OWNER’S MANUAL
WASHING MACHINE
WD14070SD6
WD14071SD6
MFL67473309 www.lg.com
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the washer is installed
correctly and safely. Leave these instructions near the washer
after installation for future reference.

Contents
2
Contents....................................2
Product Features......................3
Important safety instructions
Important safety instructions .................4
Basic safety precautions .......................5
Save these instructions.........................6
Specifications...........................7
Installation
Removing packing ................................8
Removing transit olts ..........................8
Installation place requirements .............9
Connecting water supply hose............11
Installation of drain hose .....................13
Leveling...............................................14
How to use washer
Operating washing machine ...............16
Care efore washing...........................17
Washing program ta le.......................18
Extra options .......................................19
Operating data ....................................20
Control panel.......................................21
Additional program..............................22
- Time Delay........................................22
- Steam Wash .....................................22
- Favorite.............................................22
- Pre Wash ..........................................22
Options................................................23
- Option1 .............................................23
- Option2 .............................................23
- Rinse.................................................23
- Temp. ...............................................23
- Spin ..................................................23
Other functions....................................23
- Spin Only .........................................23
- Refresh Cycle ..................................23
Child Lock ...........................................24
Beep On/Off ........................................24
Tu Clean ...........................................25
Door Lock & Detecting ........................25
Thank you for uying a LG Fully
Automatic Washing Machine.
Please read your owner’s manual
carefully, it provides instruction on safe
installation, use and maintenance.
Retain it for future reference.
Record the model and serial num er of
your washing machine.
Model No.
Serial No.
Date of Purchase
Adding detergent
Adding detergent and fa ric softener..26
Maintenance
The water inlet filter.............................28
The drain pump filter ...........................29
Dispenser drawer................................30
The washing drum ..............................31
Cleaning your washer .........................31
Cold conditions ...................................31
Troubleshooting guide
Diagnosing pro lems ..........................32
Error messages...................................34
Using SMARTDIAGNOSIS™..............35
Terms of warranty ..................36

Product Features
3
Inverter Direct Drive system
The advanced Brushless DC motor directly drives the drum without
elt and pulley.
More economical with Intelligent Wash system
Intelligent Wash System detects the size of load and water temperature,
and then determines the optimum water level and washing time to
minimize energy and water consumption.
Built-in heater
Internal heater automatically heats the water to the est temperature
on selected cycles.
Protection against creases
With the alternating rotation of the drum, creasing is minimized.
6 Motion
Washer is a le to perform various drum actions or a com ination of
different actions depending on the wash program selected.
Com ined with a controlled spin speed and the a ility of the drum to
rotate oth left and right, the wash performance of the machine is greatly
improved, giving you perfect results every time.
추가선택 예약
Low noise speed control system
By sensing the amount of load and alance, it evenly distri utes load
to minimize the spinning noise level.
Child Lock
The Child Lock prevents children from pressing any utton to change
the settings during operation.

4
Important safety instructions
For your safety, the information in this manual must e followed to minimize the risk of fire or
explosion, electric shock, or to prevent property damage, injury to persons, or death.
READ ALL INSTRUCTIONS AND EXPLANATION OF THE INSTALLATION
BEFORE USE.
WA NING
You can e killed or seriously injured if you don’t follow instructions.
Your Safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and o ey all safety messages.
This is the safety alert sym ol.
This sym ol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert sym ol and either the word DANGER,
WARNING or CAUTION.
These words mean:
WA NING
You may e slightly injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance
of injury, and tell you what can happen if the instructions are not followed.
CAUTION
You will e killed or seriously injured if you don’t immediately follow instructions.
DANGE

