ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal
dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct
andaccessories.
 Donotuseanypirateditemstoensurethesafetyandproductlifespan.
 Anydamagesorinjuriesbyusingpirateditemsarenotcoveredbythewarranty.
 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.
 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade
ofproductfunctions.
CAUTION
NOTE
Remote control and Batteries
Stand base
Power Cord
CD(Owner's Manual) / Card
RGB Cable

5
ENGLISH
ASSEMBLING AND PREPARING
 YoucansetthePowerindicatortoonoroffbyselectingOPTIONinthemainmenus.
 LocalkeysworkonPower, Programme, Volume and Inputonly.
NOTE
Parts and buttons
button Description
MODE" " Selectsthemode.(Programme☞Volume☞ INPUT)
Programme Scrollsthroughthesavedprogrammes.
Volume Adjustthevolumelevel.
INPUT Changestheinputsource.
, Adjuststhemodebuttonlevel.
HDMI IN AV IN
VIDEO
ANTENNA /
CABEL IN
MONO L
USB IN
RGB IN (PC)
AUDIO R
RemoteControl
Sensor
Buttons
Connectionpanel(Seep.34)
 (Power Button)
 Power Indicator

»LightingOn:Turnedon

»LightingOff:Turnedoff

6
ENGLISH
ASSEMBLING AND PREPARING
Lifting and moving the
Monitor set
WhenmovingorliftingtheMonitorset,readthe
followingtopreventtheMonitorsetfrombeing
scratchedordamagedandforsavetransportation
regardlessofitstypeandsize.
Setting up the Monitor set
Attaching the Stand Base
1 PlacetheMonitorsetwiththescreenside
downonaflatandcushionedsurface.
Avoidtouchingthescreenatalltimes,asthis
mayresultindamagetothescreenorsome
ofthepixelsusedtocreateimages.
Layafoammatorsoftprotectivecloth
onthesurfacetoprotectthescreenfrom
damage.
CAUTION
CAUTION
 ItisrecommendedtomovetheMonitorsetin
theboxorpackingmaterialthattheMonitor
setoriginallycamein.
 BeforemovingorliftingtheMonitorset,
disconnectthepowercordandallcables.
 HoldthetopandbottomoftheMonitor
setframefirmly.Makesurenottoholdthe
transparentpart,speaker,orspeakergrill
area.
 WhenholdingtheMonitorset,thescreen
shouldfaceawayfromyoutopreventthe
screenfromscratches.

 WhentransportingtheMonitorset,donot
exposetheMonitorsettojoltsorexcessive
vibration.
 WhentransportingtheMonitorset,keepthe
Monitorsetupright,neverturntheMonitor
setonitsside,ortilttowardstheleftorright.
Detaching the Stand Base and
Body
1 PlacetheMonitorsetwiththescreenside
downonaflatandcushionedsurface.
2 Turnthescrewtotheleft,andthenpulloutthe
Stand BasefromtheStand Body.
2 AttachtheStand Basefromthesetbyturning
thescrewtotherightwithaCoin.

7
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a table
1 LiftandtilttheMonitorsetintoitsupright
positiononatable.
Leavea10cm(minimum)spacefromthewall
forproperventilation.
3 Remove2screwsandpullouttheStand Body
fromtheMonitorset.
2 ConnectthePower Cordtoawalloutlet.
10 cm
10 cm
10 cm
10 cm
UsingtheKensingtonsecuritysystem
TheKensingtonsecuritysystemconnectoris
locatedatthebackoftheMonitorset.Formore
informationofinstallationandusing,refertothe
manualsuppliedwiththeKensingtonsecurity
systemorvisit http://www.kensington.com .
ConnecttheKensingtonsecuritysystemcable
betweentheMonitorsetandatable.
TheKensingtonsecuritysystemisoptional.
Youcanobtainadditionalaccessoriesfrom
mostelectronicsstores.
 It'saheadfixedmodel
andprohibitedfrom
adjustingtheangle.
 Ifyoutrytoadjustthe
angleforcibly,Itcanbe
damaged.
NOTE
WARNING

