LG 22M47HQ User manual

www.lg.com
LED LCD MONITOR MODEL
ENGLISH
OWNER’S MANUAL
LED LCD MONITOR
Please read this manual carefully before operating
your set and retain it for future reference.
22M47D
22M47VQ
22M47H
22M47HQ
23M47D
23M47VQ
23M47H
24M47VQ
24M47H
24M47D
24M47HQ

2
ENGLISH
TABLE OF CONTENTS
CONTENTS
3LICENSE
4ASSEMBLING AND PREPAR-
ING
4 Unpacking
6 Parts and buttons
7 - How to Use the Joystick Button
8 Moving and Lifting the Monitor
9 Setting up the Monitor set
9 - Attaching the Stand Base
9 - Detaching the Stand Base
10 - Mounting on a table
10 - Using the cable holder
12 - Mounting on a wall
13 USING THE MONITOR SET
13 Connecting to a PC
13 - D-SUB connection
13 - DVI-D connection
13 - HDMI connection
14 Connecting to AV Devices
14 - HDMI connection
15 Connecting to External Devices
15 - Peripheral device connection
16 INSTALLING THE LG MONI-
TOR SOFTWARE
16 Installing The Screen Split
18 CUSTOMIZING SETTINGS
19 Customizing settings
19 - Menu Settings
19 - -Quick Settings
21 - -Picture
23 - -General
24 - -Auto Configuration
25 - -Reset
26 - -Picture mode
27 TROUBLESHOOTING
29 SPECIFICATIONS
35 Preset Modes (Resolution)
35 Indicator
36 PROPER POSTURE
36 Proper posture for using the Monitor set.

3
ENG
ENGLISH
LICENSE
LICENSE
Each model has different licenses. Visit www.lg.com for more information on the license.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
The following content is only applied to the monitor which is sold in Europe market and which needs to
meet the ErP Directive:
* This monitor is set to be turned off automatically in 4 hours after you turned on display if there is no
adjustment to display.
* To make this setting be disabled, change the option to ‘Off’ in OSD menu of “Automatic Standby”.
22M47VQ 22M47HQ 23M47H 24M47HQ22M47H 23M47VQ 24M47H 24M47VQ

4
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual product
and accessories.
CD(Owner's Manual) /
Card
( Depending on the country ) ( Depending on the country )
Power Cord AC-DC Adapter
AC-DC Adapter
or
D-SUB Cable
( This cable is not included in all
countries. )
DVI-D Cable
( This cable is not included in all
countries. )
Stand Body Stand Base
HDMI Cable
( This cable is not included in all
countries. )

5
ENG
ENGLISH
ASSEMBLING AND PREPARING
yDo not use any unapproved accessories to ensure the safety and product life span.
yAny damages or injuries by using unapproved accessories are not covered by the warranty.
yThe accessories supplied with your product may vary depending on the model.
yProduct specifications or contents in this manual may be changed without prior notice due to upgrade
of product functions.
CAUTION
NOTE

6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Parts and buttons
Connection panel (See p.13~15)
(Joystick Button)
Power Indicator
yOn: power is on
yOff: power is off
yThe joystick button is located at the bottom of the monitor.
NOTE

7
ENG
ENGLISH
ASSEMBLING AND PREPARING
How to Use the Joystick Button
You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with
your finger.
Basic Functions
Power on Press the joystick button once with your finger to turn on the
monitor.
Power off Press and hold the joystick button once with your finger to turn off
the monitor.
/Volume
Control You can control the volume by moving the joystick button left/right.

8
ENG
ENGLISH
ASSEMBLING AND PREPARING
Moving and Lifting the Monitor
When moving or lifting the monitor, follow these
instructions to prevent the monitor from being
scratched or damaged and to ensure safe trans-
portation regardless of its shape or size.
yAs far as possible, avoid touching the moni-
tor screen. This may result in damage to the
screen or some of the pixels used to create
images.
yIt is advisable to place the monitor in the
original box or packing material before at-
tempting to move it.
yBefore moving or lifting the monitor, discon-
nect the power cord and all cables.
yHold the top and bottom of the monitor frame
firmly. Do not hold the panel itself.
yWhen holding the monitor, the screen should
face away from you to prevent it being
scratched.
yWhen moving the monitor, avoid any strong
shock or vibrations to the product.
yWhen moving the monitor, keep it upright,
never turn the monitor on its side or tilt it
sideways.
CAUTION

