BOTTOM FREEZER
REFRIGERATOR
Please read this guide thoroughly
before operating and keep it handy for
reference at all times.
P/No. 3828JL8075G
Models / Modèles / Modelos
CONGÉLATEUR
INFÉRIEUR
RÉFRIGÉRATEUR
Veuillez lire ce manuel en entier avant de mettre
en marche l’unité et conservez-le à portée de la
main pour le consulter à tout moment.
LFC22760**, LFD22860**
Owner’s Manual
Manuel d’utilisateur
2
TABLE OF CONTENTS
English Version 2
French Version 36
Warranty (Canada) 3 - 4
Safety Instructions 5 - 6
Grounding Requirements 6
Parts and Features 7
Refrigerator Installation 8 - 16
Unpacking your refrigerator 8
Installation 8
Base Grille 8
Removing, Reversing and Replacing
Your refrigerator doors
9 - 15
Pull out drawer 15
Leveling and door alignment 16
Using your refrigerator 17 - 25
Ensuring proper air circulation 17
Multi Flow
Door alarm
17
17
Setting the controls 18
Adjusting control settings 18
Food storage guide 19
Storing frozen food 19
Refrigerator Section 20
Refrigerator shelves 20
Chef Fresh 21
Crisper humidity control 21
Optibin Crisper 21
Crisper cover with lattice on inner surface 22
Design-A-Door 22
Dairy Bin 22
Egg Box 22
Water Dispenser 24
Freezer Section 23
Ice Bin 23
Wire Durabase 23
Tilting Door 23
Filter 24 - 25
Care and Cleaning 26 - 27
General cleaning tips 26
Outside 26
Inside walls 26
Door liner and gaskets 26
Plastic parts 26
Condenser coils 26
Light bulb replacement 26 - 27
Power interruptions 27
When you go on vacation 27
About the Custom Cube Ice Maker 28
Connecting the Water Line 29 - 31
Troubleshooting Guide 32 - 35
15
3
LG Electronics will repair or at its option replace, without charge, your product which proves to be defective in
material or workmanship under normal use, during the warranty period listed below from the date of original
purchase. This warranty is good only to the original purchaser of the product during the warranty period as
long as it is in any Canadian Province.
WARRANTYPERIOD
MODEL# : LABOR: 1 Years PARTS :1 Years
SERIAL NUMBER :
SEALED SYSTEM :
HOW SERVICE IS HANDLED: Call 1-888-542-2623(1-888-LG-CANADA) and choose the appropriate
prompt. Please have product type (refrigerator) and PostalCode ready.
See our website at http://www.lg.ca
This warranty provides in-home service.
No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES,
INCLUDING THE IMPLIED WARRANTYOF MERCHANTABILITY, IS LIMITED TO THE
DURATION OF THE EXPRESS WARRANTYHEREIN. LG ELECTRONICS CANADA, INC. SHALLNOT
BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVIENCE, LOSS OR ANY
OTHER DAMAGES, DIRECTOR CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR
INABILITYTO USE, THIS PRODUCTOR FOR ANY BREACH OFANY EXPRESS OR IMPLIED
WARRANTY, INCLUDING THE IMPLIED WARRANTYOF MERCHANTABILITYAPPLICABLE TO
THIS PRODUCT.
Some provinces do not allow the exclusion or limitation of incidental or consequential damages or limitations on
how long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives
you specific legal rights and you may also have other rights which vary from province to province.
THE ABOVE WARRANTYDOES NOTAPPLY TO:
1. Service trips to your home to deliver and pickup, install, instruct, or replace house fuses or correct wiring, plumbing,
or correction of unauthorized repairs.
2. Damage to the product caused by accident, vermin, fire, flood, alteration, misues, abuse, improper installation, or acts
of God.
3. Commercial use or use for other than the intended purpose.
Therefore, these costs are the responsibility of the consumer.
CUSTOMER ASSISTANCE NUMBERS:
Retain your Sales Receipt to prove date of purchase.
A copy of your Sales Receipt must be submitted at the time
warranty service is provided.
Call 1-888-542-2623(1-888-LG-CANADA) and choose the
appropriate prompt.
http://www.lg.ca
Call 1-888-542-2623(1-888-LG-CANADA) and choose the
appropriate prompt. Please have your product type
(refrigerator) and PostalCode ready.
http://www.lg.ca
To Prove Warranty Coverage:
To Obtain Product,
Customer
,
or
Service Assistance by phone:
or by Internet:
To Obtain Nearest Authorized
Service Center, Parts Distributor,
or Sales Dealer by phone:
or by Internet:
LIMITED WARRANTY
LG Electronics
Canada
Visit our website:http://www.lgservice.com
Damages caused during and/or after delivery.
