Lifasa PFCL Elite 6 User manual

POWER FACTOR REGULATOR
PFCL Elite 6/PFCL Elite 12
Instruction Manual

PFCL Elite 6 / PFCL Elite 12
- 1 -

PFCL Elite 6 / PFCL Elite 12
- 2 -
Table of contents
_________________________________________________________
1 INTRODUCTION AND SAFETY TIPS ............................................................................................................... 3
1.1 C
HECKS TO BE CARRIED OUT WHEN THE REGULATOR IS RECEIVED ................................................................... 3
1.2 D
EFINITIONS ..................................................................................................................................................... 4
1.2.1 4-Quadrant Regulator................................................................................................................................. 4
1.2.2 FCP System (FAST Computerized Program).............................................................................................. 4
1.2.3 Stages and Steps.......................................................................................................................................... 5
1.2.4 Regulation Program.................................................................................................................................... 5
1.2.5 Plug and Play.............................................................................................................................................. 5
1.2.6 Connection and Reconnection Time............................................................................................................ 5
1.2.7 Harmonics and THD ................................................................................................................................... 6
2 INSTALLATION AND START-UP ...................................................................................................................... 6
2.1 T
ECHNICAL FEATURES ...................................................................................................................................... 7
2.2 E
QUIPMENT I NSTALLATION .............................................................................................................................. 7
2.2.1 Mechanical Installation .............................................................................................................................. 7
2.2.2 Connections................................................................................................................................................. 8
2.2.3 Cable sections and protection elements ...................................................................................................... 8
2.2.4 Connection diagrams. PFCL Elite 6/12...................................................................................................... 9
3 GENERAL FEATURES ....................................................................................................................................... 11
4 FRONT PANEL: SCREEN AND KEYBOARD................................................................................................. 12
4.1 LCD S
CREEN .................................................................................................................................................. 13
4.2 N
AVIGATION KEYS .......................................................................................................................................... 13
5 REGULATOR'S OPERATION ........................................................................................................................... 14
5.1 S
TART - UP S CREEN .......................................................................................................................................... 14
5.2 D
EVICE S TATES .............................................................................................................................................. 14
5.3 M
EASUREMENT S CREENS ............................................................................................................................... 15
5.3.1 Functions of the Keys on the Measurement Screens ................................................................................. 18
5.3.2 Browsing the Measurement Screens.......................................................................................................... 19
5.4 S
ETUP S CREENS .............................................................................................................................................. 20
5.4.1 Functions of the Keys in the Setup Screens............................................................................................... 28
5.4.2 Browses the setup screens. ........................................................................................................................ 29
5.5 ERROR M
ESSAGES : ERRORS AND ALARMS .................................................................................................... 30
5.6 A
LARM R ELAY ............................................................................................................................................... 30
6 INTEGRATION OF PFCL ELITE IN SCADA POWER STUDIO ................................................................. 31
7 MAINTENANCE .................................................................................................................................................. 31
8 TECHNICAL SERVICE ...................................................................................................................................... 31

PFCL Elite 6 / PFCL Elite 12
- 3 -
1 INTRODUCTION AND SAFETY TIPS
INTERNATIONAL CAPACITORS S.A. thanks you for choosing one of the regulators from the PFCL Elite
series. These units have been built with state-of-the-art technologies, including a powerful processor that can
calculate the optimum algorithms and achieve the best correction of the cos ij.
The units comply with the EN 61010 Electrical Safety Standard, in accordance with the Low Voltage Directive
requirements (LVD 73/23/EC), as well as the EMC Directive (2004/108/EC) and are, therefore, certified for
use with the CE mark.
The purpose of this user manual is to describe the operating principles for the regulators from the PFCL Elite
series and to define the installation, start-up and operation procedures.
SAFETY
The installation and maintenance of the equipment must be performed by qualified and
authorised staff, in accordance with the national and international Standards. Any
manipulation or use of the equipment different from that specified by the manufacturer
may compromise user safety.
The main switch must be disconnected before any maintenance to be performed on the cos ij
regulation equipment. After the main switch has been disconnected, wait at least 5 minutes to make
sure that all capacitors have been discharged.
The following safety precautions must be taken into account during installation, maintenance or start-up
operations on equipment regulated with a PFCL Elite unit:
9Make sure that the units have the corresponding earthing connections before they are connected. A
faulty earthing connection could lead to a faulty operation and represent the risk of electrical
discharge to the user or person handling the equipment.
9The necessary precautions will be taken during maintenance operations to prevent the risk of
electrocution and electric shock. Make sure that the unit has been disconnected and wait until the
capacitors have been fully discharged before handling or operating the unit. We recommend the use
of safety goggles and gloves.
9Resonance can be produced when the power factor compensation units are connected with no
loads. In this case, the voltage harmonics can be amplified, causing damage to the compensation
equipment and other equipment connected to the network.
9Follow the start-up and stop procedures described in the manual to prevent damage to the unit
and/or adjacent equipment.
9Always use original spare parts or components when adjusting or replacing components and follow
the corresponding procedures described in the instruction manual.
1.1 Checks to be carried out when the regulator is received
On receiving the regulator, check that:


