LIELONGREN LLR010B User manual

LIELONGREN
Dual Alarm Digital Clock
Model: LLR010B
LIELONGREN Customer Service Team
Email:[email protected]

CONTENTS
I．INTRODUCTION...................................................................................2
I．Key Features .......................................................................................2
II．Default Setting...................................................................................2
III．Installation........................................................................................2
IV．Key Specifications .............................................................................2
SETTINGS .................................................................................................3
I．Setting Time........................................................................................3
II．Setting Alarm Time.............................................................................3
III．Setting Snooze Duration ...................................................................4
IV．Setting Alarm Mode..........................................................................4
V．Setting Buzzer Volume/ Vibration Intensity .......................................4
VI．Setting Brightness.............................................................................4
TROUBLESHOOTING.................................................................................4
TAKING CARE OF THE CLOCK....................................................................4
PACKAGE LIST ..........................................................................................5
WARRANTY..............................................................................................5
FREQUENTLY ASKED QUESTIONS .............................................................5

1

2
INTRODUCE
I．Key Features
1. 7-inch Large Display with Full Range Brightness Dimmer.
2. Dual Smart Alarm with Adjustable Alarm Duration & Snooze Duration.
3. Dual Alarm Mode with Loud Buzzer and Bed Shaker.
4. Dual USB Charger with Standard DC 5V/1A Output.
5. Alarm-Test Design, easy to set your desired buzzer volume and vibration intensity.
6. Powered by USB Adapter with Battery Backup.
7. Keeps Accurate Time within 30 Seconds per Month of Time Error.
II．Default Setting
Time Format: 24 hour
Time: 12:00
Date: 2018/1/1
Alarm Duration: 10 mins (Adjustable)
Snooze Duration: 9 mins (Adjustable)
Alarm Mode: Buzzer
Alarm Volume: Medium (MED)
III．Installation
1. Plug the AC/DC adaptor to an AC household outlet, and plug the DC jack to the back
of the unit. Your clock should now be operational.
2. Insert 2xAA batteries (not included) into the battery compartment to provide backup
power to the clock in the event of a temporary power outage.
IV．Key Specifications
Adapter Input: AC 100-240v, 50/60Hz
Adapter Output: DC 5V/2A
USB 1&2 Output: DC 5V/1A (Total DC 5V/2A)
Power Cord Length: 5ft
Vibrator Cord Length: 6ft

3
SETTINGS
I．Setting Time
1. Press and hold the TIME button for 2 seconds to enter the time setting mode. First,
the hour digits will flash. Press ▲or ▼to set the current hour (hold to advance rapidly).
2. Press TIME button again, the minute digits will flash. Press ▲or ▼to set minute.
3. Press TIME button again, the 12/24Hr digits will flash. Press ▲or ▼to set 12/24Hr
time format.
4. Press TIME button again, the year digits will flash. Press ▲or ▼to set year.
5. Press TIME button again, the month digits will flash. Press ▲or ▼to set month.
6. Press TIME button again, the day digits will flash. Press ▲or ▼to set day.
7. Press TIME button again to save and exit the time setting mode.
II．Setting Alarm Time
1. Press and hold Alarm-1 (or Alarm-2) button for 2 seconds to enter alarm setting
mode. First, the hour digits will flash. Press ▲or ▼to set the current hour (hold to
advance rapidly).
2. Press Alarm-1 (or Alarm-2) button again and the minute digits will flash. Press ▲or
▼to set the current minute.
3. Press Alarm-1 (or Alarm-2) button again and the alarm day digits will flash. Press
▲or ▼to set the current alarm day.
1-1: Single day only
1-5: Weekdays only
6-7: Weekends only
1-7: Daily
4. Press Alarm-1 (or Alarm-2) button again and the alarm duration digits will flash.
Press ▲or ▼to set the current alarm duration. Alarm Duration: Default 10 minutes
(Can be adjusted to last between 1-30 minutes)
5. Press Alarm-1 (or Alarm-2) button again to save and exit alarm setting mode.
III．Setting Snooze Duration
1. Press and hold SNOOZE button for 2 seconds to adjust the snooze duration. Press
▲or ▼to set the current duration (hold to advance rapidly).
Snooze duration: Default 9 minutes (Can be adjusted to last between 1-60 minutes)
2. Press SNOOZE button again to save and exit snooze duration setting mode.

