LG Flatron L2010P User manual

This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in
potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display,
observe the following basic rules for its installation, use, and servicing.
Use only the power cord supplied with the unit. In case you use another power cord, make sure that it is certified by the applicable
national standards if not being provided by the supplier. If the power cable is faulty in any way, please contact the manufacturer or
the nearest authorized repair service provider for a replacement.
The power supply cord is used as the main disconnection device. Ensure that the socket-outlet is easily accessible after
installation.
●Operate the display only from a power source indicated in the
specifications of this manual or listed on the display. If you are
not sure what type of power supply you have in your home,
consult with your dealer.
●Overloaded AC outlets and extension cords are dangerous. So
are frayed power cords and broken plugs. They may result in a
shock or fire hazard. Call your service technician for
replacement.

●There are no user serviceable components inside.
●There are Dangerous High Voltages inside, even when the
power is OFF.
●Contact your dealer if the display is not operating properly.
- To Avoid Personal Injury :
●Do not place the display on a sloping shelf unless properly
secured.
●Use only a stand recommended by the manufacturer.
- To Prevent Fire or Hazards:
●Always turn the display OFF if you leave the room for more than
a short period of time. Never leave the display ON when leaving
the house.
- Do not Open the Display.

●Keep children from dropping or pushing objects into the display's
cabinet openings. Some internal parts carry hazardous voltages.
●Do not add accessories that have not been designed for this
display.
●During a lightning storm or when the display is to be left
unattended for an extended period of time, unplug it from the
wall outlet.

This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in
potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display,
observe the following basic rules for its installation, use, and servicing.
●Do not allow anything to rest upon or roll over the power cord, and do not
place the display where the power cord is subject to damage.
●Do not use this display near water such as near a bathtub, washbowl, kitchen
sink, laundry tub, in a wet basement, or near a swimming pool.
-Displays are provided with ventilation openings in the cabinet to allow the release of heat generated during operation. If
these openings are blocked, built-up heat can cause failures which may result in a fire hazard. Therefore, NEVER:
●Block the bottom ventilation slots by placing the display on a bed, sofa, rug,
etc.
●Cover the openings with cloth or other material.

●Place the display in a built-in enclosure unless proper ventilation is provided.
●Place the display near or over a radiator or heat source.
Do not rub or strike the Active Matrix LCD with anything hard as this may scratch, mar, or damage the Active Matrix LCD
permanently.
Do not press the LCD screen with your finger for a long time as this may cause some afterimages.
Some dot defects may appear as Red, Green or Blue spots on the screen. However, this will have no impact or effect on the
display performance.
If possible, use the recommended resolution to obtain the best image quality for your LCD display. If used under any mode except
the recommended resolution, some scaled or processed images may appear on the screen. However, this is characteristic of the
fixed-resolution LCD panel.

This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in
potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display,
observe the following basic rules for its installation, use, and servicing.
●Unplug the display before cleaning the face of the display screen.
●Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the
display screen because over-spraying may cause electrical shock.

This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in
potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display,
observe the following basic rules for its installation, use, and servicing.
●Do not throw away the carton and packing materials. They make an ideal
container in which to transport the unit. When shipping the unit to another
location, repack it in its original material.

Proper posture to use the monitor
Adjust the angle of the monitor so that the screen slightly faces downward.
Long hours of use give eye strain. Make sure to take 10 minutes of break from the monitor every hour.

Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices
are turned off.
1. Adjust the position of the panel in various ways for maximum comfort.
●Tilt Range :
●Height Range : maximun 3.15inch (80.0mm)

●Landscape & Portrait : You can rotate the panel clockwise.
(* For detailed information, please refer to the Pivot Sofeware CD provided.)
Ergonomic
It is recommended that in order to maintain an ergonomic and comfortable viewing position, the forward tilt angle of the monitor
should not exceed 5 degrees.
1.Place the monitor in a convenient, well-ventilated location near your computer. To adjust height of your monitor, unlock the
stand lock on top of the stand.
2. Press the "PUSH" button( ), and pull the "Stand Cover" down to separate it from the stand.
3. Connect the signal cable. When attached, tighten the thumbscrews to secure the connection.
4. Connect the power cord into a proper power outlet that is easily accessible and close to the display.

