LG DI-28Z12 User manual

Digital Satellite
Colour Television
OWNER'S MANUAL
Please read this manual carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote this
information to your dealer when you require service.
Model number :
Serial number :
P/NO : 3828VA0172D (PD8TA, 026A TX)
(3828VA0172C, 3840VA0024A/B, 3840VA0016A, 373-026F)
FOR THE GUARANTEE TERMS & CONDITIONS,
PLEASE REFER TO BACK COVER OF THIS MANUAL

2

Introduction
3
Your new television set can receive analogue terrestrial television
programmes (TV mode) from broadcasters including the BBC, ITV,
CH4, S4C and CH5* and digital satellite television and radio
programmes* from broadcasters including SKY, BBC, CH4 and
CH5 from BSkyB (SKY mode)**. Some functions of this TV are
only available for a specific receiving mode i.e. NICAM sound is
only available in TV mode, so references to NICAM in this manual
apply only to TV mode. Digital satellite broadcasts use MPEG 2
sound which is of the same high quality as NICAM but only
available in SKY mode.
* Subject to signal availability.
** Subject to the necessary viewing card.
When you first switch this TV on (and whenever you switch it off
and then on at the main power switch) there will be a delay of up
to one minute while the internal digital satellite receiver initializes
itself. If the set is in SKY mode the following message will be
displayed on the screen : Initializing... Please wait. This is normal
and not a fault.
When changing programme's in SKY mode there may be a delay
of several seconds before the picture appears, the picture or
sound may also freeze or stop momentarily when the new
programme is first displayed . Again this is normal and not a fault.
Note : This set is designed to receive analogue terrestrial and
BSkyB digital satellite broadcasts only. It is not designed to receive
digital satellite broadcasts from other satellites nor can it receive
analogue satellite broadcasts or digital terrestrial broadcasts. It
can be used to display the picture and sound from analogue or
digital satellite receivers and digital terrestrial receivers provided a
scart connection or aerial is used.
Sky digibox and SkyGuide are trademarks of British Sky Broadcasting Ltd.
This product incorporates copyright protection technology that is protected
by U.S. patents and other intellectual property rights. Use of this copyright
protection technology must be authorized by Macrovision, and is intended
for home and other limited pay per view uses only unless otherwise
authorized by Macrovision. Reverse engineering or disassembly is
prohibited.

Contents
Installation 5
Location and function of controls 6
Remote control handset / Battery installation
Front panel
Basic operation 9
On and off / Programme selection
Volume adjustment / Mute function
On screen menus 10
Menu selection
Station 11
Auto programme / Manual programme / Programme edit
Picture 16
Picture adjustment / Picture format selection
Sound 17
Sound adjustment / NICAM broadcast reception
Sound output selection
Special functions 19
Child lock / Sleep timer / Tilt
Teletext 20
Switch on/off / FASTEXT / Simple text / TOP text
Special teletext functions
Connection of external equipment 23
Aerial socket / Euro SCART socket(AV1)
Audio/Video in sockets(AV2) / S-video/Audio in sockets(S-AV)
Digital satellite dish socket(DISH INPUT)
Satellite out socket (SKY OUT)
Telephone line socket(TELEPHONE INPUT LINE)
RS-232
Audio out sockets(AUDIO OUT)
Digital satellite receiving 25
What is the digital satellite?
What is the SkyGuide
Getting started 26
Switch on/off / Changing programmes
Using SkyGuide 27
SkyGuide and remote control handset
TV Guide / Services
Extra information 35
Recording a satellite programme / Adding other Channels
Looking after your Sky Viewing Card
System setup 37
Further help 38
Solving digibox problems 39
Troubleshooting check list 40
Specification 41
Satellite specification 42
Guarantee Back Cover
4