8
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a wall
Forproperventilation,allowaclearanceof10
cmoneachsideandfromthewall.Detailed
installation
instructionsareavailablefromyourdealer,seethe
optionalTiltWallMountingBracketInstallationand
SetupGuide.
IfyouintendtomounttheMonitorsettoawall,
attachWallmountinginterface(optionalparts)to
thebackoftheset.
WhenyouinstalltheMonitorsetusingthewall
mountinginterface(optionalparts),attachit
carefullysoitwillnotdrop.
PleaseuseVESAstandardasbelow.
 784.8mm(30.9inch)andunder
*WallMountPadThickness:2.6mm
*Screw:Φ4.0mmxPitch0.7mmx
Length10mm
 787.4mm(31.0inch)andabove
*PleaseuseVESAstandardwallmountpad
andscrews.
 Disconnectthepowercordfirst,andthen
moveorinstalltheMonitorset.Otherwise
electricshockmayoccur.
 IfyouinstalltheMonitorsetonaceilingor
slantedwall,itmayfallandresultinsevere
injury.UseanauthorizedLGwallmount
andcontactthelocaldealerorqualified
personnel.
 Donotovertightenthescrewsasthismay
causedamagetotheMonitorsetandvoid
yourwarranty.
 Usethescrewsandwallmountsthat
meettheVESAstandard.Anydamages
orinjuriesbymisuseorusinganimproper
accessoryarenotcoveredbythewarranty.
 UsethescrewsthatarelistedontheVESA
standardscrewspecifications.
 Thewallmountkitincludesaninstallation
manualandnecessaryparts.
 Thewallmountbracketisoptional.Youcan
obtainadditionalaccessoriesfromyourlocal
dealer.
 Thelengthofscrewsmaydifferdepending
onthewallmount.Besuretousetheproper
length.
 Formoreinformation,refertothe
instructionssuppliedwiththewallmount.
CAUTION
NOTE
Model M2241A M2341A
VESA (A x B) 75x75
Standard screw M4
Number of screws 4
Wall mount bracket
(optional)
RW120
10 cm
10 cm
10 cm
10 cm

9
ENGLISH
REMOTE CONTROL
REMOTE CONTROL
Thedescriptionsinthismanualarebasedonthebuttonsoftheremotecontrol.
PleasereadthismanualcarefullyandusetheMonitorsetcorrectly.
Toreplacebatteries,openthebatterycover,replacebatteries(1.5VAAA)matching
and endstothelabelinsidethecompartment,andclosethebatterycover.
Toremovethebatteries,performtheinstallationactionsinreverse.
MakesuretopointtheremotecontroltotheremotecontrolsensorontheMonitorset.
CAUTION
Donotmixoldandnewbatteries,asthismay
damagetheremotecontrol.
INPUT
POWER
TV/PC
MUTE PSM
LIST Q.VIEW
MENU EXIT
HOLD
ARC/MARK
USB VOL -USB VOL +
OK
PR
PR
VOL VOL
SSM I/II
1 2 3
4 5 6
7 8 9
0
SIZE MIX TIME
TEXT
REVEAL INDEX MODE UPDATE
(POWER)
TurnstheMonitorsetonor
off.
MUTE
Mutesallsounds.
TV/PC
SelectsTVorPCmode.
PSM
Recallsyourpreferredpicture
setting.
LIST(Seep.17)
Displaystheprogramme
table.
INPUT(Seep.19)
Selectstheinputmode.
Number buttons
Entersnumbers.
I/II (Seep.30)
Selectsthesoundoutput.
SSM
Recallsyourpreferredsound
setting.
Q.VIEW
Returnstothepreviously
viewedprogramme.
INPUT
POWER
TV/PC
MUTE PSM
LIST Q.VIEW
MENU EXIT
HOLD
ARC/MARK
USB VOL -USB VOL +
OK
PR
PR
VOL VOL
SSM I/II
1 2 3
4 5 6
7 8 9
0
SIZE MIX TIME
TEXT
REVEAL INDEX MODE UPDATE

