LG CP-079C User manual

www.lg.com
OWNER'S MANUAL
Colour Television
Chassis : CP-079C
P/No. : MFL61997501 (07)

Make sure to insert the power plug completely. If power
cableisnotfixedcompletely,afirecanbreakout.
Donotpulloutthepowercord.AlwaysPulloutbythepower
plug. Do not touch the plug with wet hands. Do not damage
thepowercord.
Donotunplugthepowercordwhiletheproductisinuse.Do
notusethepowerplugtoturntheproductON/OFF. Electric
shockcandamagetheproduct.
Do not overload AC outlets by plugging too many
appliances in the same socket or extension cords. They
mayresultinashockorfirehazard.
Never leave the TV set “ON”/“STANDBY” when leaving the
house. Unplug the TV before moving it or if you are not
goingtouseitforseveraldaysorduringlightningstorms.
ForOwnsafety,Never touch any part of product, the power
cord, and the antenna cable during lightning storms. You
maybeelectrocuted.
TV sets are provided with ventilation holes to allow the
release of heat generated. Make sure that these holes
are not blocked. Do not install the product in a confined
place,suchasbookcaseorbuiltincabinet.
DonotplaceanyobjectfilledwithliquidsuchasVases,cup,
glassetcontheTV set. Do not place the lighted candles on
theTVset.Thismaycausefireoranelectricshockhazard.
This unit has been engineered and manufactured to assure your personal safety,
howeverimproperusemayresultinpotential electrical shockorfirehazards.Inorderto
allow the proper operation of all safeguards incorporated in this TV set, observe the
following basicrulesforits installation, useand servicing.Keepitin anaccessibleplace
forfuturereference.(TVoperatingvoltageis: 110V~240VAC)
If you can smell a smoke or other odors or hear a strange
sound unplug the power cord and contact the service
center.Ifyoucontinuetouse,electricshockcanoccur.
Do not place the product where it might be exposed to
excessiveheat,sunlight,rainor moisture.
Important Precautions
2
Do not attempt to open the product. There are
dangerous High Voltages inside. Refer to Servicing
through Qualified Personnel if the TV is not operating
properly.

To avoid batteryleakageand damageto theremote, remove thebatteries from
theremote if youarenot going touse itforseveral days. Ifanyliquid leaks from
thebatteriesandtouchesyourskin,immediatelywashitawaywithwater.
BatteryInstallation:TheremotecontrolHandsetispoweredbytwoAA/
AAA batteries. To Load the Batteries, turn the remote control handset
over and open the battery compartment. Install two batteries as per the
polaritysymbols( and )markedinsidethebatterycompartment.
•
Do Not use the stabilizer, as this set has a In built stabilizer. Use of External Inferior
Qualitystabilizermaydamageyourproduct.
•
Do not allow children to climb over it. If the product falls /
collapses, you may be hurt. Do not drop or push objects
(like coins, hair pins etc) into the TV cabinet openings.
Someinternalparts carry hazardousvoltages.
Avoidpersonal injury / set damage by Installing the product
on a flat and stable place that can support the weight of the
setandhasnoriskofdroppingtheproduct.
While cleaning the product, Unplug the Power cord and
clean with dry & soft cloth. Do not use thinner, aerosol or
anyotherchemicaltoclean.
Important Precautions
3
1. When this crossed out wheeled bin symbol is depicted on the product
and its operator’s manual, it means the product is covered by the e-waste
Management and Handling Rules, 2011 and are meant to be recycled,
dismantled,refurbishedordisposedoff.
2. Dos
a. Theproductisrequiredtobehandedoveronlytotheauthorizedrecyclerfordisposal.
b. Keep the product in isolated area, after it becomes non-functional/un-repairable
soastopreventitsaccidentalbreakage.
Don’t
a. Theproductshouldnotbeopenedbytheuserhimself/herself,butonlybyauthorized
servicepersonnel.
b. The product is not meant for re-sale to any unauthorized agencies/scrap dealer/
kabariwalah.
c. Theproductisnotmeantformixingintohouseholdwastestream.
d. Donotkeepanyreplacedsparepart(s)fromtheproduct inexposedarea.
3. Any disposal through unauthorized agencies/person will attract action under
Environment(Protection)Act1986.
4. Hazardsof improper handlingoraccidental breakage :
a. All picture tubes are hazardous due to concentration of lead, cadmium and zinc
in it. The various chemicals and heavy metals contained in picture tubes cause
cancer, birth defects, hormone disruption, and damage body organs when they
leak into the environment. All of this can, and does, leach into the soil, ground
water,air andourownbodies.
To prevent possible injury in case of breakage, wear heavy protective clothing,
includinggloves&safetygoggles.
b. If batteries are disposed incorrectly, it can greatly harm the environment. The
chemical by-products are hazardous. The metals and chemicals found in
batteriescanmixintosoilwhichmaybehazardoustohumans,plantsandanimals.If
thrown in fire, they can cause blast and release toxic gases which may be harmful
for health.
5. To locate a nearest collection centre or call for pick-up (limited area only) for disposal of
this appliance, please contact Toll Free No. 1800-180-9999 for details. All collection
centre and pick up facilities are done by third parties with LG Electronics India Pvt. Ltd.
merelyasafacilitator.Formoredetailedinformation,pleasevisit:http://www.lge.com/in
Disposal of your old appliance (as per e-waste Rules)