Installation
Power
This set operates on a mains supply of 230V AC, 50Hz. In the
event of thunderstorms or powercuts, please pull out the aerial
plug, mains plug and telephone plug (wall socket end) and
unscrew the satellite 'F' plug. The use of aerial and telephone line
surge protectors is also recommended. These can be purchased
from your dealer.
Wiring
This set is supplied with a BS 1363 approved 13 amp mains plug,
fused at 5 amp. When replacing the fuse always use a 5 amp BS
1362, BSI or ASTA approved type. Never use this plug with the
fuse cover omitted. To obtain a replacement fuse cover contact
your dealer or "LG Electronics U.K. Ltd.".
If the type of plug supplied is not suitable for the mains sockets in
your home, then the plug should be removed and a suitable type
fitted. Please refer to the wiring instructions below:
Warning
A mains plug removed from the mains lead of this set must be
destroyed. A mains plug with bared wires is hazardous if inserted
in a mains socket.
Do not connect either wire to the earth pin, marked with the letter E
or with the earth symbol or coloured green or green and yellow.
If any other plug is fitted, use a 5 amp fuse, either in the plug, or at
the distribution board.
Important
The wires in this mains lead are coloured in accordance with the
following codes: BLUE: NEUTRAL
BROWN: LIVE
As the colours of the wires in the mains lead of this set may not
correspond with the coloured marking identifying the terminals in
your plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black. The wire which
is coloured brown must be connected to the terminal which is
marked with the letter L or coloured red.
Service
Never remove the back cover of the set as this can expose you to
very high voltage and other hazards. If the set does not operate
properly, unplug it and call your dealer.
Aerial
Connect the aerial cable to the socket marked +75 Ω on the back
cover. For the best reception an outdoor aerial should be used.
Location
Position your set so that no bright light or sunlight falls directly onto
the screen. Care should be taken not to expose the set to any
unnecessary vibration, moisture, dust or heat. Also ensure that the
set is placed in a position to allow a free flow of air. Do not cover
the ventilation openings on the back.
5

Location and function of controls
All the functions can be controlled with the remote control handset.
Some functions can also be adjusted with the buttons on the front
panel of the set.
Remote control handset
Before you use the remote control handset, please install the
batteries. See the next page.
1. POWER (rr)
switches the set on from standby or off to standby.
TV Off (yy)
switches only the TV off to standby.
2. SKY
selects SKY mode or switches the set on from standby.
TV GUIDE shows the TV guide screen.
BOX OFFICE shows the Box office screen.
SERVICES shows the customer Services screen.
INTERACTIVE shows the Interactive services screen.
colour buttons selects the corresponding colour option shown
on screen.
BACK UP shows the previous screen.
INFO shows information about the programme you have
highlighted.
HELP for help on using the SkyGuide.
3. TV/AV
selects TV or AV modes.
clears the menu from the screen.
switches the set on from standby.
4. ARC (Aspect Ratio Control)
changes the picture format.
5. MUTE
switches the sound on or off.
6. VOLUME +/-
adjusts the volume.
7. D/E(Up/Down)
selects a programme in SKY mode or a menu item.
F/G(Left/Right)
adjusts menu settings.
OK/select
accepts your selection or displays the current mode.
8. NUMBER/alphabet BUTTONS
selects a programme directly.
alphabet a~z as they become available.
9. SSM (Sound Status Memory)
recalls your preferred sound setting.
10. PSM (Picture Status Memory)
recalls your preferred picture setting.
6
TV offI/II
MENU
ARC
MUTE
VOLUME PR/CH
TV/AV
1 2 3
4 5 6
7 8 9
pqrs
SSM PSM
0
wxyz
mno
def
abc
jklghi
tuv
POWERSKY
OK
select
i
T
V
G
U
I
D
E
B
O
X
O
F
F
I
C
E
S
E
R
V
I
C
E
S
I
N
T
E
R
A
C
T
I
V
E
TEXT
HELP
INFO
BACK UP
1
2
2
3
4
5
66
7
8
10
9

Location and function of controls
11. DUAL I/II
selects the language during dual language broadcast.
selects mono sound during stereo broadcast.
12. PR/CH +/-
selects a programme.
13. MENU
calls the main menu or clears a menu.
14. TELETEXT BUTTONS
These buttons are used for the teletext.
For further details, see the 'Teletext' section.
15. VCR BUTTONS
control a LG video cassette recorder.
Battery installation
The remote control handset is powered by two AAA(Alkaline) type
batteries. To load the batteries, turn the handset over and open the
cover of the remote control handset until the battery compartment
is exposed. Install two batteries as indicated by the polarity
symbols( and ) marked inside the compartment.
Note : To avoid damage from possible battery leakage, remove the
batteries if you do not plan to use the remote control handset for an
extended period of time.
7
TV offI/II
MENU
ARC
MUTE
VOLUME PR/CH
TV/AV
1 2 3
4 5 6
7 8 9
pqrs
SSM PSM
0
wxyz
mno
def
abc
jklghi
tuv
POWERSKY
OK
select
i
T
V
G
U
I
D
E
B
O
X
O
F
F
I
C
E
S
E
R
V
I
C
E
S
I
N
T
E
R
A
C
T
I
V
E
TEXT
HELP
INFO
BACK UP
11
12
13
15
14

