LG WDN1653BDS User manual

Washing Machine
OWNER'S MANUAL
WDN1653BDS
Thank you for buying a
LG Fully Automatic Washing machine.
Please read your owner's manual carefully, it rovides
instructions on safe installation, use and maintenance.
Retain it for future reference.
Record the model and serial numbers of your washing
machine.
P/No.: MFL62526832

roduct Feature
P
ontents
C
2
Warnings...............................................................................................3
Specification..........................................................................................4
Installation.............................................................................................5
Care before washing...........................................................................10
Using the dispenser ............................................................................11
Function ..............................................................................................13
How to use washer .............................................................................14
Maintenance .......................................................................................22
Troubleshooting guide ........................................................................25
■Ultra Capacity
The Larger drum enables not just higher head drop and stronger centrifugal force, but
also less tangling and wrinkling of the laundry. Heavier loads, such as king size
comforters, blankets, and curtains, can be washed.
■Direct Drive System
The advanced Brushless DC motor directly drives the drum without belt and
pulley.
■Tilted Drum and Extra Large Door Opening
Tilted drum and extra large opening make it possible to load
and unload clothing more easily.
■Water Circulation
Spray detergent solution and water onto the load over and over.
Clothes are soaked more quickly and thoroughly during wash cycle.
The detergent suds can be removed more easily by the water shower during
rinse cycle. The water circulation system uses both water and detergent more
efficiently.
■RollerJets
Washing ball enhances the wash performance and reduces damage to the
clothing. The jets spray and help tumble clothes to enhance washing
performance while maintaining fabric care.
■Automatic Wash Load Detection
Automatically detects the load and optimizes the washing time.
■Built-in Heater
Internal heater helps to maintain water temperature at its optimum level for
selected cycles.
■Child Lock
The Child lock prevents children from pressing any button to change the settings
during operation.
■HIgH-EFFICIENCY STEAM CYCLES
During LG’s unique high-efficiency STEAM cycles, the steam nozzle injects
fabrics with hot steam to gently remove tough stains.
√fl∞°º±≈√ øπæ‡
√fl∞°º±≈√ øπæ‡

arnings
W
3
For your sa ety, the in ormation in this manual must be ollowed to minimize
the risk o ire or explosion, electric shock, or to prevent property damage,
personal injury, or loss o li e.
!
READ ALL INSTRUCTIONS BEFORE USE
WARNING!
• Read all instructions before using the washer.
• Do not wash articles that have been reviously
cleaned in, washed in, soaked in, or s otted with
gasoline, dry cleaning solvents, or other
flammable or ex losive substances, as they give
off va ors that could ignite or ex lode.
• Do not add gasoline, dry cleaning solvents, or
other flammable or ex losive substances to the
wash water. These substances give off va ors
that could ignite or ex lode.
• Under certain conditions, hydrogen gas may be
roduced in a hot water system that has not
been used for 2 weeks or more. HYDROGEN
GAS IS EXPLOSIVE. If the hot water system
has not been used for such a eriod, before
using the washing machine, turn on all hot water
faucets and let the water flow from each for
several minutes. This will release any
accumulated hydrogen gas. As the gas is
flammable, do not smoke or use an o en flame
during this time.
• Do not allow children to lay on or in the washer.
Close su ervision of children is necessary when
the washer is used near children.
• Before the washer is removed from service or
discarded, remove the door to revent children
from hiding inside.
• Do not install or store the washer where it will be
ex osed to the weather.
• Do not tam er with controls.
• Do not re air or re lace any art of the washer
or attem t any servicing unless s ecifically
recommended in the user-maintenance
instructions or ublished user-re air instructions
that you understand and have the skills to carry
out.
• See Installation Instructions for grounding
requirements.
• ALWAYS follow the fabric care instructions
su lied by the garment manufacturer.
• Do not lace items ex osed to cooking oil in
your washer. Items contaminated with cooking
oils may contribute to a chemical reaction that
could cause a load to catch fire.
• Do not use fabric softeners or roducts to
eliminate static unless recommended by the
manufacturer of the fabric softener or roduct.
GROUNDING INSTRUCTIONS
This a liance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk
of electric shock by roviding a ath of least resistance for electric current. This a liance is equi ed with
a cord having an equi ment-grounding conductor and grounding lug. The lug must be lugged into an
a ro riate outlet that is ro erly installed and grounded in accordance with all local codes and ordinance.
• Do not use an ada ter or extension cord.
• Do not remove ground rong.
• If you don’t have the ro er outlet, consult an electrician.
IMPORTANT SAFETY INSTRUCTIONS
WARNING :To reduce the risk of fire, electric shock, or injury to ersons when using
the washer, follow basic recautions, including the following:
SAVE THESE INSTRUCTIONS
WARNING :Im ro er connection of the equi ment-grounding conductor can result in risk of electric
shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the a liance
is ro erly grounded. Do not modify the lug rovided with the a liance - if it does not fit the outlet,
have a ro er outlet installed by a qualified electrician.
!
!

