OWNER’S MANUAL
MULTI POS MONITOR
L1710LT
Please read this manual carefully before operating the
your set and retain it for future reference.
MULTI POS MODELS
ENG
ENGLISH

2
ENG
ENGLISH
TABLE OF CONTENTS
CONTENTS
3ASSEMBLING AND PREPARING
3Unpacking
4Parts and buttons
5Setting up the Monitor set
5- Mounting on a table
6- Basic Adjustments of the Stand
7- Detaching the Stand
8- Mounting on a wall
9USING THE MONITOR SET
9Connecting to a RGB Cable
9- Using the PC
9- Using the MAC
10 To Use Touch Screen
10 - USB cable for the touch screen
11 CUSTOMIZING SETTINGS
11 Accessing main menus
12 Customizing settings
12 - SETUP settings
13 - COLOR settings
14 - TRACKING settings
15 - SETUP settings
16 - F·ENGINE settings
17 TROUBLESHOOTING
19 SPECIFICATIONS

3
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual product
and accessories.
yDo not use any pirated items to ensure the safety and product life span.
yAny damages or injuries by using pirated items are not covered by the warranty.
yThe accessories supplied with your product may vary depending on the model.
yProduct specifications or contents in this manual may be changed without prior notice due to upgrade
of product functions.
yUser must use shielded signal interface cables (D-sub 15 pin cable) with ferrite cores to maintain
standard compliance for the product.
CAUTION
NOTE
Power Cord
CD(Owner's Manual/
Software Installation)
Easy Setup Guide Cards
Adaptor

4
ENG
ENGLISH
ASSEMBLING AND PREPARING
yYou can set the Power indicator to on or off by selecting OPTION in the main menus.
NOTE
Parts and buttons
button Description
(Power Button) Turns the power on or off.
AC-IN LAN SERVICE
Power Indicator
yLighting On: Turned on
yLighting Off: Turned off
Connection panel ( See p.4)
(Power Button)

5
ENG
ENGLISH
ASSEMBLING AND PREPARING
Setting up the Monitor set
Mounting on a table
1Lift and tilt the Monitor set into its upright
position on a table.
Leave a 10 cm (minimum) space from the wall
for proper ventilation.
2Connect the Power Cord to a wall outlet.
3Press button on the front switch panel to
turn the power on. When monitor power is
turned on, the 'Self Image Setting Function' is
executed automatically.
10 cm
10 cm
10 cm
10 cm
AC-IN
Using the Kensington security system
The Kensington security system connector is
located at the back of the Monitor set. For more
information of installation and using, refer to the
manual supplied with the Kensington security
system or visit http://www.kensington.com .
Connect the Kensington security system cable
between the Monitor set and a table.
The Kensington security system is optional.
You can obtain additional accessories from
most electronics stores.
NOTE

6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Basic Adjustments of the Stand
1Adjust the angle of the panel as follows.
yTilt Range : 15° to 66°
Do not push the stand
with basic adjustment
to the direction of the
panel. The product may
fall down to hurt people,
or cause product
disorder or screen
damage.
CAUTION
yPush back the panel to the end, and use
from the point that it automatically returns.
15°
66°
Panel
Stand

7
ENG
ENGLISH
ASSEMBLING AND PREPARING
2After adjusting the angle of the panel for
convenience, lock with the locking handle to.
Prevent the product from moving when users
touch the screen.
yThe state which the stand locking handle is
released
yThe state which the stand locking handle is
locked
Detaching the Stand
This Monitor set satisfies the specifications of the
Wall mount plate or the interchange device.
1Place the monitor with its front facing
downward on a soft cloth.
2Separate the head and the stand with the use
of a screwdriver.
3Remove 4 screws and pull out the Stand from
the Monitor set.

