OWNER’S MANUAL
WASHING MACHINE
WM2240CS1
P/No.:MFL67360433 www.lg.com
Please read this manual carefully efore operating
your set and retain it for future reference.
ENGLISH ESPAÑOL

roduct Feature
P
ontents
C
2
Warnings...............................................................................................3
Specification..........................................................................................4
Installation.............................................................................................5
Care before washing...........................................................................10
Using the dispenser ............................................................................11
Function ..............................................................................................13
ow to use washer .............................................................................14
Maintenance .......................................................................................20
Troubleshooting guide ........................................................................23
■Ultra Capacity
The Larger drum enables not just higher head drop and stronger
centrifugal force, but also less tangling and wrinkling of the laundry.
eavier loads, such as king size comforters, blankets, and curtains, can
be washed.
■Direct Drive System
The advanced Brushless DC motor directly drives the drum without belt
and pulley.
■Tilted Drum and Extra Large Door Opening
Tilted drum and extra large opening make it possible to load
and unload clothing more easily.
■Automatic Wash Load Detection
Automatically detects the load and optimizes the washing time.
■Child Lock
The Child lock prevents children from pressing any button to change the
settings during operation.
■Magnetic Door Plunger
Safely and conveniently secure the door slightly ajar with a magnetic door
plunger. This will promote air circulation and allow the interior of the
machine to dry. To use this feature, after the load has been removed, do
not close the door completely. When the magnetic door plunger comes
into contact with the metal washer cabinet, it will secure the door slightly
open allowing the interior of the washer to dry.
추가선택 예약
추가선택 예약

arnings
W
3
ENGLISH
For your safety, the information in this manual must be followed to minimize
the risk of fire or explosion, electric shock, or to prevent property damage,
personal injury, or loss of life.
!
READ ALL INSTRUCTIONS BEFORE USE
WA NING!
• Read all instructions before using the washer.
• Do not wash articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry cleaning solvents, or other
flammable or explosive substances, as they give
off vapors that could ignite or explode.
• Do not add gasoline, dry cleaning solvents, or
other flammable or explosive substances to the
wash water. These substances give off vapors
that could ignite or explode.
• Under certain conditions, hydrogen gas may be
produced in a hot water system that has not
been used for 2 weeks or more. YDROGEN
GAS IS EXPLOSIVE. If the hot water system
has not been used for such a period, before
using the washing machine, turn on all hot water
faucets and let the water flow from each for
several minutes. This will release any
accumulated hydrogen gas. As the gas is
flammable, do not smoke or use an open flame
during this time.
• Do not allow children to play on or in the washer.
Close supervision of children is necessary when
the washer is used near children.
• Before the washer is removed from service or
discarded, remove the door to prevent children
from hiding inside.
• Do not install or store the washer where it will be
exposed to the weather.
• Do not tamper with controls.
• Do not repair or replace any part of the washer
or attempt any servicing unless specifically
recommended in the user-maintenance
instructions or published user-repair instructions
that you understand and have the skills to carry
out.
• See Installation Instructions for grounding
requirements.
• ALWAYS follow the fabric care instructions
supplied by the garment manufacturer.
• Do not place items exposed to cooking oil in
your washer. Items contaminated with cooking
oils may contribute to a chemical reaction that
could cause a load to catch fire.
• Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
G OUNDING INST UCTIONS
This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk
of electric shock by providing a path of least resistance for electric current. This appliance is equipped with
a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinance.
• Do not use an adapter or extension cord.
• Do not remove ground prong.
• If you don’t have the proper outlet, consult an electrician.
IMPO TANT SAFETY INST UCTIONS
WA NING :To reduce the risk of fire, electric shock, or injury to persons when using
the washer, follow basic precautions, including the following:
SAVE THESE INST UCTIONS
WA NING :Improper connection of the equipment-grounding conductor can result in risk of electric
shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the appliance
is properly grounded. Do not modify the plug provided with the appliance - if it does not fit the outlet,
have a proper outlet installed by a qualified electrician.
!
!

