OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
F2T2TYM0W / F2T2TYM1S
52415417
Rev.00_101822
www.lg.com
Copyright © 2022 LG Electronics Inc. All Rights Reserved.
global_main.book.book Page 1 Tuesday, October 18, 2022 2:42 PM

TABLE OF CONTENTS
This manual may contain images or
content that may be different from the
model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE...........................................................3
WARNING............................................................................................................3
INSTALLATION
Parts and Specifications ....................................................................................8
Installation Place Requirements ....................................................................11
Levelling the Appliance ...................................................................................12
Connecting the Water Supply Hose...............................................................13
Installing the Drain Hose ................................................................................15
OPERATION
Operation Overview.........................................................................................17
Control Panel ....................................................................................................19
Preparing the Wash Load ...............................................................................20
Adding Detergents and Softeners .................................................................20
Programme Table ............................................................................................23
Extra Options and Functions ..........................................................................28
Auxiliary Functions...........................................................................................30
MAINTENANCE
Cleaning After Every Wash..............................................................................32
Cleaning the Appliance Periodically ..............................................................33
TROUBLESHOOTING
Before Calling for Service................................................................................35
global_main.book.book Page 2 Tuesday, October 18, 2022 2:42 PM

3
SAFETY INSTRUCTIONS
ENGLISH
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
The following safety guidelines are intended to prevent unforeseen
risks or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as
described below.
Safety Messages
WARNING
WARNING
To reduce the risk of explosion, fire, death, electric shock, injury or
scalding to persons when using this product, follow basic precautions,
including the following:
Technical Safety
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
This symbol is displayed to indicate matters and operations
that can cause risk. Read the part with this symbol carefully
and follow the instructions in order to avoid risk.
WARNING
This indicates that the failure to follow the instructions can
cause serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can
cause the minor injury or damage to the product.
global_main.book.book Page 3 Tuesday, October 18, 2022 2:42 PM

4
SAFETY INSTRUCTIONS
• Children should be supervised to ensure that they do not play with
the appliance.
• If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
• Use a new hose or hose-set supplied with the appliance. Reusing old
hoses can cause a water leak and subsequent property damage.
• Ventilation openings must not be obstructed by a carpet.
• This appliance is intended to be used in household only.
• The inlet water pressure must be between 50 kPa and 800 kPa.
Maximum Capacity
The maximum capacity in some cycles for dry clothes to be washed is 8
kg.
The recommended maximum capacity for each washing programme
may differ. To get good wash results, please refer to Programme
Table in OPERATION chapter for further details.
Installation
• This appliance should only be transported by two or more people
holding the appliance securely.
• Do not install the appliance in a damp and dusty place. Do not install
or store the appliance in any outdoor area, or any area that is subject
to weathering conditions such as direct sunlight, wind, rain, or
temperatures below freezing.
• Make sure the power plug is completely pushed into the power
outlet.
• Do not plug the appliance into multiple outlet sockets, power boards,
or an extension power cable.
• Do not modify the power plug provided with the appliance. If it does
not fit the power outlet, have a proper outlet installed by a qualified
electrician.
global_main.book.book Page 4 Tuesday, October 18, 2022 2:42 PM

5
SAFETY INSTRUCTIONS
ENGLISH
• This appliance is equipped with a power cord having an equipment-
earthing / grounding conductor (earthing pin) and a grounding
power plug. The power plug must be plugged into an appropriate
outlet socket that is installed and earthed / grounded in accordance
with all local codes and ordinances.
• Improper connection of the equipment-grounding conductor can
result in risk of electric shock. Check with a qualified electrician or
service personnel if you are in doubt as to whether the appliance is
properly grounded.
Operation
• Never attempt to operate the appliance if it is damaged,
malfunctioning, partially disassembled, or has missing or broken
parts, including a damaged cord or plug.
• Do not apply any sharp objects to the control panel in order to
operate the appliance.
• Do not attempt to separate any panels or disassemble the appliance.
• Do not repair or replace any part of the appliance. All repairs and
servicing must be performed by qualified service personnel unless
specifically recommended in this Owner's Manual. Use only
authorized factory parts.
• Do not push down the door excessively, when the appliance door is
open.
• Do not put animals, such as pets into the appliance.
• Do not wash any items that are specified by the manufacturer as not
washable on the care label.
• Keep the area underneath and around the appliance free of
combustible materials such as lint, paper, rags, chemicals, etc.
• Do not leave the appliance door open. Children may hang on the door
or crawl inside the appliance, causing damage or injury.
• Do not put in, wash or dry articles that have been cleaned in, washed
in, soaked in, or spotted with combustible or explosive substances
(such as waxes, wax removers, oil, paint, gasoline, degreasers,
drycleaning solvents, kerosene, petrol, spot removers, turpentine,
global_main.book.book Page 5 Tuesday, October 18, 2022 2:42 PM