Display, discount, or refurbished units purchased with scratches, dents, or defects.
Proof of purchase is required and must be provided to LG in order to validate warranty.
4.
5.
Labor/1 Year, Parts/7 Years (Compressor, condenser and evaporator).
4
LG Electronics réparera ou remplacera, à sa discrétion, sans frais, le produit présentant des défauts de matériaux ou de
fabrication, dans des conditions normales d’utilisation pendant la période de garantie indiquée ci-dessous à partir de la
date d’achat d’origine.
Cette garantie est valide pour seulement l’acheteur d’origine du produit pendant la période de garantie en autant que cela
soit aux É.-U., incluant Alaska, Hawaii, territoires américains et toutes les provinces canadiennes.
Période de garantie du refrigérateur/congélateur LG
Produit Pièces Main-d’œuv re
Réfrigérateur/congélateur ans ans (service à domicile, sauf modèle GR-051)
Système scellé
(compresseur, condensateur,
évaporateur)
ans ans (service à domicile, sauf modèle GR-0
51)
Aucune autre garantie expresse est applicable à ce produit. LA DURÉ DE TOUTE GARANTIE IMPLICITE, INCLUANT LA
GARANTIE IMPLICITE DE COMMERCIALISATION, EST LIMITÉ À LA DURÉE DE LA GARANTIE EXPRESSE. LG
ELECTRONICS NE POURRA ÊTRE TENUE RESPONSABLE POUR TOUTE PERTE OU UTILISATION DE CE
PRODUIT, INCONVÉNIENT, PERTE OU TOUT AUTRE DOMMAGE, INDIRECT OU ACCESSOIRE, SURVENANT DE
L’UTILISATION OU DE L’INHABILITÉ À UTILISER CE PRODUIT OU POUR TOUT BRIS DE GARANTIE EXPRESSE
OU IMPLICITE, INCLUANT LA GARANTIE IMPLICITE DE COMMERCIALISATION APPLICABLE À CE PRODUIT.
Certains états ne permettent pas l’exclusion ou la limitation de dommages accessoires ou indirects ou les limitations sur
la durée d’une garantie implicite, par conséquent ces limitations ou exclusions peuvent ne pas s’appliquer. Cette garantie
donne des droits légaux et l’on peut en avoir d’autres qui varient d’un état à un autre ou d’une province à une autre.
LA GARANTIE CI-DESSUS NE´S APPLIQUE PAS :
1. Les déplacements de service à domicile pour la livraison ou la cueillette, l’installation, le remplacement de fusibles ou
de câblage résidentiel approprié, plomberie ou correction de réparations non autorisées.
2. Dommage au produit causé par accident, parasites, incendie, inondation ou actes de Dieu.
3. Réparations lorsque le produit LG est utilisé à d’autres fins qu’une utilisation domestique unifamiliale normale.
4. Dommage résultant d’accidents, de modifications, de mauvaise utilisation, d’abus ou d’une installation inadéquate.
Si ce produit est installé à l’extérieur d’une zone de service normale, tous frais de déplacement requis pour la réparation
du produit ou le remplacement de pièces défectueuses seront imputés au propriétaire.
NUMÉROS D’E AIDE LA CLIENTÈLE
À
Conserver la facture comme preuve de la date d’achat
Un exemplaire de la facture doit être présenté au moment où un service sous
garantie est fourni.
Téléphoner au 1-888-542-2623 (lun. au ven. 7 h à 20 h Central)
(sam. 8 h à 17 h Central)
Presser l’option du menu appropriée et avoir le type de produit (réfrigérateur),
numéro de modèle, numéro de série et code postal.
Téléphoner au 1-888-542-2623 (24 heures par jour, 7 jours par semaine)
Presser l’option du menu appropriée et avoir le type de produit (réfrigérateur),
numéro de modèle, numéro de série et code postal.
À
Par conséquent, les frais encourus sont imputés au consommateur.
LG Electronics
GARANTIE LIMITÉE
Canada
Visiter notre site web:http://www.lgservice.com
Pour obtenir une garantie
Pour obtenir un produit ou
de l’aide
Pour obtenir le centre de service
le plus proche
1
7
1
1
Dommages causés pendant et après la livraison.