5
Important safety instructions
To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow asic
precautions, including the following:
WA NING
• Before installation, check exterior
damages. If it has, do not install.
• Do not install or store the washer
where it will be exposed to the
weather.
• Do not tamper with controls.
• Do not repair or replace any part of
the washer or attempt any servicing
unless specifically recommended in
the user-maintenance instructions or
published user-repair instructions
that you understand and have the
skills to carry out.
• Keep the area underneath and around
your appliances free of combustible
materials such as lint, paper, rags,
chemicals, etc.
• The appliance is not intended for use
by young children or infirm persons
without supervision. Do not allow
children to play on, with, or inside this
or any other appliance.
• Keep small animals away from the
appliance.
• Do not leave the washer door open.
An open door could entice children to hang
on the door or crawl inside the washer.
• Never reach into washer while it is
moving. Wait until the drum has
completely stopped.
• The laundry process can reduce the flame
retardant of fa rics. To avoid such a
result, carefully follow the garment
manufacturer’s wash and care
instructions.
• Do not wash or dry articles that have
been cleaned in, washed in, soaked
in, or spotted with combustible or
explosive substances (such as wax,
oil, paint, gasoline, degreasers, dry-
cleaning solvents, kerosene, etc.)
which may ignite or explode. Oil may
remain in the tu after a whole cycle resulting
in fire during drying.
So, do not load oiled clothes.
• Do not slam the washer door closed
or try to force the door open when
locked. This could result in damage to the
washer.
• When the machine runs high
temperature, the front door may be
very hot. Don’t touch it.
• To minimize the possibility of electric
shock, unplug this appliance from the
power supply or disconnect the
washer at the household distribution
panel by removing the fuse or
switching off the circuit breaker
before attempting any maintenance or
cleaning.
• When unplugging power cord, do not
pull out by grasping the cord.
Otherwise, the power cord may e damaged.
• Never attempt to operate this
appliance if it is damaged,
malfunctioning, partially
disassembled, or has missing or
broken parts, including a damaged
cord or plug.
■Basic sa ety precautions

6
Important safety instructions
■Basic sa ety precautions
■Save these instructions
To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow asic
precautions, including the following:
WA NING
Improper connection of the equipment-grounding conductor can result in electric shock.
Check with a qualified electrician or serviceman if you are in dou t as to whether the appliance is
properly grounded. Do not modify the plug provided with the appliance - if it does not fit the
outlet, have a proper outlet installed y a qualified electrician.
G OUNDING INST UCTIONS
This appliance must e grounded. In the event of malfunction or reakdown, grounding will
reduce the risk of electric shock y providing a path of least resistance for electric current.
This appliance is equipped with a cord having an equipment-grounding conductor and
grounding plug. The plug must e plugged into an appropriate outlet that is properly installed
and grounded in accordance with all local codes and ordinance.
• Do not use an adapter this will defeat the grounding plug.
• If you don’t have the proper outlet, consult an electrician.
WA NING
• Before discarding an old machine
unplug it. ender the plug useless.
Cut off the cable directly behind the
appliance to prevent misuse.
• When a product was under water,
Please call service center. There is a
risk of electric shock and fire.
• Appliance connected to the water
mains using new hose-sets. Old hose-
sets should not be reused.
• To reduce the risk of personal injury,
adhere to all industry recommended
safety procedures including the use
of long sleeved gloves and safety
glasses. Failure to follow all of the safety
warnings in this manual could result in
property, personal injury or death.
• Do not push down the door
excessively, when washer door open.
This could topple over the washer.

7
■Name : Front loading washing machine
■Power supply : 220 - 240 V~, 50 z
■Size : 600 mm(W) ✕640 mm(D) ✕850 mm( )
■Weight : 70 kg
■Max.Watt : 2200 W (Wash) / 1100 W (Steam)
■Wash capacity : 10 kg
■Permissible water pressure : 100 - 800 kPa (1.0 - 8.0 kgf / cm
2
)
• The external hot water supply MUST NOT exceed 65°C
• Permissible cold water temperature : 4 - 25°C
• No further backflow protection required for connection to the water supply.
• The appearance and specifications may be varied without notice to lmprove the units quality.
• Specifications subject to change by manufacturer.
󳢮The appearance and specifications may vary without notice to improve the quality of the unit.
Specifications
1%
RinseTemp.40°C3
1:15
TimeLeft
Washing
■ Accessories
(For detergent and
fabric softener)
Drawer
Drain hose
Transit bolts Power plug
Control panel
Drain pump filter
Lower cover cap
• If the supply cord is damaged,
it must be replaced by the
manufacturer or its service agents
or a similarly qualified person in
order to avoid a hazard.
Drum
Door Drain plug
Adjustable feet
Inlet hose (1EA) ❈ Option : ot / Cold (2EA) Spanner