Location and function of controls
1. MAIN POWER
switches the set on or off.
2. PANEL DOOR OPENER
opens the front panel door by pressing it.
3. INTERACTIVE CARD SLOT
insert your Interactive Card here when using
Interactive services, once available, and only
when an instruction to do so appears on screen.
4. SKY VIEWING CARD SLOT
insert your Sky Viewing Card here.
5. S-VIDEO/AUDIO IN SOCKETS (S-AV)
Connect the video out socket of an S-VIDEO
VCR to the S-VIDEO socket. Connect the
audio out sockets of the S-VIDEO VCR to the
audio sockets as in AV2.
6. AUDIO/VIDEO IN SOCKETS (AV2)
Connect the audio/video out sockets of
external equipment to these sockets.
7. TV/AV/SKY
selects TV, AV or SKY modes.
clears the menu from the screen.
switches the set on from standby.
ARC (Aspect Ratio Control)
changes the picture format.
MENU
calls the main menu or clears a menu.
ii
(Information)
shows information about the programme you
have highlighted.
BACK UP
shows the previous screen.
TV GUIDE
shows the TV guide screen.
8. OK/select
accepts your selection or displays the current
mode.
F/G(Volume Down/Up)
adjusts the volume(In SKY mode, it's
available after selecting the VOLUME menu).
adjusts menu settings.
D/E(Programme Up/Down)
selects a programme or a menu item.
9. rr(Power/Standby) INDICATOR
green when power on.
red when the set(TV & SKY digibox) is in
standby mode.
orange colour when only the TV is in standby
mode.
MESSAGE INDICATOR
yellow Message waiting.
ON-LINE INDICATOR
green on-line (using the telephone line).
10. REMOTE CONTROL SENSOR
8
POWER
DOOR OPEN
INTERACTIVE CARD
SKY VIEWING CARD
S-VIDEO
BACK UP
TV GUIDE
MENUTV/AV ARC
OK
MESSAGE ON LINE
select
VIDEO AUDIO
L/MONO R
AV 2
SKY
234568
710
19
Front panel

Basic operation
On and off
1. Press the main power button to switch the set on.
2. If the set is in standby mode (when the standby indicator is red),
press the POWER (rr),TV/AV, or SKY button on the remote
control handset to fully switch the set on.
3. Press the POWER (rr)button on the remote control handset.
The set reverts to standby.
4. Press the main power button again the to switch the set off.
Note :
a. If you wish to switch only the TV off, press the TV off (
yy
) button.
To switch on, press the POWER (
rr
), TV/AV or SKY button.
b. If no broadcast signal is received for about 10 minutes, the set
will automatically switch itself to TV off mode.
c. If, while the set is switched on, the mains plug is disconnected
the set will switch to standby or power on when the mains plug
is replaced in mains power socket.
Programme selection
You can select a programme number with the PR/CH +/- or
NUMBER buttons.
Note : In SKY mode, each time you change programme, the
Search and Scan banner appears on the screen.
Volume adjustment
Press the VOLUME +/- button to adjust the volume.
Mute function
Press the MUTE button. The sound is switched off and the display
WWappears. You can cancel it by pressing the MUTE, VOLUME +/-,
SSM or I/II (only TV mode) button.
TV offI/II
MUTE
VOLUME PR/CH
TV/AV
1 2 3
4 5 6
7 8 9
pqrs
SSM
0
wxyz
mno
def
abc
jklghi
tuv
POWERSKY
9

On screen menus
10
The dialogue between you and your set takes place on screen with
an operator menu. The buttons required for the operating steps
are also displayed.
Menu selection
1. Press the MENU button.
2. Select the desired menu with the F/Gbutton then press the
OK button. Or you can press one of the four COLOURED
buttons corresponding to the coloured menu you want to
select.
3. The selected menu item changes from black to red.
Note :
a. In AV mode, only the AV name is selected in the STATION menu .
b. In Teletext mode, menus are not displayed.
c. In SKY mode, the STATION menu can not be selected the
VOLUME menu is displayed instead.
MENU
OK
select
Special menu
Sound menu
Picture menu
Station menu (TV mode)
Main menu
®
®
®
®
®