9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Attach the Stand Body to the monitor set.
Attach the Stand Base to Stand Body.
Tighten the screw to the right.
Setting up the Monitor set
Attaching the Stand Base
1Place the Monitor set with the screen side
down on a flat and cushioned surface.
Lay a foam mat or soft protective cloth
on the surface to protect the screen from
damage.
CAUTION
2
Stand Base
Stand Body
1
2
3
Detaching the Stand Base
1Place the Monitor set with the screen side
down on a flat and cushioned surface.
Stand Base
Stand Base
Stand Body
Stand Body
Pull out the Stand Body and Stand Base
from the monitor set.
Turn the screw to the left.
Pull out the Stand Base.
21
2
3
yIllustrations in this document represent typical pro-
cedures, so they may look different from the actual
product.
yDo not carry the monitor upside down by just hold-
ing the stand base. This may cause the monitor to
fall off the stand and could result in personal injury.
yWhen lifting or moving the monitor, do not touch
the monitor screen. The force applied to the moni-
tor screen may cause damage to it.
yIf you use the monitor panel without the stand
base, its joystick button may cause the moni-tor to
become unstable and fall, resulting in damage to
the monitor or human injury. In addition, this may
cause the joystick button to malfunction.
CAUTION

10
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a table
1Lift and tilt the Monitor set into its upright
position on a table.
Leave a 10 cm (minimum) space from the wall
for proper ventilation.
Using the cable holder
2Connect the AC-DC Adapter and Power Cord
to a wall outlet.
3Press the joystick button on the bottom of the
monitor to turn on the monitor.
10 cm
10 cm
10 cm
10 cm
Unplug the power cord before moving the
Monitor to another location. Otherwise electric
shock may occur.
CAUTION
Cable holder
or

11
ENG
ENGLISH
ASSEMBLING AND PREPARING
When you adjust the angle, do not hold the
bottom of the Monitor set frame as shown on
the following illustration, as may injure your
fingers.
Do not touch or press the screen when
adjusting the angle of the monitor.
Do not hold this set like below picture.Monitor
screen can detach from stand base and injure
your body.
WARNING
Tilt from +20 to -5 degrees up or down to adjust
the angle of the Monitor set to suit your view.
NOTE
Front Rear
Using the Kensington security system
The Kensington security system connector is
located at the back of the Monitor set. For more
information of installation and using, refer to the
manual supplied with the Kensington security
system or visit
http://www.kensington.com .
Connect the Kensington security system cable
between the Monitor set and a table.
The Kensington security system is optional.
You can obtain it from most electronics stores.
NOTE
When adjusting the angle, may cause damage
or abnormality over excessive force.

12
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a wall
For proper ventilation, allow a clearance of 10 cm
on each side and from the wall. Detailed
instructions are available from your dealer, see the
optional Tilt Wall Mounting Bracket Installation and
Setup Guide.
If you intend to mount the Monitor set to a wall,
attach Wall mounting interface (optional parts) to
the back of the set.
When you install the Monitor set using a wall
mounting interface (optional parts), attach it
carefully so it will not drop.
1If you use screw longer than standard, the
monitor might be damaged internally.
2If you use improper screw, the product might be
damaged and drop from mounted position.
In this case, LG Electronics is not responsible
for it.
10 cm
10 cm
10 cm
10 cm
yDisconnect the power cord first, and then
move or install the Monitor set. Otherwise
electric shock may occur.
yIf you install the Monitor set on a ceiling or
slanted wall, it may fall and result in severe
injury.
yUse only an authorized LG wall mount
and contact the local dealer or qualified
personnel.
yDo not over tighten the screws as this may
cause damage to the Monitor set and void
your warranty.
yUse only screws and wall mounts that
meet the VESA standard. Any damages
or injuries by misuse or using an improper
accessory are not covered by the warranty.
yScrew length from outer surface of back
cover should be under 8mm.
yUse the screws that are listed on the VESA
standard screw specifications.
yThe wall mount kit will include an installation
manual and necessary parts.
yThe wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.
yThe length of screws may differ depending
on the wall mount. Be sure to use the proper
length.
yFor more information, refer to the
instructions supplied with the wall mount.
CAUTION
NOTE
Back Cover
Wall mount Pad
Wall mount Pad
Back Cover
Standard screw
Max.8mm
yVESA (A x B)
A
B
Model
Wall Mount
(A x B)
75 x 75
Standard
screw M4 x L10
Number of
screws 4
Wall Mount
Plate
(Optional)
RW120
22M47D 24M47D
22M47VQ 24M47VQ
22M47H 24M47H
23M47D
23M47VQ
23M47H
22M47HQ 24M47HQ