VhohlVs ij;krjyinkFkZlsHkjhphtastlS s
Qyw nku] di] fxykl vkfn ;k tyh gbq Z
ekes cfÙk;kauj[kAas bllsvkxyxldrhgS;k
fctyhdk>VdkyxldrkgAS
•cSVjhyhdstvkSjfjeksVdksuqdlkulscpkusdsfy,]tcvkifjeksVdksdbZfnuksardbLrsekyughadjusokysgksarkscSVfj;ksa
dksmlesalsfudkynsaAvxjcSVfj;ksalsdksbZrjyinkFkZfjldjvkidhRopkijyxtkrkgS]rksrRdkyblsikuhls/kksnsaA
Ñi;k[kqndkspksVlsvkSjmRikndksuqdlkulscpkuklqfuf'prdjusdsfy,bufunsZ'kksadkges'kkikyudjsaA
•fp=kvkidsmRiknlsFkksM+kfHkUugksldrkgS]D;ksafd;gflQZfunsZ'kksadksle>usesaenndsfy,,dmnkgj.kgSA
•VhohdkvkWijsfVaxoksYVstgS%110-240V,lhA
•LVsfcykbt+j dk iz;ksx ugha djsa] D;ksafd bl lsV esa fcYV bu LVsfcykbt+j gSA ?kfV;k DokfyVh ds ckgjh
LVsfcykbt+jdsiz;ksxlsvkidsmRikndksuqdlkuigqapldrkgSA
lqfuf'pr djsafd ikWoj IyxvPNh rjg ls
yx x;k gSA ;fn ikWoj Iyx Bhd ls ugha
yxkgSrksvkxyxldrh gSA
,dghlkWdsVvFkok ,DlVsa'kudkWMZesadbZ
midj.k yxkdj ,lh vkmVysV dks
vksojyksM u djsaA ugha rks >Vdk yx
ldrkgS;kvkxyxldrhgSA
vka/kh&rwQku ds nkSjku viuh lqj{kk ds
fy,] midj.k ds fdlh fgLls dks] ikWoj
dkWMZ dks ;k ,aVhuk ds rkj dks u Nq,aA
vkidksfctyhdk>VdkyxldrkgSA
?kj ls fudyrs le; Vhoh dks dHkh ^^vkuW **
LVMaS ck; u NkMs Aas+ Vhoh dks f[kldkus ls igys
vFkok;fnvkidNq fnukasrdVhohdkbLres ky
ugha djus okys gSa vFkok vka/kh&
rwQkudsnkSjkuVhohdkIyxfudkynsaA
mRikn dks ogka u j[ksa tgka ml ij csgn
xehZ] /kwi] o"kkZ ;k ueh dk vlj gks ldrk
gksA
tcmRikn dksbLrseky djjgs gksarksikWoj
Iyx dks u fudkysaaAmRikn dks vkWu@vkWQ
djusdsfy, ikoW jIyx dkbLres kyu djAas
fctyh dk >Vdk mRikn dks {kfr igqapk
ldrkgSA
vxj vkidks /kq,a dh ;k dksbZ vkSj xa/k vk,
;k dksbZ vthc vkokt+ lqukbZ nsa] rks ikWoj
dkWMZdksIyxls fudkynsavkSj lfoZllsaVj
ls laidZ djsaA vxj vki bLrseky tkjh
j[krsgSarksfctyhdk>VdkyxldrkgSA
mRikn dks[kksyus dhdksf'k'kudjsaAblds
Hkhrj [krjukd gkbZ oksYVst gksrs gSaA vxj
Vhoh Bhd ls dke u dj jgk gks] rks
;ksX;rkizkIrdfeZ;ksalslfoZflaxdjk,Aa
[kqn dks pksV@lsVdks uqdlku ls cpkusds
fy,mRikndks,slsleryvkSjfLFkjLFkku
ij j[ksa tks lsV dk otu laHkky ldrk gks
vkSjmRikndsfxjusdk[krjkugksA
mRikn dks lkQ djrs le; ikWoj Iyx dks
fudky nsa vkSj lkQ lw[ks diM+s ls iksaNsaA
lkQ djus ds fy, fFkuj] ,vjkslksy ;k
fdlhvU;dsfedydkiz;ksxudjsaA
iSnkgksusokyhxehZdsfudyusdsfy,Vhoh
lsVksa esa osafVys'ku fNnz cus gksrs gSaA ;g
lqfuf'pr djsafd ;sfNnz canu gksaAmRikn
dks cqddsl ;kfcYV budSfcusV tSlhcan
txgksaijbaLVkyudjsaA
cPpksa dks blds Åij u p<+us nsaA vxj
mRiknfxjrk@<gtkrk gS]rks vkidkspksV
yxldrhgSA VhohdSfcusVds Nsnksaesa dksbZ
pht ¼tSlsflDds] gs;jfiu vkfn½u fxjk,a
vkSj u ?kqlk,aA dqN Hkhrjh ikVZ~l esa
[krjukdoksYVstgksrsgSA
ikWoj dkWMZ dks [khapsa ughaA ges'kk ikWoj
Iyx dks idM+dj [khapsA xhys gkFkksa ls
Iyx dks u Nq,aA ikWoj dkWMZ dks {kfr u
igqapk,aA
4
lqj{kk funsZ'k
ƒ- tc ;g dkVs x;s ifg;s okys fcu dk fpg~u fdlh mRikn vkSj blds izpkyd iqfLrdk ds lkFk layXu gksrk gS] rks bldk vFkZ gS] mRikn
bZ&vif’k”V¼izca/ku vkSj gFkkyu½ fu;e „‚ƒƒds vUrxZr] lfEefyr fd;k x;k gSA bl fu;e dsvuqlkj mRikn dks iqu% uohuhdj.k]
/oLr;kfuiVkuk pkfg,A
„- blsdjsa
d½ mRikndksdsoy vf/k—riqu%uohuhdj.kdrkZ dksfuiVku gsrqgLrkukUrfjrdjsaA
[k½ mRikndk;kZReduk jgsrks]mRikn dksi`Fkd {ks=esaj[ksa] ftllsmRiknvkdfLed {kfrlscp ldsA
blsudjsa
d½ mRikndksmiHkksDrk Lo;augha[kksysa] cfYdvf/k—r lsokdeZpkjh}kjk [kqyok;saA
[k½ mRikndksfdlh vuf/k—r,tsalh@iqjkuslkeku dsMhyj@dckM+h okysdksfQj lsucsapsaA
x½ mRikndks?kjsyq vif’k”V/kkjkds lkFku feyk,saA
?k½ mRikndscnys gq,;kvfrfjDr iwtksZadks [kqyhtxgesa uj[ksaA
…- mRikndksfdlh Hkhvuf/k—r,tsalh@O;fDr }kjkfuiVku djkusij]i;kZoj.k ¼laj{k.k½vf/kfu;eƒ‹Šˆ] dsrgrdk;Zokgh gksldrh gSA
†- xyr<axls j[kj[kko;kvdfLed VwV&QwVds [krjs%
d½ yhM] dSMfe;e o ftad dh ekStwnxh ds dkj.k lHkh fiDpj V;wc [krjukd gksrh gSA fiDpj V;wc esa fofHkUu jlk;uksa rFkk Hkkjh /kkrqvksa dh
ekStwnxh ds dkj.k okrkoj.k essa buds fjlko ls dSalj] tUe nks”k] gkeksZu fo?kVu] vkSj ‘kjhj ds vaxks dks uqdlku gks ldrk gSA ;s lHkh jlk;u
feÍhesa]Hkw&xHkZ tyesa]gok esa?kwy djgekjs‘kjhj esaizos’kdj ldrsgSA
[k½ ;fn cVS fj;kas dk xyr <xa ls fuiVku fd;k tkrk g]S rks blls i;koZ j.k dks dkQh vf/kd udq lku gks ldrk gAS jklk;fud mi&mRikn
[krjukd gkrs s gAaS cVS fj;kas eas ik, tkus okyh /kkr,q ¡ o jlk;u feÍh eas fey ldrs gaS tkfsd eu”q;k]as iMs &+ ik/Skkas rFkk tkuojkas ds fy, [krjukd gks
ldrsgAaS ;fnvkxeassQdas stkrsg]aS rksosfoLQkVs djldrsgaSrFkktgjhyhxlS kasdksNkMs +ldrsgaStkfsdLokLF;dsfy,gkfudkjdgksldrhgAaS
‡- bl mRikn ds fuiVkj.k gssrq ;k fQj utnhdh laxzg dsUæ dk irk yxkus ds fy,] d`i;k Vksy Ýh uEcj ƒŠ‚‚&ƒŠ‚&‹‹‹‹ ¼lhfer {ks= esa
miyCËk½ ij lEidZ djAas lHkh lxa gz dUsnz ,oa fid&vi lfqo/kk,a ckgjh ,tUslh }kjk pyk;h tkrh gAaS LG Electronics India Pvt. Ltd.
flQZlqfo/kkiznku djkusdkek/;e gSA vfËkdtkudkjh dsfy,osclkbV ns[ksa%http://www.lge.com/in
blsdjsa
blsudjsa
vkids iqjkus ?kjsyw midj.k dk fuiVku ¼bZ&vif’k"V fuiVk.k fu;ekoyh ds vuqlkj½vkids iqjkus ?kjsyw midj.k dk fuiVku ¼bZ&vif’k"V fuiVk.k fu;ekoyh ds vuqlkj½

POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
19
2
3
710
5
6
11
12
14
13
8
OK
EYE/*
MM/*
4
15
Location and function of controls
4. EYE/ (option)
switchestheeyefunctionOnorOff.
5. / (ProgrammeUp/Down)
selectsaprogrammeoramenuitem.
switchesthesetOnfromstandby.
(VolumeUp/Down)
adjuststhevolume.
adjustsmenusettings.
OK accepts your selection or displays the current
mode.
Allthe functions can be controlled with theremote control
handset. Some functions can also be adjusted with the
buttonsonthefrontpaneloftheset.
Remotecontrolhandset
Before you use the remote control handset, please install
thebatteries.Seethepreviouspage.
1. POWER
switchestheset fromOntostandbyorstandbytoOn.
2. NUMBERBUTTONS
switches the set On from standby or directly select a
Programmenumber.
3. MENU
selectsamenu.
6. Q.VIEW
returnstothepreviouslyviewedprogramme.
7. PSM(PictureStatusMemory)
recallsyourpreferredpicturesetting.
8. XDP/*
SelectexcellentDigitalpicture.
9. MUTE
switchesthesoundOnorOff.
10. TV/AV
selectsTVorAVmode.
switchesthesetOnfromStandby.
11. LIST
displays the programme table. press LIST key again
tocleartheLISTtablefromthescreen.
12.SLEEP
setsthesleeptimer.
13. ARC/*(option)
changepictureformat(Normal/Zoom).
14. FAVOURITE
pressing each time this button will select a stored
favouriteprogramme.
COLOURED BUTTONS :When Menu is On some of these
buttons are used for programme edit in programme edit
window
*
Remarks : 1. Some keys in remote can be non-functional,
these keys are used in other models.
# Remote Design / Aesthetic may vary from model
to model.
15. MM /*(option)
select music mode.
5