Remplace, remise ou restauration d'unités achetées avec des rayonnes, bosses ou défauts.
L'essai de l'achat est requis et se il doit proporsionar à LG pour valider la garantie.
5.
6.
CANADA
This guide contains many important safety messages. Always read and obey all safety messages.
This is the safety alert symbol. It alerts you to safety messages that inform you
of hazards that can kill or hurt you or others, or cause damage to the product.
All safety messages will be preceded by the safety alert symbol and the hazard
signal word DANGER, WARNING, CAUTION. These words mean:
All safety messages will identify the hazard, tell you how to reduce the chance of injury and tell you what can happen if
the instructions are not followed.
SAFETY MESSAGES
WARNING
To reduce the risk of fire, electric shock, or injury
to persons when using your product, basic safety
precautions should be followed, including the following:
NEVER unplug your refrigerator by pulling on the power cord.
Always grip the plug firmly and pull it straight out from the
outlet.
Repair or replace immediately all electric service cords that
have become frayed or otherwise damaged. Do not use a cord
that shows cracks or abrasion damage along its length or at
either the plug or the connector end.
When moving your refrigerator away from the wall,
be careful not to roll over or damage the power cord.
DO NOT store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
DO NOT allow children to climb, stand or hang on the
refrigerator doors or shelves in the refrigerator. They could
damage the refrigerator and seriously injure themselves.
Keep fingers out of “pinch point” areas; clearances between
Unplug your refrigerator before cleaning or making any repairs.
NOTE: We strongly recommend that any servicing be
performed by a qualified individual.
Before replacing a burned-out light bulb, unplug the
refrigerator or turn off power at the circuit breaker or fuse box
in order to avoid contact with a live wire filament. (A burned-
out light bulb may break when being replaced.) NOTE: Setting
either or both controls to the OFF position does not remove
power to the light circuit.
Read all instructions before using this appliance.
Use this appliance only for its intended purpose as described
in this use and care guide.
After your refrigerator is in operation, do not touch the cold
surfaces in the freezer compartment when hands are damp or
wet. Skin may adhere to the extremely cold surfaces.
In refrigerators with automatic icemakers, avoid contact with
the moving parts of the ejector mechanism, or with the heating
element that releases the cubes. DO NOT place fingers or
hands on the automatic icemaking mechanism while the
refrigerator is plugged in.
DO NOT refreeze frozen foods which have thawed completely.
The United States Department of Agriculture in Home and
Garden Bulletin No. 69 says:
“...You may safely refreeze frozen foods that have thawed if
they still contain ice crystals or if they are still cold below
40°F (4°C).”
“...Thawed ground meats, poultry, or fish that have any off-odor
or off-color should not be refrozen and should not be eaten.
Thawed ice cream should be discarded. If the odor or color of
any food is poor or questionable, get rid of it. The food may be
dangerous to eat.”
“Even partial thawing and refreezing reduces the eating quality
of foods, particularly fruits, vegetables and prepared foods.
The eating quality of red meats is affected less than that of
many other foods. Use refrozen foods as soon as possible to
save as much of their quality as you can.”
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
5
the doors and cabinet are necessarily small. Be careful
when you open the doors when children are in the area.
For personal safety, this appliance must be properly grounded.
Have the wall outlet and the circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
The refrigerator-freezer should be so positioned that the supply
plug is accessible for quick disconnection when accident happens.
Do not store bottles in the freezer compartment - they may
break when frozen, causing damage.
WARNING
CAUTION
You can be killed or seriously injured if you don’t follow instructions.
Indicates an imminently hazardous situation which if notavoided,
may result in minor or moderate injury, or product damage only.
DANGER You will be killed or seriously injured if you don’t follow instructions.
,
IMPORTANT: Please read carefully.
TO CONNECT ELECTRICITY
RECOMMENDED GROUNDING METHOD
The refrigerator should always be plugged into its own
individual properly grounded electrical outlet rated for
115 Volts, 60 Hz, AC only, and fused at 15 or 20 amperes.
This provides the best performance and also prevents
overloading house wiring circuits which could cause a fire
hazard from overheated wires. It is recommended that a
separate circuit serving only this appliance be provided.
Use a receptacle which cannot be turned off with a switch
or pull chain. Do not use an extension cord.
