LG WD-1050F User manual

Washing Machine
OWNER'S MANUAL
WD-1050F
Thank you for purchasing LG Fully Automatic Washer.
Please read your owner's manual carefully, it provides
instructions on safe installation, use and maintenance.
Retain it for future reference.
Record the model and serial numbers of your washing machine

Product Features
Contents
2
Protection against wrinkles
With the alternate rotation of the drum, the wrinkling in
the laundry is minimized.
Preferred temperature selection
There are 4 temperature selections between
cold and 95¡C
Low noise speed control system
By sensing the load and balance, evenly distributes the load
to minimize the spinning noise level.
Child-Lock
The Child-Lock system has been developed to prevent
children from pressing any button to change the program
during operation.
Delay finish
Delayed Washing can be set easily from 3 hours to 19 hours.
Auto Restart
Although the washing machine is turned off by a power failure, it
restarts automatically in its stopped process when power is
supplied again and the process is properly adjusted and it will be
the same when the machine unplugged in operation is plugged in
again.
Warnings ⁄⁄
˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝
3
Specification ⁄⁄
˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝
4
Installation ⁄⁄
˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝
5
Preparing your laundry ⁄⁄
˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝
7
Adding detergent⁄⁄
˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝
7
Control panel ⁄⁄
˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝
8
How to use your washing machine ⁄⁄
˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝
10
Delayed washing ⁄⁄
˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝
12
Maintaining ⁄⁄
˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝
14
Trouble-shooting guide ⁄⁄
˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝ ⁄⁄ ˝
16
Temp Eco/Rapid

Warnings
3
¡¡ÆÆ
You must read the whole of this instruction
book before you use the appliance. Follow
the advice carefully.
Keep the book for future reference.
If you sell or give away the appliance, make
sure that the book is passed to the new
owner.
¡¡ÆÆ
The following warnings are provided in the
interests of overall safety. You must read
them before the appliance is installed or
used.
ƒUThis appliance is designed to be used by adults.
Children should not be allowed to touch the
controls or play with the product.
ƒUIt is dangerous to modify the specifications of this
appliance in any way.
ƒUThis appliance is heavy. Care should be taken
when moving it.
ƒUAll packaging and transit bolts must be removed
before the appliance is used. Serious damage
may occur if this is not done.
ƒUAny plumbing work required to install this
appliance should be carried out by a qualified
plumber or a competent person.
ƒUAny electrical work required to install this
appliance should be carried out by a qualified
electrician or a competent person.
ƒUMake sure that the appliance does not stand on
its electrical supply cable.
ƒUIf the machine is situated on a carpeted floor,
please adjust the feet to ensure that air can
circulate freely.
ƒUAlways unplug the appliance and turn off the
water tap after use.
ƒUDo not overload the appliance.
ƒUOnly wash fabrics which are designed to be
machine washed. If in doubt, follow the
instructions you find on the label of the item itself.
ƒUAvoid electric heaters, candles, etc. near the
machine. It may ignite or deform the machine.
ƒUDon¡flt sprinkle water. It may cause a fire or
electric shock.
ƒUUse the exclusive AC 220V-240V outlet with
ground terminal. Do not use an extension cord or
double adapter.
ƒUMake sure that all pockets are empty. Hard,
sharp objects such as coins, safety pins, nails,
screws or stones can cause extensive damage.
ƒUDo not wash laundry stained with edible oil,
machine oil, dry-cleaning oil, gasoline, etc. It
may cause fire or explosions.
ƒUThis appliance is designed for domestic use. It
must not be used for purposes other than those
for which it was designed.
ƒUDo not machine wash fabrics which are saturated
with petroleum products. If volatile cleaning fluids
have been used, make sure that they are
thoroughly removed from the fabric before it is
placed in the appliance.
ƒUDo not operate near places with ignitable
material such as gasoline, benzene, etc. or
inflammable gas leak. Due to volatile nature of
these material, It can cause fire or explosions.
ƒUUse only the recommended quantities of fabric
softener. An excessive amount could damage
the laundry.
ƒULeave the porthole door slightly ajar between
washes to preserve the door seal.
ƒUBefore you open the door of the machine check
that the water has drained.
Do not open the door if you can still see water.
ƒUPets and children may climb into the washing
machines. Check your appliance each time
before use.
ƒUThe glass door becomes very hot during
washing. Keep children away from the appliance
while it is in use.
ƒUYou should not attempt to repair the machine
yourself. Repairs carried out by inexperienced or
unqualified persons may cause injury and/or
more serious faults to the machine.
ƒUThis product should be serviced by an authorized
Service Centre only, and only genuine spare
parts should be used.
ƒUWhen disposing of your old washing machine,
the electric cable must be cut off and the door
catch must be made inoperative to avoid it
becoming a death trap for a child.