6
SAFETY INSTRUCTIONS
vegetable oil, cooking oil, acetone, alcohol, etc.). Improper use can
cause fire or explosion.
• Do not use or store flammable or combustible substances (ether,
benzene, alcohol, chemical, LPG, combustible spray, gasoline,
thinner, petroleum, insecticide, air freshener, cosmetics, etc.) near
the appliance.
• Never reach into the appliance while it is operating. Wait until the
drum has completely stopped.
• Do not touch the door during a high temperature programme.
• In case of a water leak from the appliance or flood, disconnect the
power plug and contact the LG Electronics customer information
centre.
• Turn off water taps to relieve pressure on hoses and valves and to
minimize leakage if a break or rupture should occur. Check the
condition of the fill hoses; they should be replaced after 5 years.
• If there is a gas leakage (isobutane, propane, natural gas, etc.) within
the home, do not touch the appliance or power plug and ventilate the
area immediately.
• If the drain hose or inlet hose is frozen during winter, use it only after
thawing.
• Keep all washing detergents, softener and bleach away from
children.
• Do not touch the power plug or the appliance controls with wet
hands.
• Do not bend the power cable excessively or place a heavy object on it.
• Avoid touching any water that is drained from the appliance during
the wash.
• Make sure that drainage is working properly. If water is not drained
properly, your floor may get flooded.
• When the air temperature is high and the water temperature is low,
condensation may occur and thus wet the floor.
• Wipe off dirt or dust on the contacts of the power plug.
global_main.book.book Page 6 Tuesday, October 18, 2022 2:42 PM

7
SAFETY INSTRUCTIONS
ENGLISH
Maintenance
• Disconnect the appliance from the power supply before cleaning the
appliance. Setting the controls to the OFF or stand by position does
not disconnect this appliance from the power supply.
• Securely plug the power plug in the outlet socket after completely
removing any moisture and dust.
• Do not spray water inside or outside the appliance to clean it.
• Never unplug the appliance by pulling on the power cable. Always
grip the power plug firmly and pull straight out from the outlet
socket.
• Only qualified service personnel from LG Electronics service centre
should disassemble, repair, or modify the appliance. Contact an LG
Electronics customer information centre if you move and install the
appliance in a different location.
Disposal
• Before discarding an old appliance, unplug it. Cut off the cable
directly behind the appliance to prevent misuse.
• Dispose of all packaging materials (such as plastic bags and
styrofoam) away from children. The packaging materials can cause
suffocation.
• Cut off the power cord and remove the door before disposing of this
appliance to avoid the danger of children or small animals getting
trapped inside.
global_main.book.book Page 7 Tuesday, October 18, 2022 2:42 PM

8
INSTALLATION
INSTALLATION
Parts and Specifications
NOTE
• Appearance and specifications may change without notice to improve the quality of the appliance.
Front View
a Control Panel
b Programme Knob
c Top Plate
d Detergent Dispenser Drawer
e Drum
f Pump Filter Cover
Rear View
a Water Inlet Valve
b Power Cable
c Drain Hose
d Transit Bolts
global_main.book.book Page 8 Tuesday, October 18, 2022 2:42 PM

9
INSTALLATION
ENGLISH
Specifications
Dimension(mm)
Model F2T2TYM0W / F2T2TYM1S
Power Supply 220‒240 V~, 50 Hz
Product Weight 70.0 kg
W 600 D 560 D'' 1035
H850D'595
W
D
D’’
D’
H
global_main.book.book Page 9 Tuesday, October 18, 2022 2:42 PM

10
INSTALLATION
Accessories
Cold Supply Hose Elbow Bracket for Securing Drain Hose
Caps for Covering Transit Bolt Holes
global_main.book.book Page 10 Tuesday, October 18, 2022 2:42 PM