10
ENGLISH
REMOTE CONTROL
INPUT
POWER
TV/PC
MUTE PSM
LIST Q.VIEW
MENU EXIT
HOLD
ARC/MARK
USB VOL -USB VOL +
OK
PR
PR
VOL VOL
SSM I/II
1 2 3
4 5 6
7 8 9
0
SIZE MIX TIME
TEXT
REVEAL INDEX MODE UPDATE
MENU(Seep.25)
Accessesthemainmenus
orsavesyourinputandexit
menus.
Coloured buttons
Thesebuttonsareusedfor
teletext(onTELETEXT
modelsonly),Programmeedit.
USB Menu control buttons
USBmenu(MusicList).
EXIT
Clearsallon-screendisplays
andreturnstoMonitorset
viewingfromanymenu.
INPUT
POWER
TV/PC
MUTE PSM
LIST Q.VIEW
MENU EXIT
HOLD
ARC/MARK
USB VOL -USB VOL +
OK
PR
PR
VOL VOL
SSM I/II
1 2 3
4 5 6
7 8 9
0
SIZE MIX TIME
TEXT
REVEAL INDEX MODE UPDATE
Programme
Selectsaprogramme.
 Ifyoulostremotecontroller,youhavetobuyitatoncebecauselocalkeysworkatPower,
Programme, Volume and Input only.
NOTE
VOL
Adjuststhevolumelevel.
Navigation buttons
Scrollsthroughmenusor
options.
OK
Selectsmenusoroptionsand
confirmsyourinput.
Teletext buttons(Seep.37)
Thesebuttonsareusedfor
teletext.Forfurtherdetails,
seethe‘Teletext’section.
USB VOL(Only USB Mode)
AdjuststheUSBvolume
level.
ARC(Seep.18)
Selectsyourdesiredpicture
format.
MARK
Checkandun-checkfilesin
theUSBmenu.

11
ENGLISH
USING THE MONITOR SET
USING THE MONITOR SET
Connecting to a PC
YourMonitorsetsupportsthePlug&Play*feature.
*Plug&Play:ThefunctionwhenaPCrecognizes
aconnecteddevicethatusersconnecttoaPC
andturnon,withoutdeviceconfigurationoruser
intervention.
 Ifyoudonotuseanoptionalexternal
speaker,connectthePCtotheMonitorset
withtheoptionalaudiocable.
 TheAudiocableisoptional.Youcanobtain
additionalaccessoriesfrommostelectronics
stores.
 IfyouturntheMonitorsetonwhentheset
becomescold,thescreenmayflicker.This
isnormal.
 Somered,green,orbluespotsmayappear
onthescreen.Thisisnormal.
NOTE
RGB connection
TransmitstheanalogvideosignalfromyourPCto
theMonitorset.ConnectthePCandtheMonitor
setwiththeD-sub15pincableasshownthe
followingillustrations.Totransmitanaudiosignal,
connectanoptionalaudiocableinMonitorset.
 Connectthesignalinputcable
andtightenitbyturningthe
screwsclockwise.
 Donotpressthescreenwith
yourfingerforalongtimeasthismay
resultintemporarydistortiononthescreen.
 Avoiddisplayingafixedimageonthe
screenforalongperiodoftimetoprevent
imageburn.Useascreensaverifpossible.
CAUTION

12
ENGLISH
USING THE MONITOR SET
Adjusting the screen
Selecting an image mode
Displayimagesinitsoptimizedsettingsby
selectingoneofthepresetimagemodes.
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3 PresstheNavigationbuttonstoscrollto
Picture ModeandpressOK.
4 PresstheNavigationbuttonstoscrolltoan
imagemodeyouwantandpressOK.
Customizing image options
Customizebasicandadvancedoptionsofeach
imagemodeforthebestscreenperformance.
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3 PresstheNavigationbuttonstoscrollto
Picture Mode.
4 PresstheNavigationbuttonstoscrolltoan
imagemodeyouwantandpressOK.
5 Selectandadjustfollowingoptions,andthen
pressOK.
Mode Description
Vivid Adjuststhevideoimageforthe
retailenvironmentbyenhancingthe
Contrast, Brightness, Colour,and
Sharpness.
Standard Adjuststheimageforthenormal
environment.
Cinema Optimizesthevideoimageforthe
cinematiclookandenjoymoviesasif
youareinamovietheater.
5 Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
MENU.
6 Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
MENU.
Option Description
Backlight Adjuststhebrightnessofthe
screenbycontrollingtheLCD
backlight.Ifyoudecreasethe
brightnesslevel,thescreen
becomesdarkerandthepower
consumptionwillbereduced
withoutanyvideosignalloss.
Contrast Increasesordecreasesthe
gradientofthevideosignal.
YoumayuseContrastwhen
thebrightpartoftheimageis
saturated.
Brightness Adjuststhebaselevelofthe
signalintheimage.Youmayuse
Brightnesswhenthedarkpartof
theimageissaturated.
Sharpness Adjuststhelevelofcrispnessin
theedgesbetweenthelightand
darkareasofthepicture.The
lowerthelevel,thesofterthe
image.
Colour AdjustsintensityofallColours.
Tint AdjuststhebalancebetweenRed
andGreenlevels.
Advanced
Control
Customizestheadvanced
options.Seemoreinformation
aboutadvancedoptionsSeep.28.
Reset
Restorestheoptionstothe
defaultsetting.

