LG MC-7884NLC User manual

MICROWAVE/GRILL/CONVECTION OVEN
FOUR COMBINE MICRO-ONDES/GRIL/CONVECTION
MIKROWELLENHERD/GRILL/KONVEKTIONSOFEN
MIKROVALOVNA/ÎARNA/KONVEKCIJSKA PEâICA
OWNER’S MANUAL
MANUEL D’UTILISATION
BEDIENUNGSANLEITUNG
NAVODILA ZA DELOVANJE
PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING.
LIRE ATTENTIVEMENT LE MANUEL AVANT D’UTILISER L’APPAREIL.
BITTE LESEN SIE DIESE ANLEITUNG VOR DER INBETRIEBNAHME.
PROSIMO, DA SI PRED UPORABO PODROBNO PREBERETE NAVODILA ZA DELOVANJE.
MC-7884NLC
P/No: MFL33028801

2
GB
You cannot operate your oven with the door open due to the safety interlocks
built into the door mechanism. These safety interlocks automatically switch off
any cooking activity when the door is opened; which in the case of a
microwave oven could result in harmful exposure to microwave energy.
It is important not to tamper with the safety interlocks.
Do not place any object between the oven front face and the door or allow
food or cleaner residue to accumulate on sealing surfaces.
Do not operate your oven if it is damaged. It is particularly important that the
oven door closes properly and that there is no damage to the: (1) door(bent),
(2) hinges and latches (broken or loosened), (3) door seals and sealing
surfaces.
Your oven should not be adjusted or repaired by anyone except qualified
service personnel.
Warning
Precautions to avoid possible exposure to excessive microwave energy.
Precautions
When heating liquids, e.g. soups, sauces and beverages in your microwave
oven, delayed eruptive boiling can occur without evidence of bubbling. This
could result in a sudden boil over of the hot liquid. To prevent this possibility
the following steps should be taken:
1 Avoid using straight sided containers with narrow necks.
2 Do not overheat.
3 Stir the liquid before placing the container in the oven and again halfway
through the heating time.
4 After heating, allow to stand in the oven for a short time, stir or shake
them(especially the contents of feeding bottles and baby food jars) again
carefully and check the temperature of them before consumption to avoid
burns (especially, contents of feeding bottles and baby food jars).
Be careful when handling the container.
Warning
Always allow food to stand after being cooked by
microwaves and check the temperature of them
before consumption. Especially contents of feeding
bottles and baby food jars.
Please ensure cooking times are correctly set as
over cooking may result in the FOOD catching fire
and subsequent damage to your oven.

3
GB
How the Microwave Oven Works
Microwaves are a form of energy similar to radio and television waves and
ordinary daylight. Normally, microwaves spread outwards as they travel
through the atmosphere and disappear without effect. Microwave ovens,
however, have a magnetron which is designed to make use of the energy in
microwaves. Electricity, supplied to the magnetron tube, is used to created
microwave energy.
These microwaves enter the cooking area through openings inside the oven.
A turntable or tray is located at the bottom of the oven. Microwaves cannot
pass through metal walls of the oven, but they can penetrate such materials
as glass, porcelain and paper, the materials out of which microwave-safe
cooking dishes are constructed.
Microwaves do not heat cookware, though cooking vessels will eventually
get hot from the heat generated by the food.
A very safe appliance
Contents
Your microwave oven is one of the safest of all home
appliances. When the door is opened, the oven
automatically stops producing microwaves. Microwave
energy is converted completely to heat when it enters
food, leaving no “left over” energy to harm you when
you eat your food.
Precautions______________________________________________________2
Contents ________________________________________________________3
Unpacking & Installing ____________________________________________4 ~ 5
Method to use accessories as per mode ______________________________6
Setting the Clock _________________________________________________7
Child Lock_______________________________________________________8
Quick Start ______________________________________________________9
Micro Power Cooking _____________________________________________10
Micro Power Level ________________________________________________11
Grill Cooking ____________________________________________________12
Grill Combination Cooking_________________________________________13
Steam Keep Warm _______________________________________________14
EZ Clean________________________________________________________15
Speed Hot Air Preheat_____________________________________________16
Speed Hot Air Cooking____________________________________________17
Convection Combination Cooking ___________________________________18
Convection Preheat _______________________________________________19
Convection Cooking ______________________________________________20
Auto Cook ______________________________________________________21 ~ 23
Crispy Cook _____________________________________________________24 ~ 25
Steam Chef______________________________________________________26 ~ 29
Auto Defrost _____________________________________________________30
Auto Defrost Guide _______________________________________________31
Heating or Reheating Guide________________________________________32
Fresh Vegetable Guide ____________________________________________33
Defrosting Guide _________________________________________________34
Grill Cooking Guide ______________________________________________35
Convection Cooking Guide_________________________________________36 ~ 37
Metal Tray Cooking Guide _________________________________________38 ~39
Speed Hot Air Cooking Guide ______________________________________40
Steam Cooking Guide_____________________________________________41
Important safety instructions ________________________________________42 ~ 43
Microwave-safe Utensils ___________________________________________44
Food characteristics & Microwave cooking____________________________45 ~ 46
Questions & Answers _____________________________________________47
Plug Wiring Information/Technical Specifications ______________________48

