LG LT20CBBVIN User manual

P/No. MFL67527907-12
L
LT20CBBVIN
T24CBBVLN
LT24CBBWLN
GR-U932SSDM
GM-U792SSXM
GM-U552SSDM
AFN75754510
Copyright © 2017-2021 LG Electronics Inc. All Rights Reserved.
Model Name
ENGLISH
OWNER’S MANUAL
TOP FREEZER
REFRIGERATOR
Please read this manual carefully before operating
your set and retain it for future reference.
www.lg.com
ENGLISH
LT24CBBVLH
LT24CBBWLH
LT20CBBWIN

1
Important Safety Instructions 2-3
Requirements for Ground Connection 3
Parts and Features 4
Refrigerator Installation 5-11
5gnikcapnU
Installation 5
How to remove and Install the
Refrigerator Doors 6-7
How to reverse and Install the
Refrigerator Doors 8-11
Closing and Aligning the doors 11
Using your Refrigerator 12-15
Ensuring Proper Air Circulation 12
Adjusting the Controls 12
Adjusting Control Settings 13
Food Storage Guide 13
Refrigerator Shelves 14
Pantry Drawer 14
Ice Tray 15
Humidity Controlled Crispers 15
Door Bins 15
Dairy Bin 15
Refrigerator Care and Cleaning 16-17
Refrigerator Cleaning 16
Outside 16
Inside 16
Door Lining & Gaskets 16
Plastic Parts (Covers and Panel) 16
Back Cover 16
Replacing Refrigerator Lights 16
Power Interruptions
16
When Going on Vacation 16
When Moving 17
Troubleshooting Guide 18-22
22snoitacfiicepS
TABLE OF CONTENTS
TABLE OF CONTENTS
Smart Functions 17
Door Alarm 17

2
This manual contains several important safety notices. Always read and obey all of the following safety messages.
This is the safety alert symbol. This symbol is a warning to potential dangers that could cause death, injury
or damage to you, others or the product. All safety messages will follow after this warning symbol and the
word “DANGER”, “CAUTION” or “WARNING”. These words mean:
You may be killed or suffer fatal damage if you do not follow instructions.
You may be killed or seriously injured if you do not follow instructions.
Indicates a potentially hazardous situation which, if not avoided, may result in minor injury
or damage to the product.
All safety messages inform you of potential danger, advise you on how to reduce the risk of injury and tell you what
can occur if the instructions are not followed.
KEEP THESE INSTRUCTIONS
SAFETY MESSAGES
WARNING
DANGER
WARNING
CAUTION
IMPORTANT SAFETY INSTRUCTIONS
This symbol alerts you to flammable materials that can ignite and cause a fire if you do not take care.
To reduce the risk of fire, electrical shock or personal injury, the following precaution measures should be followed:
NEVER disconnect the refrigerator by pulling the power cord, always grip the plug firmly and disconnect it directly from the
outlet.
Immediately repair or replace all faulty or damaged service cables. Do not use cords that have cracks or abrasion damage on
the length of the cord or on the plug.
When moving your refrigerator, take care not to roll over the electrical cord.
DO NOT store or use gasoline or other combustible liquids or vapors in proximity with this or any other electrical appliance.
DO NOT permit children to climb, stand or swing from the doors or shelves of the refrigerator. This can cause serious injury
to them and damage to the product.
Keep your fingers away from areas in which they can become caught, such as the doors, hinges and cabinets. Be careful
closing the doors when children are near.
Unplug the refrigerator before cleaning or repairing.
NOTE: We strongly recommend that any repair services be performed by a qualified professional.
Never store explosive substances or chemicals in your refrigerator such as benzene, alcohol, aerosolcans, etc. It is DANGEROUS!!
This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops,
offices and other working environments; farm houses and by clients in hotels, motels and other residential type
environments; bed and breakfast type environments; catering and similar non-retail applications.
For your safety, this product should be properly grounded. Have a qualified professional check the electrical circuit and outlet
to ensure a proper ground connection.
Do not keep bottles in the freezer compartment, theycould explode after freezing and cause damage.
Read all instructions before utilizing the product. Utilize this product only as explicitly expressed in this guide.
Once the refrigerator is operating, avoid touching cold surfaces of the freezer with damp or wet hands; the skin could
become adhered to these surfaces.
In refrigerators with an automatic ice dispenser, avoid contact with moving parts of the ejector mechanism or with the
heating mechanism that discharges the cubes. DO NOT place your fingers or hands in the ice dispenser mechanism while
the refrigerator is connected.
If the use of this unit is no longer needed, please contact local authorities to dispose of this product in a safe way due contains
Cyclopentane or pentane as gas for insulation and R600a as refrigerant. Insulation gases and refrigerant require a special
elimination process. This product contains flam-mable insulation and refrigerant.
DO NOT refreeze foods which have already thawed. The Department of Agriculture of the United States, in your Bulletin of
Home and Gardens No. 69 establishes that:
“...You can refreeze food that has thawed if they contain ice crystals or are cold and below 40 °F (4 °C)”.
“...Ground beef, perishable food or seafood that is discolored or has an unpleasant odor should not be frozen or consumed.
Consumption of melted ice cream should also be avoided. If the odor or color of food is questionable, discard it. The food
may be dangerous to consume”.
“Partial thawing or refreezing reduces the quality of the food, especially fruit, vegetables and prepared meals.
The quality of red meat is less affected than that of other foods. Use refrozen products as soon as possible in order to
maintain their quality”.
Do not use mechanical devices or other means to accelerate the defrosting process.
Risk of Fire and Flammable Materials
*Refrigerant type is indicated in the label inside your refrigerator, this warning apply just for models with
R600a refrigerant.
•This appliance contains a small amount of isobutane refrigerant (R600a), but it is also combustible. When
transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating
circuit are damaged.
•If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is
standing for several minutes. In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit
occurs, the size of the room in which the appliance is used should correspond to the amount of refrigerant used. The room
must be 1 m² in size for every 8 g of R600a refrigerant inside the appliance.
•When positioning the appliance, ensure the supply cord is not trapped or damaged.
•Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type
recommended by the manufacturer