WARNING
Electrical Shock Hazard
FOR PERSONAL SAFETY, this appliance must be
properly grounded. Have the wall outlet and the
circuit checked by a qualified electrician to make sure
the outlet is properly grounded.
Ensure proper
ground exists
before use.
3-prong
grounding
plug
3-prong
grounding type
wall receptacle
Your old refrigerator may have a cooling system that used If you are throwing away your old refrigerator, make sure
CFCs (chlorofluorocarbons). CFCs are believed to harm the CFC refrigerant is removed for proper disposal by a
stratospheric ozone. qualified servicer thechnical. If you intentionally release this
CFC refrigerant, you can be subject to fines and imprisonment
under provisions of environmental legislation.
DANGER: RISK OF CHILD ENTRAPMENT
BEFORE YOU THROW AWAY
YOUR OLD REFRIGERATOR
OR FREEZER
Take off the doors.
Leave the shelves in place so that
children may not easily climb inside.
CFC DISPOSAL
GROUNDING REQUIREMENTS
Child entrapment and suffocation are not problems of
the past. Junked or abandoned refrigerators are still
dangerous... even if they will sit for “just a few days”. If
you are getting rid of your old refrigerator, please follow
the instructions at right to help prevent accidents.
This appliance contains fluid (refrigerant, lubricant), is
made of parts and materials which are reusable and / or
recyclable. All the important materials should be sent to
the collecton center of waste material and can be reused
after rework (recycling).
For take back, please contact with the local agency.
6
Where a standard two-prong wall outlet is encountered,
it is your personal responsibility and obligation to have it
replaced with a properly grounded three-prong wall outlet.
Do not, under any circumstances, cut or remove the
third (ground) prong from the power cord.
NOTE: Before performing any type of installation,
cleaning, or removing a light bulb, turn the control
(Thermostat, Refrigerator Control or Freezer Control,
depending on the model) to OFF and then disconnect the
refrigerator from the electrical source. When you are
finished, reconnect the refrigerator to the electrical source
and reset the control (Thermostat, Refrigerator Control or
Freezer Control, depending on the model) to the desired
setting.
USE OF EXTENSION CORDS
Because of potential safety hazards under certain
conditions, we strongly recommend against the use of
an extension cord.
WARNING
POWER CORD REPLACEMENT
If the power cord is damaged, it must be replaced
by the manufacturer, by our service center or by
qualified personal by LG Electronics, to avoid some
risk.
However, if you still elect to use
an extension cord, it is absolutely necessary that it be
a UL-listed (in the United States) or ACNOR (Canada),
3-wire grounding type appliance extension cord having a
grounding type plug and outlet, and that the electrical rating
of the cord be 15 amperes (minimum) and 120 volts.
Use of an extension cord will increase the clearance
needed for the back of the refrigerator.
7
Use this section to become more familiar with the parts and features.
NOTE: This guide covers several different models. The refrigerator you have purchased may have some
or all of the items listed below. The locations of the features shown below may not match your model.
PARTS AND FEATURES
*on some models
A
B
C
G
H
I
J
E
F
K
D
L
M
N
O
P
Q
AL
Digital Sensor Control Filter (Inside)*
Durabase
Divider
Egg Box
Refrigerator Door Rack
Freezer Light
Pull out Drawer
B
C
D
F
E
G
H
I
J
K
M
N
O
P
Q
Ice Bin
Optibin Crisper
Keeps fruits and vegetable fresh and crisper
Chef Fresh / Snack Pan
Can Dispenser
Temperature Control
Shelves
Refrigerator Light
Customcube Icemaker
Dairy Bin
*
UNPACKING YOUR REFRIGERATOR
Remove tape and any temporary labels from your
refrigerator before using. Do not remove any warning-
type labels, the model and serial number label, or the
TechSheet that is attached to back wall of the refrigerator.
To remove any remaining tape or glue, rub the area
briskly with your thumb. Tape or glue residue can also be
easily removed by rubbing a small amount of liquid dish
soap over the adhesive with your fingers. Wipe with warm
water and dry.
Do not use sharp instruments, rubbing alcohol, flammable
fluids or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see the Important Safety Instructions
section.
Refrigerator shelves are installed in the shipping position.
Please reinstall shelves according to your individual
storage needs.
When Moving Your Refrigerator:
Your refrigerator is heavy. When moving the
refrigerator for cleaning or service, be sure to protect
the floor. Always pull the refrigerator straight out when
moving it. Do not wiggle or walk the refrigerator when
trying to move it, as floor damage could occur.