Station
The station menu contains two selections for station search and
storage - Auto Programme and Manual Programme.
Auto programme
By auto programming, stations can be searched for and stored
automatically.
1. Press the MENU button then the RED button.
2. Select Auto Programme with the D/Ebutton then press
the OK button.
3. Select Start with the D/Ebutton.
Enter a double digit programme number at which storing is to
begin with the F/Gor NUMBER buttons.
In this way, all further stations are stored from this programme
number onwards. Up to 100 (00 to 99) stations can be stored.
4. Select Execute with the D/Ebutton.
5. Press the OK button to start auto programming.
All receivable stations are stored. The programme name is also
stored for stations which broadcast PDC(Programme Delivery
Control) or TELETEXT data, the stored stations are automatically
sorted.
If no station name can be assigned to a station, the channel
number is assigned and stored.
To stop auto programming, press the OK or MENU button.
The programme edit mode appears after completing auto-
programming. Exit the menu by pressing the TV/AV button if you
agree with the programme assignment. If not, you can edit the
programmes as you prefer. See the 'Programme edit' section.
You can now recall the stored TV programmes with the D/Eor
NUMBER buttons.
MENU
TV/AV
1 2 3
4 5 6
7 8 9
0
mno
def
abc
jklghi
tuv
OK
select
11
®
~

Manual programme
1. Press the MENU button then the RED button.
2. Select Manual Programme with the D/Ebutton then
press the OK button.
3. Select Range with the D/Ebutton.
4. Select the frequency range with the F/Gbutton.
You can select between the ranges V/UHF and the special
channel range Cable for cable TV systems.
5. Select Channel with the D/Ebutton.
Enter the double digit channel number with the F/Gor
NUMBER buttons.
You can also search for stations by pressing the OK button.
The search stops when a station has been found. If the picture
and sound are not perfect or you want another station, restart
the search.
6. If reception condition is not good, select Fine with D/E
button.
Then carry out fine tuning for the best picture and sound quality
with the F/Gbutton.
7. Select Name with the D/Ebutton.
8. Enter a station name with the F/Gbutton.
A programme name has five positions and you can use the
letters Ato Z, blank, symbols +,-or numbers 0to 9.
Press the OK button to store one position, and the next
position is called.
If you do want to stop entering the name, execute the next
step.
Station
MENU
1 2 3
4 5 6
7 8 9
0
mno
def
abc
jklghi
tuv
OK
select
12
®
®
.

Station
9. Select Auto AV with the D/Ebutton then the desired input
source(On or Off) with the F/Gbutton.
VCR automatic switching
If your VCR outputs a switching voltage (Euro SCART pin 8, 4:3
12V, 16:9 8V) when it is switched to playback, select Auto AV On.
You can now watch your recordings, normal or wide screen with
automatic picture size and VCR selection.
10. Press the MENU button to store the searched station.
11. Enter the double digit programme number with the F/Gor
NUMBER buttons.
12. Select Store? with the D/Ebutton.
13. Select Yes to execute or No to cancel storage with the F/G
button.
14. Press the OK button.
Repeat steps 3 to 14 for further programmes.
Exit the menu by pressing the TV/AV button.
Note : NTSC can only be received in AV mode. VCR automatic
switching does not operate while in SKY mode.
13
MENU
TV/AV
1 2 3
4 5 6
7 8 9
0
mno
def
abc
jklghi
tuv
OK
select
~
.
?
®

Station
Programme edit
This function enables you to delete, move or skip the stored
programmes as you like. You can also store other stations at some
programme numbers without changing the order of programmes.
Press the MENU button then the RED button.
Select Programme Edit with the D/Ebutton then press the OK
button.
Deleting programmes
1. Select the programme to be deleted with the D/Ebutton.
2. Press the RED button.
3. Press the OK button to delete the programme.
The selected programme is deleted and all the following
programmes are shifted backward one position.
Exit the menu by pressing the TV/AV button.
Inserting a free programme number
This function enables you to insert programmes later.
A programme memory is only displayed with the channel number
in the programme table.
New station data can be stored in this programme memory.
1. Select a programme number for insertion with the D/E
button.
2. Press the GREEN button.
All the following programmes are shifted forward one position to
the next programme number.
You can enter station data at a free programme number with the
'Manual Programme' menu.
Exit the menu by pressing the TV/AV button.
Moving programmes
1. Select the programme to be moved with the D/Ebutton.
2. Press the YELLOW button.
3. Move the programme to the desired programme number with
the D/Ebutton.
4. Press the OK or MENU button.
The station names and data are moved.
Exit the menu by pressing the TV/AV button.
14
MENU
TV/AV
OK
select
®