3
This appliance is not intended for use by children, persons with physical or mental disabilities, persons with reduced
sensory or mental capacity, or persons that lack experience or know-how, unless they have supervision or instruction
in relation to the use of the appliance by the person responsible for their safety. Children should be supervised to
assure that they do not play with the appliance.
Children becoming trapped or suffocated is not
a problem of the past. Discarded and abandoned
refrigerators are a hazard, even if they remain there
“for just a few days”. If you would like to dispose of
your old refrigerator, please follow the instructions
below to prevent any accidents.
BEFORE DISPOSING YOUR REFRIGERATOR
OR FREEZER WHEN NO LONGER IN USE:
Remove the doors.
Leave the shelves in place so that children
cannot easily become stuck in them.
Your old refrigerator may have a cooling system that
uses CFC’s (chlorofluorocarbons). CFC affects the
stratospheric layer of the ozone.
If you decide to throw out your old refrigerator, ensure
that CFC contaminants are properly disposed of by a
qualified professional. If you intentionally remove the
CFC refrigerant, you could be subject to fines or prison
in accordance with environmental legislation in effect.
IMPORTANT: Attentively read the following.
TO CONNECT ELECTRICITY
WARNING
ELECTRICAL SHOCK HAZARD
FOR YOUR PERSONAL SAFETY, this appliance must
be properly grounded. Have a qualified electrician
check your wall outlet to ensure that the plug is
grounded properly.
3 prong
grounding type
wall receptacle
3 prong
plug ground exists
before use
RECOMMENDED GROUNDING METHOD
Your refrigerator must always be plugged to its own
outlet which is adequately grounded. The energy current
should only be
220-240 V ~ 50/ 60 Hz, AC (according to
This provides the best performance and prevents an
overload which could cause a fire from the overheating
of the cables. It is recommended that a separate circuit
be used for this appliance, as well as a receptacle that
cannot be disconnected with a switch.
It is your responsibility and obligation to replace two-
prong outlets with that of an adequately grounded three-
prong outlet.
Do not, under any circumstance, cut or extract the third
prong from the plug.
NOTE: Before installation, cleaning or replacing LED
lamp, you must disconnect the appliance from the
power source. When finished, plug the appliance back in
and adjust the thermostat to the desired position.
USE OF EXTENSION CABLES
We do not recommend the use of extension cables.
However, if you still choose to utilize an extension cable,
it is absolutely necessary that it supports three-pronged
plugs and that the electrical current support a
minimum of 15 A and 220-240 V
( according to
the National rating).
The use of an extension cable will increase the amount
of space needed behind the refrigerator.
WARNING
REPLACING ELECTRICAL CABLE
If the power cord is damaged, it must be replaced by
our service center or qualified LG technician to avoid
any risk.
CAUTION
DANGER: CHILDREN MAY BECOME TRAPPED
CFC DISPOSAL
REQUIREMENTS FOR GROUND CONNECTION
grounding Ensure proper
WARNING
EXTENSION CABLE
Do not use an extension cable.
the National rating) and fused at 15 A.
*Image may vary acording to your national plug,
reference only

4
PARTS AND FEATURES
Use this page to become more familiar with the parts and features of your refrigerator. Page references are
included or your convenience.
NOTE: This guide
* Optional Parts: Not included with all models
covers several models. The refrigerator you have purchased may have some or all of the items
listed below. The locations of the features shown below may not match your model.
F- Deco Duct*
Ice Tray
Freezer Shelf
Freezer Temperature Control
Refrigerator Temperature Control
Shelves
Refrigerator or Lights (LED)*
Pantry Drawer*
Crispers
Freezer Light (LED)*
Freezer Door Bins
Diary Bin
Refrigerator Door Bins
Refrigerator Door Bin
Smart Functions*
Door Alarm*
A
B
C
F
G
O
E
D
B
C
D
E
F
G
K
M
N
H
I
L
J
H
I
J
M
N
L
K
AO

