Liberty av Intelix int-ps82-h2 User manual

Rev 190224 Phone: 719-260-0061

Toll-Free: 800-530-8998

Fax: 719-260-0075

INT-PS82-H2 Owners Manual

11675 Ridgeline Drive

Colorado Springs, CO

80921

INT-PS82-H2 Owners Manual

2

Important Safety Instrucons

»Please completely read and verify you understand all instrucons in this manual before operang this equipment.

»Keep these instrucons in a safe, accessible place for future reference.

»Heed all warnings.

»Follow all instrucons.

»Do not use this apparatus near water.

»Clean only with a dry cloth.

»Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers)

that produce heat.

»Use only accessories specied or recommended by Intelix.

»Explanaon of graphical symbols:

◊ Lightning bolt/ash symbol: the lightning bolt/ash and arrowhead within an equilateral triangle

symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the

product enclosure which may be of sucient magnitude to constute a risk of shock to a person or

persons.

◊ Exclamaon point symbol: the exclamaon point within an equilateral triangle symbol is intended

to alert the user to the presence of important operang and maintenance (servicing) instrucons

in the literature accompanying the product.

»WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR

MOISTURE AND OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED ON THIS APPARATUS.

»Use the mains plug to disconnect the apparatus from the mains.

»THE MAINS PLUG OF THE POWER CORD MUST REMAIN READILY ACCESSIBLE.

»Do not defeat the safety purpose polarized or grounding-type plug. A polarized plug has two blades with one wider

than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong

is provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of

your obsolete outlet. Cauon! To reduce the risk of electrical shock, grounding of the center pin of this plug must be

maintained.

»Protect the power cord from being walked on or pinched parcularly at the plugs, convenience receptacles, and the

point where they exit from the apparatus.

»Do not block the air venlaon openings. Only mount the equipment per Intelix’s instrucons.

»Use only with the cart, stand, table, or rack specied by Intelix or sold with the equipment. When/if a

cart is used, use cauon when moving the cart/equipment combinaon to avoid injury from p-over.

»Unplug this apparatus during lightning storms or when unused for long periods of me.

»Cauon! Shock Hazard. Do not open the unit.

»Refer to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as

power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not operate normally, or has been dropped.

INT-PS82-H2 Installaon Guide

3

Table of Contents

Product Overview�� 5

Product Contents�� 5

Front and Rear Panels�� 6

Front Panel - Switcher �� 6

Rear Panel - Switcher �� 7

Front Panel - HDBaseT Receiver �� 8

Rear Panel - HDBaseT Receiver �� 9

Installaon Instrucons�� 10

Mount the Matrix ��10

Rack Mounng Instrucons..................................................................................................................10

Connect Sources��10

Video Inputs .........................................................................................................................................10

HDBaseT Input ......................................................................................................................................10

Connect Displays��11

HDMI Outputs ......................................................................................................................................11

HDBaseT Output ...................................................................................................................................11

Connect Audio (Oponal)��11

Connecng Control ��12

RS232 Port Wiring ................................................................................................................................12

Relay Port Wiring ..................................................................................................................................12

IR Receiver Connecon IR Remote Control ..........................................................................................12

Connect Ethernet (Web Browser) Control (Oponal) ��13

Router Connecon ...............................................................................................................................13

Crossover Cable Connecon .................................................................................................................13

Web Browser Control ...........................................................................................................................13

Applying Power ��14

HDBaseT Cabling Requirements�� 14

A/V Diagram �� 15

IR Remote Control �� 16

On Screen Display (OSD) Menu �� 17

Accessing OSD Menu��17

Menu Opons ��17

INT-PS82-H2 Owners Manual

4

Web GUI Control / System Sengs �� 18

Switcher Control��18

Connecng to Web GUI Control ...........................................................................................................18

VIDEO SWITCHING ................................................................................................................................19

RESOLUTION .........................................................................................................................................20

AUDIO ...................................................................................................................................................21

POC CONFIGURATION ...........................................................................................................................22

EDID MANAGEMENT ............................................................................................................................23

RELAY CONFIGURATION ........................................................................................................................24

CEC - SOURCE CONTROL .......................................................................................................................25

CEC - DISPLAY CONTROL .......................................................................................................................26

CEC - USER DEFINED .............................................................................................................................27

RS232 Control - PORT MODE ................................................................................................................28

RS232 CONTROL - COMMAND .............................................................................................................29

TAGS .....................................................................................................................................................30

NETWORK .............................................................................................................................................31

SECURITY ..............................................................................................................................................32

