it to the wall, avoiding the
possibility of it falling forwards if pulled. This will prevent the TV from falling forward and causing injury. This
will also prevent the TV from damage. Ensure that children do not climb or hang from the TV.
NOTE
!
G When moving the TV undo the cords first.
G Use a platform or cabinet strong and large enough to support the size and weight of the TV.
G To use the TV safely make sure that the height of the bracket on the wall and on the TV is the same.
3
1
2
Use the eye-bolts or TV brackets/bolts to fix the TV to the wall as shown in the picture.
(If your TV has bolts in the eyebolts, loosen these bolts.)
* Insert the eye-bolts or TV brackets/bolts and tighten them securely in the upper holes.
Secure the wall brackets with the bolts on the wall. Match the height of the bracket that is mounted on the
wall.
3Use a sturdy rope to tie the TV. It is safer to tie the rope so it becomes horizontal between the wall and the
TV.
2
1
2
1
EARTHING
Ensure that you connect the earth wire to prevent possible
electric shock. If grounding methods are not possible, have a
qualified electrician install a separate circuit breaker.
Do not try to earth the TV by connecting it to telephone
wires, lightening rods or gas pipes.
Power Supply
Circuit
breaker
■The TV can be installed in various ways such as on a wall, or on a desktop etc.
■The TV is designed to be mounted horizontally.
Ofrecido por www.electromanuales.com

11
ENGLISH
DESKTOP PEDESTAL INSTALLATION
R
For adequate ventilation allow a clearance of 4” (10cm) all around the TV.
4 inches
4 inches 4 inches 4 inches
WALL MOUNT: HORIZONTAL INSTALLATION
For adequate ventilation allow a clearance of 4” (10cm) all around the TV. We recommend that you use a wall
mounting bracket of LG brand when mounting the TV to a wall.
4 inches
4 inches
4 inches 4 inches
4 inches
Attaching the TV to a desk (Only 32/37/42LG20**, 26/32/37/42LG30**, 32/37/42LG5***)
WARNING
!
GGTo prevent TV from falling over, the TV should be securely attached to the floor/wall per
installation instructions. Tipping, shaking, or rocking the machine may cause injury.
The TV must be attached to desk so it cannot be pulled in a forward/backward direction, potentially causing
injury or damaging the product. Use only an attached screw.
1-Screw
(provided as parts of the product) Desk
Stand
When installing the wall-mounted unit, use the protection cover for
desk-type stand installation. Insert the PPRROOTTEECCTTIIOONNCCOOVVEERRinto
the TV until clicking sound.
Not using the desk-type stand (Except for 19/22LS4D*)
■
Image shown may differ from your TV.
Ofrecido por www.electromanuales.com

12
PREPARATION
ENGLISH
AV 1 AV 2
ANTENNA IN
■For optimum picture quality, adjust antenna direction.
■An antenna cable and converter are not supplied.
■To prevent damage do not connect to the mains outlet until all connections are made between the devices.
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Outdoor
Antenna
(VHF, UHF)
Wall
Antenna
Socket
RF Coaxial Wire (75 ohm)
ANTENNA CONNECTION
Antenna
UHF
Signal
Amplifier
VHF
■In poor signal areas, to achieve better picture quality it may be necessary to install a signal amplifier to the
antenna as shown above.
■If signal needs to be split for two TVs,use an antenna signal splitter for connection.
AV IN 3
L/MONO
R
AUDIO
VIDEO
S-VIDEO
HDMI IN
12
VARIABLE
AUDIO OUT
RGB IN
COMPONENT IN
AUDIO
VIDEO
AV 1 AV 2
ANTENNA
IN
AV 1 AV 2
ANTENNA IN
Ofrecido por www.electromanuales.com

13
WATCHING TV /PROGRAMME CONTROL
ENGLISH
REMOTE CONTROL KEY FUNCTIONS
When using the remote control, aim it at the remote control sensor on the TV.
Installing Batteries
■
Open the battery compartment cover on the back and install the batteries matching
correct polarity (+with +,-with -).
■
Install two 1.5V AAA batteries. Do not mix old or used batteries with new ones.
■
Close cover.
1
2
3
4
5
6
7
8
9
10
OK
MENU AV MODE
GUIDE
123
456
789
0
Q.VIEW LIST
TV INPUT
D/A
POWER
VOL PR
I/II MUTE TEXT
RETURN
EXIT
FAV
INFO i
TV/RADIO
*
3
4
5
6
7
10
9
MODE
Selects the remote operating modes.
Q. MENU
Select the desired quick menu source.
MENU
Selects a menu.
Clears all on-screen displays and returns to TV view-
ing from any menu.
VOLUME UP /DOWN
Adjusts the volume.
POWER
Switches the TV on from standby or off to standby.
INPUT
External input mode rotate in regular sequence.
Switches the TV on from standby.
GUIDE
Shows programme schedule.
THUMBSTICK(Up/Down/LeftRight)
Allows you to navigate the on-screen menus and
adjust the system settings to your preference.
OK
Accepts your selection or displays the current mode.
Programme UP/DOWN
Selects a programme.
Q.VIEW
Returns to the previously viewed programme.
1
2
3
4
5
6
7
8
9
10
8
or
Ofrecido por www.electromanuales.com