13
ENGLISH
USING THE MONITOR SET
5 Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
MENU.
Adjusting the sound
Selecting an sound mode
Playthesoundinitsoptimizedsettingsby
selectingoneofthepresetsoundmodes.
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
AUDIOandpressOK.
3 PresstheNavigationbuttonstoscrolltoSound
ModeandpressOK.
4 PresstheNavigationbuttonstoscrolltoa
soundmodeyouwantandpressOK.
Customizing PC display options
Customizeoptionsofeachimagemodeforthe
bestimagequality.
 Thisfunctionworksinthefollowingmode:
RGB[PC]mode.
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3 PresstheNavigationbuttonstoscrollto
Screen andpressOK.
4 Selectandadjustfollowingoptions,andthen
pressOK.
Customizing sound options
Customizeoptionsofeachsoundmodeforthe
bestsoundquality.
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
AUDIOandpressOK.
3 PresstheNavigationbuttonstoscrolltoSound
ModeandpressOK.
4 PresstheNavigationbuttonstoscrolltoa
soundmodeyouwantandpressOK.
5 Selectandadjustfollowingoptions,andthen
pressOK.
5 Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
MENU.
6 Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
MENU.
Option Description
Resolution SelectsaproperResolution.
Auto
Config.
SetstoadjustthescreenPosition,
SizeandPhaseautomatically.The
displayedimagemaybeunstablefor
afewsecondswhiletheconfiguration
isinprogress.
Position/
Size/Phase
Adjuststheoptionswhenthe
imageisnotclear,especiallywhen
charactersareshaky,aftertheauto
configuration.
Reset Restorestheoptionstothedefault
setting.
Mode Description
Standard Selectswhenyouwantstandard-
qualitysound.
Music Selectswhenyoulistentomusic.
Cinema Selectswhenyouwatchmovies.
Option Description
Treble Controlsthedominantsoundsinthe
output.Whenyouturnupthetreble,
itwillincreasetheoutputtothe
higherfrequencyrange.
Bass Controlsthesoftersoundsinthe
output.Whenyouturnupthebass,
itwillincreasetheoutputtothe
lowerfrequencyrange.
Reset Resetsthesoundmodetothe
defaultsetting.

14
ENGLISH
WATCHING TV
WATCHING TV
Connecting an antenna or
cable
Connectanantenna,cable,orcableboxtowatch
TVreferringtothefollowing.Theillustrationsmay
differfromtheactualaccessoriesandanRFcable
isoptional.
Connecting an antenna or basic
cable
ConnecttheMonitorsettoawallantennasocket
withanRFcable(75ohm).
Connecting with a cable box
ConnecttheMonitorsettoacableboxandthe
cableboxtoawallantennasocketwith2RF
cables(75ohm).
 Useasignalsplittertousemorethan2TVs.
 Iftheimagequalityispoor,installasignal
amplifierproperlytoimprovetheimage
quality.
 Iftheimagequalityispoorwithanantenna
connected,aimtheantennatotheproper
direction.
 Visit
http://AntennaWeb.org formore
informationabouttheantennaandcable
connection.
NOTE
 Makesurenottobendthecopperwireof
theRFcable.
 Completeallconnectionsinstructions
betweendevices,andthenconnectthe
powercordtothepoweroutlettoprevent
damagestoyourMonitorset.
CAUTION
Copper wire