The unit has not been damaged during transport.


The type supplied is the same as that requested. (See label on the rear, Fig. 1.1)


Check the features shown on the unit's label, to make sure that they are valid for the type of grid
where the unit will be connected. (Voltage and power supply frequency, measurement range, etc.)


Follow the instructions described in section 2, in relation to the rest of the installation and setup.


Please contact the technical-commercial service of INTERNATIONAL CAPACITORS, SA if you
detect any anomalies.

PFCL Elite 6 / PFCL Elite 12
- 4 -
Fig. 1.1.- Rear label of the unit
1.2 Definitions
The following definitions might be useful to understand some of the sections in this manual.
1.2.1 4-Quadrant Regulator.
The regulator is capable of performing the measurement and regulation functions when the active power is
transferred from the grid to the loads (common case in a consumer installation) or when the load is
transferred to the grid (this is the case of installations with generators that not only allow the consumption of
energy, but can also export and sell energy).
1.2.2 FCP System (FAST Computerized Program).
This system controls the connection sequence of the different stages, tending to minimise the number of
operations and matching the usage times of the different stages to achieve the determined final power
demand. The operations are carried out in such a way that, in the case of stages with an identical power, the
stage that has been disconnected the longest is connected when there is demand and the stage that has
been connected the longest is disconnected in the case of a surplus.

PFCL Elite 6 / PFCL Elite 12
- 5 -
1.2.3 Stages and Steps
We must explain the difference between stages and steps. In this manual, a STAGE is described as the
capacitor banks in which the power factor compensation unit is divided, which may have different power
ratings, usually in 1:1, 1:2, 1:2:4, etc. ratios.
A step is each one of the total power fractions (power of the first step) that can be regulated with the use of
stages with a different weight.
1.2.4 Regulation Program.
The power ratings of the different groups or stages usually follow certain patterns called "programs”. The
program indicates the power ratios between different stages. The most frequent programs are:
Program 1:1:1:1. All stages have the same power. For example, a 100 kvar unit with 5 steps would be
composed of 5 identical 20 kvar stages and it would be described as a (5 x 20) kvar unit.
Program 1:2:2:2. All stages after the second stage have twice as much power as the first stage. For
example, a 180 kvar unit with 5 stages would be composed of a first 20 kvar stage and 4 identical 40 kvar
stages. It could be described as a (20 + 4 x 40) kvar unit.
Program 1:2:4:4. The power of the second stage is twice as much as the first stage and all other stages
after the third stage would have four times as much power as the first stage. For example, a 300 kvar unit
with 5 stages would be composed of a first 20 kvar stage, a second 40 kvar stage and 3 identical 80 kvar
stages. It could be described as a (20 + 40 + 3 x 80) kvar unit.
Other Programs. Other programs can be used, such as 1:2:2:4, 1:2:4:8 or 1:1:2:2, etc. The meaning of the
numbers, as assumed in previous cases, shows the proportion of the powers between the first stage, which
receives a value of 1 and the next stages (2 means twice as much power, 4 means four times as much
power, etc.).
The unit can easily configure one of the 10 standard programs, which are as follows:
1:1:1:1, 1:2:2:2, 1:2:4:4, 1:2:4:8, 1:1:2:2, 1:1:2:4, 1:2:2:4, 1:2:3:3, 1:2:3:4, 1:2:3:6.
An open program can also be configured between 1:1:1:1 and 1:9:9:9 in special cases.
1.2.5 Plug and Play.
A series of parameters must be configured when a power factor regulator is installed, to make sure that it
operates correctly. Some of these parameters might be hard to know, such as, for example, the voltage
phases or the voltage corresponding to the current measured, as well as the current transformer ratio. PFCL
Elite has been designed with a smart automatic process that detects the necessary parameters, such as:
¾C/K: calculates the ratio of the current transformer and the power of the smallest step.
¾Phase: Identifies the voltage sequence and correspondence with current. In other words, it identifies
the U
L1
, U
L2
, U
L3
, when the current measured is I
L1
, I
L2
, I
L3
and whether it is connected in the
opposite way or not.
¾Number of stages installed and Program: the system connects all stages in a sequence, finds out
how many stages are installed and then calculates the program, i.e., the power ratio of the
capacitors (see Section 1.2.4).
1.2.6 Connection and Reconnection Time.
Connection time Tc defines the minimum time between changes in the status of stages, i.e., between
connections and disconnections. Therefore, the configuration of this parameter has a direct impact on the
compensation speed, in other words, on the monitoring capacity after changes in load. Establish a shorter
connection time to improve the power factor correction when the load can change quickly.
However, a shorter Tc will lead to a higher number of connections per time unit, shortening the useful life of
the associated components (contacts, capacitors). To assess the number of connections, PFCL Elite uses
individual meters for each capacitor.
The reconnection time is the minimum time between the disconnection of a stage and its reconnection. This
time is required to discharge the capacitor enough to prevent an over-current in the system after it is
reconnected.