14
WATCHING TV /PROGRAMME CONTROL
ENGLISH
Select your country.
2
OK
TURNING ON THE TV
Firstly, connect the power cord correctly.
At this stage, the TV switches to standby mode.
In standby mode to turn TV on, press the rr
/ I, INPUT or P (or PR D E) button on the TV or
press the POWER, INPUT, D/A, P (or PR + -) or NUMBER button on the remote control and the
TV will switch on.
2
1
- When your TV is turned on, you will be able to use its features.
ON-SCREEN MENU LANGUAGE / COUNTRY SELECTION
The installation guide menu appears on the TV screen when it is switched on for the first time.
**IIffyyoouuwwaannttttoocchhaannggeeLLaanngguuaaggee//CCoouunnttrryysseelleeccttiioonn
NOTE
!
GGIf you do not finish the set-up Installation Guide by pressing RETURN or if you time out on the OSD (On
Screen Display) the installation menu will continuously appear until the set up is completed whenever the
TV is switched on
GGIf you select the wrong local country, teletext may not appear correctly on the screen and some problems
may occur during teletext operation.
GGThe CI (Common Interface) function may not be applied based on country broadcasting circumstances.
GGDTV mode control buttons may not function based on country broadcasting circumstances.
GGIn country that Digital broadcasting regulation isn’t fixed, some DTV function may not work depending
on digital broadcasting circumstances.
GGThe Country Setting “UK” should only be activated UK.
Select your desired language.
1
OK
Select OOPPTTIIOONN.
Select MMeennuuLLaanngguuaaggee
or CCoouunnttrryy.
1
2
MENU
OK
3Select your desired language or
country.
4
Save it.
OK
OK
Initializing setup
Note:
a. It will automatically disappear after approx. 40 seconds unless a button is pressed.
b. Press the BACK or RETURN button to change the current OSD to the previous OSD.
c. For those countries without confirmed DTV broadcasting standards, some DTV features might not work,
depending on the DTV broadcasting environment.
d. "Home” mode is the optimal setting for home environments, and is the TV's default mode.
e. "In Store" mode is the optimal setting for store environments.“ If a user modifies image quality data, “In
Store” mode initializes the product to the image quality set by us after a certain period of time.
f. The mode (Home, In Store) can be changed by executing Factory Reset in the OPTION menu.
If the OSD (On Screen Display) is displayed on the screen after turning on the TV, you can adjust the
Language, Select Mode, Country, Time Zone, Auto programme tuning.
Ofrecido por www.electromanuales.com

15
ENGLISH
ON SCREEN MENUS SELECTION AND ADJUSTMENT
Your TV's OSD (On Screen Display)may differ slightly from what is shown in this manual.
SETUP AUDIO
TIME OPTION LOCK
Auto tuning
Manual tuning
Programme Edit
Booster : On
Software Update : Off
Diagnostics
CI Information
SETUP
Move OK
Aspect Ratio : 16:9
Picture Mode : Vivid
• Backlight 100
• Contrast 100
• Brightness 50
• Sharpness 70
• Colour 70
• Tint 0
Move OK
E
Auto Volume : Off
Balance 0
Sound Mode : Standard
• 120Hz 0
• 200Hz 0
• 500Hz 0
• 1.2KHz 0
• 3KHz 0
AUDIO
Move OK
E
Clock
Off Time : Off
On Time : Off
Sleep Timer : Off
Auto Sleep : Off
Time Zone : Canary GMT
TIME
Move OK
Lock System : Off
Set Password
Block Programme
Parental Guidance : Off
LOCK
Move OK
Menu Language : English
Audio Language : English
Subtitle Language : English
Hard of Hearing() Off
Country :UK
Input Label
SIMPLINK : Off
Key Lock : Off
OPTION
Move OK
E
1Display each menu.
2Select a menu item.
3Move to the pop up menu.
LR
-+
-+
-+
-+
-+
RG
MENU
OK
OK
• Press the MENU button to return to normal TV viewing.
• Press the RETURN button to move to the previous menu screen.
Ofrecido por www.electromanuales.com