pecification
S
4
Name : Front loading washing machine
Power supply : 120 V~, 60 z
Size : 686 mm(W) 756 mm(D) 983 mm( ) /
1297 mm (D, door open)
Weigh : 87 kg (191.8 libras)
Wash capacity : 17 kg (37 libras)
Max. Watt : 600 W
Spin speed : 1200 rpm max.
Permissible water pressure : 0.3-10kgf/cm2(30-1000kPa)
❋The appearance and specifications may be varied without notice to raise the units quality.
 Accessories
Inlet hose 2EA Spanner Caps (4EA) Tie Strap Elbow Bracket Non-skid
pads

nstallation
I
5
ENGLISH
1. To prevent internal damage during
transport, the special 4 bolts are locked.
Before operating the washer, remove
the bolts along with the rubber bungs.
• If they are not removed, it may cause severe
vibration, noise and malfunction.
3. Take out the 4 bolts along with the rubber
bungs by slightly twisting the bung. Keep
the 4 bolts and the spanner for future use.
• Whenever the appliance is transported, the
transit bolts must be refitted.
The appliance is fitted with transit bolts to prevent internal damage during transport.
2. Unscrew the 4 bolts with
the spanner supplied.
4. Close the holes with the caps supplied.
 Removing transit bolts
cap
Install or store where it will not be exposed to temperat res below freezing or exposed to the weather.
Properly gro nd washer to conform with all governing codes and ordinances.
To red ce the risk of electric shock, do not install the washer in h mid spaces.
The base opening m st not be obstr cted by carpeting when the washing machine is installed on a
carpeted floor.
In co ntries where there are areas which may be s bject to infestation by cockroaches or other
vermin, pay partic lar attention to keeping the appliance and its s rro ndings in clean condition at
all times.
Any damage which may be ca se by cockroaches or other vermin will not be covered by the appliance
g arantee.
 Transit bolts

6
nstallation
I
■Installation clearances
The location must be large enough to fully open
the washer door.
■Washer dimensions
• Most installations require a minimum
10 cm clearance behind the washer.
■Minimum installation spacing for recessed
area installation.
The following dimensions shown are for the
minimum spacing allowed.
Additional spacing should be considered for
installation and servicing.
• Additional clearances might be required
for wall, door and floor moldings.
• Additional spacing of 2.5 cm on all
sides of the washer is recommended to
reduce noise transfer.
Companion appliance spacing should also be
considered.
[Front view]
[Side view]
129.7 cm
68.6 cm
75.6 cm
98.3 cm
■Level floor
• Allowable slope under entire washer is 1°.
• To minimize noise and vibration, the washer
MUST be installed on a solidly constructed floor.
• Carpeting and soft tile surfaces are not
recommended.
• Never install the washer on a platform or weakly
supported structure.
NOTE: A firm, solid floor is even more critical to a front-
loading washer than to a top-loader.
If yo r floor is wood and/or frame constr ction, yo
may need to reinforce it. Front-loaders se
s bstantially faster spin speeds than top-loaders,
ca sing greater vibration. If the floor is not solid,
yo r washer will vibrate. Yo will hear and feel the
vibration thro gho t yo r ho se.
■Power outlet
• Must be within 60 in. (1.5 m) of either side of the
washer. Do not overload the outlet with more
than one appliance.
• Time-delay fuse or circuit breaker is recommended.
NOTE: It is the personal responsibility and obligation of the
c stomer to have a proper o tlet installed by a
q alified electrician.

7
ENGLISH
nstallation
I
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet circuit
which powers only that appliance and has no additional outlets or branch circuits. Check the
specification page of this owner's manual to be certain.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords,
frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions
could result in electric shock or fire. Periodically examine the cord of your appliance, and if its
appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have
the cord replaced with an exact replacement part by an authorized servicer.
Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched,
closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where
the cord exits the appliance.
CAUTION
Water supply pressure must be between 30kPa and 1000kPa
(0.3~10kgf/cm2)
D n’t strip r cr ssthread when c nnecting Inlet h se t the valve.
If the water supply pressure is m re than 1000kPa, a dec mpressi n device
sh uld be installed.
• Two rubber seals are supplied with the water inlet hoses these are in
order to prevent water leaks.
• Check water tightness of washing machine connections by turning the
tap completely on.
• Periodically check the condition of the hose and replace the hose if
necessary.
• Make sure that there is no kink on the hose and that it is not crushed.
When y ur washer has tw valves,
• The Inlet hose which has red connector is for the hot water tap.
• If the washer has two valves, the energy is saved by using hot valve.
 Washing Machine is to be connected to the water mains using new hose-sets and that old
hose-sets should not be used.
 Connecting water supply hose
1. Do not use an extension cord or double adapter.
2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agents or
similarly qualified person in order to avoid a hazard.
3. Always unplug the machine and turn off the water supply after use.
4. Connect the machine to an earthed socket in accordance with current wiring regulations.
5. The appliance must be positioned so that the plug is easily accessible.
• Repairs to the washing machine must only be carried out qualified personnel. Repairs carried out by
inexperienced persons may cause injury or serious malfunctioning. Contact your local service center
• Do not install your washing machine in rooms where temperatures below freezing may occur. Frozen hoses
may burst under pressure. The reliability of the electronic control unit may be impaired at temperatures below
freezing point.
• If the appliance is delivered in the winter months and temperatures are below freezing : Store the washing
machine at room temperature for a few hours before putting it into operation.
 Electrical connection
ose connector
Rubber seal
ot water tap
ot(Option)Cold
Cold water
tap

