LG TG2402NTWV User manual

DWG.
No.
TRIG.
DR COMPLETED
LG Electronics Inc.
UNIT SCALE NS mm
REVIEWEDDESIGNED
주 연 수 전 종 묵 이 갑 선 김 현 석
RELATED DWG.
CHECKED APPROVED
17.10.17 17.10.17 17.10.1717.10.17
MODELING I
T
L
E
T
APPROVEDPREPARED
DATE
REF. NO.REV. NO. REVISION DESCRIPTION
1
2
3
4
RELEASING THIS DRAWING
WITHOUT PERMISSION LG
Electronics SHOULD BE
ACCUSED ACCORDING TO THE
LAWS AND COMPANY RULES.
PDF
ILLUSTRATOR
150 150
210
MFL70280515
MANUAL,OWNER’S
DRUM-EXPORT 1/1
MFL70280515
1. Material, printing and exterier size are refer to work tables.
2. Printing, text size and line are based on LG design film.
3. Exterier size on the drawing is cutting line.
4. Before product controlled by criteria sample.
WORK
BRAND
LG
15
MODEL
MFL70280515
F8K5XNK4.ASSPEIN
P/NO.
1
EIN
LANGUAGE
92EN+RU
PAGE
REMARK
SEC.
should comply with LG standard of LG(63)-A-5501-34
TG2402NTWV
양산처 : 국제인쇄
작업처 : 인쇄물개발파트
24inch Mini washer
2kg
모조지 80g OFFSET 인쇄
(무선제본)

www.lg.com
OWNER'S MANUAL
WASHING
MACHINE
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the product is
installed correctly and safely. Leave these instructions near the
product after installation for future reference.
TG2402NTWV
MFL70280515
Rev.00_101917 Copyright © 2017 LG Electronics Inc. All Rights Reserved.

TABLE OF CONTENTS This manual may contain images or
content different from the model you
purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS .......................................................4
IMPORTANT SAFETY INSTRUCTIONS.................................................... 4
INSTALLATION ......................................................................10
Parts ......................................................................................................... 10
Accessories .............................................................................................. 11
Specifications ........................................................................................... 11
Installation Place Requirements ............................................................... 12
Stacking Mini Washer ............................................................................... 13
Connecting the Supply Hose .................................................................... 15
Installing the Drain Hose .......................................................................... 18
Leveling the Appliance.............................................................................. 19
OPERATION ...........................................................................20
Using the Appliance.................................................................................. 20
Sorting Laundry ........................................................................................ 21
Closing the Door and Drawer ................................................................... 22
Adding Cleaning Products ........................................................................ 23
Control Panel............................................................................................ 25
Programme Table ..................................................................................... 26
Option Programme ................................................................................... 27
SMART FUNCTIONS .............................................................28
Using Smart ThinQ Application................................................................. 28
Using Smart Diagnosis™ ......................................................................... 30
MAINTENANCE......................................................................31
Cleaning the Washing Machine ................................................................ 31
Cleaning the Drum.................................................................................... 32
Cleaning the Water Inlet Filter .................................................................. 32
Cleaning the Lint Filter.............................................................................. 33
Caution on Freezing During Winter .......................................................... 33
TROUBLESHOOTING ...........................................................35
Diagnosing Problems ............................................................................... 35
Error Messages ........................................................................................ 39

4
SAFETY INSTRUCTIONS EN
The following safety guidelines are intended to prevent
unforeseen risks or damage from unsafe or incorrect
operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’
as described below.
This symbol is displayed to indicate matters and
operations that can cause risk. Read the part with this
symbol carefully and follow the instructions in order to
avoid risk.
WARNING
This indicates that the failure to follow the instructions can
cause serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can
cause the minor injury or damage to the product.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of explosion, fire, death, electric shock,
injury or scalding to persons when using this product,
follow basic precautions, including the following:
Children in the Household
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised
to ensure that they do not play with the appliance.
