LG M3202C-BA User manual

w w w. LG c o m m e r c i a l . c o m
NA IVE DISPLAY RESOLU ION
1366 x 768 (WXGA)
CONVENIEN EX ERNAL SPEAKER-OU
NEW! INFORMA ION DISPLAY FOR SERIAL NUMBER
VIEWING ANGLE and LIFE EXPEC ANCY
Enhanced in Portrait Mode (M3202C-BA)
SPLI ZOOM (self video wall)
New! Up to 5 x 5 matrix - adjusts for bezel width
LG's EXCLUSIVE XD ENGINE™
HIGH BRIGH NESS
500 cd/m2
CON RAS RA IO
3000:1 (DCR)
HDMI™/DVI WI H HDCP
178° VIEWING ANGLE (S-IPS)
Super IPS Technology allows for
clearer viewing from almost any angle
EMPERA URE SENSOR
RS-232C CON ROL
NEW! OP IONAL HIDDEN SPEAKERS
3-YEAR LIMI ED WARRAN Y
parts/labor
NOTE: IP-Cast®ready with integrated card slot using LG's IP card solution
for Digital Signage applications (sold separately). Contact
[e-mail] for more information. If using
DIRECTV's®Free-To-Guest, an additional card may be required.
HD Capable Monitor*LCD Widescreen
lcd
monitor
37" class (37.0" diagonal) M3702C-BA
32" class (31.5" diagonal) M3202C-BA

www.LGcommercial.com
LG Electronics U.S.A., Inc.
Commercial Products Division
2000 Millbrook Drive,
Lincolnshire, IL 60069
Customer Service: 888.865.3026
Contact your LG regional sales representative:
B2B: 800.897.8788
Channel Markets: 800.897.8871
I : 800.321.5501
Hospitality: 800.228.1236
M37_3202C-BA_LGE050801_PR
All screen images are simulated. Dimensions and weights are approximate. Design,
specifications, and features subject to change without notice. *DTV monitors require
an optional set-top-box to receive high-definition broadcast.
© Copyright 2008 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a
registered trademark of LG Corp.
XD Engine is a trademark of LG Electronics USA, Inc. VESA is a registered trademark
of Video Electronics Standards Association.
All other product and brand names are trademarks or registered trademarks of their
respective companies.
Printed in the USA. July 2008
Audio Output 1
Audio Inputs 3 Plus PC Sound
DTV Formats Component : 720p/1080i
DMI :720p/1080i/1080p
PC Formats Auto Scaling to XGA
DMI/DVI with DCP Yes
RS-232C Input/Output 1 / 1
S-Video 1 (S-Video has a priority but there is no input mode)
Audio Jack Built-in (No Amp) Yes
Discrete IR Input Yes
External Speaker Out Yes
AUDIO
Auto Volume Yes
Balance Yes
Audio Power 20W (10W x 2)
Speaker On/off Yes
Sound mode Clear Voice / Standard / Music /Cinema/
Sports/ Game / User
SPECIAL FEA URES
New Temperature Sensor Yes
New Split Zoom Yes (Adjusts for bezel width)
(Self Video Wall, 5 x 5 Max)
Source Selection Digital (DMI/DVI) / Analog (RGB) / Component1/
Component2 / AV
Brightness/Contrast Yes
Color Warm / Medium / Cool /, User Control (R/G/B)
Position / V
Tracking Auto / Clock / Phase
Set-up
Language (English/French/Spanish/Italian/German/
Portuguese/Korean/Japanese/
Chinese/Russian)
ISM Method Normal/White wash/Orbiter/Inversion/Dot wash
Advanced Gamma / Film mode /Black level / Noise Reduction
Time Clock / On/off timer / Auto sleep / Power on Delay
Information Display Serial Number, SET ID, S/W Version
Mute Yes
Sleep Timer Yes
Auto Power/Source Memory Yes
Key Lock Yes