11
INSTALLATION
ENGLISH
Installation Place
Requirements
Before installing the appliance, check the following
information to make sure that the appliance
should be installed in a correct place.
Installation Location
• This appliance must be installed on firm flooring
to minimize vibration during the spin cycle.
Concrete flooring is best, being far less prone to
vibration during the spin cycle than wooden
floorboards or a carpeted surface.
• If it is impossible to avoid positioning the
appliance next to a gas cooker or coal burning
stove, an insulation (850 X 600 mm) covered with
aluminum foil on the side facing the cooker or
stove must be inserted between the two
appliances.
• Ensure that when the appliance is installed, it is
easily accessible for an engineer in the event of a
breakdown.
• When installing the appliance, adjust all four feet
using spanner to ensure the appliance is stable.
• Ensure that there is enough room for full
opening of the appliance door.
• To ensure sufficient clearance for water inlet
hoses, drain hose and airflow, allow minimum
clearances of at least 20 mm at the sides and 100
mm behind the appliance. Be sure to allow for
wall, door, or floor moldings that may increase
the required clearances.
WARNING
• This appliance must only be used for domestic
household purposes and should not be used in
mobile applications.
Ventilation
• Make sure that air circulation around the
appliance should not be impeded by carpets,
rugs, etc.
Ambient Temperature
• Do not install the appliance in rooms where
freezing temperatures may occur. Frozen hoses
may burst under pressure. The reliability of the
electronic control unit may be impaired at
temperatures below freezing point.
• If the appliance is delivered in winter and
temperatures are below freezing, place the
appliance at room temperature for a few hours
before putting it into operation.
Electrical Connection
• Do not use an extension cord or double adapter.
• Always unplug the appliance and turn off the
water supply after use.
• Connect the appliance to an earthed socket in
accordance with current wiring regulations.
• The appliance must be positioned so that the
plug is easily accessible.
• Power outlet must be within 1 meter of either
side of the appliance.
Index Clearance (mm)
A
100
A C
B
C
B 5
C 20
Index Clearance (mm)
global_main.book.book Page 11 Tuesday, October 18, 2022 2:42 PM

12
INSTALLATION
WARNING
• Repairs to the appliance must only be carried out
by qualified personnel. Repairs carried out by
inexperienced persons may cause injury or
serious malfunctioning. Contact your local
authorised LG repairer.
• The power plug must be plugged into an
appropriate outlet socket that is installed and
grounded/earthed in accordance with all local
codes and ordinances.
Levelling the Appliance
Removing the Transit Bolt
Assemblies
CAUTION
• To prevent the appliance from severe vibration
and breakage, remove transit bolts and
retainers.
1 Remove the 4 transit bolts and rubber spacers
from the rear of the appliance.
2 Loosen the transit bolts by turning them
anticlockwise with an appropriate spanner.
3 Remove the transit bolts with a straight pull.
4 Fit the plastic blanking caps supplied in the
accessories bag into the gaps left by the
removal of the transit bolts. The transit bolts
should be stored for future use.
Checking the Level
When pushing down the edges of the top plate
diagonally, the appliance should not move up and
down at all (check both directions).
• If the appliance rocks when pushing the top
plate of the appliance diagonally, adjust the feet
again.
• Check whether the appliance is perfectly level
after installation.
NOTE
• Timber or suspended type flooring may
contribute to excessive vibration and unbalance.
Reinforcement or bracing of the timber floor
may need to be considered to stop or reduce
excessive noise and vibration.
• Never try to level any uneven floor by putting
pieces of wood, cardboard or similar materials
under the appliance.
Adjusting and Levelling the
Feet
When installing the appliance, the appliance
should be aligned and perfectly level. If the
appliance is not aligned and level properly, the
appliance may be damaged or may not operate
properly.
1 Loosen the plastic locking nut.
• Do not insert pieces of wood etc. under the
feet.
XX 44
X
4
1
3
2
4
global_main.book.book Page 12 Tuesday, October 18, 2022 2:42 PM