RS232 and TCP/IP Control �� 33

A/V Roung��33

Preset Sengs ��34

Audio Control ��34

Relay Control��38

RS232 Pass Through Commands��39

System Commands��41

Technical Specicaons - Switcher �� 42

Technical Specicaons - HDBaseT Receiver�� 44

INT-PS82-H2 Installaon Guide

5

The INT-PS82-H2 is an 8x2 mul-format seamless presentaon matrix switcher featuring four

HDMI, one HDBaseT, one USB-C , one DisplayPort and one VGA input as well as an HDBaseT and

two HDMI outputs, one of which is a mirrored from the HDBaseT output. The switcher supports

automac switching based on video sensing, and each output can be congured separately for auto

or manual switching. The INT-PS82-H2 provides true 4K up/down scaling up to 4K@60Hz / 4:4:4 /

8 bit deep color and both outputs can be scaled to dierent resoluons independently. The INT-

PS82-H2 provides external audio inputs that can be embedded in HDBaseT, HDMI and VGA video

inputs respecvely. Moreover, it provides an global, auxiliary MIX audio input that can be assigned

to any output. The switcher can de-embed digital and/or analog audio from both outputs for audio

reinforcement purposes.

The INT-PS82-H2 ships with an 18G HDMI 2.0 HDBaseT receiver capable of extending 4K signals up to

40m / 132’ or 1080p up to 70m / 232’. The INT-PS82-H2 can also tunnel RS232 and bi-direconal IR sig-

nals to and from the HDBAseT receiver. The extension system enables high data rates by ulizing visual

lossless compression at a 2:1 data compression rate when the signal surpasses 10Gbps, anything under

10Gbps will never be compressed. Supports stac HDR (HDR10) only when data rate exceeds 18Gbps,

supports dynamic HDR (HDR10+ / Dolby Vision) when data rate is 10Gbps or less.

The switchers funcons can be controlled by built in web server / GUI, IR remote, RS232, IP or by

front panel buon operaon. Two relay switches are built in for projector screen or shades control.

Product Overview

Product Contents

• INT-PS82-H2 8x2 HDMI 2.0 Switcher

• 70m HDBaseT 2.0 Receiver

• Quick Install Guide

• (3) 3-pin Phoenix connectors

• (7) 5-pin Phoenix connectors

• (1) 3.5mm Audio Cable (for IR cascading)

• IR Remote

• (1) IR Emier

• (1) IR Receivers

• (1) DC24V 6A power supply with US power plug

• (2) Rack mount ears with 6 mounng screws

• (4) Plasc Cushions

INT-PS82-H2 Owners Manual

6

Front and Rear Panels

Front Panel - Switcher

1 2 3 4 5

1. POWER LED - Illuminates solid RED when switcher is in standby mode or illuminates GREEN when

device is powered ON.

2. SOURCE

• 1- HDBT - HDBaseT input selecon / Le key for On Screen Display (OSD)

• 2- HDMI - HDMI input selecon / Right key for On Screen Display (OSD)

• 3- HDMI - HDMI input selecon / Up key for On Screen Display (OSD)

• 4- HDMI - HDMI input selecon / Down key for On Screen Display (OSD)

• 5- HDMI - HDMI input selecon

• 6- VGA - VGA input selecon

• 7- DP - DisplayPort input selecon

• 8- USB C - USB-C input selecon / Enter key for On Screen Display (OSD)

• AUTO - Auto switch selector. Press this to enter / exit auto switch mode. Press and hold for 2

seconds to enable On Screen Display (OSD) menu

3. OUTPUTS

• 1- HDMI - HDMI output selector

• 2- HDBT - HDBaseT output selector

Note: To make a video route, select the desired SOURCE buon, then select the desired OUTPUT

buon. The video will switch in 2 to 3 seconds. For faster switch response, select the desired SOURCE

buon, then select the desired OUTPUT buon and then press the selected SOURCE buon again.

4. RESOLUTION - Two output video resoluon selectors. Press 1.HDMI or 2.HDBT buon repeatedly

to cycle through the available video resoluons. The output will reset once an opon is selected

5. VOLUME - Variable audio control

• Press the volume knob to toggle among MIX, HDMI OUT and HDBT OUT audio control.