8
Installation
■Removing packing
1. Remove the card oard ox and
styrofoam packing.
2. Lift the washing machine and remove
the ase packing. This will require 2 or
more people or a lifting device.
3. Remove the tape securing the power
supply cord and drain hose.
4. Remove the inlet hose from the drum.
1. Unscrew the 3 olts with
the spanner supplied.
2. Take out the 3 olts along with the
ru er ungs y slightly twisting the
ung.
3. Close the holes with the caps supplied.
To prevent internal damage during transport, the 3 special olts are locked.
Before operating the washer, remove the olts along with the ru er ungs.
If they are not removed, it may cause heavy vi ration, noise and malfunction.
■Removing transit bolts
Transit bolt
WA NING
• Packaging material (e.g. Films, Styrofoam) can e dangerous for children.
There is a risk of suffocation ! Keep all packaging well away from children.
NOTE
• Keep the spanner provided for
future use.
NOTE
• Keep the transit olts for future use.
Spanner
Washer
Base Packing

9
• Level floor :
Allowa le slope under entire washer is 1˚
• Power outlet :
Must e within 1.5 meters of either side of location of washer.
Do not overload the outlet with more than one appliance.
• Additional Clearance :
For Wall, 10cm:rear / 2cm : right & left side
Do not place or store laundry products on top of washer at
any times.
They can damage the finish or controls.
■Installation place requirements
❿ Positioning
❿ Location
• Install the washer on a flat hard floor.
• Make sure that air circulation around the washer is not impeded y carpets, rugs, etc.
• Never try to correct any unevenness in the floor with pieces of wood, card oard or similar
materials under the washer. Do not uild the machine into a closed cup oard.
• If it is impossi le to avoid positioning the washer next to a gas cooker or coal urning stove,an
insulating(85x60cm) covered with aluminum foil on the side facing the cooker or stove,must e
inserted etween the two appliance.
• The washer must not e installed in rooms where the temperature can drop elow 0°C.
• Please ensure that when the washer is installed, it is easily accessi le for the engineer in the
event of a reakdown.
• With the washer installed, adjust all four feet using the transit olt spanner provided ensuring
the appliance is sta le, and a clearance of approximately 20mm is left etween the top of the
washer and the underside of any work-top.
• This equipment is not designed for maritime use or for use in a mo ile installations such as
caravans, aircraft etc.
It is also not intended for commercial or outdoor applications, or washing of items such as foot
ware, mats etc.
Installation
Washer
approx.
2cm

10
Installation
CAUTION
CAUTION concerning the Power cord
• Most appliances recommend they e placed upon a dedicated circuit; that is, a single
outlet circuit which powers only that appliance and has no additional outlets or ranch
circuits. Check the specification page of this owner's manual to be certain.
• Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets,
extension cords, frayed power cords, or damaged or cracked wire insulation are
dangerous. Any of these conditions could result in an electric shock or fire.
• Periodically examine the cord of your appliance, and if its appearance indicates
damage or deterioration, unplug it, discontinue use of the appliance, and have the cord
replaced with an exact replacement part y an authorized servicer.
• Protect the power cord from physical or mechanical abuse, such as eing twisted,
kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs,
wall outlets, and the point where the cord exits the appliance.
If the appliance is supplied from a cord extension set or an electrical porta le outlet
device, the cord extension set on electrical porta le outlet device must e positioned
so that it is not su ject to splashing or ingress of moisture.
CAUTION
• The appliance is not intended for use y young children or infirm persons without
supervision.
• Young children should e supervised to ensure that they do not play with appliance.
• Do not use an extension cord or dou le adapter.
• If the supply cord is damaged, it must e replaced y the manufacturer or its service agents or
similarly qualified person in order to avoid a hazard.
• Always unplug the machine and turn off the water supply after use.
• Connect the machine to an earthed socket in accordance with current wiring regulations.
• The appliance must e positioned so that the plug is easily accessi le.
• Repairs to the washing machine must only e carried out y qualified personnel.
Repairs carried out y inexperienced persons may cause injury or serious malfunctioning.
Contact your local service center
• Do not install your washing machine in rooms where temperature elow freezing may occur.
Frozen hoses may urst under pressure. The relia ility of the electronic control unit may e
impaired at temperatures elow freezing point.
• If the appliance is delivered in the winter months and temperatures are elow freezing : Place
the washing machine at room temperature for a few hours efore putting it into operation.
❿ Electrical connection