§Name : Front loading washing machine
§Power supply : 220-240V, 50Hz
§Size : 600mm(W)¡¿600mm(D)¡¿850mm(H)
§Weight : 67kg
§Wash capacity : 7.0kg
§Heating : 2200W
§Spin speed : 400/600/800/1000rpm
§Water consumption : 67 (9.6 / kg )
§Permissible water pressure : 0.3-10kgf/§†(30-1000kPa)
§Volume of washing container : 60
ƒ{The appearance and specifications may be varied without notice to raise
the units quality
Specification
4
Inlet hose (1EA) Spanner
Power plug
Control panel
Door
Lower cover
Levelling legs
(For detergent and
fabric softener)
Drawer
Drum
Drain hose
Lower cover cap
Drain pump filter
Drain plug
¥ If the supply cord is damaged,
it must be replaced by the
manufacturer or its service
agents or a similarly qualified
person in order to avoid a
hazard.
§§ ö
Accessories

Installation
5
Levelling leg
Higher Lower
Levelling leg
§ How to disassemble the transit bolts.
ƒUTo protect the washer during transportation, the special
4 bolts are locked. Before operating the washer, remove
the bolts.
( If they are not removed, it may cause heavy vibration, noise and
malfunction)
1. Locate the 4 bolts that secure the washer.
2. Unscrew the 4 bolts with a spanner provided.
3. Take out the 4 bolts.
§ Level adjustment
1. Select a place for installation
ƒUPlace it on a firm and even floor
ƒUPlace it more than 2cm away from the wall or other
furniture
2.Check the gap
ƒUEnsure all feet are firmly on the floor.
3.Level adjustment
ƒUAfter adjusting the level, check it by shaking the washer.
Readjust the level if necessary.
ƒULevelling should be done within 1.5 degree angle.
ƒUKeep the transit bolts and spanner
for future use
in case the machine is to be
transported again.
ƒUIf the washer is not levelled, it may cause
noise or vibration.
§ Electrical connection
ƒUDo not use an extension cord or double adapter.
ƒUIf the supply cord is damaged, it must be replaced by the manufacturer or its service agents or similarly
qualified person in order to avoid a hazard.
ƒUAlways unplug the machine and turn off the water supply after use.
ƒUConnect the machine to an earthed socket in accordance with current wiring regulations.
ƒUIf the appliance is supplied from a cord extension set or electrical portable outlet device, the
cord extension set or electrical portable outlet device should be positioned so it is not subject
to splashing or ingress of moisture.
ƒUIf a stationary appliance is provided with a supply cord and a plug, the instructions shall state
that the appliance must be positioned so that the plug is accessible.
Caution

6
§ Water drain
ƒUHook over the edge of a sink using the plastic hose hanger supplied with the machine.
ƒUMake sure there are no kinks in the hose and that it is not crushed.
Secure the hose so that it can not be dislodged while the appliance is running.
ƒUThe drain hose should not be placed higher than 85cm above the floor.
§§ ö
Connecting the inlet hose
1. Unscrew the fixing screw to
attach the faucet.
2. Push the connector up till the
rubber packing is in tight contact
with the faucet. Then tighten the 4
screws.
3 Push the water supply hose
vertically upwards so that the
rubber packing within in the hose
can adhere completely to the
faucet and then tighten it by
screwing it to the right.
¥ Make sure that the rubber seal is
inside the hose connector.
¥ Your machine comes with only
cold water connection.
¥ Make sure that there are no kinks
in the hose and that it is not
crushed.
¥ Two rings are supplied with the water inlet hose in the valve
connector in order to prevent water leaks.
¥ Your machine comes with only cold water connection.
Connect to cold water using the inlet valve.
¥ Check water tightness of washing machine connections by
turning the tap completely on.
¥ Periodically check the condition of the hose and replace the
hose if necessary.
¥ Make sure that there are no kinks in the hose and that it is not
crushed.
§§ ö
Connecting the inlet hose (How to connect the hose of screw type.)
Rubber
seal
connector