8
ENG
ENGLISH
ASSEMBLING AND PREPARING
yDisconnect the power cord first, and then
move or install the Monitor set. Otherwise
electric shock may occur.
yIf you install the Monitor set on a ceiling or
slanted wall, it may fall and result in severe
injury. Use an authorized LG wall mount
and contact the local dealer or qualified
personnel.
yDo not over tighten the screws as this may
cause damage to the Monitor set and void
your warranty.
yUse the screws and wall mounts that
meet the VESA standard. Any damages
or injuries by misuse or using an improper
accessory are not covered by the warranty.
yUse the screws that are listed on the VESA
standard screw specifications.
yThe wall mount kit includes an installation
manual and necessary parts.
yThe wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.
yThe length of screws may differ depending
on the wall mount. Be sure to use the proper
length.
yFor more information, refer to the
instructions supplied with the wall mount.
CAUTION
NOTE
Model N1710LT
VESA (A x B) 75 x 75
Standard screw M4
Number of screws 4
Wall mount bracket
(optional)
RW120
Mounting on a wall
For proper ventilation, allow a clearance of 10
cm on each side and from the wall. Detailed
installation
instructions are available from your dealer, see the
optional Tilt Wall Mounting Bracket Installation and
Setup Guide.
If you intend to mount the Monitor set to a wall,
attach Wall mounting interface (optional parts) to
the back of the set.
When you install the Monitor set using the wall
mounting interface (optional parts), attach it
carefully so it will not drop.
Please use VESA standard as below.
y784.8 mm (30.9 inch) and under
* Wall Mount Pad Thickness : 2.6 mm
* Screw : Φ4.0 mm x Pitch 0.7 mm x
Length 10 mm
y787.4 mm (31.0 inch) and above
* Please use VESA standard wall mount pad
and screws.
10 cm
10 cm
10 cm
10 cm

9
ENG
ENGLISH
USING THE MONITOR SET
yThe display link and EST network USB setting utility should already be installed before connecting
the power cable for the 2nd POS (monitor).
yAs of April 2011, the host POS authorized by the network POS is the HANASIS MICUS37 model.
For additional models, visit http://networkmonitor.lge.com.
yThe warranty does not cover any damage caused by the use of products other than the authorized
host POS.
yThe LAN and USB cables are optional. You can purchase them from an electronics store, online
stores, or your local LG stockist.
yYou can connect up to five monitors to the host POS. If you need to connect more monitors than the
number of ports in the router, use the switching hub to connect.
CAUTION
NOTE
USING THE MONITOR SET
Connecting to a LAN Cable
AC-IN LAN SERVICE
Router
USB Cable
(Not included)
LAN Cable
(Not included)
LAN Cable
(Not included)
LAN Cable
(Not included)
LAN Cable
(Not included)
Not included
Option
2nd POS (Monitor)
2nd POS (Monitor)
Switching
hub
Host POS
1Connect the router or switching hub to the
monitor with a LAN cable.
2Remove the power cable from the 2nd POS
(monitor).
3Install the display link and EST network USB
setting utility onto the host POS, and then
reboot it.
4Connect the power cable to the 2nd POS
(monitor).
5Install the LG network service driver, and check
that the screen blinks as many times as the
number of 2nd POSs (monitors), and then
reboot it.
6Check that the 2nd POSs (monitors) operate
normally and also that the touch response
works properly.
7Install SoftXpand Xpress.

10
ENG
ENGLISH
CUSTOMIZING SETTINGS
CUSTOMIZING SETTINGS
Accessing main menus
1Press MENU to access the main menus.
2Press the Navigation buttons to scroll to one of the following menus and press AUTO/SET.
3Press the Navigation buttons to scroll to the setting or option you want and press AUTO/SET.
4When you are finished, press MENU Button twice.
When you return to the previous menu, press MENU Button once.
COLOR ( See p.11)
Sets the time, date,
or Timer feature
PICTURE ( See p.11)
Sets the time, date,
or Timer feature
TRACKING ( See p.11)
Sets the time, date,
or Timer feature
SETUP ( See p.11)
Sets the time, date,
or Timer feature
SETUPCOLOR TRACKINGPICTURE