4
IV．Setting Alarm Mode
Buzzer: Wake by Noise
Vibration: Wake by Vibrator
Both: Wake by Noise and Vibrator
V．Setting Buzzer Volume/ Vibration Intensity
HI: 85dB/ Strong Vibration
MED: 75dB/ Average Vibration
LO: 65dB/ Gentle Vibration
VI．Setting Brightness
Adjust to your preferred brightness level by turning the knob on the right side of the
clock.
TROUBLESHOOTING
1. In setting mode, if no operation within 8 seconds, the clock will automatically save
the current settings and return to time mode.
2. If AC power is interrupted, the clock enters battery-backup mode, now press
SNOOZE button, the time will display for 5 seconds for emergency situations.
3.If your clock displays irrelevant time or does not function properly, which may be
caused by electro- static discharge or other interference, unplug the DC jack to
disconnect the AC power (and remove the backup battery). The clock will be reset to
default settings and you need to set it again.
TAKING CARE OF THE CLOCK
1. Place your clock on a stable surface, away from sources of direct sunlight or
excessive heat or moisture.
2. Protect your furniture when placing your units on a natural wood and lacquered finish
by using a cloth or protective material between it and the furniture.
3. Clean your unit with a soft cloth moistened only with mild soap and water. Stronger
agents such as Benzene, thinner, or similar materials can damage the surface of the unit.
Make sure the unit is unplugged before cleaning.
4. If the unit will not be used for a prolonged period of time (i.e. one month), remove
the batteries to prevent possible corrosion. Should the battery compartment become

5
corroded or dirty, clean the compartment thoroughly and replace the batteries.
PACKAGE LIST
1 x Alarm Clock
1 x Bed Shaker
1 x Power Adapter
1 x Power Cord
1 x User Manual
1 x Warranty Card
WARRANTY
100% Satisfaction Guarantee. 30 days Return & Refund policy HASSLE FREE.
Receive a full refund or free replacement if you aren't completely satisfied. Free
lifetime technical support and 6 months manufacturer's warranty.
FREQUENTLY ASKED QUESTIONS
1. Q: How to switch alarm 1 (or alarm 2) on/off?
A: Press Alarm-1 (or Alarm-2) button to switch on or off the alarm, the AL1 (AL2)
indicator will be on or off correspondingly.
2. Q: How to use the Alarm-Test Mode?
A: Long press “▲” + “Alarm2”button for 2 seconds to enter Alarm-Test-Mode,
then you can set the switch on the right to select your preferred buzzer volume and
vibration intensity.
Next, press “▲” + “Alarm2”button to exit the test mode.
3. Q: How to stop alarm ringing?
A: When Alarm 1 (or Alarm 2) is ringing (buzzer or vibrator), the related AL1
(AL2) indicator flash. Press any buttons (except SNOOZE button) to stop and reset
the alarm to go off the next day automatically.
4. Q: Can it charge my iPhone or Android?
A: Yes. It has 2 USB charging ports which can charge your phone (ios, Android,
power bank and other devices)
5. Q: Can it be used as a timer? Or just alarm with vibrator?
A: Yes. To use it as a timer, just turn off the alarm. There are 3 alarm models, sound
only, vibrator only, or both.
6. Q: Can I set alarm 1 as the buzzer and alarm 2 as the vibrator or vice versa?
A: No. When using both alarms, the alarm type must be the same.
7. Q: What’s the battery back-up system?
A: When you want full, continued use of the clock, the power cord should be
plugged in. In the event of a power outage, the battery back-up system will record

6
accurate local time and alarm time. The screen light will be on for 5 seconds when
the “Snooze”button is pressed. If you plug the power cord in again, the time will
run accurately and the alarms will be scheduled just as they were before.
8. Q: Can the clock light dimmer change the screen light from 0% to 100%?
A: Yes. The wheel-designed dimmer can adjust your screen to the preferred
brightness.
9. Does the alarm start with a lower volume and get progressively louder, or does it
start with only very loud? Vibrator same as butter?
A: The buzzer will get progressively louder and the shaker will get progressively
stronger as time passes.
10. Q: What can I do if I’m not pleased with this product?
A: Contact our customer service ASAP, they will respond within 24 hours with a
solution we guarantee you will be satisfied with.