13
INSTALLATION
ENGLISH
• Make sure that all four feet are stable and
resting on the floor.
NOTE
• Do not install the appliance on a plinth, stand or
elevated surface unless it is manufactured by LG
Electronics for use with this model.
2 To increase the height of the appliance, turn
the feet clockwise. To decrease the height of
the appliance, turn the feet anticlockwise..
3 Check if all lock nuts at the bottom of the
appliance are secured properly.
NOTE
• Proper placement and levelling of the appliance
will ensure long, regular, and reliable operation.
• The appliance must be 100% horizontal and
stand firmly in position on a hard flat floor.
• It must not ‘Seesaw’ across corners under the
load.
• Do not let the feet of the appliance get wet.
Failure to do so may cause vibration or noise.
Connecting the Water
Supply Hose
Note for Connection
• Water pressure must be between 50 kPa and
800 kPa (0.5‒8.0 kgf/cm²). If the water pressure
is more than
800 kPa , a decompression device
should be installed.
• Periodically check the condition of the water
supply hose and replace the water supply hose if
necessary.
NOTE
• Do not overtighten the water supply hose or use
mechanical devices to tighten onto the inlet
valves.
• No further backflow protection required for
connection to the water inlet.
Checking the Rubber Seal
Two rubber seals a are supplied with the water
supply hose. They are used to prevent water leaks.
Connection to taps is sufficiently tight.
• Do not use mechanical devices such as multi
grips to tighten the water supply hose. Ensure
that the curved end of the water supply hose is
connected to the appliance.
1
global_main.book.book Page 13 Tuesday, October 18, 2022 2:42 PM

14
INSTALLATION
Connecting the Hose to the
Water Tap
Connecting Screw-Type Hose to Tap with Thread
Screw the supply hose connector onto the water
supply tap.
Connecting Screw-Type Hose to Tap Without
Thread
1 Loosen the 4 fixing screws a .
2 Remove the guide plate b if the tap is too large
to fit the adapter.
3 Push the adapter onto the end of the tap so
that the rubber seal is connected to be
watertight. Tighten the 4 fixing screws.
4 Push the inlet hose c vertically upwards so
that the rubber seal within the hose can adhere
completely to the tap and then tighten the
hose by screwing it to the right.
Connecting One Touch Type Hose to Tap
Without Thread
1 Unscrew the adapter ring plate d and loose
the 4 fixing screws.
2 Remove the guide plate e if the tap is too large
to fit the adapter.
3 Push the adapter onto the end of the tap so
that the rubber seal is connected to be
watertight. Tighten the 4 fixing screws and the
adapter ring plate.
4 Pull the connector latch plate f down, push
the inlet hose onto the adapter, and release the
global_main.book.book Page 14 Tuesday, October 18, 2022 2:42 PM

15
INSTALLATION
ENGLISH
connector latch plate. Make sure the adapter
locks into place.
NOTE
• After connecting the water inlet hose to the
water tap, turn on the water tap to flush out
foreign substances (dirt, sand, sawdust, and etc.)
in the water lines. Let the water drain into a
bucket, and check the water temperature.
Connecting the Hose to the
Appliance
Screw the supply hose to the water inlet valve on
the back of the appliance.
• Do not connect the hose to the hot water supply
for models with one water inlet. Connect to the
cold water supply only.
NOTE
• After completing connection, if water leaks from
the hose, repeat the same steps. Use the most
conventional type of tap for the water supply. In
case that the tap is square or too big, remove the
guide plate before inserting the tap into the
adaptor.
• Make sure that the hose should not be kinked or
trapped.
Installing the Drain Hose
Installing the Drain Hose with
the Elbow Bracket
The drain hose should not be placed higher than
100 cm above the floor. Water in the appliance may
not drain or may drain slowly.
• Securing the drain hose correctly will protect the
floor from damage due to water leakage.
• If the drain hose is too long, do not force it back
into the appliance. This will cause abnormal
noise.
global_main.book.book Page 15 Tuesday, October 18, 2022 2:42 PM

16
INSTALLATION
• When installing the drain hose to a sink, secure it
tightly with string.
global_main.book.book Page 16 Tuesday, October 18, 2022 2:42 PM

17
OPERATION
ENGLISH
OPERATION
Operation Overview
Using the Appliance
Before the first wash, select the Cotton wash
programme and add a half amount of the
detergent. Start the appliance without clothes. This
will remove possible residues and water from the
drum that may have been left during
manufacturing.
1 Sort clothes and load items.
• Sort clothes by fabric type, soil level, colour
and load size as needed. Open the door and
load items into the appliance.
CAUTION
• Before closing the door, ensure that all clothes
and items are inside the tub and not
overhanging on the rubber door seal where they
will become caught when the door is closed.
Failing to do so will cause damage to the door
seal and the clothes.
CAUTION
• Remove items from the flexible door seal gasket
to prevent clothing and door seal damage.
2 Add cleaning products or detergent and
softener.
• Add the proper amount of detergent to the
detergent dispenser. If desired, add bleach
or fabric softener to the appropriate areas of
the dispenser.
3 Plug your machine into the mains supply and
then turn on the water supply.
4 Choose the desired cycle.
• Turn the cycle selector knob until the desired
cycle is selected.
• Now select a wash temperature and spin
speed. Pay attention to the fabric care label
of your clothes.
5 Begin a programme.
• Press the
Start/Pause button to begin the
programme. The appliance will agitate
briefly without water to measure the weight
of the load.
global_main.book.book Page 17 Tuesday, October 18, 2022 2:42 PM

