FLATRON L1781Q
FLATRON L1781Q
F
FLATRON L1781Q
FLATRON L1781Q
FLATRON L1781Q
◗ Ultra Slim Design (2.5" Folded Height)
◗ Integrated LCD Picture-Enhancing f-Engine chip
◗ Ultra Fast 8ms Response Time
◗ Digital (DVI-D) and Standard Analog VGA Inputs
◗ Auto-Synchronous Support from 640 x 350 up to 1280 x 1024 @ 75Hz
◗ Heat-Sensor Power On/Off button and Controls
◗ Convenient Auto-Pivot / Auto-Mirror Function
◗ TCO '99 Low-Emission Compliant
17" (17.0" VIS) ULTRA SLIM LCD MONITOR
TM

EPA POLLUTION PREVENTER
T
H
R
E
E
Y
E
A
R
Q
U
I
C
K
S
W
A
P
R
E
P
L
A
C
E
M
E
N
T
P
R
O
G
R
A
M
FLATRON L1781Q
FLATRON L1781Q
782LE
BACK
LIVE: 1/2”From Trim
TRIM: 8 1/2”x 11”
BLEED: 1/8”All Around
(All Black)
17" (17.0" VIS) ULTRA SLIM LCD MONITOR
www.LGusa.com
Introducing the new L1781Q monitor from LG; the slimmest flatscreen in its
class. Its f-ENGINE technology features the first LCD picture-enhancing chip to
provide not only astounding color, but superb contrast and image quality. Plus
it has many other features, like heat-sensor power on/off button, DVI-D input,
and auto-pivot/mirror function. L1781Q LCD monitor from LG. Superior
performance in a slim package.
©2005 LG Electronics U.S.A., Inc. All trademarks are property of their respective owners. Design and specifications subject to change without notice. 1/05
LG ELECTRONICS U.S.A., INC.
HEADQUARTERS
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 ◗Tel: [phone], Fax: [phone] ◗ www.LGusa.com
Saved: 01/29/2002 03:07 PM
Printed: 01/29/2002 03:07 PM
Document Name: 782LE spec sheet
Fonts: HelveticaNeue LightCond,Eurostile BoldCondensed, Zapf Dingbats,BI Frutiger BoldItalic, BLI Frutiger BlackItalic,HelveticaNeue Condensed, Eurostile BoldExtendedTwo, HelveticaNeue BoldCond, BL
Frutiger Black, R Frutiger Roman,L Frutiger Light, UB Frutiger UltraBlack,Helvetica
Graphics: Digitally, logo with icon#1/eps, LG Group/2000 CIP, 782LE_side_greyscale.eps, LG Electronics, 782LE_side.eps, gold_bar.eps, blue_bar.eps, red_bar.eps, Glowing Line (Sell Sheet)/EPS,
BW_bar.eps, BW_bar.eps, Glowing Line (B&W)/EPS,GRAY ISO 9001/EPS, 3year quickswap logo.eps, tco B&W logo/eps, ES.clr B&W
Colors: Black, Cyan, Magenta, Yellow
DISPLAY TYPE 17.0" (17.0" VIS) Color Active Matrix TFT LCD Screen
DISPLAY AREA 13.3" x 10.6" (338mm x 270mm)
DISPLAY COLORS 16.2Million (6Bits + FRC)
PIXEL PITCH 0.264mm x 0.264mm Pixel
PIXEL CONFIGURATION RGB Stripe
SURFACE TREATMENT Hard Coating 3H,Anti-Glare
ELECTRONIC INTERFACE LVDS
BACKLIGHTING 4 CCFL
MAXIMUM RESOLUTION 1280 x 1024
BRIGHTNESS 250cd/m2 (Typical)
CONTRAST RATIO 500:1 (Typical)
RESPONSE TIME 8ms (Typical)
VIEWING ANGLE H: 160º,V:160º
HORIZONTAL SCANNING
FREQUENCIES
30-83kHz,Auto-Synchronous
VERTICAL SCANNING
FREQUENCIES 56-75Hz,Auto-Synchronous
AUTO-SYNC SUPPORT640 x 350 up to 70Hz, 640 x 480 up to 75Hz,
720 x 400 up to 70Hz, 800 x 600 up to 75Hz,
832 x 624 up to 75Hz, 1024 x 768 up to 75Hz
1280 x 1024 up to 75Hz
CONTROL TYPE On-Screen Display of Adjustments
INPUT SIGNAL RGB Analog
INPUT TERMINALS 15-Pin D-SUB and DVI-D
SYNC SIGNALING Separate, Composite, SOG, Digital Signal
MEMORY MODES 13 Factory Preset, 10 User-Settable
VESA PLUG AND PLAY LEVEL DDC2B
DIGITAL ON-SCREEN CONTROLS Brightness, Contrast, Gamma, Horizontal/Vertical Position, Clock, Phase, OSD Position, f-Engine(Pre-set modes)
Color Temp (9300K, 6500K, User), Language, Factory Reset, ADC Calibration, Auto Input
FRONT PANEL CONTROLS Power,Menu (-, +), Set/Auto, f-Engine, Source
POWER REQUIREMENTS 90-264 VAC, 47-63Hz
DPMS POWER CONSUMPTION On: 40 Watts, Standby: 2 Watts, DPMS Off: 2 Watts
TILT/SWIVEL Tilt: Down 0º/Up 157º
VESA MOUNTING COMPLIANCE Standard VESA Mounting, 100mm x 100mm Screw Spacing
DIMENSIONS WITH BASE (WxDxH) 14.7" x 9.5" x 14.9" (374mm x 240mm x 378mm); Folded 14.7" x 2.5" x 12.2"
SHIPPING DIMENSIONS (WxDxH) 18.7" x 5.5" x 15.6" (476mm x 140mm x 396mm)
WEIGHT 9.5 lbs (4.3 kg) Net; 13.4 lbs (6.1 kg) Shipping
SAFETY/REGULATORYTCO ‘99, UL, FCC-B, CE, EPA Energy Star,CSA,
SEMKO, GOST,TUV-GS, ISO 13406-2,VCCI-2, C-TICK
ACCESSORIES Power Cord, Signal Cable, DVI Cable, Manual, Install Disk
LGEUS WARRANTY 3Year QuickSwap Replacement Program
