LG FLATRON F720P User manual

COLOR MONITOR
SERVICE MANUAL
Website:http://biz.LGservice.com
E-mail:http://www.LGEservice.com/techsup.html
CAUTION
BEFORE SERVICING THE UNIT,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
MODEL: F720P (F720PK-AL**Q)
CHASSIS NO. : CA-127
( ) **Same model for SVC
*Same looking with new chassis.
Issue Date; 2003. 12.

1. PICTURE TUBE
Size : 17 inch
DefIection Angle : 90°
Neck Diameter : 29.1 mm
Diagonal inch : 16”
Slot Pitch : 0.24 mm
Face Treatment : W-ARASC (Anti-Reflective and
Anti-Static Coating),
Internal Anti-Glare
2. SIGNAL
2-1. Horizontal & Vertical Sync
1) Input Voltage Level: Low= ≤0.8V, High= ≥2.1V
2) Sync Polarity : Positive or Negative
2-2. Video Input Signal
1) Voltage Level : 0~0.7 Vp-p
a) Color 0, 0 : 0 Vp-p
b) Color 7, 0 : 0.467 Vp-p
c) Color 15, 0 : 0.7 Vp-p
2) Input Impedance : 75 Ω
3) Video Color : R, G, B Analog
4) Signal Format : Refer to the Timing Chart
2-3. Signal Connector
15 Pin D-Sub Connector
2-4. Scanning Frequency
Horizontal : 30~98 kHz
Vertical : 50~160 Hz
3. POWER SUPPLY
AC 100~240V, 50/60HZ, 2.5A Max
AC 200~240V, 50Hz, 1.5A Max.(PFC version)
3-2. Power Consumption
4. DISPLAY AREA
4-1. Active Video Area :
• Max Image Size - 325.4 x 244.1mm (12.91" x 9.61")
• Preset Image Size - 310 x 230 mm (12.20" x 9.06")
4-2. Display Color : Full Colors
4-3. Display Resolution : 1600 Dots x 1200Lines
4-4. Video Bandwidth : 203MHz
5. ENVIRONMENT
5-1. Operating Temperature: 0°C~40°C (32°F~103°F)
(Ambient)
5-2. Relative Humidity : 10%~90%
(Non-condensing)
5-3. Altitude :Less Than 16,404ft
6. DIMENSIONS (with TILT/SWIVEL)
Width : 415.0 mm (16.34")
Depth : 432.0 mm (17.00")
Height : 413.0 mm (16.25")
7. WEIGHT (with TILT/SWIVEL)
Net Weight : 16.5 kg (36.38lbs)
Gross Weight : 19.5 kg (42.99lbs)
8. USB Specifications
USB Standard :
Rev. 1.0 complied bus-powered hub
Downstream power supply : 100mA for each (MAX)
Communication speed : 12 Mbps (Full), 1.5 Mbps (Low)
USB port : 1 Upstream port
4Downstream ports
CONTENTS
SPECIFICATIONS
- 2 -
SPECIFICATIONS ................................................... 2
SAFETY PRECAUTIONS ........................................ 3
TIMING CHART ....................................................... 4
OPERATING INSTRUCTIONS ................................ 5
CONTROL LOCATIONS ......................................... 7
WIRING DIAGRAM ................................................. 8
DISASSEMBLY ....................................................... 9
BLOCK DIAGRAM ................................................. 10
DESCRIPTION OF BLOCK DIAGRAM................... 11
ADJUSTMENT ...................................................... 13
TROUBLESHOOTING GUIDE .............................. 15
EXPLODED VIEW.................................................. 21
REPLACEMENT PARTS LIST .............................. 23
PIN CONFIGURATION .......................................... 30
SCHEMATIC DIAGRAM......................................... 31
PRINTED CIRCUIT BOARD................................... 33
MODE
MAX
NORMAL (ON)
STAND-BY
SUSPEND
POWER OFF
H/V SYNC
ON/ON
OFF/ON
ON/OFF
POWER CONSUMPTION
less than 110W
less than 83W
less than 8W
less than 8W
less than 1W OFF
LED COLOR
GREEN/BLUE
GREEN/BLUE
ORANGE