5
REFRIGERATOR INSTALLATION
WARNING
EXCESSIVE WEIGHT HAZARD
Use the assistance of two or more persons to move or
install the refrigerator. Not following these instructions
may cause injury to the back and other parts of the
body.
UNPACKING
Before installing your refrigerator, remove any tape
or temporary stickers. Do not remove any stickers
that feature warnings, the model serial number or the
technical label of the product located on the back of the
refrigerator.
To remove adhesive tape residue, rub it well with your
fingers and a little liquid detergent. Clean with warm
water and let dry.
Do not use sharp instruments, rubbing alcohol, flammable
liquids or abrasive cleaning products to remove the
adhesive tape or glue. These products can damage the
surface of your refrigerator. For more information, see
the section on “Important Safety Instructions”.
The shelves come already installed in their factory
position. Remove the shelves and replace them
according to your spacing needs.
Moving Your Refrigerator:
Your refrigerator is extremely heavy. Make sure you
protect the floor when moving your refrigerator for
cleaning or servicing. Always pull your refrigerator
straight out when moving it. Do not shift from side
to side or “walk” the refrigerator when attempting to
move it as this can cause damage to the floor.
WARNING
EXPLOSION HAZARD
Keep all flammable materials and vapors (such as
gasoline) away from the refrigerator. Not following
these instructions may cause death, explosion or fire.
INSTALLATION
1. Avoid placing the unit near heat sources, direct
sunlight, or humidity.
2.To avoid vibration, the unit should be leveled. If needed,
adjust the leveling screws to compensate for an
unleveled floor. The front should be slightly taller than
the rear to ensure that the doors close properly. The
leveling screws can easily be turned by slightly tilting
the front of the refrigerator, turning the leveling screws
clockwise ( ) to raise it and counter-clockwise
( ) to lower it.
3.Install the refrigerator in an area between 55 °F (13 °C)
and 110 °F (43 °C). If the surrounding temperature is
lower or higher than previously mentioned, it can
adversely affect the unit.
CAUTION: Avoid placing the unit near heat
sources, direct sunlight or humidity.
ONCE INSTALLED
1. Carefully clean your refrigerator and remove and dust
accumulated during shipping.
2.Install accessories such as the ice bin, door racks,
shelves, etc., in their proper places. These are already
packed to prevent any possible damage during
shipping.
3.Leave your refrigerator on for 2 to 3 hours before
storing food inside. Verify that there is a flow of cold air
in the freezer compartment to ensure proper cooling.
Your refrigerator is now ready for use.
WARNING:
Take care when working with the hinges, base cover
and stops, etc. You may injure yourself.
DO not place your hands or any tools in the air vents,
the base cover or in the bottom of the refrigerator. This
may cause injury or electrical shock.
Keep a Proper Distance from Adjacent Objects
Please keep the refrigerator at an adequate distance
from other objects. Insufficient spacing can reduce the
refrigerator’s freezing efficiency and increase electricity
consumption.
2” (5.08 cm)
2” (5.08 cm) 2” (5.08 cm) 2” (5.08 cm)
REFRIGERATOR INSTALLATION

6
HOW TO REMOVE AND INSTALL THE REFRIGERATOR DOORS
If entrance is less than 35 inches wide, the refrigerator’s door will need to be removed.
IMPORTANT: Before starting, turn off and unplug the refrigerator. Remove all food and the racks from the doors.
TOOLS YOU MIGHT NEED OR USE
Hex Socket Wrench Phillips Screwdriver No. 2 Flat Head Screwdriver
WARNING
ELECTRICAL SHOCK HAZARD
Before you begin, either unplug the refrigerator or
turn off the power at the circuit breaker or fuse box.
Remove food and any door rack from the refrigerator.
Failure to do so could result in death or serious injury.
1. Removing Freezer Door
Gently pry off the Top Hinge Cover with a flat head
screwdriver and remove it. See Fig. 1.
Using 10 mm or 3/8 inch socket wrench, remove
the three bolts and lift the Top Hinge (See Fig. 2). Set
parts aside.
Lift freezer door slightly and remove it (See Fig. 3) Set
parts aside.
2. Removing Refrigerator Door
Loose and remove the two bolts and the screw to
remove the middle hinge bracket from refrigerator
housing (Figure 4). Set parts aside (Figure 5).
Lift up door slightly and remove it (See Figure 6).
REFRIGERATOR INSTALLATION
Hinge Pin
Middle Hinge Bracket
Fig. 1
Fig. 3
Middle
Hinge Bracket
Fig. 4
Fig. 5
Fig. 2
1/4 in ( 6 mm)
3/8 in ( 10 mm)

REFRIGERATOR INSTALLATION
7
To replace doors, begin with refrigerator door and then
follow with freezer door.
3. Replacing Refrigerator Door
Set door on Bottom Hinge Pin (See Figure 7).
Place hinge pin of middle bracket inside the hinge pin
insert on the top of the door (See Figure 8). Hold the
door in place and line up the hinge with the holes in
the refrigerator housing.
Use the two bolts and the screw to refasten the middle
hinge with the refrigerator housing. See Figure 9.
4. Replacing Freezer Door
Set the freezer door onto the Middle Hinge pin (Figure
10).
Place upper hinge in the top of the freezer door and
line up the hinge with the holes in top of refrigerator.
Use the three bolts to fasten the hinge (See Figure 11).
Carefully, force the top hinge cover back into place over
hinge (See Figure 12).
REFRIGERATOR INSTALLATION
Fig. 8
Fig. 9
Fig. 12
Bottom
Hinge Pin
Fig. 6
Fig. 10
Fig. 7
REFRIGERATOR INSTALLATION
Fig. 11

