LG UQ80 Series User manual

UQ80*
UQ90*
www.lg.com
Head
washer
x 6
(M5 x L30)
1 2 3
1 2
AA
4-A
70UQ80*
70UQ90*
4-B 75UQ80*
75UQ90* 5-A 70UQ80*
70UQ90*
5-B 75UQ80*
75UQ90*
Head
washer
3
*M F L 7 1 8 3 3 9 2 6 2 2 0 3 R E V 0 0*
Quick Start Guide
Images shown in manual may vary depending on model
Unpacking
Check your product box for the following items. If there are
any missing accessories, contact the local dealer where you
purchased your product. The illustrations in this manual may
differ from the actual product and item.
: Depending on model
: Depending on country

Kg
90°
A
D
E
F
C
G
B
5s
1s
A B C D(mm) E
Wallmount 70/75UQ80*
70/75UQ90* 400 x 400 M6
A
C
B
D
E
The Analog Gender adapter can be purchased separately at Customer Service.
ABCD E F F G
70UQ80006LD
70UQ80006LM
70UQ8000PSC
70UQ8000PSL
70UQ8050PSB
70UQ8050PSK
70UQ90006LC
70UQ9000PSA
70UQ9000PSD
1562 972 361 907 59.9 28.8 28.4
75UQ80006LB
75UQ80006LD
75UQ80006LM
75UQ8000PSC
75UQ8000PSL
75UQ8050PSB
75UQ8050PSK
75UQ90006LC
75UQ9000PSD
1678 1027 361 964 59.9 31.8 31.4
Power requirement
Do not look into the optical output ports,
looking at the laser beam may damage
your vision
Audio with ACP (Audio Copy Protection)
function may block digital audio output.
Some USB Hubs may not
work, if a USB device con-
nected using a USB Hub is
not detected, connect it to
the USB port on the TV
directly
Connect the external power
source if your USB is needed.
An external audio device that supports SIMPLINK and ARC
must be connected using HDMI IN eARC/ARC port
When connected with a high-speed HDMI cable, the
external audio device that supports ARC outputs SPDIF
audio without additional audio cable and supports the
SIMPLINK function
ARC (Audio Return Channel)
Some USB Hubs may not work, if a USB device con-
nected using a USB Hub is not detected, connect it to
the USB port on the TV directly
Connect the external power source if your USB is needed.