DPM Select Yes
CABINE
Color Black
Monitor Dimension (W x x D) 36.54" x 22.49" x 4.43" (37”)
31.61" x 19.41" x 3.93" (32”)
Weight 47.5 lbs (37”)
35.27 lbs (32”)
Monitor with Optional Stand 36.54" x 24.45" x 8.96" (37”)
Dimensions (W x x D) 31.61" x 21.26" x 7.58" (32”)
Weight with Optional Stand 54.36 lbs (37”)
36.73 lbs (32")
Carton Dimensions (W x x D) 40.4" x 10.0" x 26.9" (37”)
35.2" x 7.4" x 23.3" (32”)
Packed Weight 56.44 Ibs (37”)
39.24 Ibs (32”)
VESA
TM
Standard Mount Interface 600mm x 400mm (37”)
200mm x 200mm (32”)
POWER
Power Supply 100 -240V~, 50/60 z
Power Type Built-in Power
Power Switch Type Tact Switch
Power Saving
Normal 180 W (37”) , 145 W (32”)
Stand-by/Suspend 1W(RGB) / 4W( DMI/DVI)
DPM Off 1W(RGB) / 4W( DMI/DVI)
Switch Off 1W
S ANDARD (CER IFICA IONS)
Safety UL / c-UL / CB scheme / TUV / NEMKO
EMC FCC Class "B" / VCCI / C-tick / GOST / CE / MIC
OP IONAL ACCESSORIES
Speakers (SP0000K) Black (fits both 32” and 37”)
Speaker Dimensions (W x x D) 1.61” x 12.92” x 2.17”
Weight (each) 0.815 lbs
Stand
(ST3700K) Black/Silver
Stand (ST3200K) Black/Silver
Stand Dimensions
(W x x D) 26.4" x 5.0" x 8.96" (37”)
22.89" x 4.00" x 7.58" (32”)
Weight 6.86 lbs (37”)
5.02 lbs (32”)
LIMI ED WARRAN Y 3 years (parts/labor)
UPC CODE
7 19192 18479 4 M3702C-BA
7 19192 18478 7 M3202C-BA
specifications
www.LGcommercial.com
36.54”
32.39”
3.94”
24.45”
22.49”
26.40”
Rear Jack Pack Panel
lcd
monitor
M3702C-BA
M3202C-BA
37" class (37.0" diagonal)
32" class (31.5" diagonal)
8.74”
4.43”
2.89”
2.61
200mm”
200mm”
31.61”
27.56”
3.15”
21.26”
19.41”
22.63”
15.54”
300mm”
400mm”
”
7.58”
3.94”
2.46”
1.96”
M3702C-BA
M3202C-BA
LR
REMOTE
CONTROL IN
RS-232C
(CONTROL)
OUT
IN
HDMI/DVI AUDIO
(RGB/DVI)
AUDIO VIDEO IN
(BNC)
S-VIDEO
SPK_OUT
Y Pb Pr
1
2
R L
VIDEO (BNC)
RGB IN
RGB OUT
COMPONENT IN (BNC)
IN
OUT
Y Pb Pr
AUDIO IN/OUT
L R
L R
L R
AUDIO
AC-IN
PANEL
LCD Panel Type 37” Widescreen TFT (Thin Film Transistor) -
LCD (Liquid Crystal Display) Panel (M3702C-BA)
32” Widescreen TFT (Thin Film Transistor) - LCD
(Liquid Crystal Display) Panel (M3202C-BA)
Display Area 37.0” diagonal (M3702C-BA)
31.5” diagonal (M3202C-BA)
Aspect Ratio 16:9
Native Resolution 1366 x 768
Pixels( x V x 3) 3,147,264
Brightness 500cd/m
2
Contrast Ratio 3,000:1 (DCR)
Viewing Angle 178°/ 178°
Color Depth 16.7 Million
Response Time 5ms (G to G) (37”) , 9ms (G to G) (32”)
Surface Treatment ard Coating(3 ), Anti-glare
MTBF 50,000 r.
(Minimum) , Portrait & Landscape (32”)
Landscape only (37")
VIDEO
Max Input Resolution 1600 X 1200@ 60 z(Analog)
1920 X 1080@ 60 z(Digital)
Recommended Resolution 1360 X 768 @ 60 z(Analog / Digital)
-Scanning Frequency 30 ~83k z (Analog / Digital)
V-Scanning Frequency 56~75 z(Analog), 60 z(Digital)
Pixel Frequency 162 M z( D-Sub), 148.5 M z ( DMI/DVI)
Sync Compatability Separate / Composite
Video Input RGB Analog / Digital
Picture mode Vivid / Standard / Cinema / Sports /Game /
User1 / User2
Color temperature Warm / Medium / Cool / User
REAR INPU S
Component Video 2 i-Res (BNC)
PC Input via 15-Pin Sub "D" 1 / 1
Composite Video Input/Output 1 (BNC) / 1 (BNC)
