LG LB632120S User manual

ENGLISH
OPERATING INSTRUCTIONS
B ILT IN OVEN
Please read this instruction manual carefully before using the oven.
This will ensure that you know the important safety information and the
correct operation of the oven.
Please keep this manual in a easily accessible place and refer to it anytime.
Please transfer this manual to new owner if you sell the oven.
LB632120S
LB632100S
P/No.: MFL35999107 www.lg.com
ENGLISH GREEK

Contents
Safety ..................................................................................... 4~14
Appliance description .............................................................. 15
Control panel ...................................................................... 16~19
For model : LB632120S ................................................. 16~17
For model : LB632100S ................................................. 18~19
Accessories ........................................................................ 20~21
Side runners .............................................................................. 22
Setting the clock ....................................................................... 23
Setting the time of day (For model:LB632120S) ...................... 23
Before using for the first time ................................................. 24
Using the oven .......................................................................... 25
Oven functions ................................................................... 26~27
Operation ............................................................................. 28~38
Switching the oven on .............................................................. 28
Switching the oven off .............................................................. 29
Indicator (For model:LB632100S) ............................................ 30
Clock functions and symbols (For model:LB632120S) ............ 31
Setting the timers (For model:LB632120S) .............................. 32
Programming the overall cooking / baking time
(For model:LB632120S) ........................................................... 33
Programming the end of cooking / baking time
(For model:LB632120S) ........................................................... 34
Combining overall cooking / baking time and end
of cooking / baking time (For model:LB632120S) .............. 35~36
Setting the time of day (For model:LB632120S) ...................... 37
Childproof safety device (For model:LB632120S) ................... 38
Baking .................................................................................. 39~40
Baking Tables ...................................................................... 41~44
Roasting .............................................................................. 45~46
Roasting tables ......................................................................... 47
2

Grilling ................................................................................. 48~49
Defrosting .................................................................................. 50
Cleaning and care ............................................................... 51~52
Oven light .................................................................................. 53
Oven door ............................................................................ 54~58
Troubleshooting ................................................................. 59~60
Technical specifications .................................................... 61~62
Installation instructions ........................................................... 63
Customer service & spare parts .............................................. 64
Warranty .................................................................................... 65
3
ENGLISH

Important safety instructions
Read and follow all instructions before using your oven to prevent
the risk of fire, electric shock, personal injury, or damage when
using the appliance. This guide does not cover all possible conditions
that may occur. Always contact your service agent or manufacturer
about problems that you do not understand.
• This oven must only be installed by a licensed electrician.
• The installer is responsible for the correct electrical connection of
the appliances and the observance of the relative safety
recommendations.
• Rating plate is located on the left side of the door and on the back
cover.
This is the safety alert symbol.This symbol alerts you to
potential hazards that can kill or hurt you and others. All
safety messages will follow the safety alert symbol and either
the word “WARNING” or “CAUTION”. These word means :
This symbol will alert you to hazards or unsafe
practices which could cause serious bodily
harm or death.
WARNING
This symbol will alert you to hazards or unsafe
practices which could cause bodily injury or
property damage.
CAUTION
4

Electrical Safety
•This appliance must be connected to the mains power supply by a
specially licensed electrician only.
•Electrical leads and cables should not be allowed to touch the
oven.
• The oven should be connected to the electricity supply by
means of a proper circuit breaker or fuse. Never use
multiple plug adapters or extension leads.
• This connection may be achieved by having the plug
accessible or by incorporation a switch in the fixed wiring in
accordance with the wiring rules.
- Failure to do so can result in a fire.
WARNING
5
ENGLISH

Safety
Damage
•If the oven has been damaged in transport, do not connect
it.
•In the event of a fault or damage to the appliance, do not
attempt to operate it.
•Repairs of the appliance should be carried out by a
licensed technician only. Wrong repairs may result in
considerable danger. If you need repairs, contact an LG
Service Center or your dealer.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•Never remove the outer casing from the oven. If the oven
is faulty and needs servicing or you are in doubt about its
condition, unplug it from the wall socket and contact the
nearest after-sales service centre
- Failure to do so can result in malfunctioning and death or
electrical shock when using.
WARNING
6

Maintenance
•The power supply of the appliance should be turned off
when it is being repaired or cleaned.
•Be careful in connecting electrical appliances to sockets
near to this appliance.
•Do not use high-pressure water cleaners or steam jet
cleaners for electrical safety reasons.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the
glass.
•The appliance should be powered down before replacing
the lamp to avoid the possibility of electric shock.
- Failure to do so can result in malfunctioning and death or
electrical shock when using.
WARNING
7
ENGLISH

Safety
Safety during Operation
•Do not touch interior parts until it has cooled down
sufficiently.
- When the oven operates, the interior parts will be very hot
and burns may occur.
WARNING
•Accessible parts may become hot during use. Young
children should be kept away.
•Accessible parts may become hot when the grill is in use,
children should be kept away.
•The appliance is not intended for use by young children or
infirm persons without supervision.
•Young children should be supervised to ensure that they do
not play with the appliance.
•Children should be kept at a safe distance when the oven
operates.
•Children should be kept at a safe distance until the oven
•This appliance is not intended for use by persons
has cooled down after cooking.
(including children)with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
WARNING
8