Preparing your laundry
Adding detergent
7
ƒUCheck pocket for any articles (coin, safety pin, paper clips, etc.)
ƒUClose zips and fasten button or hooks : loose belt or ribbons should be tied together.
ƒUNever wash whites and coloureds together.
ƒUFollow the wash code symbols on each garment label and manufacturerÕs washing instructions.
ƒUThe detergent should be used according to the instruction of the detergent manufacturer.
ƒUIf the detergent is used over the recommended amount too many bubbles will be generated thus
causing an inferior washing result. Which will cause malfunction.
ƒUUse detergent only for drum washing machine.
Soiled condition Washing Temperature
Heavily soiled - Pre wash Heavily soiled cottons : cold - 95¡£C
- Main wash Normally soiled cottons : cold - 95¡£C
Coloured cottons : cold - 60¡£C
Normally Soiled - Main wash Synthetics : cold - 60¡£C
Delicate fabrics : cold - 40¡£C
Woollens : cold - 40¡£C
§ Where to place the detergent
ƒUPull out the detergent drawer.
ƒUPut the detergent and fabric softener
in the detergent drawer before washing.
ƒUClose the detergent drawer completely.
Detergent dosages
Do not exceed manufacturerÕs recommended
dosages as shown on the detergent package.
The amounts depend on
ƒUdegree and type of soiling
ƒUamount of wash
- full load : according to manufacturersÕ instructions
- part load : 3/4 of the normal amount
- minimum load (about 1kg) : 1/2 the amount used for
full load
ƒUWater hardness in your area.
Choosing the right detergent
The type of detergent depends on
ƒUthe type of fabric
(cotton, synthetic, delicate items, wool)
ƒUcolour
ƒUwash temperature
ƒUdegree and type of soiling
NOTE : Use appropriate detergent only for wool

Control panel
8
LED display
ƒUDisplay the remaining time (Hour : Minute ) to finish.
ƒUIn case of abnormal operation, error indications are
displayed. ( )
ƒUSee trouble shooting guide.
Water temperature selector
ƒUPress the button to select water temperature.
ƒUThe water temperature
[40¡£C ¤A60¡£C ¤Acold] can be selected in Coloreds,
Synthetic
ƒU95¡£C is selected for Whites only.
ƒUBy pressing the button during operating the washer,
the present temperature is displayed.
For manual wash, rinse and spin speed
ƒUUse these buttons to change wash/rinse/spin
ƒUWhen lamp is off, no selection has been made.
ƒUPrewash is available for Coloreds, Whites, Synthetic
Door lock lamp
ƒUIt shows whether the door
can be opened or not.
ƒUwhen the lamp is on, the
door canÕt be opened.
Error display.
ƒUThe display blinks if there is
an error.
ƒUno inlet : Trouble with water
supply.
ƒUimbalance : The laundry is
tilted to one side.
ƒUno drain : If the drain pump
filter is clogged.
Rinse hold
ƒUIf you desire to leave fabrics in the machine
without spinning after rinse to prevent them
getting wrinkled, you may select rinse Hold by
pressing the Rinse button.
ƒUTo drain and spin, press the Rinse button to
turn off the rinse Hold lamp.
ReferRefer
18

