PERFORMANCE
• 4.2cu.ft.UltraCapacitywithNeveRust™
StainlessSteelDrum(IEC)
• DirectDriveMotorfortheUltimatein
DurabilityandReliability(10YearWarranty)
• 10°TilTub™forEasyReachintotheRearof
theDrum
• 1200RPMPowerfulSpinforEfcientWater
Extraction
• SenseClean™SystemforIntelligent
FabricCare
• 9WashingPrograms
• 5TemperatureLevels
• RollerJets™
• SanitaryCycle
• DelayWash(upto19hours)
STYLE AND DESIGN
• UpfrontElectronicControlPanelwithDual
LEDDisplayandDial-A-Cycle™
• LargeChromeRimmedDoorwithGlass
• StackablewithMatchingDryer
• OptionalMatchingDrawerPedestal
TECHNOLOGY BENEFITS
• LGAnti-VibrationSystem
• LoDecibel™QuietOperation
• HighlyEnergyandWaterEfcient
LAUNDRY
LGusa.com
WM2301HW/HR
FrontLoadWashers
LGoffersthemostdesignercolorsandhighlystylizeddesigns
inthefrontloadindustry.Withlaundrymovingoutofthe
basementandclosertothelivingareas,stylehasbecomean
importantelementinthepurchaseprocess.
LGfrontloadwashersexceed
EnergyStar®classications
byaminimumof39%.
NSFcertiestheSANITARYcycle
whichisintendedforreducing
99.9%ofbacteriaandotherharmful
microscopicorganismsonlaundry.
Availablecolors:
WildCherryRedWhite

LAUNDRY
WM2301HW/HR
FrontLoadWashers
TYPE
FrontLoader •
DesignLook FrontControl
IntelligentElectronicControlswithDualLEDDisplay •
Dial-A-Cycle™ •
Capacity* IEC4.2cu.ft.
DryLinenCapacity >10.1kg
ENERGY
EnergyStarCompliant •
WASHPROGRAMS
9Programs Sanitary(158°F),Drain+Spin,BabyWear,
 Bulky/Large,Cotton/Normal,PermPress,
 Delicates,HandWash/Wool,SpeedWash
5Wash/RinseTemps ExtraHot/Cold,Hot/Cold,
 Warm/Warm,Warm/Cold,Cold/Cold
SpinSpeeds ExtraHigh(1200max),High(1020/980),
 Medium(980/600),
 Low(950/600/400),NoSpin
No.ofWaterLevels Automaticallyadjuststosizeofload
No.ofSoilLevel 5
10Options Prewash,Rinse&Spin,ExtraRinse,StainCycle,
 WaterPlus,LoadSize,TubClean,SpinSense™,
 DelayWash(upto19hours),CustomProgram
FABRICCAREFEATURES
SenseClean™System •
RollerJets™ •
CONVENIENCEFEATURES
4TrayDispenser Prewash,MainWash(withliquid
 detergentcup),Bleach,Softener
EndofCycleBeeper •
ChildLock •
Self-Diagnosis •
AutoBalancing •
LGAnti-VibrationSystem •
LoadSense •
AutoSudsRemoval •
ForcedDrainSystem •
StatusIndicator(s) •
InternalWaterHeater(1000W) •
LevelingLegs 4AdjustableLegs
LoDecibel™QuietOperation •
MOTORANDAGITATOR
MotorType/MotorSpeed BPMDirectDrive/Variable
Axis Horizontal
MATERIALSANDFINISHES
NeveRust™StainlessSteelDrum •
EasyLoadingTilTub™ •
Cabinet PaintedSteel
ControlPanel Plastic
TopPlate Painted(W,R)
TransparentDoorGlass •
DoorRim Chrome
AvailableColors White(W),WildCherryRed(R)
POWERSOURCE
Ratings ULListed
ElectricalRequirements/Type 120V,10Amps/Electric
OPTIONS
Pedestal WDP3W,WDP3R
Pedestal(WxHxD) 27"x133/5"x282/5"
StackingKit WSTK1,RSTK1
DIMENSIONS
Product(WxHxD) 27"x3811/16"x293/4"
 (51"Dwithdooropen)
Carton(WxHxD) 291/2"x421/4"x311/4"
Weight:Product/Shipping 190lbs./208.5lbs.
WARRANTY
 1YearPartsandLabor,2YearsControlBoard,
 10YearsMotor,LifetimeonDrum
UPCCODES
WM2301HW 048231010252
WDP3W 048231008556
WSTK1 048231008327
WM2301HR 048231010283
WDP3R 048231008976
RSTK1 048231008983
LGElectronicsU.S.A.,Inc.
1000SylvanAvenue,EnglewoodCliffs,NJ07632
CustomerServiceandTechnicalSupport:(800)243-0000
Designandspecificationsaresubjecttochangewithoutnotice.
©2009LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.
AllRightsReserved.LGDesignandLife’sGoodaretrademarksofLGElectronicsInc.
Allothertrademarksarethepropertyoftheirrespectiveowners.
*PerIEC60456washestheequivalentof4.2cu.ft.conventionalagitatorwasher.