SAFETY PRECAUTIONS
- 3 -
SAFETY-RELATED COMPONENT WARNING!
There are special components used in this color monitor
which are important for safety. These parts are marked
on the schematic diagram and the replacement
parts list. It is essential that these critical parts should be
replaced with the manufacturer's specified parts to
prevent X-radiation, shock, fire, or other hazards. Do not
modify the original design without obtaining written
permission from manufacturer or you will void the original
parts and labor guarantee.
CAUTION: No modification of any circuit should be
attempted.
Service work should be performed only after
you are thoroughly familiar with all of the
following safety checks and servicing
guidelines.
SAFETY CHECK
Care should be taken while servicing this color monitor
because of the high voltage used in the deflection circuits.
These voltages are exposed in such areas as the
associated flyback and yoke circuits.
FIRE & SHOCK HAZARD
An isolation transformer must be inserted between the
color monitor and AC power line before servicing the
chassis.
• In servicing, attention must be paid to the original lead
dress specially in the high voltage circuit. If a short
circuit is found, replace all parts which have been
overheated as a result of the short circuit.
• All the protective devices must be reinstalled per the
original design.
• Soldering must be inspected for the cold solder joints,
frayed leads, damaged insulation, solder splashes, or
the sharp points. Be sure to remove all foreign
materials.
IMPLOSION PROTECTION
All used display tubes are equipped with an integral
implosion protection system, but care should be taken to
avoid damage and scratching during installation. Use only
same type display tubes.
X-RADIATION
The only potential source of X-radiation is the picture tube.
However, when the high voltage circuitry is operating
properly there is no possibility of an X-radiation problem.
The basic precaution which must be exercised is keep the
high voltage at the factory recommended level; the normal
high voltage is about 26kV. The following steps describe
how to measure the high voltage and how to prevent X-
radiation.
Note : It is important to use an accurate high voltage
meter calibrated periodically.
• To measure the high voltage, use a high impedance
high voltage meter, connect (–) to chassis and (+) to
the CDT anode cap.
• Set the brightness control to maximum point at full
white pattern.
• Measure the high voltage. The high voltage meter
should be indicated at the factory recommended level.
• If the meter indication exceeds the maximum level,
immediate service is required to prevent the possibility
of premature component failure.
• To prevent X-radiation possibility, it is essential to use
the specified picture tube.
CAUTION:
Please use only a plastic screwdriver to protect yourself
from shock hazard during service operation.

TIMING CHART
- 4 -
VIDEO
SYNC D
A
EF
BC
kHz
µs
µs
µs
µs
µs
µs
Hz
ms
ms
ms
ms
ms
ms
MODE 1
–
43.269
23.112
17.778
5.334
1.556
1.556
2.222
–
85.008
11.763
11.093
0.670
0.023
0.069
0.578
640
X
480
85Hz
Yes
MODE 2
+
53.674
18.631
14.222
4.409
0.569
1.138
2.702
+
85.061
11.756
11.178
0.578
0.019
0.056
0.503
800
X
600
85Hz
Yes
MODE 3
+
68.677
14.561
10.836
3.725
0.508
1.016
2.201
+
84.997
11.765
11.183
0.582
0.015
0.044
0.523
1024
X
768
85Hz
Yes
MODE 4
+
91.146
10.971
8.127
2.844
0.406
1.016
1.422
+
85.024
11.762
11.235
0.527
0.011
0.033
0.483
1280
X
1024
85Hz
Yes
MODE 5
+
93.750
10.666
7.901
2.765
0.316
0.948
1.501
+
75.000
13.333
12.800
0.533
0.011
0.032
0.490
1600
X
1200
75Hz
MARK
A
B
C
D
E
F
A
B
C
D
E
F
MODE
FACTORY PRESET MODE
Resolution
Recall
H
O
R
I
Z
O
N
T
A
L
V
E
R
T
I
C
A
L
Sync Polarity
Frequency
Total Period
Video Active Time
Blanking Time
Front Porch
Sync Duration
Back Porch
Sync Polarity
Frequency
Total Period
Video Active Time
Blanking Time
Front Porch
Sync Duration
Back Porch
VESA
* Mode 5 is not preset mode but TCO check resolution!