PFCL Elite 6 / PFCL Elite 12
- 6 -
1.2.7 Harmonics and THD
Non-linear loads, such as those in rectifiers, inverters, speed drives, kilns, etc., absorb non-sinusoidal
periodic currents from the grid. These currents are composed of a fundamental frequency component, rated
at 50 or 60 Hz, plus a series of overlapping currents, with frequencies that are multiples of the fundamental
frequency; they are defined as harmonics. The result is a deformation of the current and, as a consequence,
of the voltage, which leads to a series of associated secondary effects (overloads in conductors, machines
and automatic switches, phase offsets, interferences in electronic equipment, RCCB trips, etc.).
The level of harmonics is usually measured with the total harmonic distortion rate (THD), which is the ratio,
usually as a %, of the RMS value of the harmonic content and the value of the fundamental component.
2 INSTALLATION AND START-UP
This section contains information and warnings that the user must respect at all times to guarantee his own
safety and the safe operation of the device.
WARNING! The PFCL Elite regulators are connected to units with capacitors that remain
charged even after the voltage has been disconnected. Wait at least 5 minutes after the
equipment is disconnected, before the internal components of the equipment are handled, in
order to avoid the risk of electric shock.
Any manipulation or use of the equipment different from that specified by the
manufacturer may compromise user safety.
The power supply must be disconnected from the unit when it shows signs of deterioration or a faulty
operation. In this case, contact a qualified service representative.
The persons responsible for the installation or operation of the PFCL Elite 6 or PFCL Elite 12 regulator must
follow the common safety measures for LV or MV installations to guarantee a safe operation, depending on
the installation location. In addition, they must take into account all safety warnings stated in this instruction
manual.

PFCL Elite 6 / PFCL Elite 12
- 7 -
2.1 Technical features
The main features of the unit are marked on the label on the rear (see Fig. 1.1) and they are also described
in the quick guide attached. They are summarised in the following table:
Main power supply and
voltage measurement
480, 400, 230, or 110 Vac. +15 % -10 %; 50/60 Hz, (see label) Power supply: U
L1
-
U
L2
. Measurement U
L1
,U
L2
, U
L3
and U
N
Power supply cables Section 1.5 mm2, gl 0.5 to 2 A protection fuse
Current measurement
circuit
Current transformer (CT), In /5 A AC., preferably on phase L1. Min. cable section.
2.5 mm2
Leakage current
measurement circuit
Nominal current of transformer secondary: I¨sec = 2 mA AC. Transformer with
ratio of 500: I¨= 1 A AC. +20%
Current measurement
margin
Current I: 0.05 ... 5 A AC (maximum overload +20%)
Leakage current I¨: 0.01 ... 1 A AC(maximum overload +20%)
Measurement accuracy Voltage and current: 1%; cos ϕ: 2% ±1 digit
Temperature
measurement External temperature approximation. Range: 0 ... 80ºC. Accuracy: ±3ºC
Consumption 8.2 VA (empty); 9.3 VA (6 relays); 11 VA (12 relays)
Output Relays. Contacts for Umax. 250 Vac., 4 A AC., AC1.
Cabling and output relay
protection
Cable section 1.5 mm2, protection with circuit breaker (C curve) of 6 A or gl 6 A
fuse
Alarm relay Switched relay for use exclusively for the alarms
Standards IEC 62053-23 (2003-01) Ed. 1.0
IEC 61326-1, EN61010-1, UL 508
Safety/Insulation Category III, Class II, according to EN 61010-1
Protection degree IP40 (equipment mounted, cabinet front panel)
IP30 (equipment not mounted) according to EN-60529
Admissible
environmental conditions
Temperature: -20 ... +60ºC; Relative humidity: max. 95% (without condensation).
Max. altitude: 2000 m
Control system FCP (a program that minimises the number of operations)
Communications Interface: RS485. Protocol: MODBUS.
Speed: 9600, 19200, 38400
The PFCL Elite regulator
measures and operates
in 4 quadrants according
to the attached diagram.
2.2 Equipment Installation
2.2.1 Mechanical Installation
In mechanical terms, the equipment is installed in a cabinet's front panel or in a panel. The panel fixing drill
must be drilled in compliance with DIN 43 700, (dimensions: 138+1x138+1 mm).