 Accessories
pecification
S
4
Name : Front loading washing machine
Power su ly : 120 V~, 60 Hz
Size : 686 mm(W)×756 mm(D)×983 mm(H) /
1295 mm (D, door o en)
Weigh : 87 kg (192 lbs)
Wash ca acity : 16 kg (35 lbs)
Max. Watt : 1200 W
S in s eed : 1200 r m max.
Permissible water ressure : 0.3-10kgf/cm2(30-1000kPa)
❋The a earance and s ecifications may be varied without notice to raise the units quality.
Inlet hose 1EA
❈ O tion Hot/Cold (2EA) S anner Ca s (4EA) Tie Stra Elbow Bracket Non-skid ads

nstallation
I
5
1. To revent internal damage during
trans ort, the s ecial 4 bolts are locked.
Before o erating the washer, remove
the bolts along with the rubber bungs.
• If they are not removed, it may cause severe
vibration, noise and malfunction.
3. Take out the 4 bolts along with the rubber
bungs by slightly twisting the bung. Kee
the 4 bolts and the s anner for future use.
• Whenever the a liance is trans orted, the
transit bolts must be refitted.
The a liance is fitted with transit bolts to revent internal damage during trans ort.
2. Unscrew the 4 bolts with
the s anner su lied.
4. Close the holes with the ca s su lied.
 Removing transit bolts
cap
Install or store where it will not be exposed to temperat res below freezing or exposed to the weather.
Properly gro nd washer to conform with all governing codes and ordinances.
To red ce the risk of electric shock, do not install the washer in h mid spaces.
The base opening m st not be obstr cted by carpeting when the washing machine is installed on a
carpeted floor.
In co ntries where there are areas which may be s bject to infestation by cockroaches or other
vermin, pay partic lar attention to keeping the appliance and its s rro ndings in clean condition at
all times.
Any damage which may be ca se by cockroaches or other vermin will not be covered by the
appliance g arantee.
 Transit bolts

6
nstallation
I
■Installation clearances
The location must be large enough to fully o en
the washer door.
■Washer dimensions
• Most installations require a minimum
10 cm clearance behind the washer.
■Minimum installation spacing or recessed
area installation.
The following dimensions shown are for the
minimum s acing allowed.
Additional s acing should be considered for
installation and servicing.
• Additional clearances might be required
for wall, door and floor moldings.
• Additional s acing of 2.5 cm on all
sides of the washer is recommended to
reduce noise transfer.
Com anion a liance s acing should also be
considered.
[Front view]
[Side view]
■Level loor
• Allowable slo e under entire washer is 1°.
• To minimize noise and vibration, the washer
MUST be installed on a solidly constructed loor.
• Car eting and soft tile surfaces are not
recommended.
• Never install the washer on a latform or weakly
su orted structure.
NOTE: A firm, solid floor is even more critical to a front-
loading washer than to a top-loader.
If yo r floor is wood and/or frame constr ction, yo
may need to reinforce it. Front-loaders se
s bstantially faster spin speeds than top-loaders,
ca sing greater vibration. If the floor is not solid,
yo r washer will vibrate. Yo will hear and feel the
vibration thro gho t yo r ho se.
■Power outlet
• Must be within 60 in. (1.5 m) of either side of the
washer. Do not overload the outlet with more
than one a liance.
• Time-delay fuse or circuit breaker is recommended.
NOTE: It is the personal responsibility and obligation of the
c stomer to have a proper o tlet installed by a
q alified electrician.