8
nstallation
I
 Installation of drain hose
about
about
about
max. 100cm
min. 60cm
ose
Retainer
Laundry tub
Tie
strap
max. 100cm
min. 60cm
about
about
about
• The drain hose should not be placed
higher than 100 cm above the floor.
• Proper securing of the drain hose will
protect the floor from damage due to
water leakage.
• When the drain hose is too long, do
not force back into the washer. This
will cause abnormal noise.
• When installing the drain hose sink,
secure it tightly with a string.
• Proper securing of the drain hose will
protect the floor from damage due to
water leakage.
• Place the end of the drain hose in the
hole of the floor drain system.
This equipment is not designed for maritime use or for use mobile installations such as
caravans, aircraft etc.
Turn off the stopcock if the machine is to be left for any length of time (e.g. holiday),
especially if there is no floor drain(gully) in the immediate vicinity.
When disposing of the appliance, cut off the mains cable, and destroy the plug Disable the
door lock to prevent young children being trapped inside.
Packaging material (e.g. Films, Styrofoam) can be dangerous for children. There is a risk
of suffocation !
Keep all packaging well away from children.

9
ENGLISH
nstallation
I
 Level adjustment
 Installation of non-skid pads (optional)
1. Adjusting the washing machine level properly prevents
excessive noise and vibration.
Install the appliance on a solid and level floor surface,
preferably in a corner of the room.
NOTE: Extend the feet no more than necessary to level the
washer. The more the feet are extended, the more the
washer will vibrate.
2. If the floor is uneven, adjust the adjustable feet as
required. (Do not insert pieces of wood etc. under the
feet)
Make sure that all four feet are stable and resting on the
floor and then check that the appliance is perfectly level.
(Use a spirit level)
❊After the washer is level, tighten the lock nuts up towards
of the base of the washer. All lock nuts must be tightened.
NOTE: If there are vibration and noise d ring the spin cycle,
re-check the leveling of the washer, adj st the feet as
req ired, and tighten the lock n ts sec rely to prevent
changes in adj stment.
R n the washer with a test load to make certain yo r
washer is properly leveled. P t approximately 6 po nds
of la ndry in the machine. Then, press POWER,
RINSE+SPIN, and START/PAUSE, in that order.
When the machine spins at high speed, verify that it is
stable. If not, adj st
❊ Diagonal Check
When pushing down the edges of the washing machine top
plate diagonally, the machine should not move up and down at
all. (Please, check both of two directions)
f machine rocks when pushing the machine top plate
diagonally, adjust the feet again.
Some floor surfaces are too slippery to
prevent the washer from moving on the floor
during heavily unbalanced loads. While it is
normal for an occasional load to be out of
balance, excess noise and vibration can
result from the washer moving out of position.
If these conditions are encountered, follow
the instructions below for installation of the
non-skid pads. These pads will help prevent
the washer from moving during heavy out of
balance conditions thereby reducing noise
and vibration.
• Non-skid pads
✼ Place the pads under both front feet.
Adjustable feet Adjustable feet
Lock nut
This side up
Stick adhesive side to floor
Remove backing

