9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Installing on a wall
Install the monitor at least 10 cm away from the
wall and leave about 10 cm of space at each side
of the monitor to ensure sufficient ventilation. De-
tailed installation instructions can be obtained from
your local retail store. Please refer to the manual
to install and set up a tilting wall mounting bracket.
10 cm
10 cm
10 cm
10 cm
To install the monitor to the wall, attach a wall
mounting bracket (optional) to the back of the moni-
tor.
Make sure that the wall mounting bracket is securely
fixed to the monitor and to the wall.
.
1Use the screws and wall mounting bracket that
comply with the VESA standard.
2Screws which are longer than the standard
length may damage the inside of the monitor.
3A non-VESA standard screw may damage the
product and cause the monitor to fall. LG Elec-
tronics is not liable for any accidents relating to
the use of non-standard screws.
4The monitor is VESA standard compliant.
5Use it according to the VESA standard as speci-
fied below.
y784.8 mm (30.9 inch) or shorter
* Thickness of the wall mount plate: 2.6 mm
* Fastening screw: Diameter 4.0 mm x Pitch 0.7
mm x Length 10 mm
y787.4 mm (31.0 inch) or longer
*
Use the wall mount plate and screws conform-
ing to the VESA standard
.
yUnplug the power cord before moving or in-
stalling the monitor to avoid electric shocks.
yInstalling the monitor on the ceiling or on a
slanted wall may result in the monitor falling
off, which could lead to injury.
yUse an authorized LG wall mount and con-
tact a local dealer or qualified professional.
yApplying excessive force when fastening
screws may cause damage to the monitor.
Damage caused in this way will not be cov-
ered by the product warranty.
yUse the wall mounting bracket and screws
that conform to the VESA standard. Damage
caused by the use or misuse of inappropri-
ate components will not be covered by the
product warranty.
yUse the screws specified in the VESA stan-
dard.
yThe wall mount kit includes the installation
guide and necessary parts.
yThe wall mounting bracket is optional. The
accessories can be purchased at your local
retail store.
yThe length of the screw may differ for each
wall mounting bracket. Ensure the correct
length of the screw is used.
yFor more information, please refer to the
user manual supplied with the wall mounting
bracket.
CAUTION
NOTE
MODELS DX2343 DX2743
VESA (A x B) 75 x 75 100 x 100
Stand Screw M4 M4
Required
Screw
4 4
Wall Mount
Plate (Option-
al)
RW120
D2343P D2743P