11
1. Unscrew the adapter ring plate and the 4
adapter retaining screws.
2. Push the adapter onto the end of the tap
so that the rubber seal forms a watertight
connection. Tighten the adapter ring plate
and the 4 screws.
3. Push the water supply hose vertically
upwards so that the rubber packing within
the hose can adhere completely to the
tap and then tighten it by screwing it to
the right.
• Water supply pressure must be between 1 kPa and 8 kPa (1. - 8. kgf / cm
2
).
• Do not strip or crossthread when connecting inlet hose to the valve.
• If the water supply pressure is more than 8 kPa, a decompression device should be installed.
• Periodically check the condition of the hose and replace the hose if necessary.
Type-A : Connecting Screw-type hose to tap with thread
• Screw the hose connector onto water
supply tap.
■Connecting water supply hose
❿ Step1 : Check rubber seal inlet hose
❿ Step2 : Connect hose to water tap
• Two rubber seals are supplied with the
water inlet hoses.
They are used for preventing water leaks.
Make sure the connection to taps is
sufficiently tight.
Do not use pliers, multi grips or leverage
tools to tighten. Hand tighten only.
Use a cloth if necessary.
Upper
connector Rubber
packing
Plate
Water supply
hose
Fixing screw
Hose
connector
Rubber
seal
Type-B : Connecting Screw-type hose to tap without thread
Installation

12
1. Unscrew the adapter ring plate and
the 4 adapter retaining screws.
2. Remove the guide plate if the tap is
too large to fit the adapter.
3. Push the adapter onto the end of
the tap so that the ru er seal forms
a watertight connection.
Tighten the adapter ring plate and
the 4 screws.
4. Pull the connector latch plate down,
push the inlet hose onto the adapter,
and release the connector latch plate.
Make sure the adapter locks into place.
Please use the horizontal tap
Horizontal tap Extension tap Square tap
Ring plate
Guide plate
Latch plate
Type-C : Connecting one touch type hose to tap without thread
❿ Step3: Connect hose to washer
• Make sure that there are no kinks in the
hose and that they are not crushed.
❿ When your washer has two valves.
• The Inlet hose which has red connector is
for the hot water tap.
• If the washer has two valves, the energy is
saved y using hot valve.
Installation
NOTE
• After completing connection, if water leaks from the hose, repeat the same steps.
NOTE
• After connecting inlet hose to water
tap, turn on the water tap to flush
out foreign su stances (dirt, sand or
sawdust) in the water lines. Let
water drain into a ucket, and
check the water temperature.

13
Installation o drain hose
• The drain hose should not e placed
higher than 100 cm a ove the floor.
Water in the washer does not drain or
drains slowly if a ove this height.
• Securing the drain hose correctly will
protect the floor from damage due to
water leakage.
• If the drain hose is too long, do not force
ack into the washer.
This will cause a normal noise, possi le
water leakage and malfunction.
• When installing the drain hose to a sink,
secure it tightly with string.
• Securing the drain hose correctly will
protect the floor from damage due to
water leakage.
a out 100 cm
a out 145 cm
a out 105 cm
max. 100 cm
Hose
Retainer
Tie strap
Laundry tu
max. 100 cm
max. 100 cm
Installation

14
•Diagonal Check
When pushing down the edges of the
washing machine top plate diagonally,
the machine should not move up and down
at all (Please, check oth directions). If
machine rocks when pushing the machine
top plate diagonally, adjust the feet again.
2. If the floor is uneven, turn the adjusta le feet
as required. (do not insert pieces of wood
etc. under the feet)
Make sure that all four feet are sta le and
resting on the floor and then check that the
appliance is perfectly level. (use a spirit
level)
1. Leveling the washing machine properly
prevents excessive noise and vi ration.
Install the appliance on a solid and level
floor surface, prefera ly in a corner of the
room.
■Leveling
•Once the washer is level, tighten the lock
nuts up towards the ase of the washer.
All lock nuts must e tightened.
Raise Lower
Lock
Nut
Tighten all 4
locknuts securely
Installation
NOTE
• Tim er or suspended type flooring
may contri ute to excessive
vi ration and un alance.
NOTE
Do not install the machine on a raised platform.