PFCL Elite 6 / PFCL Elite 12
- 8 -
2.2.2 Connections
The following points must be checked before the unit is powered:
The installation and maintenance of the equipment must be performed by qualified and
authorised staff, in accordance with the national and international Standards.
All connections must remain inside the electrical panel.
Take into account that, when the device is connected, the terminals may be hazardous to the
touch, and opening the covers or removing elements may expose these parts. Do not use the
device until it is fully installed.
This regulator has a series of associated capacitor units that remain charged up to 5 minutes
after the unit has been disconnected from the grid. Make sure that all capacitors have been
discharged before handling the unit.
The installation of an external current transformer (CT) is necessary to measure the current. Usually, the
transformation ratio of this CT is In/5 A, where Inmust be a minimum of 1.5 times over the total maximum
current of the load.
The current transformer (CT) must be installed on the connection point where all of the loads' current
circulates and where the current of the capacitors will be compensated (see Fig. 2.1).
The current transformer (CT) should preferably be connected to phase L1, while the voltage connections
should be connected to phases L1, L2 and L3 (see diagram in Fig. 2.2). Connections P1, P2, S1 and S2
shown on the said diagrams should be respected. In case the connection layout mentioned above is not
respected, the phase must be adjusted, following the procedure described in section 5.5.
&255(&7 ,1&255(&7

The current transformer (CT)
must measure the joint current
of the capacitors and the loads.
If this does not work, make
sure that the CT is not short-
circuited.

When the CT is connected in this
position, NO CAPACITORS WILL
BE CONNECTED, even when
inductive loads are present. The
unit will not perform the
compensation functions.



When the CT is connected in this
position, ALL CAPACITORS WILL
BE CONNECTED. However, they
will not be disconnected when the
load decreases.
Risk of over-compensation in the
grid with no load.
Fig. 2.1.- Location of the current transformer
2.2.3 Cable sections and protection elements
The power circuit must be protected with gl (IEC 269) or M type fuses (IEC 127) with a rating of 0.5 to 2 A. A
circuit breaker or equivalent device must be used to connect and disconnect all of the unit's control circuits
(PFCL Elite power supply + relay circuits and contact coils) from the power supply grid. The circuit breaker
must be installed on the equipment and be easy to access. The power circuit and relay contact circuits must
be connected with cables with a minimum section of 1.5 mm
2
. The cables of the current transformer's (CT)
secondary must have a minimum section of 2.5 mm
2
. In the case of distances between the CT and the
regulator over 25 m, this section must be increased by 1 mm
2
for every 10 m.