16
WATCHING TV /PROGRAMME CONTROL
ENGLISH
Use this to automatically find and store all available programmes.
When you start auto programming in digital mode, all previously stored service information will be deleted.
AUTO PROGRAMME TUNING
• Use NUMBER buttons to input a 4-digit
password in Lock System ‘On’.
• If you wish to keep on auto tuning select YES
using the button. Then, press the OK
button. Otherwise select NO.
Select SETUP.
2Select Auto Tuning.
3Select Yes.
4Run Auto tuning.
SETUP
Move OK
Auto tuning
Manual tuning
Programme Edit
Booster : On
Software Update : Off
Diagnostics
CI Information
Auto tuning
SETUP
Move OK
Auto tuning
Manual tuning
Programme Edit
Booster : On
Software Update : Off
Diagnostics
CI Information
Auto tuning
All service-information will be updated.
Continue?
SECAM L Search
Yes No
1
MENU
OK
OK
OK
• Press the MENU button to return to normal TV viewing.
• Press the RETURN button to move to the previous menu screen.
Ofrecido por www.electromanuales.com

17
APPENDIX
ENGLISH
TO VIEW THE USER'S GUIDE ON THE CD-ROM
To view the User's guide on the CD-ROM, Adobe Acrobat Reader must be installed on your PC.
The "ACRORD" folder on the CD-ROM contains the installation program for Acrobat Reader.
If you want to install Acrobat Reader, Open "My Computer" Open the folder "LG" Open the folder "ACRORD"
double-click your language.
TToovviieewwtthheeUUsseerr''ssgguuiiddee
The User's guide files are included in the supplied CD-ROM.
Load the supplied CD-ROM into the CD-ROM drive of your PC.
After a while, the web page of the CD-ROM will open automatically.(Windows users only)
If the web page does not appear automatically, open the User's guide file directly.
Open "My computer" Open the folder "LG" Double click the "index.htm" file.
MAINTENANCE
Early malfunctions can be prevented. Careful and regular cleaning can prolong the life of your new TV.
Caution: Be sure to switch the power off and unplug the power cord before you begin any cleaning.
Cleaning the Screen
A good way to keep the dust off your screen for a while is to wet a soft cloth in a mixture of lukewarm water
and a little fabric softener or dish washing detergent. Wring the cloth until it is almost dry, and then use it
to wipe the screen.
Ensure there is no excess water on the screen. Allow any water or dampness to evaporate before switching on.
Cleaning the Cabinet
ATo remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth.
ADo not to use a wet cloth.
Extended Absence
GIf you expect to leave your TV dormant for prolonged periods (such as a holiday), unplug the power
cord to protect against possible damage from lightning or power surges.
CAUTION
2
1
TROUBLESHOOTING
TThheeTTVVddooeessnnoottooppeerraatteepprrooppeerrllyy..
The remote control
does not work
Power is suddenly
turned off
ACheck to see if there is any object between the TV and the remote control causing
an obstruction. Ensure you are pointing the remote control directly at the TV.
AEnsure that the batteries are installed with correct polarity (+ to +, - to -).
AEnsure that the correct remote operating mode is set: TV, VCR etc.
AInstall new batteries.
AIs the sleep timer set?
ACheck the power control settings. Has the Power supply been interrupted.
AIs Auto sleep activated on this station?
Ofrecido por www.electromanuales.com

18
ENGLISH
APPENDIX
No picture &No sound
No or poor colour
or poor picture
Poor reception on
some channels
Lines or streaks
in pictures
No picture
when connecting HDMI
Horizontal/vertical bars
or picture shaking
Picture appears slowly
after switching on
ACheck whether the TV is switched on.
ATry another channel. The problem may be with the broadcast.
AIs the power cord inserted correctly into the mains?
ACheck your antenna direction and/or location.
ATest the mains outlet by plugging another TV into the same outlet.
AThis is normal, the image is muted during the TV startup process. Please contact
your service centre, if the picture has not appeared after five minutes.
AAdjust Colour in menu option.
AAllow a sufficient distance between the TV and the VCR.
ATry another channel. The problem may be with the broadcast.
AAre the video cables installed properly?
AActivate any function to restore the brightness of the picture.
ACheck for local interference such as an electrical appliance or power tool.
AStation or cable channel experiencing problems, tune to another station.
AStation signal is weak, reposition the antenna to receive weaker stations.
ACheck for sources of possible interference.
ACheck antenna (Change the position of the antenna).
ACheck HDMI cable over version 1.3.
If the HDMI cables don’t support HDMI version 1.3, it can cause flickers or no
screen display. In this case use the latest cables that support HDMI version 1.3.
TThheevviiddeeooffuunnccttiioonnddooeessnnoottwwoorrkk..
TThheeaauuddiiooffuunnccttiioonnddooeessnnoottwwoorrkk..
APress the VOLUME button.
ASound muted? Press MUTE button.
ATry another channel. The problem may be with the broadcast.
AAre the audio cables installed properly?
AAdjust Balance in menu option.
AA change in ambient humidity or temperature may result in an unusual noise
when the TV is switched on or off and does not indicate a fault with the TV.
ACheck HDMI cable over version 1.3.
ACheck USB cable over version 2.0.
Picture OK & No sound
Unusual sound from
inside the TV
No sound when
connecting HDMI or
USB
No output from one
of the speakers
*This feature is not available for all models.
Ofrecido por www.electromanuales.com