ON/OFF MENU OK / VOL PR
134 5B5A
2
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
OnandOff
1. PressthemainpowerbuttontoswitchthesetOn.
2. Ifthe set is in standby mode,press the POWER,
TV/AVorNUMBERbuttonsontheremotecontrol
handsettoswitchitOnfully.
3. PressthePOWERbuttonontheremotecontrolhandset.
Thesetrevertstostandbymode.
4. PressthemainpowerbuttonagaintoswitchthesetOff.
Note : while the set is switched On and mains plug is
disconnected, if mains plugged again then set will switch to
standbyorpowerOn.
Programme selection
You can select a programme number with the or
NUMBER Buttons.
Volume adjustment
Press the button to adjust the volume.
Quick view
Press the Q.VIEW button to view the last programme
Mute function
Press the MUTE button. The sound is switched Off and
the display appears.
You can cancel it by pressing the MUTE, button.
On screen language selection (option)
The menu can be displayed on the screen in desired language.
First select your language.
1. Pressthe MENU buttonand then buttonto selectthe
specialmenu.
2. Press the button after selecting language by pressing
button.
3. Pressthe buttontoselectsthedesiredlanguage.
All the On screen display will appear in the selected
language.
4. RepeatedlypresstheMENU buttontoreturnto normalTV
viewing.
Basic operation
6
Location and function of controls
Shown below is a simplified representation of front panel, here shown may be
somewhatdifferentfromyourset.
2. REMOTE CONTROL SENSOR
3. POWER/STANDBY INDICATOR
Illuminates brightly when the set is
in standby mode dims when the set
is switched On
1. MAIN POWER (ON/OFF)
switches the set On or Off.
4. MENU
selects a menu.
5A. OK /
It accepts your selection when it is in menu.
Otherwise it selects input (TV or AV)
5B. (Volume Up/Down)
adjusts the volume.
adjusts menu settings.
(Programme Up/Down)
selects a programme or a menu item.
switches On the set from standby.