PFCL Elite 6 / PFCL Elite 12
- 9 -
2.2.4 Connection diagrams. PFCL Elite 6/12.
Fig. 2.2.- PFCL Elite 6/ PFCL Elite12 Connection diagram
(*) Nominal voltage, depending
on the type. See label on the
unit.
No. Description of the
t
erminals
U
L1
Voltage input L1 (*)
U
L
2
Voltage input L2 (*)
U
L
3
Voltage input L3 (*)
U
N
Voltage input LN (*)
COM Relay common
1 Relay output 1
2 Relay output 2
3 Relay output 3
4 Relay output 4
5 Relay output 5
6 Relay output 6
7 Relay output 7
8 Relay output 8
9 Relay output 9
10 Relay output 10
11 Relay output 11
12 Relay output 12
IS1 Current input S1
IS2 Current input S2
IS1 Leakage current input
S1
IS2 Leakage current input
S2
A+ RS-485 Input A(+)
B- RS-485 Input B(-)
S RS-485 S Input
ALARM
NC or NO Relay output
NOTE: The two COM terminals are not internally connected. In the case of the model with 12 relay outputs,
the two COM outputs of the regulator must be short-circuited.
Leakage current connection ( I )
The leakage current transformer must be connected in such a way that it measures the current of the
capacitor bank. This will detect any leakage in the capacitors of the capacitor bank.
The transformer must have a ratio with 500 spirals and the current measured must not exceed 1 A AC.
Fig. 2.4.- Connecting the leakage current transformer (I¨)
Only for
PFCL Elite 12

PFCL Elite 6 / PFCL Elite 12
- 10 -
Connecting RS-485 Communications elements
The PFCL Elite regulators can be connected to a computer or another unit by means of the RS-485 bus
series included. With this system, the data can be centralised in a single SCADA registry point (Power
Studio® System).
In a network of equipment, the PFCL Elite regulator communicates by question-answer (slave).
The PFCL Elite regulator communicates with the MODBUS RTU© protocol, which enables it to access the
electrical parameter and the main variables and configurations. Contact the manufacturer to obtain the table
of addresses.
See section 4.4. to change the communications configuration.
Fig. 2.5.- Example of an RS-485 network, using PFCL Elite 6/ PFCL Elite12

PFCL Elite 6 / PFCL Elite 12
- 11 -
3 GENERAL FEATURES
The PFCL Elite 6/PFCL Elite 12 power factor regulators
measure the grid cos ijand regulate the connection and
disconnection of capacitors to correct it. The PFCL Elite 6
and PFCL Elite 12, models can control a different number
of relay outputs each.
Type Maximum no. outputs
PFCL Elite 6 6 relay outputs, plus an alarm relay
PFCL Elite 12 12 relay outputs, plus an alarm relay
Here are some of the most important features of this series of regulators:
- Power and voltage measurement circuits in the same inputs.
- Different models for different voltages (110, 230, 400 and 480 Vac).
- Indiscriminate use of the 50 or 60 Hz frequency.
- Easy to install, with no need to use tools.
- Dimensions in compliance with DIN 43 700 (144 x 144 mm front panel).
- 4-quadrant control (see Fig.3.1), with indication about the stages connected, indication of the cos ij,
type of reactive power (inductive or capacitive ), and display of energy import or export
(EXPORT icon).
- LCD screen with 15 digits and seven segments, on 4 lines, plus 55 icons to display the different
operating conditions.
- Grid analyzer function, with the measurement of many different system parameters.
- Measurement of the leakage current with an associated alarm, disconnection of capacitors and
search and deactivation of the faulty capacitor.
- Simple configuration, with only 5 keys, with a Plug&Play function and no need to disconnect the
power supply.
- Many different programs, from 1:1:1:1 to 1:9:9:9. This can divide the total power in up to 46 steps in
PFCL Elite 6 and up to 100 steps in PFCL Elite 12.
- FCP system that minimises the number of capacitor connections and disconnections.
- RS-485 Communications (Modbus protocol), to supervise and display the different regulator
parameters. The SCADA Power Studio software can be used to display and configure the said
parameters.
- 4-Quadrant measurement and compensation:
Fig. 3.1.- Signs in 4-quadrant measurements

PFCL Elite 6 / PFCL Elite 12
- 12 -
4 FRONT PANEL: SCREEN AND KEYBOARD
The regulator's front panel shows the following signs:
Fig. 4.1.- Front panel of the device
NOTE: The setup process, different parameters and regulation modes are described in detail in the
Regulator Operation section (Section 5).
LCD Screen Navigation keys
Fig. 4.2.- LCD screen for the device
Fig. 4.3.- Keyboard

PFCL Elite 6 / PFCL Elite 12
- 13 -
4.1 LCD Screen
The regulator's screen is of the LCD type and is composed of the following (Fig 4.4.):
- 15 digits with 7 segments, arranged on 4 lines, with which the equipment provides information about
the variables measured or the configuration variables in alphanumerical form.
- Icons associated to the capacitors of the capacitor bank, with which the equipment shows its
connection or disconnection state.
- Icons for units or general information displayed on the screen.
- Icons for the setup screens, which open this screen.
Capacitor icons
Unit icons
Setup screen icons
Digits
Fig. 4.4.- Information displayed on the LCD screen
4.2 Navigation keys
The navigation keys have different functions, depending on the regulator's status
and the screens displayed. The said functions are described later on with the
description of the type of screen (Section 5).