10
are before washing
C
1. Fabric Care Labels
Look for a care label on your clothes. This will tell you about the fabric content of your
garment and how it should be washed.
2. Sorting
To get the best results, sort clothes into loads that can be washed with the same wash
cycle.
Different fabrics need to be washed in different ways.
Always sort dark colors from pale colors and whites. Wash separately as dye and lint
transfer can occur causing discoloration of white clothing. If possible, do not wash
heavily soiled items with lightly soiled ones.
Soil (Heavy, Normal, Light) Separate clothes according to amo nt of soil.
Color (White, Lights, Darks) Separate white fabrics from colored fabrics.
Lint (Lint Prod cers, Collectors) Wash lint prod cers and lint collectors separately.
3. Check before loading
Combine large and small items in a load. Load large items first.
Large items should not be more than half the total wash load.
Do not wash single items. This may cause an out-of-balance load. Add one or two similar
items.
• Check all the pockets to make sure that they
are empty. Things such as clip, matches,
pens, coins, and keys can damage both your
washer and your clothes.
• Close zippers, hooks, and strings to make
sure that these items do not snag on other
clothes.
• Pretreat dirt and stains by brushing a little
detergent dissolved in water onto stains like
collars and cuffs to help lift dirt.
WARNING
To reduce the risk of fire, electric shock, or injury to persons, read the
IMPO TANT SAFETY INST UCTIONS before operating this appliance.
NOTE: Do not wash or spin water-proof clothes.

11
ENGLISH
sing the dispenser
U
The a tomatic dispenser consists of fo r compartments which hold 1) liq id chlorine bleach,
2) liq id fabric softener, 3) liq id or powdered detergent for prewash and 4) liq id or
powdered detergent
and color safe bleach for main wash.
All la ndry prod cts can be added at once in their respective dispenser compartments.
They will be dispensed at the appropriate time for most effective cleaning. After loading the
la ndry
additives into the dispenser, close the dispenser drawer.
Add detergent, bleach and fabric softener to the automatic dispenser following
these steps:
1. Open the dispenser drawer.
2. Load the laundry products into the appropriate compartments.
3. Close the dispenser drawer.
■About detergent
Low sudsing detergent is recommended for this washer. Use the manufacturer's
recommended amount.
If low sudsing detergent is not available, a reduced amount of regular detergent may be
used.
Because reducing the amount of detergent may reduce cleaning, it is important to
pretreat stains,
sort carefully by color and soil level, and avoid overloading.
Detergent usage may need to be adjusted for water temperature, water hardness, size
and soil level of the load.
For best results, avoid using too much detergent.
• Add detergent to this compartment
when using the Prewash option.
Liquid or powdered detergent may
be used in this compartment. The
detergent will automatically be
dispensed during Prewash if the
Prewash option is selected.
• Add 1/2 the recommended amount
of detergent to the Prewash
compartment and the
recommended amount of detergent
to the main wash compartment.
NOTE : Liq id detergent will drain
into the washer dr m as it is
added.
Liquid Chlorine
Bleach
Compartment
Liquid Fabric
Softener
Compartment
Prewash
Compartment
Main Wash
Compartment
1. Prewash Detergent
Compartment

12
sing the dispenser
U
Liquid Detergent Box
Insert
• Add measured detergent to this
compartment for Main wash. Detergent
is flushed from the dispenser at the
beginning of the cycle. Either powdered
or liquid detergent can be used.
• Liquid or powdered color-safe bleach
may be added to the main wash
compartment along with the same type
of liquid or powdered detergent.
• When using liquid detergent, make sure
the liquid detergent box and insert are
in place. Do not exceed the maximum
fill line.
• For powered detergent, remove both
the liquid detergent box and insert.
• Powdered detergent will not dispense
with the liquid detergent box and insert
in place.
2. Main Wash Detergent
Compartment
• Add measured liquid chlorine bleach to
this compartment. The bleach will be
automatically dispensed at the proper
time during the wash cycle.
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing of
the bleach which could result in
damaged clothes.
• Do not pour undiluted liquid chlorine
bleach directly onto the load or into the
drum. Fabric damage can occur.
• Do not use powdered bleach in this
compartment.
3. Liquid Bleach Compartment
• Add recommended amount of fabric
softener to this compartment.
• Dilute concentrated softeners with
warm water to the fill line.
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing
of the fabric softener which could result
in stained clothes.
• Do not pour fabric softener directly on
the wash load.
• The fabric softener will be automatically
dispensed during the last rinse cycle.
4. Fabric Softener Compartment
NOTE: Do not place, store, or spill la ndry
prod cts (soap, detergent, bleach,
softener, etc.) on the top of yo r
washer or dryer. These prod cts
can damage the finish or controls if
left there too long.