The dialogue between you and your set takes place on
screen with an operator menu. The buttons required
fortheoperatingstepsarealsodisplayed.
Menuselection
1. PresstheMENUbuttonandthen buttontodisplay
eachmenu.
2. Press the button and then button to select a
menu item.
3. Pressthe buttontodisplaythesubmenuor thepull-
downmenu.
4 Change the setting of an item in the sub or pull-down
menuwith or .
You can move to the higher level menu with OK button
andtomovetothelowerlevelmenupressthe button.
Note :
a. In the AV mode the Programme Menu is not displayed.
b. In sound menu woofer is optional (In some models)
On screen menus
Manual programme
Programme edit
or
CSM
Programme
22
Auto programme
Time
Special
Sound
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
7

Setting upTV stations
Programme Up to 200 programmes can be stored by programme
numbers (0 to199). Once you have preset the
stations you will be able to use the or NUMBER
buttons to scan the stations you programmed.
Programmes can be tuned using automatic or
manualmodes.
Autoprogrammetuning
All channel that can be received are stored by this
method.Itisrecommendedthatyou use auto programme
duringinstallationofthisset.
1. PresstheMENUbuttonandthen buttontoselect
theProgrammemenu.
2. Pressthe buttonandthen buttontoselectAuto
programme.
3. Press the button to display the Auto programme
menu.
4. Pressthe buttontoselectStoragefrom.
5. Select the beginning programme number with the
button or NUMBER buttons on the Storage
frompull-downmenu.Any number under 10 is
enteredwithanumeric'00'infrontofit,i.e.'005' for5.
6. Pressthe buttontoselectthestart.
7. Press the button to begin auto programming. All
receivable stations are stored. To stop auto
programming,presstheMENUbutton.
WhenautoprogrammingiscompletedtheProgramme
editmenuappearsonthescreen.Seethe'Programme
edit'sectiontoeditthestoredprogramme.
8. PresstheMENUbuttontoreturntonormalTV viewing.
Note : In some models up to 100 TV stations can be
stored.
Auto Programme
22
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
8

Setting upTV stations
Manualprogrammetuning
Manual programme offer you to manually tune and
arrange the programme in whatever order you desire.
Also you can assign a programme name with five
characterstoeach.
1. Press the MENU button and select the Programme
menu.
2. Press the button and then button to select
Manualprogramme.
3. Pressthe buttontodisplaytheManualprogramme
menu.
4. Press the button to select Search. Press the
button to commence searching on the Search
pull-down menu. If a programme is found the search
will stop. Press OK button to store the programme. If
programmereceptionispoorgoforfinetunning.
5. Ifthisstation is the one required, press the button
to select Storage. Select the desired programme
number (0 to 199) with the button or NUMBER
buttonsontheStorage. pull-down menu.Any number
under10 is entered with a numeric '00'in front of it, i.e.
'005' for 5. Press OK button to store the programme.
6. Press the button to select System. Select a TV
systemwiththe button on the System pull-down
menu;
BG : (India/NewZealand/M.East/Africa/Australia)
I : (HongKong/SouthAfrica)
DK : (EastEurope/China/Africa/CIS)
M : (USA/Korea/Philippines)(option)
7. Pressthe button to select Channel. Press the
buttonto select V/UHF or Cable on theChannel
pull-downmenu.
Ifpossible,selectthechannelnumber1to69(V/UHF)
and 1 to 47 (cable) directly with the number buttons,
Any number under 10 is entered with a numeric '0' in
frontofiti.e.'05'for5.
8. Press the OK button to store it. The display Stored will
appear.
9. Tostoreanotherstation,repeatsteps4&5.
Manual programme
Programme
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
9