- 5 -
OPERATINGINSTRUCTIONS
REARVIEWFRONTVIEW
FrontControlPanel
SeeFront ControlPanel
PowerButtonD-SubSignalConnector
ACPowerSocket
1.PowerButton
This button is used to turn the monitor ON and
OFF.
2.PowerIndicator
This Indicator lights up green when the monitor
operates normally. If the monitor is in stand-by,
suspend or DPMS off mode, this indicator color
changes to amber.
3.MENU(orOSD)Button
Use this button to enter or exit the on screen
display.
4.Button
Use these buttons to choose or adjust items in
the onscreendisplay.
5.SELECT (orSET)Button
Use this button to enter aselection in the on
screen display..
100
100
125
4
3
The Contrast and Brightness functions are also available in
the OnScreenDisplay(OSD)menu.
Button
Button
Bring upContrastadjustment
Bring up Brightness adjustment
4

Universal Serial Bus
- 6 -
USB connection (Option)
(1) Connect the upstream port of the monitor to the downstream port of the USB
compliant PC or another hub using the USB cable.
(2) Connect the USB compliant peripherals to the downstream ports the monitor.
*USB(Universal Serial Bus) is supported WINDOWS98 and Higher.
Making use of USB (Universal Serial Bus)*
USB(Universal Serial Bus) is an innovation in connecting your different desktop peripherals conveniently to your
computer. By using the USB, you will be able to connect your mouse, keyboard, printer, and other peripherals to
your monitor instead of having to connect them to your computer. This will give you greater flexibility in setting
up your system. USB allows you to connect chain up to 120 devices on a single USB port, and you can “hot”
plug (attach them while the computer is running) or unplug them while maintaining Plug and Plug auto detection
and configuration. This monitor has an integrated bus-powered USB hub, allowing up to 2 other USB devices to
be attached it.
USB Downstream Ports
Connect the cables from USB compliant
peripherals-such as keyboard, mouse,
printer, scanner, etc.
USB Upstream Port
To USB downstream port
of the USB compliant PC
or another hub cable
USB Upstream connector USB Downstream connector

CONTROLLOCATIONS
- 7 -
VR901
:BAdjustment (190VLine)
+
VR801
: High Voltage Adjustment (26kV)

WIRING DIAGRAM
- 8 -
P301
P302
P303
Signal
Cable
AC
Socket
FBT
P801
S-
S+
P901 P702
P451
P902
P401
P201P250
P402

DISASSEMBLY
- 9 -
1. TILT/SWIVEL & BACK COVER REMOVAL
1) Set the monitor face downward.
2) Carefully remove the Tilt/Swivel by pulling it upward.
3) Pressing the latch (a), Back cover by pushing it upward. (See Figure. 1)
4) Release the latch (c). (See Figure. 2 and Tip Spec.)
5) Slide the Back Cover away from the Front Cabinet of the monitor.
2. TOTAL CHASSIS ASSEMBLY REMOVAL
1) Set the monitor face downward.
2) Pressing the latch (a), Main Chassis
by pushing it upward.
Back Cover
Cabinet
(b)
Tip
C
B
A
Tip Spec.
A(Width) : 5.0~15.0mm
B(Depth) : 0.6~0.9mm
C(Height) : 12.0mm
Figure. 1 Figure. 2
(a) (a)
CDT
(a)