7
nstallation
I
Rubber seal
Hose connector
CAUTION concerning the Power Cord
Most a liances recommend they be laced u on a dedicated circuit; that is, a single outlet circuit
which owers only that a liance and has no additional outlets or branch circuits. Check the
s ecification age of this owner's manual to be certain.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords,
frayed ower cords, or damaged or cracked wire insulation are dangerous. Any of these conditions
could result in electric shock or fire. Periodically examine the cord of your a liance, and if its
a earance indicates damage or deterioration, un lug it, discontinue use of the a liance, and have
the cord re laced with an exact re lacement art by an authorized servicer.
Protect the ower cord from hysical or mechanical abuse, such as being twisted, kinked, inched,
closed in a door, or walked u on. Pay articular attention to lugs, wall outlets, and the oint where
the cord exits the a liance.
CAUTION
▶ Water supply pressure must be between 30kPa and 1000kPa
(0.3~10kgf/cm2)
▶ D n’t strip r cr ssthread when c nnecting Inlet h se t the valve.
▶ If the water supply pressure is m re than 1000kPa, a dec mpressi n device
sh uld be installed.
• Two rubber seals are su lied with the water inlet hoses these are in
order to revent water leaks.
• Check water tightness of washing machine connections by turning the
ta com letely on.
• Periodically check the condition of the hose and re lace the hose if
necessary.
• Make sure that there is no kink on the hose and that it is not crushed.
▶ When y ur washer has tw valves,
• The Inlet hose which has red connector is for the hot water ta .
• If the washer has two valves, the energy is saved by using hot valve.
 Washing Machine is to be connected to the water mains using new hose-sets and that old
hose-sets should not be used.
 Connecting water supply hose
1. Do not use an extension cord or double ada ter.
2. If the su ly cord is damaged, it must be re laced by the manufacturer or its service agents or
similarly qualified erson in order to avoid a hazard.
3. Always un lug the machine and turn off the water su ly after use.
4. Connect the machine to an earthed socket in accordance with current wiring regulations.
5. The a liance must be ositioned so that the lug is easily accessible.
• Re airs to the washing machine must only be carried out qualified ersonnel. Re airs carried out by
inex erienced ersons may cause injury or serious malfunctioning. Contact your local service center
• Do not install your washing machine in rooms where tem eratures below freezing may occur. Frozen hoses
may burst under ressure. The reliability of the electronic control unit may be im aired at tem eratures below
freezing oint.
• If the a liance is delivered in the winter months and tem eratures are below freezing : Store the washing
machine at room tem erature for a few hours before utting it into o eration.
 Electrical connection

8
nstallation
I
 Installation of drain hose
about
about
about
max. 100cm
min. 60cm
Hose
Retainer
Laundry tub
Tie
stra
max. 100cm
min. 60cm
about
about
about
• The drain hose should not be laced
higher than 100 cm above the floor.
• Pro er securing of the drain hose will
rotect the floor from damage due to
water leakage.
• When the drain hose is too long, do
not force back into the washer. This
will cause abnormal noise.
• When installing the drain hose sink,
secure it tightly with a string.
• Pro er securing of the drain hose will
rotect the floor from damage due to
water leakage.
• Place the end of the drain hose in the
hole of the floor drain system.
This equi ment is not designed for maritime use or for use mobile installations such as
caravans, aircraft etc.
Turn off the sto cock if the machine is to be left for any length of time (e.g. holiday),
es ecially if there is no floor drain(gully) in the immediate vicinity.
When dis osing of the a liance, cut off the mains cable, and destroy the lug Disable the
door lock to revent young children being tra ed inside.
Packaging material (e.g. Films, Styrofoam) can be dangerous for children. There is a risk
of suffocation !
Kee all ackaging well away from children.

9
nstallation
I
 Level adjustment
 Installation of non-skid pads (optional)
1. Adjusting the washing machine level properly prevents
excessive noise and vibration.
Install the appliance on a solid and level floor surface,
preferably in a corner of the room.
NOTE: Extend the feet no more than necessary to level the
washer. The more the feet are extended, the more the
washer will vibrate.
2. If the floor is uneven, adjust the adjustable feet as
required. (Do not insert pieces of wood etc. under the
feet)
Make sure that all four feet are stable and resting on the
floor and then check that the appliance is perfectly level.
(Use a spirit level)
❊After the washer is level, tighten the lock nuts up towards
of the base of the washer. All lock nuts must be tightened.
NOTE: If there are vibration and noise during the spin cycle,
re-check the leveling of the washer, adjust the feet as
required, and tighten the lock nuts securely to prevent
changes in adjustment.
Run the washer with a test load to make certain your
washer is properly leveled. Put approximately 6 pounds
of laundry in the machine. Then, press POWER,
RINSE+SPIN, and START/PAUSE, in that order.
When the machine spins at high speed, verify that it is
stable. If not, adjust
❊ Diagonal Check
When pushing down the edges of the washing machine top
plate diagonally, the machine should not move up and down at
all. (Please, check both of two directions)
If machine rocks when pushing the machine top plate
diagonally, adjust the feet again.
Some floor surfaces are too slippery to
prevent the washer from moving on the floor
during heavily unbalanced loads. While it is
normal for an occasional load to be out of
balance, excess noise and vibration can
result from the washer moving out of position.
If these conditions are encountered, follow
the instructions below for installation of the
non-skid pads. These pads will help prevent
the washer from moving during heavy out of
balance conditions thereby reducing noise
and vibration.
• Non-skid pads
 Place the pads under both front feet.
Adjustable feet Adjustable feet
Lock nut
This side up
Stick adhesive side to floor
Remove backing