•Never block the air vents
- The oven may overheat and automatically switch itself off. It
will remain inoperable until it has cooled sufficiently.
•Do not cover the ventilation with cloths or paper.
- The cloths or paper may catch fire as hot air is evacuated
from the oven.
•Do not spill water in the vents.
WARNING
9
ENGLISH

Safety
Safety during Operation
•When in use, the oven interior surfaces become very hot!
Care should be taken to avoid touching heating elements
inside the oven.
- These walls may be hot enough to burn skin even after
cooking is finished, though they do not appear to be so, keep
away from hot spot.
•The oven surfaces will become hot when the appliance is
operated at a high temperature for a long period of time.
•The oven door must be closed when cooking is
performing.
•When cooking, take care when opening the oven door as hot
air and steam will escape rapidly.
- The hot air or steam released may cause scalding.
•When cooking dishes that contain alcohol, the alcohol can
evaporate due to the high temperatures. The vapor can
catch fire if it comes into contact with a hot oven part.
•Never store flammable or easily deformable materials in
the oven. To reduce the risk of fire in the oven cavity.
•Should an oven fire occur, leave the oven door closed and
turn the oven off. If the fire continues, throw baking soda
on the fire or use a fire extinguisher. Do not put water or
flour on the fire.
- Flour may be explosive and water can cause a grease fire to
spread and cause personal injury.
•Use oven gloves when removing a dish from the oven.
- The trays and racks are hot.
WARNING
10

•The oven must be secured by properly installed anti-tip
devices. To check if the bracket is installed properly
- To reduce the risk of tipping of the oven.
•Do not store this equipment outdoors. Do not use this product
near water (for example, near a kitchen sink, in a wet
basement, or near a swimming pool, and the like)
•Be sure all packing materials are removed from the appliance
before operating it.
•Do not use this oven for commercial purposes.
- This oven has been designed only for the cooking of household
foods.
•Do not use the oven door as a rest table for hot items or
cookware.
•Never use your appliance for warming or heating the room.
•Do not step, lean, or sit on the door of the oven.
- These can cause the oven to tip resulting in burns or serious injuries.
WARNING
•Do not touch an electric cord with a wet hand.
- It is very dangerous. You can get an electric shock.
•Be careful not to damage the power cable.
•Do not operate this appliance if it has a damaged power
cable or plug.
•Do not immerse power cable or plug in water and keep
power cable away from heated surfaces.
•Do not let cord hang over edge of table or counter.
WARNING
11
ENGLISH

Safety
Safety during Operation
•Don’t spread aluminium foil on the bottom of the oven and
do not place any baking trays or tins on it.
- The aluminium foil blocks the heat, which may result in
damage to the enamel surfaces and cause poor cooking
results and this will result in poor baking by disturbing heat
circulation.
WARNING
•Please ensure cooking times are correctly set
- Over cooking may result in the food catching fire and
subsequent damage to your oven.
WARNING
•Don’t pour water into the oven bottom when it is hot.
- This could cause damage to the enamel surfaces.
•When cooking very moist cakes, use the deep pan.
- Dripping fruit juices from the baking tray will leave stains,
which become indelible.
•Frozen foods such as pizzas should be cooked on the wire
grill.
- If the Baking tray is used, it may become deformed due to the
great difference in temperature.
•Do not heat unopened food containers.
- Build-up of pressure may cause container to burst and result
in injury.
WARNING
12

Disposal
•The packaging material can be completely recycled. You can
obtain addresses for environmentally-friendly disposal operations
from your local authority.
•If you wish to store your oven away temporarily, choose a dry,
dust-free place. Dust and damp may adversely affect the working
parts in the oven.
•Your new oven has been correctly packaged for
transportation. Remove all of the packaging material before
putting the appliance into use.
CAUTION
13
ENGLISH

Safety
Used appliances
For the protection of the environment, used appliances must
be Disposed of property.
•The appliance must not be disposed of along with normal
domestic waste.
•Your local authority will inform you of times for uplifting special
waste or identify public disposal facilities for you.
Used appliances must be rendered unusable prior to
disposal so that they no longer present a risk. To achieve
this, disconnect from the mains supply and remove the
power supply cable.
WARNING
14

Overview
Oven levels are numbered from the bottom up.
The 5 and 6 levels are mainly used for grill functions.
The cooking tables throughout this operating instructions give you
suggested oven level, however you can change these to suit
yourself.
Note : Rating plate can be located at left-hand inner edge of the
door or front-side of the oven.
Appliance description
Control panel
Door
handle
Top-heating
and grill heating
element Oven light
Air outlet
Door seal
Rear wall heating
element
Oven cavity
Full glass door
Side runners
Rating plate
Level 6
Level 5
Level 4
Level 3
Level 2
Level 1
15
ENGLISH

Control panel
For model : LB632120S
1. Timer button
2. Clock button
3. Operating mode knob
4. Time display
16

5. Less button
6. More button
7. Temperature knob
17
ENGLISH

Control panel
For model : LB632100S
1. Function indicator
2. Operating mode knob
18

3. Heating Indicator
4. Temperature knob
19
ENGLISH

Accessories
Wire grill
For dishes,baking tins, grilling and
roasting tins.
For grilling meat, place the wire grill on
the upper level of deep pan.
Deep pan
For moist cakes, for roasting and for
catching roasting juices or fat.
20