15
❿ Concrete loors
❿ Wooden loors (Suspended loors)
• The installation surface must e clean, dry and level.
• Install washer on a flat hard floor.
❿ Tile loors (Slippery loors)
• Position each foot on the Tread Mate and level the machine to suit. (Cut Tread Mate into
70x70 mm sections and stick the pieces on to the dry tile where machine is to e placed.)
• Tread Mate is a self adhesive material used on ladders & steps that prevents slipping.
•Wooden floors are particularly suscepti le to vi ration.
•To prevent vi ration we recommend you place ru er cups under
each foot under washer at least 15mm thick, secured to at least
2 floor eams with screws.
•If possi le install the washer in one of the corners of the room, where the floor is more sta le.
•
Fit the ru er cups to reduce vi ration.
• You can o tain the ru er cups (p/no.4620ER4002B) from the LG spares dept.
If vi ration persists with ru ers fitted. The flooring structure or rigidity may e
inadequate for proper operation.
Ru er Cup
Installation
NOTE
• Proper placement and leveling of the washer will ensure long, regular and relia le
operation.
• The washer must e 100% horizontal and stand firmly in position.
• It must not “Seesaw” across corners under load.
• The installation surface must e clean, free from floor wax and other lu ricant coatings.
• Do not let the feet of the washer get wet. If feet of the washer get wet, slipping may occur.

16
How to use washer
Operating washing machine
2. Open the door and load laundry.
1. Sort Laundry.
(Refer to 17 page)
3. Press the Power utton.
4. Select a Program.
(Refer to 18 ~ 20 page)
5. Add detergent.
(Refer to 26 ~ 27 page)
6. Press the Start/Pause utton.
Select options at this time
(Refer to 22 ~ 25 page)
■Additional Program
■Temperature
■Spin Speed
■Other functions

17
■Care before washing
3.Caring before loading
Combine large and small items in a load. Load
large items first. Large items should not be more
than half the total wash load. Do not wash single
items.
This may cause an out-of-balance load. Add one or
two similar items.
• Check all pockets to make sure that they are
empty. Items such as nails hair clip matches
pens coins and keys can damage both your
washer and your clothes.
• Close zippers hooks and strings to make sure
that these items don’t snag on other clothes.
• Pre treat dirt and stains by brushing a little
detergent dissolved in water onto stains like
collars and cuffs to help lift dirt.
• Check inside of the drum and remove any item
from a previous wash.
2.Sorting
To get the best results sort clothes into loads that
can be washed with the same wash cycle.
Water temperature and spin speed and different
fabrics need to be washed in different ways.
Always sort dark colors from pale colors and whites.
Wash separately as dye and lint transfer can occur
causing discolouration of white etc. If possible do
not wash heavily soiled items with lightly soiled one.
• Soil (Heavy Normal Light)
Separate clothes according to amount of soil.
• Color (White Lights Darks)
Separate white fabrics from colored fabrics.
• Lint (Lint producers Collectors)
Wash lint producers and lint collectors separately.
1.Care Labels
Look for a care label on your clothes.
This will tell you about the fabric content of your
garment and how it should be washed.
Wash temperature
Normal machine wash
Permanent press
Hand wash
Sort laundry by...
Soiling
Colour
Wash
temperature
Fabric type
Delicate
Do not wash
How to use washer
NOTE
• Before the first wash select a cycle (Cotton 60°C add a half load of detergent) allow
the unit to wash without clothing. This will remove residues and water from the drum
that may have been left during manufacturing.