INSTALLATION
1. Avoid placing the unit near heat sources, direct sunlight,
or moisture.
2. To avoid vibration, the unit must be level. If required,
adjust the leveling screws to compensate for
unevenness of the floor. The front should be slightly
higher than the rear to aid in door closing. Leveling
screws can be turned easily by tipping the cabinet
slightly. Turn the leveling screws clockwise ( ) to
raise the unit, counterclockwise ( ) to lower it.
3. Install this appliance in an area where the temperature
is between 55°F (13°C) and 110°F (43°C.) If the
temperature around the appliance is too low or high,
cooling ability may be adversely affected.
NEXT
1. Clean your refrigerator thoroughly and wipe off all dust
accumulated during shipping.
2. Install accessories such as ice cube bin, drawers,
shelves, etc., in their proper places. They are packed
together to prevent possible damage during shipment.
3. Let your refrigerator run for 2 or 3 hours before putting
food in it. Check the flow of cold air in the freezer
compartment to ensure proper cooling. Your refrigerator
is now ready for use.
WARNING:
Be careful when you work with hinge, base grille,
stopper etc. You may be injured.
Do not put hands or metal sticks into air vents, base
grille or bottom of refrigerator. You may be injured or
receive an electrical shock.
BASE GRILLE
To remove the base grille:
1. Grasp the grille with both hands.
2. Pull the grille toward yourself.
To install the base grille:
1. Place clips in openings in the metal panel.
2. Push the grille toward the refrigerator until it snaps
into place.
REFRIGERATOR INSTALLATION
WARNING
Excessive Weight Hazard
Use two or more people to move and install
refrigerator.
Failure to do so can result in back or other injury.
WARNING
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion or fire.
8
CAUTION: Avoid placing the unit near heat sources,
direct sunlight or moisture.
Explosion Hazard
A proper distance from adjacent items
Please keep the refrigerator at a proper distance from other
things. Too small a distance from adjacent items may result
in lowered freezing capability and increased electricity charge
consumption.
More than
1”(2.5 cm)
to back
More than
1”(2.5 cm)
to top
More than
0.125”
to hinge
(0.3 cm)
side
Keep it at a
proper distance
HOW TO REMOVE DOOR HANDLES
NOTE: Handle appearance may vary from
illustrations on this page.
1. Removing Refrigerator Handle
Grasp the handle tightly with both
hands and slide the handle up (1)(this
may require some force).
necessary to remove the refrigerator door handles.
To move refrigerator through ahouse door, it may be,
The keyhole slots (2) on the back of the
handle allow the handle to separate
from the mounting screws (3).
CAUTION: It could be damaged and
broken when you hit with hammer
while you remove and attach the
handle.
CAUTION: When you assemble or
disassemble handle, you must push
and pull with moment force.
REFRIGERATOR INSTALLATION
HOW TO REPLACE DOOR HANDLES
1. Replacing Refrigerator Door Handle
Align keyhole slots (1) on the top and
bottom of the back of the handle with
the screws (2) mounted on the front of
the door.
Press the handle against the door
front, making sure that the screws (2)
go into the keyhole slots (1).
Holding the handle with both hands,
press it firmly against the front of the
door and slide the handle down (3).
T O O L S Y O U M A Y N E E D
Hex head socket wrench Phillips screwdriver Flat head screwdriver
10 mm
1/4 in
3/8 in
NOTE: Handle appearance may vary from
illustrations on this page.
REFRIGERATOR INSTALLATION
10
HOW TO REMOVE REFRIGERATOR DOOR (models without water dispenser)
1. Removing Refrigerator Door
NOTE: Handle appearance may vary.
IMPORTANT: Before you begin, turn the refrigerator OFF and unplug it. Remove food and any bins from doors.
Left Door
Loosen the cover screw (1).
Disconnect door switch wire (2).
Loosen hinge bolts (3).
Lift off the top hinge (4).
Place the door on a non-scratching surface with the inside up.
Right Door
CAUTION: When removing top hinge, be careful that the door does not fall forward.
Loosen the cover screw (1).
Disconnect door switch wire (2).
Loosen hinge bolts (3).
Lift off the top hinge (4).
Place the door on a non-scratching surface with the inside up.
Loosen ground screw (6).
Disconnect wire harness (5).