Finetuning
Normallyfinetuningisonlynecessaryifreceptionispoor.
1. Repeatthe'Manualprogrammetuning'steps1to3.
2. Pressthe buttontoselectFine.
3. Press the button to fine tune for the best picture
andsoundontheFinepull-downmenu,thenpressOK
buttontostorethesetting.
4. RepeatedlypresstheMENU buttontoreturntonormal
TVviewing.
5. Change of “ ”fromYellowto red indicates tuning
isproper.
Assigningaprogrammename
1. Repeatthe'Manualprogrammetuning'steps1to3.
2. Pressthe buttontoselectName.
3. Press the button on the Name pull-down menu. You
can use a blank, +, -, the numeric 0 to 9 and the
alphabetAtoZ.
With the button you can select in the opposite
direction.
4. Select the next position by pressing the button and
then take your choice of the second character, then
pressOKbutton.
5. Repeatthe'Manualprogrammetuning'steps5to8.
6. Repeatedly press the MENU to return to normal TV
viewing.
Setting upTV stations
Programme
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
10

Programme edit
This function enables you to delete, skip or copy the
stored programmes.Also you can move some stations to
otherprogrammenumbers.
1. PresstheMENU button and then buttontoselect
theProgrammemenu.
2. Press the button and then button to select
programmeedit.
3. Press the button to display the Programme edit
menu.
Deletingaprogramme
1. Select a programme to be deleted with the or
button.
2. PresstheREDbuttontwice.
The selected programme is deleted, all the following
programmesareshifteduponeposition.
Copyingaprogramme
1. Select a programme to be copied with the or
button.
2. PresstheGREENbutton.
All the following programmes are shifted down one
position.
Movingaprogramme
1. Select a programme to be moved with the or
button.
2. PresstheYELLOWbutton.
3. Move the programme to the desired programme
numberwiththe or button.
4. Press the YELLOW button again to release this
function.
Skippingaprogrammenumber
1. Select a programme number to be skipped with the
or button.
2. PresstheBLUEbutton.Theskippedprogrammeturns
toblue.
3. Press the BLUE button again to release the skipped
programme.
When a programme number is skipped it means that
you will be unable to select it using the button
during normal TV viewing. If you want to select the
skipped programme, directly enter the programme
number with the NUMBER buttons or select it in the
programme edit or table menu. Skipped prog. No.
appearsBLUE.
Repeatedly press the MENU to return to normal TV
viewing.
Programme edit
Programme edit
Setting upTV stations
Programme
G
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
11

Favourite Prog.
This function lets you select your favourite programmes
directly.
1. PresstheMENUbuttonandthen buttontoselect
theProgrammemenu
2. Press the button and then button to select
FavouriteProg.
3. Press the OK button to display the Favourite Prog.
menu.
4. Pressthe buttontoselectFavouriteProg.
5. Select a desired programme with the button
or NUMBER buttons.Any number under 10 is entered
withanumeric'00'infrontofiti.e'005'for5.
6. Tostoreanotherprogrammerepeatsteps5to6.
Youcanstoreupto8programmes.
7. Repeatedly press the MENU or button to return to
normalTVviewing.
Repeatedly press the FAVOURITE KEY button to select
storedfavouriteprogrammes.
Setting upTV stations
Programme
G
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
12
list
list list
list.
list list
list
list
list
list

CSM.
CSM
PSM(PictureStatusMemory)
1. Press the PSM button on the remote to change
fordesiredPSMsetting.
Note: PSM status change to user automatically when
contrast,brightness,colourandsharpnesssetmanually.
Youcanalsorecalla desired picture (Dynamic, Standard,
Mild Game, or User) with PSM button on the remote
control. The picture Dynamic, Standard, Mild and Game
areprogramedforgoodpicturereproductionatthefactory
andcannotbechanged.
Pictureadjustment
You can adjust picture contrast, brightness, colour
intensity, sharpness and Tint (NTSC input only) to the
levelsyouprefer.
1. Press the MENU button and then button to select
thePicturemenu.
2. Press the button and then button to select
Contrast,Brightness,Colour,SharpnessorTint.
3. Pressthe buttontomakeappropriateadjustments
oneachsubmenu.
YoucanalsoselectUserorstandardPSMsettingby
directlypressingPSMbutton.
4. PresstheOK buttontostoreitforthepictureUser.
5. RepeatedlypresstheMENUbuttontoreturntonormal
TVviewing.
CONTRAST
CSM
Picture adjustment
CSM (Colour Status Memory)
Reddish
Greenish
Bluish
Excellentdigitalpictureselection(option)
When thisfunction is On,picture quality willbe enhanced.
RepeatedlypresstheXDP/*buttontoswitchOnorOff.
Note:IfyoupressthePSMorEYE/* buttonwiththeXDP/*
function,theexcellentdigitalpicturefunctionisautomatically
switchedOff.
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
13