‘
“
®

Skipping programmes
1. Select the programme to be skipped with the D/Ebutton.
2. Press the BLUE button.
The station name turns grey and the programme is skipped.
When you press the BLUE button again, the station name returns
to black and skip is cancelled. With the D/Ebutton the skipped
programme cannot be found. If you want to find the skipped
programme, directly enter the programme number with the
NUMBER buttons.
Exit the menu by pressing the TV/AV button.
Note : The programme number 01 cannot be skipped.
Changing the station name
You can select a station name from the name list. This is useful, for
example, in case of stations without station name.
1. Select the programme at which you want to change a name
with the D/Ebutton.
2. Press theGbutton.
3. Select a name from the name list with the D/Eor MENU
button.
4. Store the name with the OK button.
5. Press the Fbutton.
Repeat steps 1 to 5 for further programmes.
Exit the menu by pressing the TV/AV button.
MENU
TV/AV
OK
select
15
Station

‘
“
®

16
Picture adjustment
You can adjust picture contrast, brightness, colour intensity, tint
and sharpness to the level you prefer.
1. Press the MENU button then the GREEN button.
2. Select a desired item with the D/Ebutton.
3. Adjust the value with the F/Gbutton.
Note : Tint adjustment is available when receiving a NTSC signal
via the AV input sockets.
At this point you can complete your adjustment or store your
setting for immediate recall by following steps 4 to 7.
4. Select Store with the D/Ebutton.
5. Press the OK button.
6. Select Favorite 1 or Favorite 2 with the D/Ebutton.
7. Press the OK button.
Exit the menu by pressing the TV/AV button.
Your setting for picture is now stored are remains your preferred
setting until you store different values with this menu. Your
preferred setting is retained even when the set is switched off by
the main power button.
To recall your preferred setting, press the PSM button until the
desired picture (Standard, Favorite 1 or Favorite 2)appears.
The Standard picture is programmed for good picture reproduc-
tion at the factory and cannot be changed.
Picture format selection
You can watch the TV in various picture formats.
Press the ARC button to switch to 4:3, 16:9, Zoom 1, Zoom 2 or
Auto picture format. Also see page 13, VCR automatic switching.
4:3 Normal
This is normal picture size 4 by 3 as displayed on all TV sets.
16:9 Wide screen
Cinema screen pictures are viewed like this. Some TV stations
broadcast programmes (mainly films) in the mode. To enjoy the
cinema picture, select this mode.
Zoom 1
The normal 4 by 3 picture is magnified to fill the whole screen but
the extreme top and bottom of the picture are lost.
Zoom 2
Similar to Zoom 1 but the picture is shifted upwards so that
subtitles at the bottom of the picture can be viewed, therefore the
top of the picture is lost.
Auto Picture format
When your TV receive the wide screen signal, it will automatically
change to the picture format to be sent.
If you want to change the desired picture format, press the ARC
button.
Note : Satellite 16:9 Wide screen. Some TV stations (BBC)
broadcast programmes in Wide screen 16:9 format on Digital
Satellite but the actual picture has black bands at the side showing
a smaller 14:9 display. This has done by the broadcaster to retain
compatibility with non wide screen TV’s. Pressing the ARC button
will not expend the picture any further as the broadcast is actually
in 16:9 mode. If you view the same programme on terrestrial
analogue the picture will probably be broadcast in 4:3 and
therefore the ARC will expand the picture to 16:9 mode. This is not
a fault of the TV but is due to the way some broadcasters transmit
their programmes differently on digital and analogue formats.
®
MENU
ARCTV/AV
PSM
OK
select

Sound
Sound adjustment
You can adjust the sound treble, bass, balance, UBB (Ultra Bass
Booster) and surround as you prefer. The surround sound creates
the sound effect surrounded around as in a concert hall and UBB
stresses and emphasizes heavy sound.
1. Press the MENU button then the YELLOW button.
2. Press the D/Ebutton to select a desired item.
3. Adjust the value with the F/Gbutton.
You can store the values you have set under the sound menu.
4. Select Store with the D/Ebutton.
5. Press the OK button.
6. Select Favorite 1 or Favorite 2 with the D/Ebutton.
7. Press the OK button.
Exit the menu by pressing the TV/AV button.
To recall your preferred setting press the SSM button until the
sound (Standard, Favorite 1 or Favorite 2)appears. The
Standard sound is programmed for good sound reproduction at
the factory and cannot be changed.
17
I/II
MENU
SSM
OK
select
®

