LG 47WV30MS-B User manual

Direct LED
Super Narrow Bezel Display
LGsolutions.com
Specifications
Native Display Resolution 1366 X 768 (HD)
High Brightness 800 cd/m2(47WV30MS-B)
500 cd/m2(47WV30B -B)
Shine-Out Film Gives More Visibility (47WV30MS-B only)
Contrast Ratio 1,300:1 (Typ.), 500,000:1 (DC )
178° Viewing Angle
Viewing Angle and Life Expectancy Portrait and Landscape
Mode
RJ-45 LAN Control
HDMI™/DVI With HDCP
RS-232C Control
Convenient External Speaker-Out
Energy Star® 5.0 Compliant
Split Zoom (Self Video Wall) Up to 15 x 15 matrix - Adjusts
for bezel width
USB Playback
USB Port
Temperature Sensor
3- ear Limited Warranty Parts/Labor/Backlight
Features
TCO Total Cost of Ownership
The WV30 series are Energy Star® 5.0 compliant
consuming approximately 40% less energy than non-
compliant models. In standby mode, they use less than one
watt of power and meet the environmental regulations such
as EPA and Erp, while excluding the use of harmful
materials ( oHS) and reducing CO2 emissions.
IPS In Plane Switching
Super IPS accurately display an image’s quality and color
at an 178° ultra wide viewing angle. There is no fall-off in
color accuracy and no diversion in contrast ratio at wide
angles. From bright sunlight to the most challenging
lighting environments these displays are designed to
reproduce and maintain the ultimate color temperature for
lifelike images.
BEZEL WIDTH
The WV30 series with ultra slim bezel widths of 3.9mm
(left/top), 2.4mm (right/bottom) will draw attention to
screen images and not the display for impactful messaging.
With the ability for a 15x15 matrix the image will almost
seamlessly broadcast larger than life images.
47" class (47.0" measured diagonally)
47WV30MS-B