Sound adjustment
Sound AVL(AutoVolumeLeveler)
Volume adjustment
If you select AVL On, the set automatically keeps On an
equalvolumelevelevenifyouchangeprogrammes.
YoucanadjustVolume.
1. PresstheMENUbuttonand then button toselect
theSoundmenu.
1. PresstheMENUbuttonandselecttheSoundmenu.
2. Pressthe buttonandthen buttontoselectAVL.
2. Pressthe buttonandthen buttontoselect
volume.
3. Press the button to select On or Off on theAVL.
Pull-downmenu.
3. Makedesiredadjustmentwiththe onthevolume
OSD.
4. RepeatedlypresstheMENU buttontoreturntonormal
TVviewing.
4. AfteradjustmentthevolumeOSDwillDisappear.
MusicMode(option)
You can hear music while the TV screen is Off using the
function.
1. PresstheMM/*buttontostartthemusicmode.
2. Press any key to exit from Music Mode except MM/*
key&Vol.keys
3. Volume level can be changed (Vol+/Vol-) in music
mode.
Music Mode On
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
14

Time functions
OnTime
1. PresstheMENU buttonandthen buttontoselect
theTimemenu.
2. Pressthe buttonandthen buttontoselectOnTime.
3. PressOK
4. Pressthe buttontoselectOnTimeOnorOff
5. Pressthe button.
6. Selectandadjusthourandminutebypressingthe ,
button.
Autosleep
If you select Auto Sleep On the set will automatically
switch itself to standby mode approximately ten minutes
afteraTVstationstopsBroadcasting.
1. PresstheMENUbuttonand then button.toselect
theTimemenu.
2. Pressthe button andthen buttontoselect
AutoSleep.
3. Pressthe and buttontoselectOn.
4. Repeatedly press the MENU or button to return to
normalTVviewing.
Note:
a. ONTimefunctionworksonlyinstandbymode.
b. TocancelthesetOn/Offtime,settheOn/Offtimerto--:--.
c ToviewtheremainingOn/OfftimeselecttheTimemenu.
d. When youswitchthemainpowerOff,the Timeis reset
andtheOn/Off timeisOff.
e. Timeraccuracyis 15sec.
Timefunctions
The time uses 24 hrs. system and must be set to the
correcttimebeforeoperatingtheset.
1. PressMENUtoselect Timemenu.
2. and keyselecttimefunction.
3. Afterselecting‘TimeFunction’press keytoenter‘Time’.
4. SetTimeusing and keys.
5. PressOKtostore.
6. Repeatedly press MENU to return to normal TV
viewing.
Note:
a. Intheeventofpowerinterruption,timemustbereset.
b. Timeresetsifmainsisunplugged.
c. Timeraccuracyis 15sec.
On/OffTime
By using this function in On mode the set automatically
switches On or Off at a preset time.You must set the time
correctlybeforeusingOn/Offtimefunction.
OffTime
1. PresstheMENUbuttonandthen , buttonto
selecttheTimemenu.
2. Pressthe buttonandthen buttontoselectOff
Time.
3. PressOK
4. Pressthe buttontoselectOffTimeOnorOff.
5. Pressthe button.
6. Select and adjust hour and minute by pressing the
,button.
7. Repeatedly press the MENU or button to return to
normalviewing.
±
Time
--:--
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
15

Special functions
Onscreenlanguageselection(option)
The menu can be displayed on the screen in desired
language.Firstselectyourlanguage.
1. PresstheMENU button and then button to select
theSpecialmenu.
2. Pressthe buttonandthenthe buttontoselect
language
3. PressOKbutton.
AlltheOnscreendisplayedwillappearintheselected
language.
4. Repeatedly press the MENU or Button to return
normalTVviewing.
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
16
TVandAVmodes/Input(option)
Input canbeset toTVorAV mode.AVmodeisusedwhena
DVD,orotherequipmentconnectedtotheset.
Note:When aVCR isconnectedvia theaerial socket;the
set is used in TV mode. See the connection of external
equipment’section.
1. Press the menu button and then buttonto select
thespecialmenu.
2. Press the button and then button to select
Input.
3. Pressthe and buttonselectTV,AV
Note:AvoidgivinginputatLoutorRoutsocketontheback
oftheset.
ToreturnTVmode,pressthe orNUMBERbutton.
Alternativelyyou can select thTV orAV mode bypressing
theTV/AVbutton
Special
Childlock
When Child lock is ON, Remote control handset is needed to
control the functions. This feature can be used to prevent
unauthorizedviewing.
1. Press theMENUbuttonand the buttonto select
thespecialmenu.
2. Pressthe buttonandthen buttontoselectthe
childlock.
3. Pressthe and button ontheremotecontrol
handsettoselectOn.
4. RepeatedlypresstheMENUor buttontoreturnto
normalTVviewing.
WiththelockOn,thedisplayChildLockOnappearsonthe
screen if any button on the front panel is pressed while
viewingtheTV.