10
are before washing
C
1. Fabric Care Labels
Look for a care label on your clothes. This will tell you about the fabric content of your
garment and how it should be washed.
2. Sorting
To get the best results, sort clothes into loads that can be washed with the same wash
cycle.
Different fabrics need to be washed in different ways.
Always sort dark colors from ale colors and whites. Wash se arately as dye and lint
transfer can occur causing discoloration of white clothing. If ossible, do not wash
heavily soiled items with lightly soiled ones.
Soil (Heavy, Normal, Light) Separate clothes according to amo nt of soil.
Color (White, Lights, Darks) Separate white fabrics from colored fabrics.
Lint (Lint Prod cers, Collectors) Wash lint prod cers and lint collectors separately.
3. Check be ore loading
Combine large and small items in a load. Load large items first.
Large items should not be more than half the total wash load.
Do not wash single items. This may cause an out-of-balance load. Add one or two similar
items.
• Check all the ockets to make sure that they
are em ty. Things such as cli , matches,
ens, coins, and keys can damage both your
washer and your clothes.
• Close zi ers, hooks, and strings to make
sure that these items do not snag on other
clothes.
• Pretreat dirt and stains by brushing a little
detergent dissolved in water onto stains like
collars and cuffs to hel lift dirt.
WARNING
To reduce the risk o ire, electric shock, or injury to persons, read the
IMPORTANT SAFETY INSTRUCTIONS be ore operating this appliance.
NOTE: Do not wash or spin water-proof clothes.

11
sing the dispenser
U
The a tomatic dispenser consists of fo r compartments which hold 1) liq id chlorine bleach,
2) liq id fabric softener, 3) liq id or powdered detergent for prewash and 4) liq id or
powdered detergent
and color safe bleach for main wash.
All la ndry prod cts can be added at once in their respective dispenser compartments.
They will be dispensed at the appropriate time for most effective cleaning. After loading the
la ndry
additives into the dispenser, close the dispenser drawer.
Add detergent, bleach and abric so tener to the automatic dispenser ollowing
these steps:
1. O en the dis enser drawer.
2. Load the laundry roducts into the a ro riate com artments.
3. Close the dis enser drawer.
■About detergent
Low sudsing detergent is recommended for this washer. Use the manufacturer's
recommended amount.
If low sudsing detergent is not available, a reduced amount of regular detergent may be
used.
Because reducing the amount of detergent may reduce cleaning, it is im ortant to
retreat stains,
sort carefully by color and soil level, and avoid overloading.
Detergent usage may need to be adjusted for water tem erature, water hardness, size
and soil level of the load.
For best results, avoid using too much detergent.
• Add detergent to this com artment
when using the Prewash o tion.
Liquid or owdered detergent may
be used in this com artment. The
detergent will automatically be
dis ensed during Prewash if the
Prewash o tion is selected.
• Add 1/2 the recommended amount
of detergent to the Prewash
com artment and the
recommended amount of detergent
to the main wash com artment.
NOTE : Liq id detergent will drain
into the washer dr m as it is
added.
Liquid Chlorine
Bleach
Com artment
Liquid Fabric
Softener
Com artment
Prewash
Com artment
Main Wash
Com artment
1. Prewash Detergent
Compartment