• Rotate the knob to increase decrease volume of the selected audio

• Press and hold the knob at least 3 seconds to mute selected audio, rotate the knob to unmute

INT-PS82-H2 Installaon Guide

7

Rear Panel - Switcher

1 2

3 4

5

1. INPUT

• 1- HDBT - RJ45 / HDBaseT Input, external 5 pin phoenix for balanced audio input

• 2- HDMI - HDMI input, external 5 pin phoenix for balanced audio input

• 3- HDMI - HDMI input, external 5 pin phoenix for balanced audio input

• 4- HDMI - HDMI input

• 5- HDMI - HDMI input

• 6- VGA - VGA with 3.5mm audio input

• 7- DP - DisplayPort input

• 8- USB C - USB-C input (supports ALT-DP video mode)

• IR - 3.5mm IR input to connect IR receiver for IR pass through

• MIX - 5 pin phoenix for global balanced audio input

2. OUTPUTS

• 1- HDMI - HDMI output

• 2- HDMI - HDMI output (mirrors HDBT output)

• 2- HDBT - HDBaseT output

• IR IN - 3.5mm IR input to connect IR receiver for IR pass through

• IR OUT - 3.5mm IR input to connect IR emier for IR pass through

3. AUDIO OUTPUT

• 1 - 5 pin phoenix for balanced analog audio input and one digital SPDIF audio output for

1-HDMI output audio de-embedding

• 2 - 5 pin phoenix for balanced analog audio input and one digital SPDIF audio output for

2-HDBT output audio de-embedding

4. CONTROL

• RS232 - 3 pin phoenix connector for RS232 control

• RELAY 1-2 - (2) 3 pin phoenix connectors for relay control

• IR EYE - 3.5mm IR input to connect IR receiver for local switcher control

• TCP/IP - RJ45 to control device via network / web GUI

• FIRMWARE - Type A USB port for rmware upgrade

5. DC24V- Locking power supply port

INT-PS82-H2 Owners Manual

8

Front Panel - HDBaseT Receiver

1 2

1. MODE SWITCH

• CTRL - When placed in control mode, HDBaseT receiver will receiver RS232 pass through

commands from the switcher

• UPDATE B - Update mode for system program

• UPDATE A - Update mode for Valens program

2. POWER LED - Illuminates solid RED when power is applied

INT-PS82-H2 Installaon Guide

9

Rear Panel - HDBaseT Receiver

1 2 3 4 5

1. DC12V- Locking power supply port

2. HDBT IN - RJ45 HDBaseT connecon. Connect Cat6 cable to HDBT output transmier of the INT-

PS82-H2

3. IR IN / IR OUT

• 3.5mm IR input port for connecon to IR receiver or IR system

• 3.5mm IR output port for connecon to IR emier

4. RS232 - 3 pin Phoenix connector port for connecng / passing RS232 control from INT-PS82-h2

5. HDMI OUT - HDMI output port for connecon to video display

INT-PS82-H2 Owners Manual

10

Installaon Instrucons

Mount the Matrix

Rack Mounng Instrucons

At least 2 inches of free air space is required on both sides of the INT-PS82-H2 for proper side venlaon. Avoid

mounng the INT-PS82-H2 near a power amplier or any other source of signicant heat.

Aach the supplied rack ears to the sides of the INT-PS82-H2 matrix. The matrix requires one rack unit (1 RU) of

space. It is recommended that you leave an empty rack space above and below the INT-PS82-H2 for addional

cooling.

Connect Sources

Connect source devices to the HDBaseT, HDMI, Display Port, USB-C or VGA inputs. When using HDMI cables for

source inputs, use a High Speed HDMI cable that is less than or equal to 1.5 meters in length for 4k60 signals and

5 meters for 1080p signals. The HDBaseT input is compable with all Intelix HDBaseT transmiers.

When connecng a source device to the USB-C input using a USB-C cable, be sure the USB-C cable is capable

of supporng video and is no longer than 2 meters (6.6’) in total length. The INT-PS82-H2 USB-C input supports

ALT-DP mode for video, to ensure a laptop is compable with the INT-PS82-H2 check the laptops capability of

supporng this mode.

Note that not all laptops with USB-C port opons will support video or more specically AT-DP video mode.

Video Inputs

HDBaseT Input

Connect a solid core CAT6 F/UTP rated category cable to the INT-PS82-H2 HDBaseT input and a

compable Intelix HDBaseT transmier. The INT-PS82-H2 is compable will all Intelix branded HDBaseT

transmiers. Use TIA/EIA-568B wiring for Category 6 connecon between the transmier and the

INT-PS82-H2 receiver input.

Connect a source device to the HDMI input of an Intelix compable HDBaseT transmier using a High

Speed HDMI cable that is less than or equal to 1.5 meters in length for 4k60 signals and 5 meters for

1080p signals.

Note: The HDBaseT receiver input supports up to 40m/132’ for 4K@60Hz / 4:2:0 / 8 bit color signals

(up to 10Gbps) and 70m/232’ for 1080p signals using CAT6 F/UTP cable.