BLOCK DIAGRAM
- 10 -
SIGNAL
INPUT

DESCRIPTION OF BLOCK DIAGRAM
- 11 -
1. Line Filter & Associated Circuit.
This is used for suppressing noise of power input line
flowing into the monitor and/or some noise generated
in this monitor flowing out through the power input
line.
That is to say, this circuit prevents interference
between the monitor and other electric appliances.
2. Degauss Circuit & Coil.
The degauss circuit consists of the degaussing coil,
the PTC (Positive Temperature Coefficient) thermistor
(TH901), and the relay (RL901). This circuit eliminates
abnormal color of the screen automatically by
degaussing the slot mask in the CDT when turn on the
power switch.
When you need to degauss while using the monitor,
select DEGAUSS on the OSD menu.
3. SMPS (Switching Mode Power Supply).
This circuit works with power of 100~240V or
200~240V (50/60Hz) specially for PFC version.
The operation procedure is as follows:
1) AC input voltage is rectified and smoothed by
the bridge diode (D901) and the capacitor (C905).
2) The rectified voltage (DC voltage) is applied to the
primary coil of the transformer (T901).
3) The control IC (IC901) generates switching pulse
to turn on and off the primary coil of the
transformer (T901) repeatedly.
4) Depending on the turn ratio of the transformer, the
secondary voltages appear at the secondary coil of
the transformer (T901).
5) These secondary voltages are rectified by each
diode (D924, D926, D923, D929, D922, D921,
D920) and operate the other circuits. (Deflection,
Video Amplifier, etc.)
4. Display Power Management Circuit.
This circuit control power consumption of the monitor
by detecting H and V sync signal. There are stand-by
and suspend mode. When no horizontal or vertical
sync signal input, the circuit consists of Q913, Q915
and IC401 control signal becomes stand-by and
suspend mode. It’s power consumption is below 8W.
5. X-ray Protection.
This circuit detects the rectified DC voltage comes
from the FBT pin 4. If the high voltage of the FBT
reaches up to about 30kV (abnormal state), H.V
control (IC802) detects. It stops B+voltage supplied to
the FBT (T701), and high voltage is not be generated,
(In the normal state, the high voltage is about 26kV.)
6. Micom(Microprocessor) Circuit.
The operating procedure of Micom (Microprocessor)
and its associated circuit is as follows:
1) H and V sync signal is supplied from Signal Cable to the
Micom (IC401).
2) The Micom (IC401) distinguishes polarity and
frequency of Hand V sync.
3) The Micom controls each OSD function signals.
(H-size, H-position, V-size, etc.)
4) The controlled data of each mode is stored in IC402.
User can adjust screen condition by each OSD
function. The data of the adjust screen condition is
stored automatically.
7. Horizontal and Vertical Synchronous Processor.
This circuit generates the horizontal drive pulse and
the vertical drive pulse by taking sync-signal from
Signal Cable. This circuit consists of the
TDA4841(IC801) and the associated circuit.
8. Oscillating Circuit for D/D Converter.
This circuit generates the pulse wave which has the
horizontal period by taking the output of the
TDA4841(IC801).
9. D/D (DC to DC) Converter.
This circuit supplies DC voltage to the horizontal
deflection output circuit by decreasing DC 190V which
is the secondary voltage of the SMPS in accordance
with the input horizontal sync signal.
10. D/D Drive & Convert Circuit.
This circuit is used for supplying B+voltage to
horizontal deflection output transistor (T801).
11. Horizontal Deflection Output Circuit.
This circuit makes the horizontal deflection by
supplying the saw-tooth current to the horizontal
deflection yoke.