4
GB
Place the oven in the level location of your choice with
more than 85cm height but make sure there is at least
20cm of space on the top and 10cm at the rear for proper
ventilation. (Attention: This does not apply if the microwave oven
is installed in a fitted cupboard!). The front of the oven should be
at least 8cm from the edge of the surface to prevent tipping.
An exhaust outlet is located on top or side of the oven. Blocking
the outlet can damage the oven.
Unpacking &
Installing
Unpack your oven and place it on a flat level surface.
By following the basic steps on these two pages you will be able to quickly check that your oven is operating
correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your
oven make sure you remove all accessories and packing. Check to make sure that your oven has not been
damaged during delivery.
THIS OVEN SHOULD NOT BE USED FOR COMMERCIAL CATERING
PURPOSES
GLASS TRAY
ROTATING RING
STEAMER
STEAM COVER
STEAM PLATE
STEAM WATER
BOWL
(METAL TRAY,
CRISPING TRAY)
RACK

GB
5
The DISPLAY will count down from 30 seconds. When it
reaches 0 it will sound BEEPS. Open the oven door and
test the temperature of the water. If your oven is operating the water
should be warm. Be careful when removing the container it may
be hot.
YOUR OVEN IS NOW INSTALLED
Fill a microwave safe container with 300 ml (1/2 pint)
of water. Place on the GLASS TRAY and close the oven
door. If you have any doubts about what type of container to
use please refer to page 44.
Open your oven door by pulling the DOOR HANDLE.
Place the ROTATING RING inside the oven and place
the GLASS TRAY on top.
Plug your oven into a standard household socket. Make
sure your oven is the only appliance connected to the
socket. If your oven does not operate properly, unplug it
from the electrical socket and then plug it back in.
The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
Press the STOP/CLEAR button, and press
the START button one time to set 30
seconds of cooking time.

GB
6
Caution: Be sure to use accessories refer to cook guide.
Method to use accessories as per mode
Steam Cover
Steam Plate
Steam Water Bowl
Steam Plate +
Steam Water Bowl
Steamer (Assembly)
Steam Cover+
Steam Water Bowl
Rack
Glass Tray
Microwave Grill Convection Steam Keep Warm Speed Hot Air Combination Crispy
: Acceptable
: Not Acceptable

7
GB
Setting the
Clock
You can set either12 hour clock or 24 hour clock.
In the following example I will show you how to set the time for 14:35 when using the 24 clock.
Make sure that you have removed all packaging from your oven.
When your oven is plugged in for the
first time or when power resumes after a
power cut, a ‘0’ will be shown in the
display; you will have to reset the clock.
If the clock (or display) shows any
strange looking symbols, unplug your
oven from the electrical socket and plug
it back in and reset the clock.
Make sure that you have correctly installed your oven as described
earlier in this book.
Press STOP/CLEAR.
Press CLOCK once.
(If you want to use a 12 hour clock, Press CLOCK once more. If you want to
change different option after setting clock, you have to unplug and plug it
back in.)
Turn DIAL until display shows “14: ”.
Press START for hour confirmation.
Turn DIAL until display shows “14:35”.
Press
START .
The clock starts counting.

8
GB
Child
Lock
Your oven has a safety feature that
prevents accidental running of the oven.
Once the child lock is set, you will be
unable to use any functions and no
cooking can take place.
However your child can still open the
oven door.
Press and hold STOP/CLEAR until “L” appears on the display and BEEP
sounds.
The CHILD LOCK is now set.
To cancel CHILD LOCK press and hold STOP/CLEAR until “L” disappears.
You will hear BEEP when it’s released.
Press STOP/CLEAR.

9
GB
Quick
Start
Press STOP/CLEAR.
Press QUICK START four times to select 2 minutes on HIGH power.
Your oven will start before you have finished the fourth press.
During QUICK START cooking, you can extend the cooking time up to 99 minutes 59 seconds by repeatedly
pressing the QUICK START button or by using DIAL.
The QUICK START feature allows you to
set 30 seconds intervals of HIGH power
cooking with a touch of the QUICK
START button.
In the following example I will show you how to set 2 minutes of cooking on high power.

10
GB
Micro Power
Cooking
Make sure that you have correctly installed your oven as described
earlier in this book.
Press STOP/CLEAR.
Turn MODE DIAL to select MICRO.
Turn DIAL until display shows “720”.
Press START for power confirmation.
Your oven has five microwave Power
settings.
In the following example I will show you how to cook some food on 720W(80%) power for 5 minutes and 30
seconds.
Turn DIAL until display shows “5:30”.
Press START.
When cooking you can increase or decrease cooking time by turning
DIAL.
Power Level
HIGH
MEDIUM HIGH
MEDIUM
DEFROST
(MEDIUM LOW)
LOW
Power Output
900W(Max.)
720W
540W
360W( )
180W
%
100%
80%
60%
40%
20%