47WV30BR-B


PANEL
Mode 47WV30MS-B 47WV30BR-B
Panel Size 47" class (47.0" measured diagonally)
Panel Technology IPS
Aspect Ratio 16:9
Native Resolution 1366 x 768 (HD)
Pixels (H x V x 3) 3,147,264
Brightness 800 cd/m2500 cd/m2
Contrast Ratio (Typ.) 1,300:1
Dynamic CR (DCR) 500,000 : 1
Color Gamut 72%
Tni 110°C
Viewing Angle 178°/178°
Color Depth 16.7 Million (8-bit)
Response Time 12ms (G to G)
Surface Treatment Hard Coating (3H), Anti-glare
Orientation Portrait and andscape
VIDEO
Max Input Resolution 1366 X 768 @ 60Hz (RGB, HDMI/DVI)
Rec. Resolution 1366 X 768 @ 60Hz (RGB, HDMI/DVI)
H-Scanning Freq. 30 ~68kHz (RGB, HDMI/DVI)
V-Scanning Freq. 56~75Hz (RGB), 63Hz (HDMI/DVI)
Pixel Frequency 80 MHz (RGB, HDMI/DVI)
Sync Compatability Separate/Composite/Digital
Video Input RGB, HDMI/DVI
Picture mode Vivid/Standard/Cinema/Sports/Game
Color temperature Warm/Medium/Cool
INPUT
(Rear)
Digital DVI, HDMI/DVI with HDCP
Analog Component(BNC), RGB, AV(BNC)
Audio RGB/DVI Audio, Component Audio
External Control RS232C, RJ45(WO ), IR Receiver
USB Yes (x1)
HDTV Formats 480p / 576p / 720p / 1080i/1080p
OUTPUT
(Rear)
Digital DVI without HDCP
Analog RGB
Audio External speaker
External Control RS232C
AUDIO
Balance Yes
Audio Power 20W (10W x 2)
Speaker On/off Yes
Clear Voice II Yes
Sound Mode Standard, Music, Cinema, Sports, Game
LG Electronics U.S.A., Inc.
HE B2B Division
2000 Millbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
www.LGsolutions.com/support
Contact your LG Regional Sales Representative:
Channel: 800.897.8871
Hospitality: 800.228.1236
E-mail: [e-mail]
SPEC_47WV30MS_031308_PR
All screen images are simulated. Dimensions and weights are approximate.
Design, specifications, and features subject to change without notice.
© Copyright 2013 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s
Good” is a registered trademark of LG Corp.
ENERGY S AR is a registered trademark of the U.S. Environmental Protection
Agency. In Plane Switching is a trademark of LG Philips LCD Ltd. VESA is a
trademark of Video Electronics Standards Association. HDMI, the HDMI logo
and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
All other product and brand names are trademarks or registered trademarks
of their respective companies.
Printed in the USA. March 2013
LGsolutions.com
Direct LED
Super Narrow Bezel Display
SPECIAL
FEATURES
Mode 47WV30MS-B 47WV30BR-B
Temperature Sensor
Cooling FAN
Split Zoom (Self Video Wall, 15 x 15 Max) Yes, supports natural mode
Source Selection Digital(HDMI/DVI) / DVI / Analog(RGB) /
Component/USB
Brightness/Contrast/Backlight
Position/Size
Auto Config/Phrase
anguage (OSD/USB Playback) English/French/Spanish/Italian/German/
Portuguese/Korean/Japanese/Chinese/Russian
anguage (CD Manu) English/French/Spanish/Italian/German/
Portuguese/Korean/Japanese/Chinese/Russian
Czech/Arabic/Greece/Hungarian/Indonesian/
Kazakh/Netherlandic/Polish/Slovak/Taiwanese/
Turkish/Ukrainian/Swedish/Finnish
ISM Method Normal/Color Wash/White Wash
Advanced Color Temp, Dynamic Contrast, Dynamic Color,
Noise Reduction, Gamma, Black evel, Film Mode
Time Clock/On/off Timer/Sleep Timer/Auto off, Power on Delay
Information Display Model/Type, Serial Number, S/W Version,
IP Address, Homepage
Input abel
Auto Power/Source Memory
DPM Select Yes (Installation Menu)
Energy Saving Yes, Off /Minumum/Medium/Maximum/Screen Off
File Play with USB Yes
ENVIRONMENT
CONDITIONS
Operation Tempature 0°C ~40°C
Operation Humidity 10% ~80%
CABINET
Color Black
Bezel Width 3.9mm (left/top), 2.4mm (right/bottom)
Monitor Dimension 41.2" x 23.3" x 3.6"
Monitor Weight 63.9 lbs
Carton Dimensions 43.7” x 26.3” x 10.6”
Packed Weight 75.0 Ibs
Handle Yes
VESA
TM
Standard
Mount Interface 800mm x 400mm
POWER
Power Supply 100 -240V~, 50/60Hz
Power Type Built-in Power
Power Consumption
Max/Normal 220W(Max), 160W(Typ)
DPMS Off 1.0W(RGB)/1.0W(HDMI/DVI)
Power Off 0.5W
STANDARD
CERTIFICATIONS
Safety U / c-U / CB / TUV / KC
EMC FCC / CE / KCC
Erp/Energy Star 5.0 Yes / Yes
MEDIA PLAYER
External Media player Attatchable
SOFTWARE
Supersign Compatibility: Elite-s
WARRANTY
3-Year imited Warranty (Parts/ abor/Backlight)
UPC
7 19192 19098 6 7 19192 18949 2
ACCESSORIES
Remocon, Power cable, RGB Cable, DVI Cable, Manual (CD), Bolt (16Unit), IR Receiver,
Guide Bracket
47" class (47.0" measured diagonally)
47WV30MS-B

47WV30BR-B

Rear Jack Pack Panel
0.2”
0.1”
23.3”
41.2” 1.4” 2.1”
3.6”
DVI OUT DVI IN COMPONENT IN
VIDEOAV IN AUIDO
RGB OUT
RGB IN
SPEAKER
(8Ω)
AUDIO
(RGB/DVI)
REMOTE
CONTROL IN
USB LAN
RS-232C
(CONTROL)
/DVI
800mm
400mm
3.0”
4.5”