Sound
NICAM broadcast reception
This set can receive the high quality NICAM (Near Instantaneous
Companding Audio Multiplex) digital sound.
Sound output can be selected according to type of the received
broadcast as follows by pressing the I/II button repeatedly.
1. When NICAM mono is received, you can select NICAM
MONO or FM MONO.
2. When NICAM stereo is received, you can select NICAM
STEREO or FM MONO. If the stereo signal is weak, switch to
FM mono.
3. When NICAM dual is received, you can select DUAL I, DUAL
II,DUAL I II or FM MONO.
Language selection for dual language broadcast
If a programme is received in two languages (dual language), you
can switch to DUAL I, DUAL II or DUAL I II by pressing the I/II
button repeatedly.
DUAL I sends the primary broadcast language to the loudspeakers.
DUAL II sends the secondary broadcast language to the loudspeakers.
DUAL I II sends a separate language to each loudspeaker.
Sound output selection
In AV mode, you can select output sound for the left and the right
loudspeakers.
Repeatedly press the I/II button to select the sound output.
L+R : Audio signal from audio L input is sent to left loudspeaker
and audio signal from audio R input is sent to right loud-
speaker.
L+L : Audio signal from audio L input is sent to left and right
loudspeakers.
R+R : Audio signal from audio R input is sent to left and right
loudspeakers.
I/II
18

Special functions
Child lock
The TV can be set so that the remote control handset is needed to
control it.
This feature can be used to prevent unauthorized viewing.
1. Press the MENU button then the BLUE button.
2. Select Child Lock with the D/Ebutton.
3. Select On with the F/Gbutton on the remote control handset.
Exit the menu by pressing the TV/AV button.
With the child lock on, the display Child Lock appears on the screen
if any button on the front panel is pressed while viewing the TV.
Sleep timer
You don't have to remember to switch the set off before you go to
sleep. The sleep timer automatically switches the set to standby
after the preset time elapses.
1. Press the MENU button then the BLUE button.
2. Select Sleep Timer with the D/Ebutton.
3. Set the desired time with the F/Gbutton.
Exit the menu by pressing the TV/AV button.
You can set the sleep timer up to four hours at intervals of ten
minutes. The timer begins to count down from the number of
minutes selected.
Note : To cancel this function, press the
F
/
G
button to select --:-- .
Tilt
In order to obtain the best picture, i.e. least tilt please set the tilt as
follows:
In the Northern hemisphere to 0, +1 or +2
1. Press the MENU button then the BLUE button.
2. Select Tilt with the D/Ebutton.
3. Adjust the purity with the F/Gbutton.
Exit the menu by pressing the TV/AV button.
19
MENU
TV/AV
®

Teletext
Teletext is a free service broadcast by most TV channels which
gives up-to-the-minute information on news, weather, television
programmes, share prices and many other topics.
The teletext decoder of this TV can support the Simple, TOP and
FASTEXT systems. Simple(standard teletext) consists of a number
of pages which are selected by directly entering the corresponding
page number. TOP and FASTEXT are more modern methods
allowing quick and easy selection of teletext information.
Switch on/off
Press the TEXT button to switch to teletext. The initial page or the
last selected page appears on the screen. The teletext decoder will
be in the teletext mode transmitted by the broadcast station.
Two page numbers, TV channel name, date and time are displayed
on the screen headline. The first page number indicates your
selection while the second shows the current page displayed.
Press the TEXT or TV/AV button to switch off teletext. The
previous mode reappears.
FASTEXT
The teletext pages are colour coded along the bottom of the screen
and are selected by pressing the corresponding coloured button.
Page selection
1. Press the button to select the index page.
2. You can select the pages which are colour coded along the
bottom line with the same coloured buttons.
3. Corresponding to the Simple text, you can select a page by
entering its three digit number with the NUMBER buttons in
FASTEXT mode.
4. The D/Ebutton can be used to select the preceding or
following page.
TV/AV
1 2 3
4 5 6
7 8 9
TEXT
INFO
0
mno
def
abc
jklghi
tuv
i
20
i