18
OPERATION
6 End of programme.
• When the programme is finished,
ENd will
appear on the electronic display.
NOTE
• Your machine features a half-load detection
system.
- If you put less than half the maximum load of
laundry into your machine it will automatically
set the half-load function, regardless of the
programme you selected.
- This means that the selected programme will
take less time to complete and will use less
water and energy.
• If you want to pause/cancel a running program
or add laundry
Press the button to pause or
restart the selected program.
- When you want to add
laundry, you can use this
function.
LED lights up when the
programme starts and the
door is unlocked.
- You can open the loading
door and add laundry.
LED lights up when the
programme starts and the
door is locked.
- The step where you can add
laundry has passed.
Off If you want to cancel a running
program, turn the program
knob to “Off” position.
- Your machine will stop
washing process and the
program will be cancelled.
- To drain the water in the
machine, turn the program
knob to any program
position.Your machine will
drain the water and cancel
the program.
global_main.book.book Page 18 Tuesday, October 18, 2022 2:42 PM

19
OPERATION
ENGLISH
Control Panel
The actual control panel may differ from model to model.
Control Panel Features
Description
a
Programme Knob
• Programmes are available according to the clothes type.
• The lamp will light up to indicate the selected programme.
b
Display
• The display shows the settings, estimated remaining time, options, and status messages.
When the appliance is turned on, the default settings in the display will illuminate.
c
Customizing Washing Programme Buttons
Use these buttons to adjust the water temperature or spin speed settings for the selected
programme.
• The current settings are shown in the display.
• Press the button for that option to select other settings.
d
Extra Options and Functions
• To use the extra functions, press and hold the corresponding button for 3 seconds. The
corresponding symbol lights up in the display.
• This allows you to select an additional programmes and will light when selected.
e
Start/Pause Button
• This button is used to start the wash cycle or pause the wash cycle.
• If a temporary stop of the wash cycle is needed, press this button.
• If you switch your machine to the standby mode, the
Start/Pause led on the electronic display
will blink.
global_main.book.book Page 19 Tuesday, October 18, 2022 2:42 PM

20
OPERATION
Preparing the Wash Load
Sort the wash load for best washing results, and
then prepare the clothes according to the symbols
on their care labels.
Sorting the Clothes
• Soil level (Heavy, Normal, Light): Separate
clothes according to soil level. If possible, do not
wash heavily soiled items with lightly soiled
ones.
• Colour (White, Lights, Darks): Wash dark or dyed
clothes separately from whites or light colours.
Mixing dyed clothes with light clothes can result
in dye transfer or discolouration of lighter
clothes.
• Lint (Lint producers, Collectors): Wash separately
lint producing fabrics from lint collecting fabrics.
Lint producers can result in pilling and linting on
the lint collectors.
Checking the Clothes Care Label
The symbols tell you about the fabric content of
your garment and how it should be washed.
Symbols on the Care Labels
NOTE
• The dashes under the symbol give you
information about the type of fabric and the
maximum allowance of mechanical stress.
Checking the Clothes before
Loading
• To help distribute the load evenly during
spinning, combine large and small items in a
load.
• Do not wash single small items. Add 1-2 similar
items to the load to prevent an out-of-balance
load.
• Check all pockets to make sure that they are
empty. Items such as nails, hair clips, matches,
pens, coins and keys can damage both your
appliance and clothes.
• Wash delicates (stockings, underwired bras) in a
wash net.
• Close zippers, hooks and strings to make sure
that these items do not snag on other clothes.
• Pre-treat dirt and stains by brushing a small
amount of detergent dissolved water onto stains
to help lift dirt.
Adding Detergents and
Softeners
Detergent Dosage
• Detergent should be used according to the
instruction of the detergent manufacturer and
selected according to type, colour, soiling of the
fabric and the washing temperature. Use only
Symbol Wash / Fabric type
• Normal Wash
• Cotton, Mixed Fabrics
• Easy Care
• Synthetic, Mixed Fabrics
• Special Delicate Wash
• Delicates
• Hand Wash Only
• Wool, Silk
• Do not wash
global_main.book.book Page 20 Tuesday, October 18, 2022 2:42 PM