13
ENGLISH
unction
F
■Select cycles designed for different types of fabric and soil levels.
Cycle Fabric Type Spin Speed Soil
Level Pre- Wash Quick Cycle Water plus Stain Cycle Extra
inse inse+ Spin Maximum
Load
Wash Temp.
NOTE: To protect yo r garments, not every Wash/Rinse temperat re, spin speed, soil level or option is available with
every cycle.
Less than
8.0 kg
HAND WASH/
WOOL
Warm
ot
Ecowarm
Cold
Tap Cold
Normal
eavy
Light
Less than
8.0 kg
Less than
4.0 kg
Less than
17.0 kg
Less than
3.5 kg
Less than
4.0 kg
BULKY/
LA GE
Large items such
as blankets and
comforters
Low
Medium
No Spin
Cold
Warm
Ecowarm
Tap Cold
Normal
eavy
Light
DELICATES
Dress
shirts/blouses,
nylons, sheer or
lacy garments
Medium
Low
No Spin
Warm
Ecowarm
Cold
Tap Cold
Normal
Light
D AIN+
SPIN
Items labeled
“hand-washable”
Low
No spin
Warm
ot
Ecowarm
Cold
Tap Cold
Normal
eavy
Light
COTTON/
NO MAL
Cotton, linen,
towels, shirts,
sheets, jeans,
mixed loads
igh
Extra igh
Medium
Low
No Spin
ot
Warm
Ecowarm
Cold
Tap Cold
Light
eavy
Normal
SPEED
WASH
Lightly soiled
clothing and small
loads
Extra igh
igh
Medium
Low
No Spin
Warm
ot
Ecowarm
Cold
Tap Cold
Normal
eavy
Light
PE M.
P ESS
Dress shirts/pants,
wrinkle-free
clothing,
poly/cotton blend
clothing,
tablecloths
Medium
igh
Low
No Spin
-
-
-
-
Drain, Spin
Only
igh
Extra igh
Medium
Low
No Spin
ECOMMENDED LOADS

14
ow to use washer
H
1. POWER ON/OFF BUTTON
2. CYCLE SELECTOR KNOB
3. START/PAUSE BUTTON
4. CYCLE SETTINGS BUTTONS
5. TIME AND STATUS
Turn this knob to select the desired cycle.
Once the desired cycle has been selected, the
standard presets will be shown in the display.
These settings can be adjusted using the cycle
settings buttons anytime before starting the
cycle.
Press to turn the washer ON. Press again to
turn the washer OFF.
NOTE: Pressing the ON/OFF button during a
cycle will cancel that cycle and any load settings
will be lost.
Press this button to START the selected cycle.
If the washer is running, use this button to
PAUSE the cycle without losing the current
settings.
NOTE: If you do not press the START/PAUSE
button within 4 minutes of selecting a cycle,
the washer automatically turns off.
The display shows the selected settings and
options, as well as the estimated time remaining
in the cycle.
6. OPTION BUTTON
The option buttons allow you to select additional
cycle options and will light when selected.
Certain buttons also allow you to activate
special functions by pressing and holding the
button for 3 seconds.
For detailed information about the individual
options, please see the following pages.
Use these buttons to adjust the desired cycle
options for the selected cycle.
4
123
5
6
6

15
ENGLISH
ow to use washer
H
THE TIME AND STATUS DISPLAY
1. ESTIMATED TIME REMAINING
When the START/PAUSE button is pressed, the
washer automatically detects the wash load
(weight) and optimizes the washing time, based
on the selected cycle and options. The display
will then indicate the estimated time remaining for
the selected wash cycle.
NOTE: The cycle time displayed may appear
much longer than that of a top-loading washer.
The displayed time is for the complete cycle,
rather than just the agitation portion of the cycle,
as is typically shown on a top-loading washer.
2. CYCLE COMPLETION INDICATOR
This portion of the display shows which stage
of the wash cycle is currently underway (LOAD
SENSING, WAS , RINSE, or SPIN).
3. DOOR LOCK INDICATOR
Indicates that the door is locked. The washer
door will lock while the washer is operating.
The door can be unlocked by pressing the
START/PAUSE button to stop the washer.
NOTE: If the temperature in the washer is too
high, the door cannot be unlocked until the
washer has cooled. If the water level is too
high, select the DRAIN & SPIN cycle to drain
excess water. Do not try to force open the door.
The time and status display shows the cycle progress and estimated time remaining, cycle options,
and other status messages for your washer.
3
1
2