REFRIGERATOR INSTALLATION
8
HOW TO REVERSE AND INSTALL THE REFRIGERATOR DOORS
You may find it more convenient to have the doors converted from the left opening type (factory installed) to the right
opening type. Directions refer to the right side as the side on your right as you face the unit.
TOOLS YOU MIGHT NEED OR USE
WARNING
ELECTRICAL SHOCK HAZARD
Before you begin, either unplug the refrigerator or
turn off the power at the circuit breaker or fuse box.
Remove food and any door rack from the refrigerator.
Failure to do so could result in death or serious injury.
1. Removing Freezer Door
Gently pry off the top hinge cover with a flat head
screwdriver and remove.
Using 10mm or 3/8 inch socket wrench, remove the
three bolts and lift off the top hinge. Set parts aside.
Slightly lift up the refrigerator door and remove it.
Turn the freezer door upside down on a non-scratch
surface.
Loosen the screw to remove the Door Closer/Stop and
Hinge Pin Insert.
Move the Hinge Pin Insert Bracket to the other side of
the door, keeping the same orientation, and move the
Hinge Pin Insert into the hole on the left side of the
bracket.
Reverse the Door Closer/Stop by flipping it over. Place it
on top of the Hinge Pin Insert Bracket, and tighten both
down with the screw.
Pry off the cover on the top left side of the refrigerator to
uncover the screw holes.
Set the freezer door and top hinge parts to the side and
remove the refrigerator door.
REFRIGERATOR INSTALLATION
Hinge Pin
Middle Hinge Bracket
Hinge Pin
Insert Bracket
Hinge Pin Insert
Cover (on top of
refrigerator)
Hex Socket Wrench Phillips Screwdriver No. 2 Flat Head Screwdriver
Fig. 2
REFRIGERATOR INSTALLATION
NOTE: Door reversal must be done by an authorized installer or service person.
1/4 in ( 6 mm)
3/8 in ( 10 mm)

REFRIGERATOR INSTALLATION
9
2. Reversing and Reinst
alling Refrigerator Door
Using a ¼” socket wr
ench, loosen and remove Hinge
Pin fr
om the Middle Hinge Bracket. Remove washer
undernea
th the middle hinge and set aside.
NOTE: At this point the door
will be loose. Slightly lift the
door and remove it.
Loosen and remove the tw
o bolts and use the Phillips
head screwdriver to remov
e the Middle Hinge Bracket
from the refrigerat
or housing. Set parts aside.
Remove the washer fr
om the Bottom Hinge Pin.
Using a ¼” socket wr
ench, loosen and remove the
Hinge Pin from the Bott
om Hinge. Reattach the
Hinge Pin to the opposit
e side of the hinge.
NOTE:
NOTE:
WARNING:
This is easier to do
while the hinge is still
attached.
Using a 3/8’’ socket wrench with a 2-Inch extension
and screwdriver, loosen the two bolts and one screw, and
remove the Bottom Hinge from right side of the housing.
Remove the Decorative Caps on the bottom of the
refrigerator housing. You will need these holes for the
Bottom Hinge.
Move the Bottom Hinge to the left side of the housing,
keeping the same orientation, and reattach with the
two bolts and one screw. The flat screw must be
placed on the exterior side of the hinge. Move the
Decorative Bolt to the hole on the lower right side
of the housing.
If you reinstall or replace doors, move
The leveler feature only applies on some models.
REFRIGERATOR INSTALLATIONREFRIGERATOR INSTALLATION
Leveler
the leveler to the opposite side.
Turn the refrigerator door upside down on a non
scratching surface. Loosen the three screws to remove
the hinge pin bracket, the hinge pin insert and the door
closer.

10
With a flat-head screwdriver, carefully pry off and
remove the cover over the screw holes on the left side of
refrigerator housing.
Remove the outer lower Decorative Screw from the
housing at the area between the freezer and refrigerator
doors (You will need this hole for the Middle Hinge
Bracket.)
Flip the Middle Hinge Bracket, (flange will now be on
top) position it on left side of the refrigerator and reattach
with two bolts and a Phillips screwdriver. Place the
refrigerator door down over the pin on the bottom hinge.
Place the washer between the refrigerator door and
middle hinge and re-attach Hinge Pin to Hinge Bracket
with a ¼” socket wrench.
NOTE: Bracket has been flipped, but Hinge Pin stays
in the same orientation with its hexagonal end facing
upward.
Insert the Decorative Screw into the outer hole on the
rightside of the housing. Attach cover on the right side.
Cover is force-fitted.
REATTACHING THE DOORS
Place the freezer door down over the Hinge Pin on the
Middle Hinge Pin Bracket.
Place the Upper Hinge Pin on top of the freezer door
and line up the Upper Hinge with holes on top of the
refrigerator. Use the three bolts to replace the Hinge.
Middle Hinge
Bracket
Flange
Decorative
Screw
REFRIGERATOR INSTALLATION
Door
Closer/
Stop
Hinge Pin
Insert
Hinge
Pin Bracket
Reverse the Door Closer/Stop by flipping it over.
Place the hinge pin bracket, and the hinge pin insert
keeping the same orientation on the opposite door
side, then place the door clooser on top, and tighten
the 3 philliphs screws.
Hinge Pin
Insert
Hinge
Pin Bracket
Door
Closer/
Stop