9
Wash program selector
ƒU5 programs can be set depending on the
type of the laundry.
ƒUIf the power button is pressed.
Coloreds program is automatically set.
ƒUBy pressing the button, [ Coloreds ¤A
Whites¤ASynthetic¤ADelicate¤A Wool ]
can be selected.
Start/Pause button
ƒUUse the button to start or
pause wash cycle.
ƒUThe power turns off
automatically 4 minutes
after the pause button is
pressed.
Time Delay
ƒUPress the button when delayed washing is needed.
ƒUWhen the button is pressed, [ ]is displayed,
A maximum delay of [ ]hours can be set.
ƒUEach press advances time delay by the hour.
ƒUUse [Power]button to cancel [Time Delay].
Eco/Rapid
ƒUIf you push the Eco/Rapid button in White program,
Eco function is selected. Eco function gives you
almost the same washing effect as that in 95¡£C with
less energy consumption
ƒUIf you push the Eco/Rapid button in Coloreds or
Synthetic program, Rapid function is selected. Rapid
function reduces the whole time including the washing
and rinsing time about by half an hour.
Child - lock
ƒUChild Lock system can be
set and canceled by
pressing both [Temp] and
[Eco/Rapid ] button
simultaneously.
ƒUOnce Child Lock is set, all
button are inoperable.
ƒUChild Lock system can be
set anytime even during
Power-off, on pause and
operation.
ƒUIt is automatically cancelled
when an operational error
occurs and when the cycle
ends.
Power button
ƒUPress the button to turn power on
and off.

How to use your washing machine
10
§§ ö
§§ ö
The whole washing process is carried out automatically with just one touch.
§§ ö
§§ ö
If no program is selected, Coloreds program will commence.
§§ ö
In case of automatic washing
1. Press the
¡¡aa
Power¡¡bb button. Coloreds program is automatically set with power on
2. Press the Start/Pause button to start the washing machine.
3. The Coloreds program is carried out.
ƒUThe optimum wash program is selected once the load is detected.
§§ ö
To get the washing program preferred
1. Press the
¡¡aa
Power¡¡bb button.
2. Press the program button. By additional push, each light of the programs on the control
panel will be turned on in order as follows.
¡¡aa
Coloreds ¤¤
ì
Whites ¤¤
ì
Synthetic¤¤
ì
Delicate¤¤
ì
Wool ¤¤
ì
Coloreds ¡¡bb
ƒUMake adjustment to water temperature, rinse or spin cycles to suit your wash needs by pressing these buttons.
ƒUThe time required can be slightly changed according to the laundry amount, water supply and water temperature.
[More convenient manual operations of Coloreds program ]
It is more convenient to operate manually in Coloreds program than in others because Coloreds
program is first set with power on.
In Coloreds,
ƒUWhen you want wash only, press the [Wash] button to select the washing method.
ƒUWhen you want rinse only,
press the [Rinse] button to select the rinsing method.
ƒUWhen you want Spin only,
press the [Spin] button to select the Spin speed,
ƒUWhen you want Wash & Rinse only,
press the [ Wash ] button and [ Spin ] button respectively to select each method.
ƒUWhen you want Rinse & Spin only,
press the [Rinse] button and [ Spin ] button respectively to select each method.
Synthetic
Delicate Delicate laundry easily
damaged.(silk, curtains.....)
about
one hour & 
9 minutes
400
(600)
400
(600)
Main wash Cold
(40°C)

WOOL Machine washable woollens
with pure new wool only.
about
45 minutes
Cold
(40°C)
Main wash
(Below 2.0kg)
(Below 3.0kg)
(Below 4.0kg)
Washing
time
Whites
Main wash
(Pre + Main)

about
2 hours & 
20 minutes
95°C
First check if the laundry is machine
washable.
White cottons and linen(towels, sheets...)
Coloreds
800 
(1000,400,600)
800 
(1000,400,600)
800 
(1000,400,600)
about
one hour & 
46 minutes
40°C
(Cold, 60°C)
Normal
(Super, Hold)
Normal
(Super, Hold)
Normal
(Super, Hold)
Normal
(Super, Hold)
Normal
(Super, Hold)
Main wash
(Pre + Main)
Color fast garments
(shirts, night dresses, pyjamas...)
and lightly soiled white cotton
(underwear...)
¥ To change wash, rinse, spin and water temperature.
¥ ( ) indicates choice that can be manually taken.
Program