11
ENG
ENGLISH
CUSTOMIZING SETTINGS
Customizing settings
SETUP settings
1Press MENU to access the main menus.
2Press the Navigation buttons to scroll to SETUP and press OK.
3Press the Navigation buttons to scroll to the setting or option you
want and press OK.
- To return to the previous level, press MENU.
4When you are finished, press EXIT.
When you return to the previous menu, press MENU.
The available Programme settings are described in the following:
Menu Description
BRIGHTNESS To adjust the brightness of the screen.
CONTRAST To adjust the contrast of the screen.
GAMMA Set your own gamma value. : -50/0/50
On the monitor, high gamma values display whitish images and low gamma values display high
contrast images.
BRIGHTNESS
CONTRAST
GAMMA

12
ENG
ENGLISH
CUSTOMIZING SETTINGS
COLOR settings
1Press MENU to access the main menus.
2Press the Navigation buttons to scroll to PICTURE and
press OK.
3Press the Navigation buttons to scroll to the setting or
option you want and press OK.
- To return to the previous level, press MENU.
4When you are finished, press EXIT.
When you return to the previous menu, press
MENU.
The available picture settings are described in the following:
Menu Description
PRESET sRGB Set the screen color to fit the sRGB standard color specification.
6500K Slightly reddish white.
9300K Slightly bluish white.
RED Set your own red color levels.
GREEN Set your own green color levels.
BLUE Set your own blue color levels.
COLOR
PRESET
RED
GREEN
BLUE

13
ENG
ENGLISH
CUSTOMIZING SETTINGS
TRACKING settings
1Press MENU to access the main menus.
2Press the Navigation buttons to scroll to AUDIO and press
OK.
3Press the Navigation buttons to scroll to the setting or
option you want and press OK.
- To return to the previous level, press MENU.
4When you are finished, press EXIT.
When you return to the previous menu, press
MENU.
The available audio options are described in the following:
Menu Description
SHARPNESS To adjust the clearness of the screen.
TRACKING
SHARPNESS

14
ENG
ENGLISH
CUSTOMIZING SETTINGS
SETUP settings
1Press MENU to access the main menus.
2Press the Navigation buttons to scroll to TIME and press OK.
3Press the Navigation buttons to scroll to the setting or option you
want and press OK.
- To return to the previous level, press MENU.
4When you are finished, press EXIT.
When you return to the previous menu, press MENU.
The available time settings are described in the following:
Menu Description
LANGUAGE To choose the language in which the control names are displayed.
OSD
POSITION
To adjust position of the OSD window on the screen.
SOUND xxxxxxx
POWER
INDICATOR
Use this function to set the power indicator on the front side of the monitor to ON or OFF.
If you set OFF, it will go off.
If you set ON at any time, the power
indicator will automatically be turned on.
FACTORY
RESET
Restore all factory default settings except "LANGUAGE."
Press the ▼ , ▲ buttons to reset immediately.
yIf this does not improve the screen image, restore the factory default settings.
yIf necessary, perform the white balance function again.
NOTE
SETUP
LANGUAGE ENGLISH
HORIZONTAL
VERTICAL
SOUND ON 1
POWER INDICATOR ON
FACTORY RESET NO
OSD POSITION

15
ENG
ENGLISH
TROUBLESHOOTING
TROUBLESHOOTING
Check the following before calling for service.
No image appears
Is the power cord of the display
connected?
yCheck and see if the power cord is connected properly to the power
outlet.
Is the power indicator light on?
yPress the Power button.
Is the power on and the power
indicator blue or green?
yAdjust the brightness and the contrast.
Is the power indicator flickering?
yIf the display is in power saving mode, try moving the mouse or
pressing any key on the keyboard to bring up the screen.
yTry to turn on the PC.
Do you see a "OSD LOCKED" message on the screen?
Do you see “OSD LOCKED” when
you push MENU button?
yYou can secure the current control settings, so that they cannot be
inadvertently changed. You can unlock the OSD controls at any time
by pushing the MENU button for several seconds: the message
y“OSD UNLOCKED” will appear.
Display image is incorrect
The screen color is mono or
abnormal.
yCheck if the signal cable is properly connected and use a screwdriver
to fasten if necessary.
yMake sure the video card is properly inserted in the slot.
ySet the color setting higher than 24 bits (Color Quality) at Control
Panel ►Settings.
The screen blinks.
yCheck if the screen is set to interlace mode and if yes, change it to the
recommend resolution.
Touch screen does not work.
Did you install the touch screen
driver?
yInstall the touch screen driver on the installation CD bundled with the
product.
yMake sure that the USB cable for touch screen is connected to your
PC.
yMake sure your PC and accessories are USB-enabled.