12
sing the dispenser
U
Liquid Detergent Box
Insert
• Add measured detergent to this
com artment for Main wash. Detergent
is flushed from the dis enser at the
beginning of the cycle. Either owdered
or liquid detergent can be used.
• Liquid or owdered color-safe bleach
may be added to the main wash
com artment along with the same ty e
of liquid or owdered detergent.
• When using liquid detergent, make sure
the liquid detergent box and insert are
in lace. Do not exceed the maximum
fill line.
• For owered detergent, remove both
the liquid detergent box and insert.
• Powdered detergent will not dis ense
with the liquid detergent box and insert
in lace.
2. Main Wash Detergent
Compartment
• Add measured liquid chlorine bleach to
this com artment. The bleach will be
automatically dis ensed at the ro er
time during the wash cycle.
• Do not exceed the maximum fill line.
Overfilling can cause early dis ensing of
the bleach which could result in
damaged clothes.
• Do not our undiluted liquid chlorine
bleach directly onto the load or into the
drum. Fabric damage can occur.
• Do not use owdered bleach in this
com artment.
3. Liquid Bleach Compartment
• Add recommended amount of fabric
softener to this com artment.
• Dilute concentrated softeners with
warm water to the fill line.
• Do not exceed the maximum fill line.
Overfilling can cause early dis ensing
of the fabric softener which could result
in stained clothes.
• Do not our fabric softener directly on
the wash load.
• The fabric softener will be automatically
dis ensed during the last rinse cycle.
4. Fabric So tener Compartment
NOTE: Do not place, store, or spill la ndry
prod cts (soap, detergent, bleach,
softener, etc.) on the top of yo r
washer or dryer. These prod cts
can damage the finish or controls if
left there too long.

13
unction
F
■Select cycles designed for different types of fabric and soil levels.
Cycle
SANITARY
STEAM
FRESHTM Dress shirts, blouses
Heavily soiled
underwear, work
clothes, diapers, etc.
Extra Hot/Cold
Fabric type Spin Speed Soil
Level
Pre-
Wash Rinse + Spin Extra Rinse Stain Cycle Water
plus
Maximum
Load
Wash/Rinse
Temp.
Steam
High ( )
Extra High ( )
No spin ( )
Low ( )
Medium ( )
Normal
Heavy
Light
Less than
2.0 kg
Less than
8.0 kg
NOTE: To protect your garments, not every Wash/Rinse temperature, spin speed, soil level or option is available with
every cycle.
BULKY/
LARGE
Large items such as
blankets and
comforters
Warm/Cold
Warm/Warm
Hot/Cold
Cold/Cold
Low ( )
Medium ( )
No spin ( )
Normal
Heavy
Light Less than
8.0 kg
SPEED
WASH
Lightly soiled clothing
and small loads
Hot/Cold
Cold/Cold
Warm/Cold
Warm/Warm
Extra High ( )
No spin ( )
Low ( )
Medium ( )
High ( )
Normal
Heavy
Light Less than
4.0 kg
ALLERGIENETM
Cotton, underwear,
pillow covers,
bed sheets,
baby wear
High ( )
No spin ( )
Low ( )
Medium ( )
Less than
8.0 kg
PERM.
PRESS
Dress shirts/pants,
wrinkle-free clothing,
poly/cotton blend
clothing, tablecloths
Warm/Cold
Warm/Warm
Hot/Cold
Cold/Cold
Medium ( )
High ( )
No spin ( )
Low ( )
Normal
Heavy
Light Less than
8.0 kg
DELICATES
Dress shirts/blouses
nylons, sheer or lacy
garments
Cold/Cold
Warm/Cold
Warm/Warm
Medium ( )
No spin ( )
Low ( )
Normal
Heavy
Light
Less than
4.0 kg
HAND WASH/
WOOL
Items labeled
"hand washable"
Warm/Cold
Warm/Warm
Cold/Cold
Low ( )
No spin ( )
Normal
Light Less than
3.5 kg
COTTON/
NORMAL
Cotton, linen, towels
shirts, sheets, jeans
mixed loads
Warm/Cold
Warm/Warm
Hot/Cold
Cold/Cold
High ( )
Extra High ( )
No spin ( )
Low ( )
Medium ( )
Normal
Heavy
Light Less than
16.0 kg
RECOMMENDED LOADS

14
1. POWER ON/OFF BUTTON
2. CYCLE SELECTOR KNOB
3. START/PAUSE BUTTON
5. CYCLE SETTING BUTTONS
6. DELAY WASH BUTTON
ow to use washer
H
Turn this knob to select the desired cycle. Once
the desired cycle has been selected, the standard
presets will be shown in the display. These
settings can be adjusted using the cycle setting
buttons anytime before starting the cycle.
Press to turn the washer ON. Press again to turn
the washer OFF.
NOTE: Pressing the ON/OFF button during a
cycle will cancel that cycle and any load settings
will be lost.
Press this button to START the selected cycle.
If the washer is running, use this button to
PAUSE the cycle without losing the current
settings.
NOTE: If you do not press the START/PAUSE
button within 4 minutes of selecting a cycle, the
washer automatically turns off.
4. STEAM BUTTON
Press the STEAM button to add steam to the
selected cycle for added cleaning power.
NOTE: Steam can only be added to the
following cycles: STEAM FRESH™,
ALLERGIENE™, SANITARY, BULKY/LARGE,
COTTON/NORMAL, and PERM. PRESS
Press this button to delay the start of the wash
cycle. Each press of the button increases the
delay time by one hours, up to 19 hours.
7. LED DISPLAY
The display shows the settings, estimated time
remaining, options, and status messages for
your WASHER. The display will remain on
through the cycle.
8. OPTION BUTTONS
The option buttons allow you to select additional
cycle options and will light when selected.
Certain buttons also allow you to activate
special functions by pressing and holding the
button for 3 seconds.
For detailed information about the individual
options, please see the following pages.
Use these buttons to select the desired cycle
options for the selected cycle. The current
options are shown in the display. Press the
button for that option to view and select other
settings.