15
ENGLISH
WATCHING TV
Accessing the TV for the
first time
WhenyouaccesstheMonitorsetforthefirst
time,theinitialsettingscreenappears.Selecta
languageandcustomizethebasicsettings.
1 Connectthepowercordtoapoweroutlet.
2 Press ontheMonitorsettoturnthe
Monitorseton.
ThePowerindicatorlightingisturnedon.
 YoucanalsoswitchtheMonitorsetfrom
PCmodetoTVmode,pressTV/PC.
 YoucanalsoaccessInitial Settingby
accessingOPTION inthemainmenus.
 IfyoudonotoperatetheMonitorset
within40secondswhenthesettingmenu
screenappears,thesettingmenuswill
disappear.
NOTE
NOTE
NOTE
NOTE
WhentheMonitorsetisinPowersaving
mode,thePowerindicatorlightingblinks.
 Todisplayimagesinthebestqualityfor
yourhomeenvironment,selectHome
Use mode.
 Store Demomodeissuitableforthe
retailenvironment.
 IfyouselectStore Demo mode,the
previouslycustomizedsettingswillswitch
tothedefaultsettingsofStore Demoin5
minutes.
Ifyoudonotcompletetheinitialsetting,it
willappearwheneveryouaccesstheTV.
3 Theinitialsettingscreenappearsifyouaccess
theTVforthefirsttime.
4 Followtheon-screeninstructionstocustomize
yourMonitorsetaccordingtoyourpreferences.
Language

ModeSetting

AutoTuning
SelectsHome Usefor
thehomeenvironment.
Selectsalanguagefor
thedisplay.
Scansandsaves
availableprogrammes
automatically.
5 Whenthebasicsettingsarecomplete,press
OK.
6 ToturntheMonitorsetoff,press onthe
Monitorset.
ThePowerIndicatorturnsoff.
Disconnectthepowercordfromthepower
outletwhenyoudonotusetheMonitorset
foralongperiodoftime.
CAUTION

16
ENGLISH
WATCHING TV
Watching TV
1 Press ontheRemotecontrolor onthe
MonitorsettoturntheMonitorseton.
2 PressINPUTandselectAntenna.
3 ControltheMonitorsetusingthefollowing
buttonsandmenuswhileyouarewatchingTV.
Managing programmes
Automatically setting up
programmes
Usethistoautomaticallyfindandstoreallavailable
programmes.
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3 PresstheNavigationbuttonstoscrollto
Auto TuningandpressOK.
4 SelectYestostartautomatictuning.
TheTVscansandsavesavailableprogrammes
automatically.
5 Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
MENU.
Button / Menu Description
PR(
,
) Scrollsthroughthesaved
programmes
0 - 9 Selectsaprogrammebyentering
numbers
VOL (
,
)Adjuststhevolumelevel
MUTE Mutesallsounds
PSM Selectsoneofthepresetimage
modes(Seep.27)
SSM Selectsoneofthepresetaudio
modes.(Seep.29)
ARC Resizesanimage(Seep.18)
4 ToturntheMonitorsetoff,Press onthe
Remotecontrolor ontheMonitorset.
Manually setting up programmes
ManualTuningletsyoumanuallytuneandarrange
thestationsinwhateverorderyoudesire.
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3 PresstheNavigationbuttonstoscrollto
Manual TuningandpressOK.
4 PresstheNavigationbuttonstoscrollto
TV System.
5 PresstheNavigationbuttonstoscrollto
V/UHF or Cable.
6 PresstheNavigationbuttonsorNumber
buttonstoscrollSelectthedesiredchannel
number.
6 PresstheNavigationbuttonstoscrollto
Commencesearching.
7 PresstheNavigationbuttonstoscrollto
StoreandpressOK
8 Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
MENU.
Editing your programme list
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3 PresstheNavigationbuttonstoscrollto
Programme EditandpressOK.
4 Editprogrammesusingthefollowingbuttons.
Button Description
Navigation Scrollsthroughprogrammetypes
orprogrammes
OK Selectsaprogrammetoview
Colour
Button
Addsordeletesaprogramme.
Thedeletedprogrammedisplays
ingray.