Polyamide, Acrylic,
Polyester
about
one hour & 
46 minutes
40°C
(Cold, 60°C)
Main wash
(Pre + Main)
Wash Rinse Spin Temp

11
3. Press the Start/Pause button to start the cycle.
ƒUThe optimum washing is carried out by detecting the amount of the laundry.
Completion of washing
ƒUIf the washing is completed, the display shows [ ] with a beep.
ƒUSwitch off the appliance and turn off the tap.
§§ ö
§§ ö
To change settings in Child - Lock mode.
ƒUChild-Lock (If you want to lock all the buttons to prevent a child from setting, you use this option.)
ƒ{The Child system can be programmed and cancelled only by pressing both [ Temp. ] and
[ Eco/Rapid ]buttons simultaneously. If you want to change the program when the Child-Lock is on,
1.Press both [ Temp ] and [ Eco/Rapid ] buttons simultaneously.
2.Press the [ Start / Pause ] buttons..
3.Change the program and press the
[Start / Pause ] button.
If you want to deactivate Child -Lock during wash cycle, press both [ Temp ]and [ Eco / Rapid ]
buttons simultaneously again.
ƒƒUU‹‹^^If the light turns on, the door can not be opened
Start / Pause Start / Pause
Temp Eco/Rapid
Change 
the program
Door Lock


Delayed washing
12
Super
Normal
Hold
Super
Normal
Hold
Wash Rinse Spin Time Delay Temp Eco/R
no inlet
imbalance
Door Lock
Pre
Main
no drain
E
Ra
Ch
Super
Normal
Hold
400 600 800 1000 Cold
40
60
95
§
§ Time Delay setting.
example) If you want to set the washing completed in 5 hours,
Press the [Time Delay ] button and adjust the time.
If the [ Time Delay ]
button is pressed,
[ ]is
displayed
Press the [Time
Delay ] button
twice and set the
time to [ ]
ƒUMinimal 3 hours delay ƒUThe washing is completed in 5 hours
ƒUTime delay is possible between 3 to 19 hours and not possible under 3 hours.
ƒUTime delay does not proceed during power failure
ƒU According to the condition of water supply and temperature, the delayed time and the actual washing time
can vary slightly.
ƒUThe [ Power ] button can be pressed to cancel the time delay.
ƒUPressing the button once will increase the time delay. If the button is pressed continuously, the
time increases automatically by the hour.
ƒUSet the time delay and press the [ Start / Pause ] button, then the remaining time display stays on
with two points blinking between hour and minute.

13
Rapid
Start / Pause
Program
Coloreds Whites Synthetic Delicate
Wool
Eco
apid
hild Lock
§
§ Prepare the washing.
ƒUPlug the power into the exclusive AC 200-240V outlet.
ƒUTurn on the water tap.
ƒU Put in the laundry and close the door.
ƒUPlace the detergent and fabric softener in the drawer.
1. .Press the ¡¡aa Power¡¡bb button
2. .Press the Program selection button to select the program required.
ƒUSelect the rinse, spin and water temperature.
3. .Press the Time Delay button
ƒUSelect the finish time required by pressing the [ Time Delay ] button
4. .Press the Start / Pause button
The Washing is completed at the selected time.
ƒU Take out the laundry, unplug the power plug and turn off the tap.
The Washing program for when you go out.
ƒU If you are unable to unload the washing machine at the end of the washing cycle, it is better to
select rinse [ Hold ] to reduce wrinkle taking place.