15
ow to use washer
H
THE LED DISPLAY
1. ESTIMATED TIME REMAINING
When the START/PAUSE button is pressed, the
washer automatically detects the wash load
(weight) and optimizes the washing time, based
on the selected cycle and options. The display
will then indicate the estimated time remaining for
the selected wash cycle.
NOTE: The cycle time displayed may appear
much longer than that of a top-loading washer.
The displayed time is for the complete cycle,
rather than just the agitation portion of the cycle,
as is typically shown on a top-loading washer.
2. CYCLE COMPLETION INDICATOR
This portion of the display shows which stage
of the wash cycle is currently underway (LOAD
SENSING, WASH, RINSE or SPIN).
3. AUTOMATIC LOAD SIZE SENSING
At the beginning of the cycle, the washer
tumbles the load and detects the weight of the
clothes. The display will indicate the
approximate load size in the LOAD SIZE
display. This allows you to adjust the amount of
detergent and other additives for best results
and improved efficiency.
4. DOOR LOCK INDICATOR
Indicates that the door is locked. The washer
door will lock while the washer is operating.
The door can be unlocked by pressing the
START/PAUSE button to stop the washer.
NOTE: If the temperature in the washer is too
high, the door cannot be unlocked until the
washer has cooled. If the water level is too
high, select the DRAIN & SPIN cycle to drain
excess water. Do not try to force open the door.
5. DELAY WASH INDICATOR
This indicator shows that the washer has been
set for DELAY WASH. The washer will start
automatically after the set delay time has
passed.
The LED display shows the settings, estimated time remaining, options, and status messages for your
washer. When the washer is turned on, the display will illuminate.

16
ow to use washer
H
OPERATING THE WASHER
Once you have loaded the washer and added
laundry products (detergent, bleach, and/or fabric
softener):
❶Press the ON/OFF button to turn on the
washer. The lights around the cycle
selector knob will illuminate.
❺Press the START/PAUSE button to begin the
cycle. The door will latch, the display
will change, and the washer will
calculate the estimated time
remaining. Once the washer has
calculated the estimated total cycle time, the
washer will start. To pause the cycle at any
time, press PAUSE.
NOTE: The cycle time displayed may appear
much longer than that of a top-loading
washer. The displayed time is for the
complete cycle, rather than just the agitation
portion of the cycle, as is typically shown on a
top-loading washer.
NOTE: If the temperature in the washer is too
high, the door cannot be unlocked until the
washer has cooled. If the water level is too
high, select the SPIN cycle to drain excess
water. Do not try to force the door
open.Washing time can be reduced
significantly for small or lightly soiled loads by
selecting the Speed Wash cycle and setting
the Soil Level button to Light.
❻When the load is finished, the beeper (if set)
will sound and the door will unlock.
Remove damp clothes from the washer
immediately. Check under the door seal for
small items.
❷Turn the cycle selector knob to the desired
cycle. The display will show the
preset Rinse/Wash Temperature,
Spin Speed, Soil Level, and Option
settings for that cycle.
❹Select any additional cycle options, such as
STEAM, DELAY WASH, EXTRA RINSE, or
STAIN CYCLE, by pressing the button for that
option.
❸If you would like to change the settings for
that cycle, press the appropriate cycle
settings button(s) until the indicator light for
the desired setting is lit.
NOTE: To protect your garments, not every
wash/rinse temperature, spin speed, soil
level, or option is available with every cycle.
NOTE: To protect your garments, not every
wash/rinse temperature, spin speed, soil
level, or option is available with every cycle.