17
ENGLISH
WATCHING TV
DisplayingprogrammeLIST
Selecting the programme list
Youcancheckwhichprogrammesarestoredin
thememorybydisplayingtheprogrammelist.
1 PressLIST buttontoaccesstheProgramme
List.
2 Whenyouarefinished,pressMENU or EXIT.
NOTE
 Youmayfindsomeblueprogrammes.
Thesehavebeensetuptobeskippedby
autoprogrammingorintheprogramme
editmode.
 Someprogrammeswiththechannel
numbershownintheprogramme
LISTindicatethereisnostationname
assigned.
Selectingaprogrammeintheprogrammelist
1 PresstheNavigationbuttonstoprogramme.
2 Switchtothechosenprogrammenumber,
pressOK.
Favouriteprogrammeisaconvenientfeaturethat
letsyouquiklyscanuptoprogrammesofyour
choicewithouthavingtowaitfortheTVtoscan
throughallthein-betweenprogrammes.
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3 PresstheNavigationbuttonstoscrollto
Programme EditandpressOK.
4 PresstheNavigationbuttonstoscrollto
ProgrammeyouwantandpressGREEN
button.
5 Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
MENU.
Favourite programme setup
NOTE
 Thiswillautomaticallyincludethe
selectedprogrammeintoyourfavourite
programmelist.
Selectingfavouriteprogramme
Displayingthefavouriteprogrammelist
1 PressGreen buttontoaccesstheFavourite
ProgrammeList.
2 Whenyouarefinished,pressMENU or EXIT.

18
ENGLISH
WATCHING TV
-16:9:Thefollowingselectionwillallowyou
toadjustthepicturehorizontally,inlinear
proportion,tofilltheentirescreen(usefulfor
viewing4:3formattedDVDs).
-Just Scan:FollowingSelectionwillleadtoyou
viewthepictureofbestqualitywithoutlossof
originalpictureinhighresolutionimage.
Note:IfthereisnoiseinoriginalPicture,You
canseethenoiseattheedge.
-Original:WhenyourMonitorsetreceivesawide
screensignalitwillautomaticallychangetothe
pictureformatbroadcast.
-4:3:Thefollowingselectionwillallowyoutoview
apicturewithanoriginal4:3aspectratio,gray
barswillappearonboththeleftandrightofthe
screen.
-14:9:Youcanviewapictureformatof14:9or
ageneralMonitorsetprogrammeinthe14:9
mode.The14:9screenisviewedinthesame
wayasin4:3,butismagnifiedtotheleftand
right.
-Zoom 1 & 2:Thefollowingselectionwillallow
youtoviewthepicturewithoutanyalteration,
whilefillingtheentirescreen.However,thetop
andbottomofthepicturewillbecropped.
Just Scan
Original
Using additional options
Adjusting aspect ratio
Resizetheimagetoviewtheimageatitsoptimal
sizebypressingARCwhileyouarewatching
Monitorset.
 Ifafixedimagedisplaysonthescreenfora
longperiodoftime,itwillbeimprintedand
becomeapermanentdisfigurementonthe
screen.Thisis“imageburn”or“burn-in”and
notcoveredbythewarranty.
 Iftheaspectratioissetto4:3foralong
periodoftime,imageburnmayoccuron
theletterboxedareaofthescreen.
CAUTION
 Youcanonlyselect4:3, 16:9 (Wide) inRGB
mode.
 InHDMI(over720p)mode,Just Scanis
available.
NOTE