PFCL Elite 6 / PFCL Elite 12
- 14 -
5 REGULATOR'S OPERATION
5.1 Start-up Screen
A start-up screen will be displayed when the PFCL Elite is powered, showing the
unit's version, voltage model and number of relays available. This information must
be included when reporting any fault or defect.
After a few seconds, the unit will display the first measurement screen, i.e., the default
screen.
5.2 Device States
The PFCL Elite regulators can have two states:
-Normal State (RUN): This is the normal operating state of the regulator, where it measures the installation's
cos ij, among many other parameters, and automatically regulates the connection and disconnection of
capacitors to correct this value. The regulation method depends on different parameters configured in the
setup state (SETUP).
The variable measurement screens will always be displayed when the unit is in the Normal state. The unit will
automatically open this default screen after 10 minutes of inactivity and no key is pressed (see Section 5.3).
The Manual Connection/Disconnection of Capacitors can only be carried out in this state by holding
keys or key .
Hold down key to change the state from normal to setup. The regulator will sequentially disconnect all
capacitors that are connected before opening the setup state.
-Setup State (SETUP): The different work parameters of the regulator can be configured in this state.
Likewise, the equipment will not perform the regulation functions while active in this state, i.e., it will not
connect or disconnect capacitors to regulate cosine.
The setup screens will always be displayed when the unit is in the Setup state. The unit will automatically
open the verification screen after there are 10 minutes of inactivity and no key is pressed (see Section 5.5).
Likewise, if there are another 10 minutes of inactivity and no key is pressed, the unit will automatically return
to the Normal state (RUN) on the default screen (see Section 5.3).
Hold down key to change from the setup state to the Normal state. A verification screen will be displayed
first. Confirm the change to the Normal state by holding down . Or, press
to continue in the setup state.

PFCL Elite 6 / PFCL Elite 12
- 15 -
5.3 Measurement Screens
In the normal state, the regulator measures different parameters, which can be displayed on different
screens. The device also acquires the maximum and minimum values of the said parameters and displays
them after the last reset, even after the unit is turned off and restarted.
All measurement screens show the capacitors that are connected at that moment, the flashing backlight and
the alarm icon. Most screens also display the alarm code.
The unit's measurement screens are as follows (in order):
Default screen: Cos III, phase-phase voltage III and current (PM1; TypeM1):
The following data is displayed:
¾Three-phase cosine and its type ( inductive or capacitive).
¾Three-phase phase-phase voltage.
¾Current.
The EXPORT word under the icon that shows the type of cosine indicates
that the power measured is exported. When the installation is consuming
(importing) power, the PHASE parameter must be reconfigured in the
setup menu.
Three-Phase Power Screen (PM2; TypeM1):
The following data is displayed:
¾Three-phase active power (in kW).
¾Three-phase reactive power and its type ( inductive, or
capacitive) (in kvar).
¾Apparent power (in kVA).
Phase-neutral voltage screen (PM3; TypeM1):
The following data is displayed:
¾L1 Phase-neutral voltage, with respect to the neutral (in V).
¾L2 Phase-neutral voltage, with respect to the neutral (in V).
¾L3 Phase-neutral voltage, with respect to the neutral (in V).
¾Frequency (in Hz).
Phase-Phase Voltage Screen (PM4; TypeM1):
The following data is displayed:
¾Phase-phase voltage of L1-L2 (in V).
¾Phase-phase voltage of L2-L3 (in V).
¾Phase-phase voltage of L3-L1 (in V).
¾Frequency (in Hz).