17
ow to use washer
H
STEAM CYCLES
STEAM cycles include the Steam
Fresh™, Allergiene™, Sanitary,
Bulky/Large, Cotton/Normal and Perm.
Press cycles. Adding the Steam option to
these cycles provides superior cleaning
performance while reducing energy and water
consumption. By using a hot steam spray from
above and cooler water below, fabrics get the
cleaning benefits of a super hot wash, without the
energy usage or potential damage to fabrics.
CAUTION:
Do not touch the door during steam cycles. The
door surface can become very hot.
Allow the door lock to release before opening
the door.
Do not attempt to override the door lock
mechanism or reach into the washer during a
steam cycle. Steam can cause severe burns.
IMPORTANT NOTES ABOUT STEAM CYCLES:
• Steam may not be clearly visible during the steam
cycles. This is normal. Too much steam could
damage clothing.
• Do not use steam with delicate fabrics such as
wool, silk, or easily discolored fabrics.
• Do not touch the door.
❶Turn on the washer and turn the cycle selector
knob to select a cycle with the STEAM option.
❷Press the STEAM button. The washer will
automatically adjust the cycle settings.
❸Set any other desired options.
❹Press the START/PAUSE button to start the
cycle. The washer will start automatically.
To Add STEAM to a Standard Cycle: ❶Turn on the washer and turn the cycle selector
knob to select the Steam FreshTM cycle.
❷Load up to 5 items and close the door.
NOTE: If there is any moisture inside the
drum, such as from a previous wash cycle,
wipe the drum dry with a towel before adding
clothes.
❸Press the STEAM button until the correct
number of items is shown in the display.
No other options need to be set.
❹Press the START/PAUSE button to start the
cycle.
After the Steam FreshTM cycle is complete, the
washer will tumble the clothes for up to 30
minutes to prevent rewrinkling.
After removing clothes from the Steam FreshTM
cycle, they may feel slightly damp. Place clothes
on a hanger for at least 10 minutes to allow them
to dry.
• The Steam FreshTM cycle is not recommended
for use with 100% cotton clothing.
• Remove stains from clothing before using the
Steam FreshTM cycle; the high heat could cause
stains to set permanently.
• Do not use Steam FreshTM with the following
items:wool, blankets, leather jackets, silk, wet
clothes, lingerie, foam products, or electric
blankets.
• Best results are achieved when articles are of
similar size and fabric type. Do not overload.
To Use the Steam Fresh™ Cycle:
Steam FreshTM uses the power of steam alone to
quickly reduce wrinkles and odor in fabrics. It
brings new life to wrinkled clothes that have been
stored for an extended time and makes heavily
wrinkled clothes easier to iron. Steam FreshTM can
also be used to help reduce odors in fabrics.
Using the Steam Fresh™ Cycle

18
ow to use washer
H
CYCLE SETTING BUTTONS
Each cycle has preset settings that are selected
automatically. You may also customize the
settings using the cycle setting buttons. Press
the button for that setting until the indicator light
for the desired value is lit.
The washer automatically adjusts the water level
for the type and size of wash load for best
results and maximum efficiency. It may seem
there is no water inside the drum in some cycles,
but this is normal.
NOTE: To protect your garments, not every
wash/rinse temperature, spin speed, soil level, or
option is available with every cycle. See the
Cycle Guide for details.
Selects the wash and
rinse temperature
combination for the
selected cycle. Press the
WASH/RINSE button
repeatedly to scroll
through available settings.
• Your washer features a heating element to
boost the hot water temperature for Extra Hot
settings. This provides improved wash
performance at normal water heater settings.
• Select the water temperature suitable for the
type of load you are washing. Follow the fabric
care label for best results.
• Warm rinses are regulated at approximately
86°F (30°C).
• Warm rinses leave the loads drier than cold
rinses. Warm rinses can increase wrinkling.
• In cold climates, a warm rinse makes the load
more comfortable to handle.
• Cold rinses use less energy, and the rinse
temperature depends on the cold water at the
faucet.
WASH/RINSE
Adjusts the selected cycle
to allow more time for
heavily soiled clothes or
less time for lightly soiled
clothes. Press the SOIL
LEVEL button until the
indicator light for the desired setting is lit.
SOIL LEVEL
The washer drum spins at
up to 1,200 RPM. This
extracts more water from
clothes, reducing drying
time and saving energy.
Press the SPIN SPEED
button until the indicator light for the desired
setting is lit. Some fabrics, such as delicates,
require a slower spin speed.
The Drain & Spin cycle:
The Spin Speed button also activates the Drain &
Spin cycle to drain the tub and spin clothes; for
example, if you want to remove clothes before the
cycle has ended.
SPIN SPEED
To activate the DRAIN & SPIN cycle:
❶Press the ON/OFF button to turn on the
washer.
❷Press the SPIN SPEED button.
❸Select the desired spin speed.
NOTE: If NO SPIN is selected, the washer will
drain only.
❹Press the START/PAUSE button.