- 12 -
12. High Voltage Output & FBT (Flyback Transformer).
The high voltage output circuit is used for generating
pulse wave to the primary coil of the FBT (Flyback
Transformer (T701)). A boosted voltage (about 26kV)
appears at the secondary of the FBT and it is supplied
to the anode of the CDT.
And there are another output voltages such as the
dynamic focus voltage.
13. H-Linearity Correction Circuit.
This circuit corrects the horizontal linearity for each
horizontal sync frequency.
14. Vertical Output Circuit.
This circuit takes the vertical wave from the
TDA4841(IC801) and performs the vertical deflection
by supplying the saw-tooth wave current from the
TDA4867J (IC601) to the vertical deflection yoke.
15. Dynamic Focus Output Circuit.
This circuit takes H and V parabola wave from the
TDA4841(IC801), and amplifies these waves to offer
to the FBT (T701).
16. H& V Blanking and Brightness Control.
This circuit eliminates the retrace line by supplying a
negative pulse to the G1 of the CDT.
17. Image Rotation (Tilt) Circuit.
This circuit corrects the tilt of the screen by supplying
the image rotation signal to the tilt coil which is
attached to the CDT near the deflection.
18. Static Convergence Control Circuit.
This circuit corrects the convergence of the screen by
supplying the convergence signal to the 4H (STC) coil
which is attached to the CDT near the deflection.
19. Moire Reduction Circuit
This circuit reduce interference between the periodical
display pattern and the CDT's slot (or dot).
The positions of every other one dot video signal
beams (red, green, and blue beam) are shifted finely,
thus reducing interference.
20. OSD Circuit.
This circuit is used for performing the OSD (On-
Screen- Display) function.
When a user selects the OSD Select/Adjustment
control, the adjustment status displays on the screen.
21. Video Pre-Amp Circuit.
This circuit amplifies the analog video signal from 0-
0.7V to 0-4V. This circuit is operated by taking the
clamp, R, G, B drives, and contrast signals from the
Micom (IC401).
22. Video Output Amp Circuit.
This circuit amplifies the video signal which comes
from the video pre-amp circuit and amplified video
signal is applied to the CDT cathode.