16
ENG
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
Display Screen Type 43.27 cm (17.0 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size: 43.27 cm
Pixel Pitch 0.264 mm x 0.264 mm (Pixel Pitch)
Video Signal Resolution 1280 x 1024 @75 Hz (Fixed)
Horizontal Frequency Not Supported
Vertical Frequency Not Supported
Input Form Separate TTL / SOG (Sync On Green)
Input Connector Lan cable
Rated Voltage AC 100-240 V~ 50 / 60 Hz
Power
Consumption
On Mode : 25 W (Typ.) - LAN ON
Sleep Mode ≤ 7 W
Off Mode ≤ 1 W
Dimensions Width x Height x Depth
With Stand 369.6 mm x 315 mm x 94.6 mm
Without Stand 369.6 mm x 315 mm x 62.4 mm
Weight
Tilt Range 15° to 66°
Environmental
conditions
Operating Temperature
Operating Humidity
10°C to 35 °C
20 % to 80 % non-Condensing
Storage Temperature
Storage Humidity
-10°C to 60 °C
5 % to 90 % non-Condensing
Product specifications shown above may be changed without prior notice due to upgrade of product functions.
L1710LT
HANASIS MICUS37
Indicator
Resolution Horizontal Frequency(kHz)
On Mode Blue
Sleep Mode Blue Color Blinking
Off Mode Off
Host POS All-in-One POS System (MICUS37) Product of Hanasis
CPU Intel Core 2 Duo CPU E7600 @ 3.06 GHz
RAM 2 GB
HDD 40 GB
OS Embedded POS Ready 2009 Ver 2.0 SP3 (.NET Framework 3.5 must be installed on
your computer.)
Multi user Up to 5 via router
Interface RJ45 (supporting TCP/IP)
Resolution 1280*1024 only
USB 4 USB ports (devices other than the receipt printer, barcode scanner, card reader, key-
board/mouse are not supported)

17
ENG
ENGLISH
SPECIFICATIONS
PROPER POSTURE
The proper posture for using the product when seated.
Your gaze should fall
slightly lower than your
natural eye level.
Stand tilt Range
15° to 30°
Adjust the location of
the Monitor set to avoid
it reflecting light.
yAdjust the screen so that you can comfortably look at it at a slight downward angle from your natural eye level.
yTake a break for approximately 10 minutes every hour to reduce any fatigue caused by long-time usage.
yThe stand of the touch monitor allows the product to be used in the optimum position.
yAdjust the stand angle between 15 and 30 degrees to create the optimum user environment.

18
ENG
ENGLISH
SPECIFICATIONS
The proper posture for using the product when standing.
Gaze downward
toward the center of
the monitor.
Always maintain
good posture, with
your back upright
and legs together.
Stand tilt Range
45° to 66°(68°)
Adjust the location of
the Monitor set to avoid
it reflecting light.
yAdjust the screen so that you can comfortably look at it at a slight downward angle from your natural eye level.
yTake a break for approximately 10 minutes every hour to reduce any fatigue caused by long-time usage.
yThe stand of the touch monitor allows the product to be used in the optimum position.
yAdjust the stand angle between 15 and 30 degrees to create the optimum user environment.

Make sure to read the Safety Precautions before
using the product.
Keep the Owner’s Manual (CD) in an accessible
place for future reference.
The model and serial number of the SET is
located on the back and one side of the SET.
Record it below should you ever need service.
MODEL
SERIAL