13
ENG
ENGLISH
USING THE MONITOR SET
USING THE MONITOR SET
Connecting to a PC
yYour Monitor set supports Plug & Play*.
*Plug & Play: A PC recognizes a connected
device that users connect to a PC and turn
on, without device configuration or user
intervention.
D-SUB connection
Transmits analog video from your PC to the
Monitor set. Connect the PC and the Monitor set
with the supplied D-sub 15 pin signal cable as
shown in the following illustrations.
yMac adapter
For Apple Macintosh use, a separate plug
adapter is needed to change the 15 pin
high density (3 row) D-SUB VGA connector
on the supplied cable to a 15 pin 2 row
connector.
yWhen using a D-Sub signal input cable
connector for Macintosh
NOTE
HDMI connection
Transmits the digital video and audio signals from
your PC to the Monitor set. Connect the PC and
the Monitor set with the HDMI cable as shown in
the following illustrations.
yIf you use HDMI PC, it can cause compatibility
problem.
NOTE
DVI-D connection
Transmits a digital video signal from your PC to
the Monitor set. Connect the PC and the Monitor
set with a DVI cable as shown in the following
illustrations.

14
ENGLISH
USING THE MONITOR SET
yConnect the signal input cable
and tighten it by turning the
screws clockwise.
yDo not press the screen with
your finger for a long time as this may
result in temporary distortion on the screen.
yAvoid displaying a fixed image on the
screen for a long period of time to prevent
image burn. Use a screensaver if possible.
CAUTION
yWhen you want to use two PC in our Monitor,
please connect the signal cable(D-SUB/
DVI-D/HDMI) respectively in Monitor set.
yIf you turn the Monitor set on while it is cold,
the screen may flicker. This is normal.
ySome red, green, or blue spots may appear
on the screen. This is normal.
NOTE
Connecting to AV Devices
HDMI connection
Transmits the digital video and audio signals from
your AV devices to the monitor. Connect your AV
device to the monitor with the HDMI cable as il-
lustrated below.
yIf you use HDMI PC, it can cause compatibility
problem.
NOTE

15
ENG
ENGLISH
USING THE MONITOR SET
Connecting to External Devices
Peripheral device connection
Connect peripheral devices to the monitor using
headphone ports.
yPeripheral devices are sold separately.
yCables with angled plugs may have clear-
ance issues, use straight plugs when pos-
sible.
Angle Type Straight Type
NOTE
NOTE
yHeadphones or speakers may not work nor-
mally, depending on the server PC settings.
(sold separately)

16
ENG
ENGLISH
INSTALLING LG MONITOR SOFTWARE
CAUTION
INSTALLING THE LG MONITOR SOFTWARE
Installing The Screen Split
1Set the default Web browser to Internet Explorer.
Insert the the owner's manual CD included in the product package into your PC's CD driver and install the
LG Monitor Software.
2
Click the "Screen Split" on the CD's main
screen. When the file download window ap-
pears, click the Run button. (The file download
window may vary depending on the operating
system and the Internet Explorer version, but
the installation procedures are same.)
yService Pack 1 or higher is required for
Windows 7 & Windows 8.
3
Follow the instructions to proceed with the
installation.
4
Check "I accept the terms of the agreement" on
the License Agreement screen and then click
the [Next] button.