REFRIGERATOR INSTALLATION
11
Tighten the bolts. Force-fit Top Hinge Cover over Top
Hinge.
Replace cover on the top left side of the refrigerator
to the right top to cover the holes. Cover is also
force-fitted.
Cover (on top of
refrigerator)
REFRIGERATOR INSTALLATION
REFRIGERATOR INSTALLATION
After changing doors, make sure that the corners
of the Door Gaskets are not folded over. To ensure a
good seal, apply a small amount of silicon grease on
the corners of gaskets.
Corners
Corners
Door Alignment
If the space between your doors is uneven, follow the
instructions below to align the doors:
1. Gently pry off the Top Hinge Cover with a flat head
screwdriver and remove.
2.Loosen the Top Hinge Bolts using a 10 mm or 13/32
inch socket wrench or open-end wrench.
3.Have someone hold the freezer door so the space
between the two doors is even, and retighten the top
hinge bolts.
4.Replace the Top Hinge Cover.
CLOSING THE DOORS AND LEVELING
To avoid vibration, the unit must be leveled. If necessary,
adjust the leveling legs to compensate for unevenness
of the floor. The front should be slightly higher than the
rear to aid in door closing.
The refrigerator has two front leveling legs, one on
the right and one on the left. If your refrigerator seems
unstable or if you would like the doors to close more
easily, simply adjust the tilt of the refrigerator by
following the instructions below:
1. Plug the refrigerator into a 3 prong grounded outlet.
Move the refrigerator into its final position.
2.
NOTE: Having someone push against the top of the
refrigerator takes some weight off the leveling legs.
This will make it easier to adjust the level.
3.Open both doors again and check to make sure that
they close easily. If they don't, tilt the refrigerator slightly
more to the rear by turning both leveling legs
to the left. It may take several more turns, and you
should extend both
legs theamount.
Use an 11/16” (18 mm) wrench or an adjustable
wrench to adjust the leveling legs, turn the leveling
legs to the left to raise that side of the refrigerator or
to the right to lower it. It may take several turns of the
leveling leg to adjust the tilt of the refrigerator.

12
ENSURING PROPER AIR CIRCULATION
In order to obtain stable temperature, the air must flow
between the freezer and refrigerator sections. As shown
in the illustration below, the cold air enters through
the bottom part and circulates upward. This air returns
below the freezer floor and the rest of the air enters the
refrigerator section through the top vent.
Do not block any of these vents with packages of food.
This can interrupt the flow of air and cause temperature
and moisture problems.
IMPORTANT: Because air circulates between both
sections, any odors formed in one section will transfer
to the other. You must thoroughly clean both sections to
eliminate odors. To prevent odor transfer and drying out
of food, make sure you wrap or cover foods tightly (See
the “Food Storage Guide” section for details).
NOTE: If you close the fresh food
compartment door applying
more force than necessary,
freezer door may get open and
close again, due internal air flow
of refrigerator.
ADJUSTING THE CONTROLS
Your refrigerator has two controls that allow you to
regulate the temperature the freezer and refrigerator
compartments.
Refrigerator Control
Initially set the Refrigerator Control on the middle
setting (number 3). To do so, press the TEMPERATURE
ADJUST button until it reaches the middle position
(the third LED turns ON). Leave the refrigerator on this
setting for 24 hours to reach the correct temperature.
After 24 hours, adjust the compartment temperature
as you desire. ALWAYS wait 24 hours before you adjust
the temperature. If you want to set the refrigerator
compartment temperature to a warmer temperature
than the current, continue pressing the TEMPERATURE
ADJUST button until it reaches the desired temperature.
Demo Mode (For Store Use Only)
Demo Mode disables all cooling in the refrigerator and
freezer sections to conserve energy while on display in
a retail store. When activated, OFF will display on the
control panel.
To deactivate:
Press the TEMPERATURE ADJUST button until your
desired temperature setting is reached. The OFF light
will turn off once the Demo Mode is deactivated.
Freezer Control
The freezer control should come from factory on the
middle setting (number 3). Wait 24 hours before
adjusting the freezer compartment temperature. Roll
the knob to set the freezer temperature as you desire.
ALWAYS wait 24 hours after any adjustment to reach the
desired temperature.
NOTE: Setting at higher number
of the freezer compartment, the
temperature of freezer compartment
becomes colder.
USING YOUR REFRIGERATORUSING YOUR REFRIGERATOR