19
ENGLISH
WATCHING TV
Using the input list
Selectinganinputsource
1 PressINPUTtoaccesstheinputsourcelist.
2 PresstheNavigationbuttonstoscrolltooneof
theinputsourcesandpressOK.
Input source Description
Antenna or
cable
WatchTVovertheairandcable
AV WatchthecontentsinaVCRor
otherexternaldevices
RGB ViewaPCdisplayonthescreen
HDMI WatchcontentsinaDVDorDigital
settopboxorotherhighdefinition
devices
On-screen menu language
Theinstallationguidemenuappearsonthe
Monitorsetscreenwhenitisswitchedonforthe
firsttime.
1 PresstheNavigationbuttonstoscrollto
Desired Language andpressOK.
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
OPTION andpressOK.
3 PresstheNavigationbuttonstoscrollto
Language andpressOK.
4 PresstheNavigationbuttonstoscrollto
Desired Language optionyouwantandpress
OK.
5 Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
MENU.
IfyouwanttochangeLanguage
 Ifyoudonotfinishtheset-upInstallation
GuidebypressingEXITorifyoutimeouton
theOSD(OnScreenDisplay)theinstallation
menuwillcontinuouslyappearuntiltheset
upiscompletedwhenevertheMonitorsetis
switchedon.
NOTE
Locking the buttons on the
Monitor set
LockthebuttonsontheMonitorsettopreventany
unwantedoperationsoraccidentsbychildren.
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrollto
OPTION andpressOK.
3 PresstheNavigationbuttonstoscrollto
Key LockandpressOK.
4 PresstheNavigationbuttons
toscrolltoOn
andpressOKtoactivatetheKeylockfeature.
-TodeactivatetheKeylockfeature,selectOff.
5 Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
MENU.
 TheMonitorsetisprogrammedtoremember
thelastsettingafteryouturntheMonitorset
off.
 Ifyouturnthemonitorsetoffwhilethekey
lockfeatureisactivatedandwishtoturnit
backon,pressthe onthemonitorset.
Youcanalsoswitchthedeviceonusingthe
remotecontrolbypressingthe , INPUT
,PR orNumberbuttons.
 IfyoupressanybuttonontheMonitorset
withtheKeylockfeatureactivated, Key
Lock ONappearsonthescreen.
NOTE

20
ENGLISH
ENTERTAINMENT
H
D
MI
IN
AV
IN
VIDE
O
A
NTENNA
/
C
ABEL I
N
MO
N
O
L
USB IN
RGB IN (PC
)
A
U
DI
O
R
ENTERTAINMENT
Using integrated media
features
Connecting USB storage devices
ConnectUSBstoragedevicessuchasaUSB
flashmemory,externalharddrive,orMP3player
totheMonitorsetandusemultimediafeatures
(“Browsing files”Seep.21).
ConnectaUSBflashmemoryorUSBmemory
cardreadertotheMonitorsetasshownonthe
followingillustration.TheUSBscreenappears.
or
 BackupyourfilessavedonaUSBstorage
devicefrequently,asyoumayloseor
damagethefilesandthismaybenot
coveredbythewarranty.
CAUTION
TipsforusingUSBstoragedevices
 OnlyaUSBstoragedeviceisrecognizable.
 IftheUSBstoragedeviceisconnected
throughaUSBhub,thedeviceisnot
recognizable.
 AUSBstoragedeviceusinganautomatic
recognitionprogrammemaynotbe
recognized.
 AUSBstoragedevicewhichusesitsown
drivermaynotberecognized.
 TherecognitionspeedofaUSBstorage
devicemaydependoneachdevice.
 PleasedonotturnofftheMonitorsetor
unplugtheUSBdevicewhentheconnected
USBstoragedeviceisworking.Whensuch
deviceissuddenlyseparatedorunplugged,
thestoredfilesortheUSBstoragedevice
maybedamaged.
 PleasedonotconnecttheUSBstorage
devicewhichwasartificiallymaneuveredon
thePC.Thedevicemaycausetheproductto
malfunctionorfailtobeplayed.Neverforget
touseonlyaUSBstoragedevicewhichhas
normalmusicfiles,imagefiles.
 PleaseuseonlyaUSBstoragedevicewhich
wasformattedasaFAT,FAT16,FAT32file
systemprovidedwiththewindowsoperating
system.Incaseofastoragedevice
formattedasadifferentutilityprogramme
whichisnotsupportedbyWindows,itmay
notberecognized.
 PleaseconnectpowertoaUSBstorage
device(over0.5A)whichrequiresanexternal
powersupply.Ifnot,thedevicemaynotbe
recognized.
 PleaseconnectaUSBstoragedevicewith
thecableofferedbythedevicemaker.
 SomeUSBstoragedevicesmaynotbe
supportedoroperatedsmoothly.
 FilealignmentmethodofUSBstoragedevice
issimilartoWindowXPandfilenamecan
recognizeupto100Englishcharacters.
 Besuretobackupimportantfilessincedata
storedinaUSBmemorydevicemaybe
damaged.Wewillnotberesponsibleforany
dataloss.
 IftheUSBHDDdoesnothaveanexternal
powersource,theUSBdevicemaynotbe