ADJUSTMENT
- 13 -
GENERAL INFORMATION
All adjustment are thoroughly checked and corrected
when the monitor leaves the factory, but sometimes
several adjustments may be required.
Adjustment should be following procedure and after
warming up for a minimum of 30 minutes.
•Alignment appliances and tools.
- IBM compatible PC.
- Programmable Signal Generator.
(eg. VG-819 made by Astrodesign Co.)
- EPROM or EEPROM with saved each mode data.
- Alignment Adaptor and Software.
- Digital Voltmeter.
- White Balance Meter.
- Luminance Meter.
- High-voltage Meter.
AUTOMATIC AND MANUAL DEGAUSSING
The degaussing coil is mounted around the CDT so that
automatic degaussing when turn on the monitor. But a
monitor is moved or faced in a different direction, become
poor color purity cause of CDT magnetized, then press
DEGAUSSING on the OSD menu.
ADJUSTMENT PROCEDURE & METHOD
-Install the cable for adjustment such as Figure 1and run
the alignment program on the DOS for IBM compatible PC.
-Set external Brightness and Contrast volume to max position.
1. Adjustment for B+ Voltage.
1) Display cross hatch pattern at Mode 4.
2) Adjust P905 voltage to 190V ± 0.2V with VR901.
2. Adjustment for High-Voltage.
1) Display cross hatch pattern at Mode 4.
2) Adjust CDT Anode voltage to 26kV ± 0.2kV with
VR801.
3. Adjustment for Horizontal Raster Center.
1) Display cross hatch pattern at Mode 4.
2) Adjust the Back Raster should be center of the
screen with SW801.
4. Adjustment for Factory Mode (Preset Mode).
1) Display cross hatch pattern at Mode 1~4.
2) Run alignment program for F700PJ on the IBM
compatible PC.
3) EEPROM → ALL CLEAR → Y(Yes) command.
<Caution> Do not run this procedure unless the
EEPROM is changed. All data in EEPROM (mode
data and color data) will be erased.
4) COMMAND → PRESET START → Y(Yes)
command.
5) DIST. ADJ. → FOS. ADJ command.
6) Adjust H-POSITION as arrow keys to center of the
screen.
7) Adjust H-SIZE as arrow keys to 310 ± 2mm.
8) Adjust V-POSITION as arrow keys to center of the
screen.
9) Adjust V-SIZE as arrow keys to 230 ± 2mm.
10)Adjust TRAPEZOID as arrow keys to be the best
condition.
11) Adjust TILT as arrow keys to be the best condition.
12) Display cross hatch pattern at Mode 4.
13) DIST. ADJ. → BALANCE DATA command.
14) Adjust balance of Pin-Balance as arrow keys to be
the best condition.
15) Adjust parallelogram as arrow keys to be the best
condition.
16) Save of the Mode.
17) Save of the System.
18)Display from Mode 4 and repeat above from
number 6) to 15).
19) COMMAND → PRESET EXIT → Y (Yes) command.
5. Adjustment for White Balance and Luminance.
1) Set the White Balance Meter.
2) Press the DEGAUSSING on the OSD menu for
demagnetization of the CDT.
3) Display color 0,0 pattern at Mode 4.
4) COMMAND → PRESET START → Y(Yes)
command.
5) Set Bightness and Contrast to max position.
6) COLOR ADJ. → LUMINANCE command of the
alignment program.
7) COLOR ADJ. → BIAS ADJ. command of the
alignment program.
8) Check whether blue color or not at R-BIAS and G-
BIAS to min position, Sub-Brightness to 90 position,
B-BIAS to 75 or 100(75: when CDT is
M41QBF423X07(P), 100: when CDT is
M41QEV423X01(CH)) position. If it's not blue color,
the monitor must repair.
9) Adjust Screen control on the FBT to 0.15 ± 0.05FL
of the raster luminance.
10)Adjust R-BIAS and G-BIAS command to x=0.283 ±
0.006 and y=0.298 ± 0.006 on the White Balance
Meter with PC arrow keys.

- 14 -
11) Display color 15,0 box pattern(70x70mm) at mode 4.
12)DRIVE ADJ command.
13)Set B-DRIVE to 85 at DRIVE of the alignment
program.
14)Adjust R-DRIVE and G-DRIVE command to white
balance x=0.283 ± 0.003 and y=0.298 ± 0.003 on
the White Balance Meter with PC arrow keys.
15)Adjust SUB-CONTRAST command to 47±1FL of
the raster luminance.
15)Display color 15,0 full white patten at Mode 4.
16)COLOR ADJ. → LUMINANCE → ABL command.
17) Adjust ABL to 32 ± 1FL of the luminance.
18) Exit from the program.
6. Adjustment for Focus.
1) Display H character in full screen at Mode 4.
2) Adjust two Focus control on the FBT that focus
should be the best condition.

- 15 -
TROUBLESHOOTING GUIDE
1. NO POWER
NO POWER
(POWER INDICATOR OFF)
TROUBLE IN
BRIDGE DIODE
(D901)
TROUBLE IN
FUSE (F901)
TROUBLE IN
IC901
CHECK
FUSE OK?
(F901)
CHECK
D901
BRIDGE DIODE?
NO
YES
YES
NO
NO
CHECK
C905(+) VOLTAGE
145VDC at 110V input
310VDC at 220V input
TROUBLE IN
D924, D926, D923,
D922, D921, D920
TROUBLE IN
Q912, Q913, Q915, Q914,
IC903, IC904, Q902
YES
NO
CHECK
D924, D926, D923,
D922, D921, D920 ?
YES