13
ADJUSTING CONTROL SETTINGS
Give the refrigerator time to cool down completely before
adding food. It is best to wait 24 hours before adding
food to the refrigerator. The mid-settings indicated in the
previous section should be correct for normal household
refrigerator usage. The controls are set correctly when
milk or juice is cold to your liking and ice cream is firm.
The refrigerator control functions as the thermostat for
the entire appliance. The higher the number setting, the
longer the compressor will run to keep the temperature
colder. The freezer control adjusts the cold air flow from
the freezer to the refrigerator. Setting the freezer control
to a lower temperature keeps more cold air in the freezer
compartment to make it colder.
If you need to adjust the temperature in the refrigerator
or freezer, begin by adjusting the refrigerator first. Wait
24 hours after the refrigerator adjustment to check the
freezer temperature. If it is too warm or too cold, then
adjust the freezer control as well.
Use the settings listed in the table below as a guide.
CONDITION/REASON: RECOMMENDED
ADJUSTMENT:
REFRIGERATOR section
is too warm
Opening the door often
Adding a large amount
of food
Room temperature is
very warm
Adjust the
REFRIGERATOR setting
to the next highest
number and wait 24
hours, then check.
FREEZER section is too
warm/ ice is made too
slowly
Opening the door often
Adding a large amount
of food
Room temperature is
very low (not cycling
often enough)
Using ice frequently
Air vents blocked by
objects
Adjust the FREEZER
setting to the next
highest number and wait
24 hours, then check.
Remove any objects
blocking air flow.
REFRIGERATOR section
is too cold
Controls not set
correctly for your
conditions
Adjust the
REFRIGERATOR setting
to the next lowest
number and wait 24
hours, then check.
FREEZER section is too
cold
Controls not set
correctly for your
conditions
Adjust the FREEZER
setting to the next lowest
number and wait 24
hours, then check.
FOOD STORAGE GUIDE
ITEMS HOW TO STORE
Storing Fresh Food Wrap or store food in the
refrigerator in airtight and
moisture-proof material unless
otherwise noted. This prevents
food odor and taste transfer
throughout the refrigerator. For
dated products, check date code
to ensure freshness.
Butter or
margarine
Store opened butter in a covered
dish or in a closed compartment.
When storing a larger quantity,
wrap in freezer packing and
freeze.
Cheese Store in original packaging until
you are ready to use it. Once
opened, tightly rewrap with
plastic wrap or aluminum foil.
Vegetables with
skins (carrots,
peppers)
Place in bags or plastic containers
inside the crisper.
Fruit Wash and let dry; store in plastic
bags in the refrigerator. Do not
wash or pit berries until you
are ready to eat them. Berries
should be selected and kept in
their original packaging (if there
is any) or in a paper bag closed
halfway and set on a shelf.
Leafy Vegetables Remove original packaging and
trim any dirty or discolored parts.
Wash in cold water and drain.
Place in a plastic bag or plastic
container and store in the crisper.
Fish Consume fish or seafood the
same day purchased.
Chef Fresh Store any meat in original airtight,
moisture-proof packaging.
Rewrap if necessary.
Leftovers Cover leftovers with plastic
wrap or aluminum foil. Plastic
containers with airtight lids can
also be used.
USING YOUR REFRIGERATOR
Packaging Recommendations:
Us se s containers.
Us s containers o surface.
Package f o resistance.
Wr yered stic.
Use wat roo stic.
Us rec s t store frozen foods.
Follow these or container instructions in order
t re est freezing.
USING YOUR REFRIGERATOR

14
Do not use:
Bread r
Plas c o safe f storing.
Containers seals.
Wax wax stic.
Thin wr ot wat roof.
Freezing
IMPORTANT: o k ottle freez
c r t ter free
caus
For the a use of your freezer do not store exces
food. not introduce a large of unfrozen f
that cannot frozen within 24 hours (no re
2 – 3 or 0,91 kg - 1,36 kg of food squar
inch of ce in the freezer). Sufficient ce st
left in order for the air to circulate r around
es. Leave enough ce in order to close y
refrigerator ty.
Storage es can vary on the t
quality of the food, the way its or
container used, (in c son to air and ty),
the t rature it stored in. Ice crystals f
inside your are it indicates the air
t av condensed.
NOTE: Let w foods cool off at r t ratur
for ro ately 30 then wr accordingly
the ethods ove and freeze. By letting y
w foods cool off fore you introduce to y
freez save y rgy.
WARNING
SUFFOCATING DANGER
Adequate ventilation is required when using dry ic
ry ice is oxide (CO2). When it e rates
roduces oxygen, causing dizziness, slight headache
unconsciousness or death. not inhale these r
and r ventilate the r while in use f dry ic
USING YOUR REFRIGERATORUSING YOUR REFRIGERATOR
REFRIGERATOR SHELVES
The glass shelves in your refrigerator are adjustable to
meet your individual storage needs.
Adjusting the shelves to fit different heights of items will
make finding the exact item you want easier. Doing so
will also reduce the amount of time the refrigerator door
is open which will save energy.
IMPORTANT: Do not clean glass shelves with warm water
while they are cold. Shelves may break if exposed to
sudden temperature changes or impact.
NOTE: Glass shelves are heavy. Use special care when
removing them.
Adjusting Shelves
Remove shelves from the shipping position and replace
shelves in the position you want.
To remove a shelf: Tilt up the back of the shelf in the
direction of and lift it in the direction of . Pull
the shelf out.
To reinstall a shelf: Slide the shelf into the guides
until it stops.
PANTRY DRAWER (on some models)
To remove the Pantry Drawer: Grasp the drawer handle
and pull it forward to the drawer stop. Lift up and pull
out.
T
o replace the Pantry Drawer: Slide the drawer back all
the way past the drawer stop.
1
2
12
1
2