19
ow to use washer
H
LOAD SIZE SENSING SYSTEM
At the beginning of the cycle, the
washer tumbles the load and
detects the weight of the clothes.
The display will indicate the approximate load size
in the LOAD SIZE display. This allows you to adjust
the amount of detergent and other additives for best
results and improved efficiency.
Example 1: If the washer has detected a small
load size, the display may only show one lighted
bar. Only a small amount of detergent should be
used, because the amount of clothing and the
quantity of water that will be used is small.
Example 2: If the washer has detected a large
load size, the display may show all four bars
lighted. More detergent should be used, because
the amount of clothing and the quantity of water
that will be used is greater.
NOTE: Because the washer uses a very small
amount of water, care should be taken when
deciding how much detergent to use. Normal
loads only need about half the detergent
manufacturer's recommended amount. This
saves detergent by using it in a more
concentrated manner. However, for heavily soiled
loads, additional detergent should be added.
Never exceed manufacturer
Recommended
amount for this
load
Recommended
amount for this
load
Detergent
manufacturer's
recommended
amount for a
full load
Detergent
manufacturer's
recommended
amount for a
full load
The LOAD SIZE display:
❶Load the washer, select the desired cycle and
options, and then start the cycle by pressing
the START/PAUSE button.
❷The washer will tumble for a short time to
detect the size of the load. After the washer
detects the load size, the washer will show the
detected size in the LOAD SIZE display for 10
seconds before it continues with the cycle.
❸During the 10 second delay in step three,
press the START/PAUSE button to pause the
cycle.
❹Fill the detergent and additive compartments
of the detergent drawer with detergent/
additive amounts based on the load size the
machine has detected. Following these
guidelines can save detergent.
❺Press the START/PAUSE button again to
resume the cycle.
To check the load size during the wash portion of
the cycle, press and hold the RINSE+SPIN
button for 3 seconds. The LOAD SIZE display
will be activated for 10 seconds.
NOTE: The load detection routine only works
with dry clothes. Since the detection system is
detecting the WEIGHT of the load, it will be
affected by unusually heavy articles in the load.
For example, a garment that is already wet that
is loaded with other items will cause the LOAD
SIZE reading to be inaccurate.
If you do not desire to take advantage of the load
size detection feature, simply load the desired
amount of detergent and additives in the
dispenser and start the washer in the usual
manner.
To use Automatic Load Size Sensing:

20
ow to use washer
H
CYCLE OPTION BUTTONS
NOTE: To protect your garments, not every
wash/rinse temperature, spin speed, soil level or
option is available with every cycle. See the Cycle
Guide for details.
Your washing machine features several
additional cycle options to customize cycles to
meet your individual needs. Certain option
buttons also feature a special function (see the
following page for details) that can be activated
by pressing and holding that option button for 3
seconds.
❶Turn on the washer and turn the cycle selector
knob to select the desired cycle.
❷Use the cycle settings buttons to adjust the
settings for that cycle.
❸Press the cycle option button(s) for the option
you would like to add. The cycle option
buttons, except DELAY WASH, will light when
selected.
❹Press the START/PAUSE button to start the
cycle. The washer will start automatically.
To Add Cycle Options to a Cycle: ❶Press the ON/OFF button to turn on the
washer.
❷Press the RINSE+SPIN button.
❸Press the START/PAUSE button.
To activate the Rinse+Spin cycle:
Once you have selected the cycle and
other settings, press this button to
delay the start of the wash cycle. Each
press of the button increases the delay
time by one hour, up to 19 hours.
DELAY WASH
Select this option to add a 16-
minute prewash and spin cycle
to the chosen cycle. This is
especially useful for heavily soiled items.
PRE-WASH
Select this option to rinse and
spin a load separately from a
regular cycle. This can be helpful
in preventing fresh stains from setting in fabrics.
RINSE+SPIN
This option will add an extra
rinse cycle to the selected cycle.
Use this option to help ensure
the removal of detergent or bleach residue from
fabrics.
EXTRA RINSE
Select this option for heavily
stained clothes, such as play
clothes or work clothes. Stain
Cycle will add extra wash time to the selected
cycle, as well as an additional rinse cycle.
STAIN CYCLE
Select this option to add extra
water to the wash and rinse
cycles for superior results,
especially with large or bulky items.
WATER PLUS