18
Washing program table
• Recommended courses according to the laundry type.
How to use washer
Cotton Eco
Easy Care
Mix
Provide optimized washing performance
with less energy consumption.
This cycle is suitable for casual shirts
that do not need ironing after washing.
Enables various fabrics to be
washed simultaneously.
Program Description Fabric type Proper
Temp.
Maximum
Load
Provides better performance by
combining various drum motions. Color fast garments (shirts
nightdresses pajamas etc) and
normally soiled cotton load
(underwear).
Polyamide Acrylic Polyester.
Various kind of fabrics except special
garments. (Silk/delicate sports wear
dark clothes wool Duvet/Curtains).
Allergy
Care
Removes allergens such as house
mites pollen and cat fur.
Cotton underwear pillow covers
bed sheets baby wear.
Silent
Was
Provides less noise and vibration and
saves money by using overnight
electricity.
Color fast garments (shirts
nightdresses pajamas etc)and lightly
soiled white cotton (underwear).
Refres
Removes wrinkles within 20mins with
steam.
Cotton mixed Polyester mixed Dress
shirts blouses.
Duvet
This cycle is for large items such as
bed cover pillows sofa covers etc.
Cotton bedding except special
garments (delicates wool silk etc.)
with filling: duvets pillows blankets
sofa covers with light filling.
Sports
Wear
This cycle is suitable for sports wear
such as jogging clothes and running
wear.
Coolmax Gore-tex fleece and
Sympatex.
Dark
Was
If it's possible for clothes to decolorate
please use this cycle. The cycle
prevent decolorization. (Please use
detergent for colored fabrics.)
Dark garments made from cotton or
mixed fabrics.
Delicate
This cycle is for delicate clothes such
as underwear blouse etc. Delicate easily damaged laundry.
Wool
Enable to wash wool fabrics.
(Please use detergent for
machinewashable woolens).
Machine washable woolens with
pure new wool only.
Quick 30
This cycle provides fast washing time
for small loads and lightly soiled
clothes.
Colored laundry which is lightly
soiled fast.
Intensive 60
Within 60mins provide better washing
performance and energy efficiency.
Cotton and mix fabrics.
(Special PROGRAM within 60 mins
for normally soiled laundry).
40°C
(Cold to 95°C)
60°C
(Cold to 60°C)
40°C
(Cold to 60°C)
40°C
(Cold to 40°C)
60°C
40°C
(Cold to 60°C)
No choice
40°C
(Cold to 40°C)
30°C
(Cold to 40°C)
40°C
(Cold to 40°C)
30°C
(Cold to 40°C)
60°C
(Cold to 60°C)
Rating
Less than
5.5 kg
Less than
6.5 kg
3 items
1 single
size
Less than
3.0 kg
Less than
5.5 kg
Cotton

19
How to use washer
NOTE
• Neutral detergent is recommended.
• The wool cycle features gentle tumbling and low-speed spin for garment care.
Extra options
* : This option is automatically included in the cycle and can not be deleted.
• Water Temperature: Select water temperature to suit wash cycles.
Always follow garment manufacture’s care label or instructions when washing.
• Set program at “Cotton Eco 40°C Intensive Normal Rinse 1400RPM” is for normally
soiled load and test in accordance or in conformity with AS/NZS 2040.1.
• The test results depend on water pressure water hardness water inlet temperature room
temperature type and amount of load degree of soiling utilized detergent fluctuations in
the main electricity supply and chosen additional options.
• For best washing results we recommend to mix dry detergent with warm water.
*
*
*
Time
Delay
Steam
Was Favorite
Program Pre
Was
Medic
Rinse
Rinse+
Spin
Time
Save
Intensive
Cotton
Cotton Eco
Easy Care
Mix
Allergy Care
Silent Was
Refres
Duvet
Sports Wear
Dark Was
Delicate
Wool
Quick 30
Intensive 60

20
How to use washer
Operating data
Max RPM
1400
1400
1000
1400
1400
1000
–
1000
800
1400
800
800
1400
1400
Program
Cotton
Cotton Eco
Easy Care
Mix
Allergy Care
Silent Was
Refres
Duvet
Sports Wear
Dark Was
Delicate
Wool
Quick 30
Intensive 60