INT-PS82-H2 Installaon Guide

11

Connect Displays

HDMI Outputs

Connect display devices to the HDMI 1 and 2 output using a High Speed HDMI cable that is less than or

equal to 1.5 meters in length for 4k60 signals and 5 meters for 1080p signals.

Connect a solid core CAT6 F/UTP rated category cable to the INT-PS82-H2 HDBaseT output and

the supplied HDBaseT receiver. Use TIA/EIA-568B wiring for Category 6 connecon between the

INT-PS82-H2 and the receiver

Connect a display device to the HDMI output of the HDBaseT receiver using a High Speed HDMI cable

that is less than or equal to 1.5 meters in length for 4k60 signals and 5 meters for 1080p signals.

Note: The HDBaseT transmier supports up to 40m/132’ for 4K@60Hz / 4:4:4 / 8 bit color signals (up

to 18Gbps) and 70m/232’ for 1080p signals using CAT.6 F/UTP cable

HDBaseT Output

The INT-PS82-H2 supports stereo balanced analog audio inputs and outputs as well as digital audio outputs via

Toslink.

Connect an audio amplier to the audio output of the DL-AS61U-H2, the switcher features a le and right

balanced audio output and a digital TOSLINK output.

Connect Audio (Oponal)

INT-PS82-H2 Installaon Guide

12

Relay Port Wiring

For the normally open contacts (NO), connect a circuit between the NO and COM terminals of the

3-pin phoenix connector

For the normally closed contacts (NC), connect a circuit between the NC and COM terminals of the

3-pin phoenix connector

RELAY 1 / 2

I/O STATE RELAY STATE

NO NC

ON CLOSED OPEN

OFF OPEN CLOSED

If IR extension is required, connect the suppled IR receiver to the IR EXT port, ensuring the IR receiver

eye is placed in line of sight when using the suppled remot

Connect a control system to the INT-PS82-H2 via RS232 for switcher control.

Connecng Control

RS232 Wiring

Connect the system controller RX signal

to TX on the INT-PS82-H2 , then connect

the controllers TX signal to RX on the

INT-PS82-H2.

RS232 Sengs:

• 9600 baud

• 8 Data Bits

• 1 Stop Bit

• Parity = none

INT-PS82-H2 RS232 Port

Conncected RS232 Device pins

TX G RX

RX G TX

RS232 Port Wiring

IR Receiver Connecon IR Remote Control

INT-PS82-H2 Installaon Guide

13

Connect Ethernet (Web Browser) Control (Oponal)

The INT-PS82-H2 can be controlled via Ethernet through a web browser interface.

The TCP/IP port requires a standard straight-through Category 5

or greater cable with the TIA/EIA-568B crimp paern for opmal

operaon.

The default sengs for the TCP/IP port are:

IP address: 192.168.0.178

TIA/EIA-568B

Orange/White

Orange

Green/White

Blue

Blue/White

Green

Brown/White

Brown

Pin 1

Pin 2

Pin 3

Pin 4

Pin 5

Pin 6

Pin 7

Pin 8

1 8

Connect the Ethernet cable between to the switcher and a

router with a straight-through cable or between the matrix and

a computer with a crossover cable.

Router Connecon

1. Congure the router to use the same IP range as the matrix, such as 192.168.0.1.

2. Connect the computer to the router.

3. Connect the INT-PS82-H2 to the router

Crossover Cable Connecon

1. Congure the computer to use the same network prex as the IP address assigned to the matrix. For

example, the IP address of the matrix is 192.168.0.178. Set the computer to use a stac IP address within

the same network range, such as 192.168.0.42.

2. Connect the network crossover cable to the computer and to the TCP/IP port on the INT-PS82-H2

Web Browser Control

The INT-PS82-H2 includes a web portal to allow control of the matrix via a standard web browser. The IP address

is the same address that is used for TCP/IP control.

TIA/EIA-568A

Green/White

Green

Orange/White

Blue

Blue/White

Orange

Brown/White

Brown

Pin 1

Pin 2

Pin 3

Pin 4

Pin 5

Pin 6

Pin 7

Pin 8

1 8 TIA/EIA-568B

Orange/White

Orange

Green/White

Blue

Blue/White

Green

Brown/White

Brown

Pin 1

Pin 2

Pin 3

Pin 4

Pin 5

Pin 6

Pin 7

Pin 8

1 8

Crossover Cable Pinout

INT-PS82-H2 Installaon Guide

14

Connect the included power supply to the INT-PS82-H2 power port, connect the IEC power cord connected to

power supply to a power source.

Applying Power

Twisted Pair Wiring

Use TIA/EIA-568B wiring for Category 6

connecon between send and receive

units.