16
ow to use washer
H
OPERATING THE WASHER
Once you have loaded the washer and added
laundry products (detergent, bleach, and/or fabric
softener):
❶Press the ON/OFF button to turn on the
washer. The lights around the cycle
selector knob will illuminate.
❺Press the START/PAUSE button to begin the
cycle. The door will latch, the display
will change, and the washer will
calculate the estimated time
remaining. Once the washer has
calculated the estimated total cycle time, the
washer will start. To pause the cycle at any
time, press START/PAUSE.
NOTE: The cycle time displayed may appear
much longer than that of a toploading washer.
The displayed time is for the complete cycle,
rather than just the agitation portion of the
cycle, as is typically shown on a top-loading
washer.
NOTE: If the temperature in the washer is too
high, the door cannot be unlocked until the
washer has cooled. If the water level is too
high, select the DRAIN & SPIN to drain
excess water. Do not try to force the door
open.
Washing time can be reduced significantly for
small or lightly soiled loads by selecting the
Speed Wash cycle and setting the Soil Level
button to Light.
❻When the load is finished, the signal (if set)
will sound and the door will unlock.
Remove damp clothes from the washer
immediately. Check under the door seal for
small items.
❷Turn the cycle selector knob to the desired
cycle. The display will show the
preset Wash Temp., Spin Speed,
Soil Level, and Option settings for
that cycle.
❹Select any additional cycle options, such as
PRE-WAS , RINSE+SPIN,
QUICK CYCLE, STAIN
CYCLE, or TUB CLEAN by
pressing the OPTION button
until the desired option is lit.
NOTE: To protect your
garments, not every wash/rinse
temperature, spin speed, soil
level, or option is available with
every cycle.
❸If you would like to change the settings for
that cycle, press the appropriate cycle setting
button(s) until the indicator light for the
desired setting is lit.
NOTE: To protect your garments, not every
wash temp., spin speed, soil level, or option is
available with every cycle.

17
ENGLISH
ow to use washer
H
CYCLE SETTING BUTTONS
Each cycle has preset settings that are selected
automatically. You may also customize the
settings using the cycle setting buttons. Press
the button for that setting until the indicator light
for the desired value is lit.
The washer automatically adjusts the water level
for the type and size of wash load for best
results and maximum efficiency. It may seem
there is no water inside the drum in some
cycles, but this is normal.
NOTE: To protect your garments, not every
wash temp., spin speed, soil level, or option is
available with every cycle. See the Cycle Guide
for details.
Selects the wash temperature
for the selected cycle.
Press the WAS TEMP. button
until the indicator light for the
desired setting is lit.
• Select the water temperature suitable for the
type of load you are washing. Follow the fabric
care label for best results.
WASH TEMP.
Adjusts the selected cycle to
allow more time for heavily
soiled clothes or less time for
lightly soiled clothes.
Press the SOIL LEVEL button
until the indicator light for the
desired setting is lit.
SO L LEVEL
The washer drum spins at up to
1,200 RPM.
This extracts more water from
clothes, reducing drying time
and saving energy.
Press the SPIN SPEED button
until the indicator light for the desired setting is
lit. Some fabrics, such as delicates, require a
slower spin speed.
SP N SPEED
Adjusts the end-of-cycle signal
volume or turns it off.
S GNAL

18
ow to use washer
H
CYCLE OPTION BUTTONS
Your washing machine features several additional cycle options to customize cycles to meet your
individual needs. Certain buttons also feature a special function (see the following page for details) that
can be activated by pressing and holding that button for 3 seconds.
❶Turn on the washer and turn the cycle
selector knob to select the desired cycle.
❷Use the cycle settings buttons to adjust the
settings for that cycle.
❸Add the desired cycle options by pressing
the button for that cycle (DELAY WAS ,
WATER PLUS, and EXTRA RINSE) or by
pressing the OPTION button until the light
next to the desired option is lit.
❹Press the START/PAUSE button to start the
cycle. The washer will start automatically.
NOTE: To protect your garments, not every
wash/ rinse temperature, spin speed, soil
level, or option is available with every cycle.
See the Cycle Guide for details.
To Add Cycle Options to a Cycle:
Once you have selected the cycle
and other settings, press this button
to delay the start of the wash cycle.
Each press of the button increases
the delay time by one hour, up to 19 hours.
DELAY WASH
This option will add an extra rinse
cycle to the selected cycle. Use this
option to help ensure the removal of
detergent or bleach residue from
fabrics.
EXTRA R NSE
Select this option to add extra water
to the wash and rinse cycles for
superior results, especially with
large or bulky items.
WATER PLUS