PFCL Elite 6 / PFCL Elite 12
- 16 -
Currents and Temperatures Screen (PM5; TypeM1):
The following data is displayed:
¾Current (in A).
¾Leakage current (in mA).
¾Temperature (in ºC).
Comments about temperature measurements:
the unit uses an internal sensor to display the approximate external
temperature of the equipment (internal cabinet temperature), which will be
reached when the current conditions remain stable: number of stages
connected, ventilation (forced or not), external cabinet temperature, load
consumption, etc. If these parameters are not stable, the error in the
temperature reading can increase significantly.
Cos III and PF Screen (PM6; TypeM1):
The following data is displayed:
¾Three-phase cosine and its type ( inductive, or capacitive).
¾Power factor, PF.
THDs Screen (PM7; TypeM2):
The following data is displayed:
¾THD harmonic distortion of the voltage (in %).
¾THD harmonic distortion of the current (in %).
Voltage Harmonics Screens (PM8 and PM9; TypeM2):
There are two screens. The first screen shows harmonics 3, 5 and 7
and the second screen shows harmonics 9, 11 and 13. The following
data is displayed:
¾3rd or 9th voltage harmonic (in %).
¾5th or 11th voltage harmonic (in %).
¾7th or 13th voltage harmonic (in %).
Current Harmonics Screens (PM10 and PM11; TypeM2):
There are two screens. The first screen shows harmonics 3, 5 and 7 and the
second screen shows harmonics 9, 11 and 13. The following data is
displayed:
¾3rd or 9th current harmonic (in %).
¾5th or 11th current harmonic (in %).
¾7th or 13th current harmonic (in %).

PFCL Elite 6 / PFCL Elite 12
- 17 -
Screens with the Number of Capacitor Connections (PM12, PM13, PM14 and PM15; TypeM3):
The number of screens will depend on the number of capacitors configured. We will have a maximum of 4
screens, since the information of 3 capacitors will be shown on a single screen.
The screens are alternated automatically to show the number of connections for each capacitor (C1, C2,...up
to C12).
Flashing capacitor icons on the measurement screens:
¾The icons of the capacitors configured as ON (forced connection) will be turned off for 1 second
every 4 seconds.
¾The icons of the capacitors configured as OFF (forced disconnection) will be turned on for 1 second
every 4 seconds.
¾The icons of the capacitors that have been cancelled by the leakage current alarm will flash every
second.
¾In the case of the disconnection after changing to the setup screen or due to a leakage alarm, only
the steps connected will start flashing every second.

PFCL Elite 6 / PFCL Elite 12
- 18 -
5.3.1 Functions of the Keys on the Measurement Screens
The measurement screens will always be displayed when the unit is in the Normal state (RUN). Use the
keyboard to browse these screens. The functions of each key displayed on the measurement screens are
described next:
Browses the screens and returns to the previous screen. This can only be done from
the instantaneous measurement screens, not from the maximum or minimum
measurement screens.
Browses the screens and opens the next screen. This can only be done from the
instantaneous measurement screens, not from the maximum or minimum measurement
screens.
Opens the maximum measurement screen (if available).
Opens the minimum measurement screen (if available).
Returns to the instantaneous measurement screen from the maximum or minimum
measurement screen. It also returns to this screen automatically after 5 seconds of
inactivity, when no key has been pressed.
long
Connecting capacitors manually: Hold down the key (for more than 3 seconds) and
the regulator will connect the steps sequentially at different time intervals, in
accordance with the connection time setting (see Section 5.5).
long
Disconnecting capacitors manually: Hold down the key (for more than 3 seconds)
and the regulator will disconnect the steps sequentially at different time intervals, in
accordance with the connection time setting (see Section 5.5).
long
Deletes the maximum measurements from the screen (only on the maximum
measurements screen).
Deletes the number of connections (only on the connection number screen).
long
Deletes the minimum measurements from the screen (only on the minimum
measurements screen).
long
After opening the Setup state (SETUP), any steps connected will be automatically
disconnected, with the corresponding disconnection time.
+
long
Deletes the minimum and maximum measurements from the screen (only on the
minimum and maximum measurements screen).

PFCL Elite 6 / PFCL Elite 12
- 19 -
5.3.2 Browsing the Measurement Screens
Forcing stages and changing to the Setup mode
Setup Screens
Manual Switch. Connection
Manual switch. Disconnection
Long Press
Long Press
Long Press
Browsing the measurement screens
Type M1
Screen
Type M1
Min
Type M1
Max
Maximum
deletion
Long Press Long Press
Previous
screen
Next
screen
Minimum
deletion
Browsing the measurement screens with no minimum measurements.
Browsing the connections screen.
Type M2
Screen
Type M2
Max
Long Press
Previous
Screen
Next
Screen
Maximum
deletion
Type M3
Screen
Long Press
Num.
Connections
deletion
Previous
Screen
Next
Screen