15
USING YOUR REFRIGERATOR
Fill with potable water only.
ICE TRAY
Pour potable water to the indicated
level in the picture. Do not overfill
with water or ice cubes will be
difficult to remove.
For quick freezer, adjust the freezer
dial to 3.
Do not bend the ice tray, dping so
may result in damage to the tray.
To remove ice cubes easily, pour
water on the back of the tray soak
it in water before removing ice
cubes.
WARNING:
HUMIDITY CONTROLLED CRISPERS
The crispers provide fresher tasting fruit and vegetables
by letting you easily control humidity inside the drawer.
You can control the amount of humidity in the
moisture sealed crispers by adjusting the control to any
setting between VEGETABLES and FRUIT.
VEGETABLES keeps moist air in the crisper for
best storage of fresh, leafy vegetables.
FRUIT
lets moist air out of the crisper for best storage
of fruit.
To remove and install the crisper drawers:
1. Pull the crisper drawer out to the drawer stop.
2. Lift the front of the crisper up, then pull it straight out.
3. To install, slightly tilt up the front, insert the drawer into
the frame and push it back into place, past the
drawer stop.
To remove the crisper glass:
1. Remove the crisper drawers (as described above).
2. Reach in under the glass and lift up.
3. Gently push the glass up and out.
To remove the crisper cover:
1. Remove both crisper drawers.
2. Remove the crisper glass.
3. While holding the support and crisper cover, pull up
and out.
DOOR BINS
The door bins are removable
for easy cleaning and adjust-
ment.
1. To remove the bin, simply
lift the bin up and pull
straight out.
2. To replace the bin, slide it in
above the desired support
and push down until it
snaps into place.
NOTE: Some bins may vary in appearance and will only
fit in one location.
DAIRY BIN
1. To remove the Dairy Bin, simply lift up and pull out.
2. To replace the Dairy Bin, slide it in above the desired
support slots and push down until it stops.
Dairy Bin
Dairy Bin

16
WARNING
EXPLOSION HAZARD
Do not use flammable cleaners. Not following these
instructions can cause death, explosion or fire.
The refrigerator, as well as the freezer, do their own
de-freezing. This process does not prevent the build
up of contaminants, therefore it is suggested that you
clean both parts once a month; clean spilled liquids
immediately.
REFRIGERATOR CLEANING
Unplug your refrigerator.
Pull out all of the removable parts (such as the
vegetable and dairy doors).
Use a clean sponge (or a soft rag) and use it with
lukewarm water mixed with detergent. Do not use
abrasive or concentrated cleaners.
Hand wash it, and dry it thoroughly.
Plug the refrigerator back in.
OUTSIDE
NOTE: Avoid the usage of chemical products that
contain phosphates or bleach.
INSIDE (Allow freezer to slightly warm up a small
degree to prevent cloth from sticking)
In order to eliminate bad odors, clean the inside of
the refrigerator with a mixture of baking powder and
lukewarm water (one teaspoon of baking powder per cup
of water). Ensure that the powder dissolves thoroughly, in
order to prevent any sort of damage.
DOOR LINING AND GASKETS
Use only a mild detergent (such as dish soap).
PLASTIC PARTS (Covers and Panels)
Do not use abrasive, paper or rough products. These
could damage the product.
BACK COVER
WARNING
ELECTRICAL SHOCK HAZARD
Before you begin, either unplug the refrigerator or turn
off power at the circuit breaker or fuse box.
NOTE: Back Cover should only be
removed by a qualified technician.
In order to get an efficient
performance of your refrigerator,
clean the back cover of it at least
twice a year.
REPLACING REFRIGERATOR LIGHTS
The refrigerator and freezer compartment lights are
LED interior lighting, and service should be performed
by a qualified technician.
BACK
COVER
REFRIGERATOR CARE AND CLEANING
POWER INTERRUPTIONS
1. In case of a black out, call your electric company and
ask how long it will last.
2.In case of a 24 hour or less black out, do not open the
refrigerator; this will keep the food fresh.
3.In case of a longer black out, do one of the following
options:
Pull out all of the frozen food and keep them in an ice
chest.
Put 2 lbs (907 g) of frozen ice (make sure you use
gloves) for each square foot (28 L) inside the freezer.
This task will preserve the food fro 2 to 4 days.
In case you do not possess neither ice chest or dry ice,
consume your food as soon as possible.
REMEMBER: In a power failure, a full freezer stays cold
longer than a partially filled one. A freezer full of meat
stays cold longer than a freezer full of baked goods. If
you see that food contains ice crystals, it may be safely
refrozen, although the quality and flavor may be affected.
If the condition of the food is poor or if you feel it unsafe,
dispose of it.
WHEN GOING ON VACATION
If you decide to leave your refrigerator on when going
away, consider these steps:
1. Consume all of the perishable items and freeze the
rest.
2.Empty the ice bin.
If you decide to leave your refrigerator off:
1. Remove all of the food.
2.Unplug your refrigerator.
3.Clean and dry it well.
4.Make sure the doors stay open (use blocks or tape) in
order to prevent bad odors and fungi from happening.