19
ENGLISH
ow to use washer
H
CYCLE OPTION BUTTONS (cont.) SPECIAL FUNCTIONS
Selecting Cycle Options with the
OPT ON Button
• Only woolen items that are designated as
“Machine-Washable” should be washed in this
washing machine.
• Wash only small loads for optimum fabric care
(less than 3.5kg)
• Only neutral (wool safe) detergents should be
used. (Only a small quantity of detergent is
needed due to the small load size and low volume
of water in the cycle.)
• The AND WAS /WOOL cycle uses a gentle
tumble action and low speed spin for ultimate
fabric care.
HAND WASH/WOOL
The wool wash cycle of this machine has been
approved by Woolmark for the washing of machine
washable Woolmark products provided that the
products are washed according to the instructions on
the garment label and those issued by the
manufacturer of this washing machine, M0807
Press the OPTION button to add
one of the following options to a
cycle. Pressing the button
repeatedly will cycle through the
options.
NOTE: Do NOT use this cycle with
clothes, and do NOT add detergent or fabric softener.
Use this option to prevent
unwanted use of the washer or
to keep cycle settings from
being changed while the washer
is operating. Press and hold the
OPTION button for 3 seconds to
activate or deactivate C ILD LOCK.
The child lock indicator will be shown in the
display, and all buttons are disabled except the
POWER button.
Once C ILD LOCK is selected, the display will
alternate between CL and the time remaining.
NOTE: C ILD LOCK lasts after the end of the
cycle. If you want to deactivate this function,
press and hold the OPTION button for 3
seconds.
Certain buttons also activate special functions,
including C ILD LOCK.
Press the OPTION button to
select this option to add 15
minutes prewash and spin cycle
to the chosen cycle. This is especially useful for
heavily soiled items.
PRE-WASH
CH LD LOCK
Select this option to rinse and
spin a load separately from a
regular cycle. This can be helpful
in preventing fresh stains from setting in fabrics.
R NSE+SP N
The QUICK CYCLE option has a
very short cycle time.
Recommended uses include
freshening newly purchased clothing or items that
have been packed away.
QU CK CYCLE
Select this option for heavily
stained clothes, such as play
clothes or work clothes. Stain
Cycle will add extra wash time to the selected cycle,
as well as an additional rinse cycle.
STA N CYCLE
A buildup of detergent residue
can occur in the wash tub over
time and can lead to a mildewy or
musty smell. The TUB CLEAN cycle is specially
designed to remove this buildup. After the cycle has
finished, Use the door magnet to hold the door ajar so
the tub can dry thoroughly.
NOTE: Do NOT use this cycle with clothes, and do
NOT add detergent or fabric softener.
NOTE: If you use the TUB CLEAN cycle on a monthly
basis, the wash drum will be kept clean.
TUB CLEAN

20
 The water inlet filter
- " " error message will blink on the control panel when water does not enter the
detergent drawer.
- If your water is very hard or contains traces of lime deposit, the water inlet filter may
become clogged.
It is therefore a good idea to clean it from time to time.
aintenance
M
 The drain pump filter
❋ The drain filter collects threads and small objects left in the laundry.
Check regularly that the filter is clean to ensure smooth running of your machine.
CAUTION First drain using the drain and then open the pump filter to remove whatever
any threads or objects.
Be careful when draining if the water is hot.
❋ Allow the water to cool down before cleaning the drain pump filter.
❋ Before cleaning the washer interior, unplug the electrical power cord to avoid electrical
shock to avoid electrical shock hazards.
❋ When disposing of the appliance, cut off the mains cable, and destroy the plug Disable the
door lock to prevent young children being trapped inside.
2
3
2
3
!
2. Unplug the drain plug ( ),
allowing the water to flow out. At
this time use a vessel to prevent
water flowing on to the floor.
When water does not flow any
more, turn the pump filter ( )
open to the left.
3. Remove any foreign material
from the pump filter ( ). After
cleaning, turn the pump filter
() clockwise and insert the
drain plug ( )to the original
place. close the lower cover
cap.
1. Open the lower
cover cap ( ) by
using a finger. Turn
the drain plug ( ) to
pull out the hose.
1. Turn off the
water tap.
2. Unscrew the
water inlet
hose.
3. Clean the
filter using a
hard bristle
brush.
4. Tighten up
the inlet
hose.