- 16 -
2. NO CHARACTER
CHECK
IC302 PIN 5, 6, 7 ?
CHECK
IC302 PIN 19, 20, 21
PIN 10 (5V) ?
CHECK
IC303 PIN 1, 3, 5
PIN10 (12V),
PIN 6 (80V) ?
TROUBLE IN
P301, SIGNAL CABLE,
PC SIGNAL
TROUBLE IN
IC302, P302
TROUBLE IN
IC303
TROUBLE IN
CDT SOCKET
NO
YES
NO
NO
YES
YES
CHECK
R, G, B CATHODE
VOLTAGE?
TROUBLE IN
IC304
NO
YES
NO CHARACTER

- 17 -
3. NO RASTER
NO VIDEO
(POWER INDICATOR
GREEN-Worldwide / BLUE-Russia
CHECK
POWER INDICATOR
GREEN / BLUE
CHECK
SCREEN CONTROL
KNOB OF FBT
CHECK
VOLTAGE AT
D924/D926 CATHODE (190V)
D923/D929 CATHODE (80V)
IC905 OUT (12V)
D921 CATHODE
(6.3V)?
CHECK
IC401 (MICOM) PIN 6
5V (HIGH), IC801 PIN 10
15V (HIGH)?
ROTATE SCREEN
CONTROL KNOB TO
CLOCKWISE or
COUNTER CLOCKWIES
TROUBLE IN
IC401 (MICOM),
IC801
TROUBLE IN
CDT SOCKET, BOARD
TROUBLE IN PRIMARY
CIRCUIT OF T901
TROUBLE IN
P302 SIGNAL CABLE
AMBER
GREEN / BLUE
OK
YES
NO
YES
NO
or AMBER)
or AMBER ?

- 18 -
4. NO VERTICAL DEFLECTION
NO V-DEFLECTION
(ONE HORIZONTAL LINE)
CHECK
IC601 Pin 3
(15V) ?
CHECK
IC601 PIN 7
(47V)?
TROUBLE IN
T901 15V LINE
TROUBLE IN
T701 47V LINE
TROUBLE IN
IC601, V-CIRCUIT
NO
NO
YES
YES
CHECK
IC801 PIN 12
(SAWTOOTH WAVE)? TROUBLE IN
IC801
NO
YES

- 19 -
5. TROUBLE IN DPM
CHECK
IC401 (MICOM)
PIN 40, 41 (H/V INPUT)
SIGNAL?
CHECK
IC401 PIN 9, 8
WAVEFORM?
CHECK
IC401 PIN 6
(5V, HIGH)?
CHECK
IC401 PIN 17, 18 ?
CHECK PC,
(PC IS NOT GOING INTO
DPM MODE)
TROUBLE IN
X401, IC401
TROUBLE IN
IC401
TROUBLE IN
IC401
TROUBLE IN
T901 or PC
INPUT H/V SYNC SIGNAL
NO H/V SYNC SIGNAL
NO
NO
NO
DPMS TABLE
Mode Item
NORMAL
STAND-BY
SUSPEND
OFF
H / V SYNC
ON / ON
OFF / ON
ON / OFF
OFF / OFF
LED
GREEN / BLUE
AMBER
AMBER
AMBER
VIDEO
NORMAL
OFF(0V)
OFF(0V)
OFF(0V)
YES
YES
CHECK
B+ LINE
(12V, 15V, 80V,
5V) ?
TROUBLE IN
Q913, Q915
NO
YES
STAND-BY/SUSPEND/
DPMS OFF MODE FAILURE

- 20 -
6. NO DEGAUSSING
CHECK
IC401 PIN 6
(5V)?
CHECK
Q920 COLLECTOR
VOLTAGE
(0.5V)?
CHECK
P901?
CHECK
RL901?
TROUBLE IN
IC401 (MICOM)
TROUBLE IN
D925
TROUBLE IN
P901
TROUBLE IN
RL901
TROUBLE IN
TH901,
DEGAUSSING COIL
NO DEGAUSSING
NO
NO
NO
NO
YES
YES
YES
YES