17
WHEN MOVING
If you decide to take your refrigerator with you when
moving, consider the following:
1. Remove all of the food from it, and place the frozen
food in an ice chest with dry ice.
2.Unplug your refrigerator.
3.Empty the water from its tray.
4.Clean and dry it with a rag.
5.Pull out all of the removable parts, and wrap them with
adhesive tape.
6.Depending on the model of the refrigerator, lift the top
part of the refrigerator so it can roll with ease, or screw
the levelers so it won´t scratch the floor. Consult to the
section “Closing and Aligning Doors”.
7. Keep the doors closed with the cable glued to the
refrigerator cabinet with an adhesive tape.
When your refrigerator arrives to your home, put
everything back into place and read the section
“Refrigerator Installation” in order to obtain installation
preparation.
REFRIGERATOR CARE AND CLEANINGREFRIGERATOR CARE AND CLEANING
REFRIGERATOR CARE AND CLEANINGSMART FUNCTIONS
DOOR ALARM (On Some Models)
The Door Alarm function is designed to prevent refri-
gerator malfunctions that could occur if the refrigerator
door remains open. If the refrigerator door remains open
for longer than 1 minute, an alarm sounds at 30-second
intervals. The alarm will stop when both refrigerator
doors are closed properly.
NOTE: This function can not be deactivated.
Smart Diagnosis
LG ThinQ Application
This feature is only available on models with the
or logo.
Use this feature to help you diagnose and solve
problems with your appliance.
This featu re is only available on models with the
or logo.
The LG ThinQ application allows you to
communicate with the appliance using a
smartphone.
Search for the LG ThinQ application from the
Google Play Store or Apple App Store on a smart
phone.
•
Smart Diagnosis
If you experience a problem while using the
appliance, this smart diagnosis feature will help
you diagnose the problem.
Communicate with the appliance from a
smartphone using the convenient smart features.
• The application is subject to change for
appliance improvement purposes without
notice to users.
• Functions may vary by model
LG ThinQ Application Features
Installing the LG ThinQ
Application
N OTE
N OTE
• Follow instructions to download and install the
application.
• Run the LG ThinQ application and follow the
instructions in the application to register the
appliance.
• For reasons not attributable to LGE’s negligence, the
service may not operate due to external factors such as,
but not limited to, Wi-Fi unavailability, Wi-Fi disconnec-
tion, local appstore policy, or app unavailability.
• The feature may be subject to change without prior
notice and may have a different form depending on
where you are located.
Follow the instructions below to use the audible diagnosis
method.
• Launch the LG ThinQ application and select the Smart
Diagnosis feature in the menu. Follow the instructions for
audible diagnosis provided in the LG ThinQ application.
Using Audible Diagnosis to Diagnose Issues
N OTE
For best results, do not move the phone while
the tones are being transmitted.
1. Open the fridge door.
2. Press and hold the “Temperature Adjust” button until
you hear 4 beeps.
3.
4.
If the buzzer sounds 4 times, open the freezer
door and hold the phone near the speaker hole.
After the data transfer is complete, the diagnosis
will be displayed in the application.

18
UNDERSTANDING SOUNDS YOU MAY HEAR
Your new refrigerator may make sounds that your old one did not make. Most of the new sounds are normal. Hard
surfaces, like the floor, walls and cabinets, can make the sounds seem louder than they actually are. The following
describes the kinds of sounds you may hear and what may be causing them.
Clicking:
The defrost control will click when the automatic defrost
cycle begins and ends. The thermostat control (or
refrigerator control, depending on the model) will also
click when cycling on and off.
Rattling:
Rattling noises may come from the flow of refrigerant, the
water line, or items stored on top of the refrigerator.
Whooshing:
refrigerator and freezer compartments.
fan.
the refrigerator when the doors are open.
Gurgling:
As each cycle ends, you may hear a gurgling sound
caused by the refrigerant flowing through the cooling
system.
Popping:
Contraction and expansion of the inside walls.
Sizzling:
Water dripping on the defrost heater during a defrost
cycle.
Vibrating Noise:
If the side or back of the refrigerator is touching a
cabinet or wall, some of the normal vibrations may make
an audible sound. To eliminate the noise, make sure that
the sides and back cannot vibrate against any wall or
cabinet.
Dripping:
Water running into the drain pan during the defrost cycle.
Pulsating or High-Pitched Sound:
Your refrigerator is designed to run more efficiently to
keep your food items at the desired temperature.
The high efficiency compressor may cause your
new refrigerator to run longer than your old one,
but is still more energy efficient than previous models.
While the refrigerator is running, it is normal to hear
a pulsating or high-pitched sound.
Problem Possible Causes Solutions
Refrigerator is not
cooling.
The power supply cord is unplugged. Firmly plug the cord into a live outlet with
proper voltage (see Electrical & Grounding
Requirements).
A household fuse has blown or a
circuit breaker has tripped.
Replace the fuse or reset the circuit
breaker. If the problem persists, contact
an electrician.
The refrigerator control is set to the
OFF position.
Refer to the Setting the Controls section.
The refrigerator is in the defrost cycle. Wait about 30 minutes for defrost cycle
to end.
The OFF light is illuminated. The refrigerator is in DEMO mode. The
Demo Mode disables the cooling system
and only the lamps and display will work
normally.
To disable Demo Mode, press the
TEMPERATURE ADJUST button until you
set the desire temperature level. When
demo mode is deactivated, the OFF light will
turn off.
TROUBLESHOOTING GUIDE
TROUBLESHOOTING GUIDE