Maintaining the washer
14
§Unplug the power plug prior to maintaining.
§Clean the filter periodically every 3 months.
3
2
3
1
2
100
ƒUWhen no water flows through detergent drawer, or filter is clogged with foreign material Ò no
inlet Ó is displayed on the control panel.
Turn off the water tap. Unplug the power plug from
the outlet.
Disconnect the inlet hose
123
Open the lower cover cap
( ¥L ) by using coin.
Turn the drain plug ( ¥M)
to pull out the hose.
Unplug the drain plug ( ¥M),
then the water flows out,
At this time use a vessel
to prevent water flowing on
the floor. If the water does
not flow any more,turn the
pump filter ( ¥N) open to the
left.
Take out any foreign
material from the pump
filter ( ¥N). After cleaning,
turn the pump filter ( ¥N)
clockwise and insert the
drain plug ( ¥M)to the
original place. close the
lower cover cap.
12 3
Pull out the filter with a tool or by hand and
clean it using a toothbrush.
Connect the inlet hose and check
water leakage.
45
§
§ Clean the filter in the inlet valve
§
§ Clean the drain pump filter
ƒU Insert the filter in its original place.

15
1
MAX
MAX
§
§ To prevent being frozen in winter
§
§ When the machine is frozen
§
§ Maintenance of the drawer
Turn off the water tap and remove the inlet
hose.
Drain water in the machine using
drain plug ( ¥L ).
12
12
34
Pour hot water (about 50¡£C)
on the faucet and
remove the inlet hose.
Submerge the separated
hose in hot water
(about 50¡£C)
Pour the hot water in the
drawer and maintain it for
10 minutes for melting
Connect the inlet hose to
the water tap and check
the drain after turning on
the water tap and
operating the washing
machine.
Pull out the drawer
slightly upward.
Wash it clearly. Insert it in its original
place.
123

Trouble - Shooting guide
16
§Check the following before asking for service if the error massage is displayed during washing, rinsing, spinning.
§Request for service in the case of failure or damage except the following.
no inlet
no drain
imbalance
Symptom Check points Solution
¥ Is the water tap turned off ?
¥ Is the water frozen?
¥ Is the water pressure low or the
filter clogged ?
¥ Is there foreign matter in the
drain filter ?
¥ Is the drain hose bent or higher
than 85cm above the floor ?
¥ Is the hose clogged ?
¥ Is the hose frozen ?
¥ Is the laundry tilted to one side
in the drum?
¥ Is the washer leveled?
¥ Is the door opened?
¥ Turn the water tap on.
¥ Melt it with 50¡C hot water
¥ Disconnect the inlet hose and
clean the filter.
¥ Clean and remove foreign
material from drain filter.
¥ Put the drain hose evenly.
¥ Place the drain hose under
85cm from the floor.
¥ Melt it with 50¡C hot water.
¥ Spread the laundry evenly.
¥ Release imbalance by pressing
the [Start / Pause ] button. If it
happens after rinsing or spinning,
call for service.
¥ Install it on a firm and even floor.
¥ Close the door.
❈If [ ] is not released,
call for service.
¥ Unplug the power plug and
call for service
ReferRefer
15
ReferRefer
14
ReferRefer
14
ReferRefer
6
ReferRefer
15
ReferRefer
5

17
ReferRefer
Symptom Check points Solution
¥ Did you press the [ Power ]
button?
¥ Is the power plug unplugged?
¥ Is the power supply correct?
¥ Is the short-circuit breaker
turned off?
¥ Did you use more detergent
than recommended?
¥ Did you use low suds detergent
for the front loading washing
machine?
¥ Did you remove the transit
bolts?
¥ Is the washer tilted?
¥ Is the drain pump clogged with
foreign material ?
¥ Is the washer loaded with
excessive clothes?
¥ Close the water tap.
¥ Unplug the power plug.
¥ Call for service
¥ Turn it on.
¥ Plug it to power supply.
¥ Use exclusive AC220-240V
outlet with ground terminal.
¥ Turn it on.
¥ Use the recommended
amount.
¥ Use detergents for front
loading washing machines
only.
¥ Remove it.
¥ install it on the firm and
even floor and level it.
¥ Remove foreign material
from the drain filter.
¥ Remove the excessive
loads.
If the water overfill due to the abnormal water valve,
you will get Ò Ó display.
Ò Ó
is displayed if the water level sensor malfunctions.
ReferRefer
14

Memo
18

Memo
19

P/No.: 3828ER3001J
3828ER3001R(CIS)