5. After connecting cables, put the stand cover correctly into the holes on the stand. If securely connected, you can hear the click
sound from the latch.

6. Power on the PC, then the monitor.

Control Function
Power Button
Power (DPMS)
Indicator
Use this button to turn the display on or off.
This Indicator lights up green when the display operates normally. If the
display is in DPM (Energy Saving) mode, this indicator color changes to
amber.

MENU Button
Use this button to enter or exit the On Screen
Display.
Buttons
Use these buttons to choose or
adjust items in the On Screen
Display.
SELECT Button
Use this button to enter a selection in the On
Screen Display.
Direct Access Function
Bring up Contrast and Brightness adjustment.

LIGHT VIEW
This function optimizes the brightness, contrast or
color value to the surrounding conditions and settings
and enables you to enjoy the most suitable picture by
adjusting the surroundings (DAY/NIGHT/USER
MODE).
●TEXT: For viewing letters
●MOVIE: For viewing movies
●PHOTO: For viewing pictures or the
photographs
●USER MODE: This function memorizes the
manual adjustment -Brightness, Contrast and
Color value on the On Screen Display.
AUTO Adjustment Function
When adjusting your display settings, always press the
AUTO button before entering the On Screen
Display(OSD). This will automatically adjust your
display image to the ideal settings for the current
screen resolution size (display mode).
The best display mode is 1600 X 1200@60Hz.
SOURCE Selection: SOURCE → →SELECT
Use this button to make dvi digital, dvi analog or dsub
analog connector active. This feature is used when
two computers are connected to the display. The
default setting is Dsub.
●DVI DIGITAL
●DVI ANALOG
●DSUB ANALOG

CONTROLS LOCKED/UNLOCKED: MENU and
This function allows you to secure the
current control settings, so that they
cannot be inadvertently changed. Press
and hold the MENU button and button
for 3 seconds: the message "CONTROLS
LOCKED" appears.
You can unlock the OSD controls at any
time by pushing the MENU button and
button for 3 seconds: "CONTROLS
UNLOCKED" will appear.

Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On
Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The
following section is an outline of the available adjustments and selections you can make using the OSD.
NOTE
- Allow the display to stabilize for at least 30 minutes before making image adjustments.
To make adjustments in the On Screen Display, follow these steps:
1. Press the MENU Button, then the main menu of the OSD appears.
2. To access a control, use the or Buttons. When the icon you want becomes highlighted, press the SELECT Button.
3. Use the Buttons to adjust the item to the desired level.
4. Accept the changes by pressing the SELECT Button.
5. Exit the OSD by Pressing the MENU Button.

The following table indicates all the On Screen Display control,adjustment,and setting menus.
Main Menu Sub Menu A D Reference
CONTRAST/ BRIGHTNESS CONTRAST
To adjust the brightness and contrast of the screen
BRIGHTNESS
COLOR ADJUSTMENT
USER(R/G/B)
To customize the color of the screen
9300K
6500K
IMAGE POSITION H POSITION
To adjust the position of the screen
V POSITION
TRACKING
AUTO
To improve the clarity and stability of the screen
CLOCK
PHASE
SETUP
LANGUAGE
To customize the screen status for a user's
operating environment
IMAGE SIZE
TRANSPARENCY
ZOOM
OSD POSITION HORIZONTAL
To adjust position of the OSD window on the
screen
VERTICAL
: Adjustable A : Analog Input D : Digital Input
You were introduced to the procedure of selecting and adjusting an item using the OSD system.

OSD Adjust Description
CONTRAST
To adjust the contrast of the screen.
BRIGHTNESS
To adjust the brightness of the screen.
