LG WM2655HVA User manual

TOUGH ON STAINS.
GENTLE ON FABRICS.
So long to dirt, odors, and household allergens and
experience a level of clean you have never experienced
before. Our steam technology powerfully penetrates
fabrics for advanced cleaning, while being oh-so gentle
to even your most delicate fabrics. This washer also
features the Allergiene™ Cycle, which helps remove
those unwanted household allergens like dust mites
and pet dander. That’s right...now you can take it easy –
This washer has it all under control.
There’s no clean like a steam clean. Our
Steam Technology gently but powerfully
penetrates fabrics to virtually eliminate dirt,
odors and wrinkles.
Now using the cold cycle on your washer
doesn’t have to mean compromising.
ColdWash™ Technology uses cold water and
enhanced washing motions to penetrate
deep into fabrics, giving you cold water
savings with warm water performance.
Get your clothes clean and experience a
smarter way to wash with our innovative
6Motion™ Technology. Each wash cycle
combines up to 6 different wash motions to
provide a revolutionary cleaning experience.
Extra Large Capacity SteamWasher™ with ColdWash™
WM2655HVA
Steam Technology ColdWash™ Technology 6Motion™ Technology
SPECIFICATIONS
•3.6 cu. ft. Extra Large Capacity with
NeveRust™ Stainless Steel Drum
•Direct Drive Motor with
10-Year Limited Warranty
•1,200 RPM
•9 Washing Programs
•5 Temperature Settings
(All Cold Rinses)
STYLISH DESIGN
•Upfront Electronic Control Panel with
Dual LED Display and Dial-A-Cycle™
•Chrome Rimmed Glass Door
•Stackable with Matching Dryer
(Stacking Kit Sold Separately)
•Optional Matching Drawer Pedestal
INNOVATIONS
•Steam™ Technology
•AAFA Certified Allergiene™ Cycle
•NSF Certified Sanitary Cycle
•ColdWash™ Option
•6Motion™ Technology
•SmartDiagnosis™
•TrueBalance™ Anti-Vibration System
•Magnet Ventilation
•ENERGY STAR Most Efficient 2012
•LoDecibel™ Quiet Operation
•SenseClean™
•Delay Wash (Up to 19 Hours)
•10° TilTub™

Design, features and specifications are subject to change without notice.
Non-metric weights and measurements are approximate.
© 2012 LG Electronics USA, Inc. All rights reserved. “LG Life’s Good” is a
registered trademark of LG Corp. All other product and brand names are
trademarks or registered trademarks of their respective companies. 4/17/12
Extra Large Capacity SteamWasher™ with ColdWash™
WM2655HVA
CapaCity
Capacity 3.6 cu. ft.
appEaRaNCE
Design Look Front Control
Intelligent Electronic Controls with Dual LED Display •
Dial-A-Cycle™ •
ENERGy
Energy Star •
2012 ENERGY STAR MOST EFFICIENT •
WaSH pROGRaMS
No. of Programs 9
Wash Programs Cotton/Normal, Bulky/Large, Perm. Press, Delicates,
Hand Wash/Wool, Speed Wash, Sanitary, Allergiene™, Tub Clean
No. of Options 9
Options Prewash, Rinse+Spin, Delay Wash, Water Plus,
Extra Rinse, Child Lock, ColdWash™, Signal On/Off, Steam
No. of Wash/Rinse Temps Extra Hot, Hot, Warm, Cold, Tap Cold (All Cold Rinses)
Spin Speeds Extra High (1,200 max.), High, Medium, Low, No Spin
No. of Water Levels Automatically adjusts to the size of load
No. of Soil Levels 5
FaBRiC CaRE FEatURES
Steam •
ColdWash™ Option •
Allergiene™ Cycle •
SenseClean™ System •
CONVENiENCE FEatURES
4 Tray Dispenser Prewash, Main Wash (with liquid detergent cup),
Bleach, Fabric Softener
TrueBalance™ Anti-Vibration System •
SmartDiagnosis™ •
LoadSense •
Status Indicator(s) •
End of Cycle Signal •
Child Lock •
Auto Suds Removal •
Forced Drain System •
Internal Water Heater •
LoDecibel™ Quiet Operation •
Leveling Legs 4 Adjustable Legs
Easy Loading TilTub™ •
MOtOR aND aGitatOR
Motor Type Direct Drive Motor
Motor Speed Variable
Max RPM 1,200
Axis Horizontal
MatERiaLS aND FiNiSHES
NeveRust™ Stainless Steel Drum •
Cabinet PCM
Control Panel Plastic
Top Plate Painted
Transparent Glass Door •
Door Rim Chrome Rimmed Glass Door
Available Colors Graphite Steel (V)
pOWER SOURCE
Ratings UL Listed
Electrical Requirements 120V, 10 Amps
Type Electric
OptiONS
Pedestal WDP4V
Pedestal (WxHxD) 27" x 13 3/5" x 28 2/5"
Stacking Kit KSTK1
DiMENSiONS
Product (WxHxD) 27" x 38 11/16" x 29 3/4"
(51" D with door open)
Carton (WxHxD) 29 1/2" x 42 1/4" x 31 1/4"
Weight (Product/Carton) 181.8 lbs/192.9 lbs
LiMitED WaRRaNty
1 Year Parts and Labor,
10 Years Motor
Lifetime on Drum
UpC CODES
WM2655HVA Washer (Graphite Steel) 048231 013208
DLEX2655V Electric Dryer (Graphite Steel) 048231 013215
DLGX2655V Gas Dryer (Graphite Steel) 048231 013222
WDP4V Pedestal (Graphite Steel) 048231 011211
KSTK1 Stacking Kit (Chrome) 048231 013024
LG Electronics U.S.A., Inc.
1000 Sylvan Avenue Englewood Cliffs, NJ 07632
Customer Service and Technical Support: [phone]
LG.com
Optional
dryer & pedestals
sold separately.