Other functions
17
POWER MUTE
PSM TV/AV
MENU
Q-VIEWARC/* LIST
SLEEP
FAVOURITE
XDP/*
13
46
79
PR
VOL VOL
PR
5
8
0
2
OK
EYE/*
MM/*
Pictureformat(ARC) (option)
You can watch TV in various picture formats; Normal,
Zoom.
Repeatedly press the ARC button to select your desired
pictureformat.
Normal(4:3)
Thispictureformatis4:3ofgeneralTV.
Zoom(14:9)
You can enjoy the cinema in a vast screen through the
Zoom mode. The screen 4:3 is magnified to the
upper/lower sides so that the screen 16:9 is full. The
bottomandtopofthepicturemaybelost.
Note:
a.WhenyouswitchthesettoOff,Zoom pictureformat
isresettotheNormal(4:3).
b.In the 1/2 size sub picture and vertical four sub
picture of PlP mode the picture format is not
available.
c.ThismenuwillappearonlyinEnglish.
Special Blueback
IfyouselectOninthe Blueback pull-downmenu, theblue
background appears on the screen when there is no
signalorpoorsignal.
1. PresstheMENU buttonandthen button toselect
theSpecialmenu.
2. Press the button and then button to select
Blueback.
3. Press the button to select On or Off on the Blue
backpull-downmenu.
4. Repeatedly press the MENU button to return to
normalTVviewing.
Note: a.Thebluebackgroundautomaticallyappearson
thescreen whenthereisnosignalinTVmode.
b.Ifany OSDappearsonscreen,bluebackwillgoOff.
Sleep timer
You don't have to remember to switch the set Off before
you go to sleep. The sleep timer automatically switches
thesettostandbyafterthepresettimeelapses.
Press the SLEEP button to select the number of minutes.
The display - - - will appear on the screen, followed by
10, 20, 30, 60, 90 120, 180 and 240. The timer begins to
countdownfromthenumberofminutesselected.
Note:
a. To view the remaining sleep time, press the SLEEP
buttononce.
b. To cancel the sleep time repeatedly press the SLEEP
button untilthedisplay --- appears.
c. When you switch the set off, the set releases the
presetsleeptime.

Connection of external equipment
You canconnect additional equipment,such asVCRs,
camcordersetc.toyourset.
Hereshownmaybesomewhatdifferentfromyourset.
Aerial socket
1. Connect the RF out socket of the VCR to the aerial
socketonthebackoftheset.
2. Connect the aerial cable to the RF aerial in socket of
theVCR.
3. Store the VCR channel on a desired programme
numberusingthe'Manualprogrammetuning'section.
4. Select the programme number where the VCR
channelisstored.
5. PressthePLAYbuttonontheVCR.
AudioVideoin/outsockets
1. Connect the audio/video out sockets of the VCR to
audio/video in sockets of the set and in sockets of the
VCRtooutsocketsoftheset.
2. If the VCR is connected to theAV sockets on the set,
presstheTV/AVbuttontoselectAV.
3. Press the PLAY button on the VCR. The VCR
playbackpicture appearsonthescreen.
You can also record programmes received by the TV
onvideotapeviaaudio/videooutsockets.
18

Troubleshooting check list
NOTE:
i) Colour patch might appear in yourTV set if you rotate or shift the position of the set
while it is On or in standby mode. If patch appears in yourTV set try the following
beforecalling yourservice centreordealer.PlacetheTVsetin desired positionand
switch it Off by the main power switch. Allow the set tocool down for at least 30
minutes and then switch it On. The degaussing circuit (inbuilt) in your set will
remove thepatch automatically.Pleasecallserviceonlyincasethis operationdoes
nothelp.
ii) In case of no sound on all channels, check for system.It should be 'BG' for India.In
caseofsomeothersystemselect'BG'anddoAutoProgramming.
Remote control does not work
Check Audio/Video sockets (VCR only)
Check the batteries in remote control
Adjust volume
Adjust colour
Adjust brightness
Adjust contrast
Check for local interference
Check aerial
Check aerial (plugged into TV?)
Check aerial (broken lead?)
Try another channel (weak signal)
Is the TV switched On
The mains plug-(plugged in and
switched On)
Check following items and try
to adjust these
Poor colour
No colour
Poor reception on some channels
Lines or streaks in picture
Picture blurred
Picture OK, poor sound
Sound OK, poor picture
No picture, no sound
Symptoms
19