HDBaseT Cabling

To ensure proper performance of the INT-PS82-H2, it is recommended that you use solid

core, shielded Category 6 F/UTP cabling at a minimum. Category 5e F/UTP may perform

well but may not support power over HDBaseT reliably over longer distances.

For opmized HDBaseT performance use the following Liberty Wire and Cable branded

cabling;

Category 6 plenum; 24-4P-P-L6SH

Category 6A plenum; 24-4P-P-L6ASH

Category 6 NON-plenum; 24-4P-L6SH

Category 6A NON -plenum; 24-4P-L6ASH

When using shielded category cabling ALWAYS...

....use shielded connectors

....properly ground the category cable

HDBaseT Cabling Requirements

INT-PS82-H2 Installaon Guide

15

A/V Diagram

Display

Projector

Projector Screen

Laptop

(HDMI)

Laptop

(USB-C)

Laptop

(DP)

Legacy

PC

Audio

Amp

Audio

Mixer

IR Remote

INT-PS82-H2

Receiver

Control System

HDMI

VGA/A

DP

CAT

AUDIO

RS232

IR

USB

RELAY

HDMI

Source

up to 70m / 232’

Intelix

Transmi�er

(not included)

up to 70m / 232’

Web GUI

Control

INT-PS82-H2 Installaon Guide

16

IR Remote Control

1. Video Source Selecon

2. Output Selecon

3. Auto Switch Mode

• Press AUTO to enable automac switching mode, and

then select output channel

4. Video Blackout

• Press BLACK, and then select output channel to make it

output black screen

5. On Screen Display (OSD) Menu

6. Navigaon buons: OK, UP, DWON, LEFT and RIGHT for

OSD menu.

7. Return to the previous OSD menu.

8. MIX input audio control: Mute, Volume Down and Volume

Up.

9. HDMI output audio control: Mute, Volume Down and

Volume Up.

10. HDBT output audio control: Mute, Volume Down and

Volume Up.

INT-PS82-H2 Installaon Guide

17

On Screen Display (OSD) Menu

The OSD menu will allow you to set audio, video and other system sengs by either using the front

panel buons on the switcher or by the supplied IR remote. There are two ways to access the OSD

controls on the INT-PS82-H2.

1) Press and hold the MENU/2S (AUTO) buon on the front panel of the INT-PS82-H2 for 2 seconds

2) Press the MENU buon on the IR remote

To control direcon and selecon of menu opons, use either the front panel buons or IR remote to conrm

selecons.

Navigate to a desired menu / submenu opon to change or adjust sengs using the front panel buons

or using the IR remote. Press ENTER on the front panel buons or the OK buon on the IR remote for

sengs to take place.

NOTE: When turning OFF HDCP support in the OPTION menu, encrypted HDCP content will not pass.

Accessing OSD Menu

Menu Opons

There are 5 menu opons in the OSD menu;

PICTURE: Picture mode, color temperature and aspect rao sengs for outputs

SOUND: Volume and mute sengs control for the outputs

OPTION: Output resoluon sengs, allows HDCP to be turned either ON or OFF for output support

SYSTEM: Allows for factory reset to be iniated

INFO: Displays current output resoluon, sofware (SW) version and current IP address sengs.

INT-PS82-H2 Installaon Guide

18

Web GUI Control / System Sengs

Network a PC computer and the INT-PS82-H2 then open a web browser and type in IP address of the

INT-PS82-H2. The default IP address is 192.168.0.178. Be sure the computer you are using to connect

to the INT-PS82-H2 is in the same IP range to access the web GUI / server.

The login screen will appear. The default user name and password is admin

Switcher Control

Connecng to Web GUI Control

INT-PS82-H2 Installaon Guide

19

The Video menu allows you to route A/V signals to the HDMI and HDBaseT output of the switcher, enable

/ disable auto switching mode for each output and save and recall video switching presets. By default the

INT-PS82-H2 is set to auto switching mode.

To switch the video route for either HDMI and HDBT outputs, check the 1-8 buons corresponding to the

desired input, only one input can be selected at one me for each output.

To enable / disable auto switching mode, check the AUTO buon.

To save or recall video presets, click the desired preset buon and click SAVE or RECALL.

VIDEO SWITCHING

INT-PS82-H2 Installaon Guide

20

The Resoluon menu allows you to set the scaled output of each output channel.

To adjust the scaled output of each output, select the desired resoluon under HDMI OUTPUT or HDBT OUTPUT

then click CONFIRM. When using the AUTO selecon, the scaled output will match the connected displays nave

resoluon.

RESOLUTION

Liberty AV Intelix INT-PS82-H2 User manual

Popular Matrix Switcher manuals by other brands