17
ENG
ENGLISH
INSTALLING LG MONITOR SOFTWARE
6
When the installation is complete, restart your
system.
If you run Screen Split, the Screen Split icon [
] appears in the system tray at the right bottom of
the PC screen.
Right-click the Screen Split icon and select a
layout you want.
5
The Screen Split installation starts as shown
below.
yScreen Split: This program automatically
splits the program window as desired.
Monitor Selection only supported in
extend display.
This program supported Windows 7&
Windows 8.
NOTE
NOTE

18
ENG
ENGLISH
CUSTOMIZING SETTINGS
CUSTOMIZING SETTINGS
Activating the Main Menu
1 Press the joystick button on the bottom of the monitor.
2 Move the joystick up/down (/) and left/right(/) to set the options.
3 Press the joystick button once more to exit the main menu.
Button Menu Status Description
Main menu disabled Enables the main menu.
Main menu enabled
Exits the main menu.
(Holding down the button to turn off the monitor: You can turn off
the monitor this way at any time, including when the OSD is on.)

Main menu disabled
22M47VQ
22M47H
22M47HQ
23M47VQ
23M47H
24M47VQ
24M47H
24M47HQ
Adjusts the monitor volume level.
22M47D 23M47D 24M47D
Enables the navigation OSD.
Main menu enabled Enters the menu features.

Main menu disabled
22M47VQ
22M47H
22M47HQ
23M47VQ
23M47H
24M47VQ
24M47H
24M47HQ
Adjusts the monitor volume level.
22M47D 23M47D 24M47D
Enables the navigation OSD.
Main menu enabled Operates the Input change.

Main menu disabled Enables the main menu.
Main menu enabled Enters the reader feature.

Main menu disabled Enables the main menu.
Main menu enabled Turns off the monitor.
Main Menu Features
Main Menu Description
Menu Configures the screen settings.
Picture Mode Select picture mode to achieve the best display effect.
Input
You can choose the input signal.
• When two input signals are connected, you can select the input
signal (D-SUB/DVI-D/HDMI) you want.
• When only one signal is connected, it is automatically detected.
The default setting is D-SUB.
Monitor off Turns off the monitor.
Exit Exits the main menu.
Joystick Button
Power Indicator

19
ENG
ENGLISH
CUSTOMIZING SETTINGS
Each option is described below.
Customizing settings
Menu Settings
-Quick Settings
1 To view the OSD menu, press the joystick button at the
bottom of the monitor and then enter the Menu.
2 Go to Quick Settings > Brightness by moving the joystick.
3 Configure the options following the instructions that appear in the
bottom right corner.
4 To return to the upper menu or set other menu items, move the
joystick to  or pressing ( / OK) it.
5 If you want to exit the OSD menu, move the joystick to  until you
exit.
Menu > Quick Settings Description
Brightness Adjusts the color contrast and brightness of the screen.
Contrast
Volume
22M47VQ
22M47H
22M47HQ
23M47VQ
23M47H
24M47VQ
24M47H
24M47HQ
Adjusts the volume.
NOTE
yJog joystick button down ( ) in the Volume menu will
enable/disable the Mute function.
Ratio Adjusts the screen ratio.
Wide Displays the video in wide-screen, regardless of the video signal input.
Original Displays a video according to the input video signal aspect ratio.
SMART ENERGY
SAVING
High
Enables SMART ENERGY SAVING you can save energy with this energy- high efficient
function.
Low Enables SMART ENERGY SAVING you can save energy with this energy- low
efficient function.
Off Disables SMART ENERGY SAVING .
NOTE
yThe display may look the same for Wide, Original options at the recommended resolution (1920 x
1080).
yThe ratio is disabled in the interlaced signal.

20
ENG
ENGLISH
CUSTOMIZING SETTINGS
yTOTAL POWER REDUCTION: How much power is saved while using the monitor.
yTOTAL CO2 REDUCTION: Change the TOTAL POWER REDUCTION to CO2.
ySAVING DATA(W/h)
546 mm
(21.5 inch)
584 mm
(23 inch)
600 mm
(23.6 inch)
SMART SAVING (High) 4 W/h 4 W/h 4 W/h
SMART SAVING (Low) 2 W/h 2 W/h 2 W/h
ySaving Data depends on the Panel. So,those values should be different from each panel and panel
vendor.If option of SMART ENERGY SAVING is High or Low, monitor luminance become higher or
lower depend on source.
yLG calculated these values by using “broadcast video signal”
(including broadcast video: IEC 62087)
ySMART SAVING refers to how much power can be saved using the SMART ENERGY SAVING
function.
yIf option of SMART ENERGY SAVING is High or Low, Picture Mode will automatically be Custom and
Reader Mode and Color Wizard will automatically be Off.
NOTE
