Life Span Workplace DT-5 User manual

Item Number Description
1
2
3
4
5
6
7
8
9
10
Lift Frame Upright
Support Bracket
Desktop
Leg
M8*10L Bolt
M8 Washer
M8*16L Bolt (Pre-installed)
M8*45L Carriage Bolt (Pre-installed)
M8 Lock Nut (Pre-installed)
Set Screw (Pre-installed)
At LifeSpan we strive to make our equipment easy to assemble and start using. Parts that can be
pre-assembled are always assembled and tested on the production line
Prior to starting the assembly process take all of the parts out of the box, remove plastic bags and lay the
parts out on the oor to become familiar with the components.
Since this desk can be heavy, it is recommended that you use two people during assembly and follow these
assembly instructions to reduce any problems that could occur.
Tandem Desk:
Assembly Instructions
4
Included in Hardware Bag
Wrench-13mm
Allen Wrench-5mm
3
8
9
6
1
2
5
7
6
M8*10L Bolt
M8 Washer
For Warranty, Limitations and Exclusions please refer to your DT-5 or DT-7 Owner’s Manual.
The Maximum Load Capacity of this desk is 300 lbs. (136 kg)

Assembling and Attachment
A. Fully assemble the DT-5 or DT-7 prior to assembling and
attaching the Tandem Desk. Remove the “LifeSpan”placard
from the lift frame upright (1) from the side of the desk you are
assembling the Tandem Desk to.
B. Attach the support bracket (2) to the DT-5 or DT-7 lift frame
upright (1) with the three M8*10L bolts (5) and M8 washers (6)
found in the hardware bag. There are three dierent mounting
heights (29 in/74 cm, 30 in/76 cm, 31 in/79 cm). Choose the
appropriate mounting height and tighten the support bracket
to the lift frame upright.
Suggestion: Loosely install the lower bolt rst before installing
the upper two bolts.
C. Lay the desktop upside down so that the frame is facing up.
Attach the leg (4) to the desktop (3) using the four pre-installed
M8*16L bolts (7) and M8 washers (6).
D. With the help of a second person, ip the desk
right side up and set the desktop frame into the
support bracket (2) installed in step B. Align the
bolt holes of the support bracket and desktop
frame.
E. Install the two M8*45L bolts (8), M8 washers (6)
and M8 lock nut (9) and tighten.
F. Check to be sure the desk is level and make
any necessary adjustments by loosening the
set screw (10) in the leg and raising or lowering
the desk accordingly and re-tightening the set
screw.
2
1
6
5
3
4
6
7
10
2
8
6
9

Item Number Description
1
2
3
4
5
6
7
8
9
Tandem Desk Frame
Tandem X Desk Frame
Leg
M8*16L Bolt
M8 Washer
M8*70L Carriage Bolt (Pre-installed)
M8 Lock Nut (Pre-installed)
M6*40L Screw
Set Screw (Pre-installed)
At LifeSpan we strive to make our equipment easy to assemble and start using. Parts that can be
pre-assembled are always assembled and tested on the production line
Prior to starting the assembly process take all of the parts out of the box, remove plastic bags and lay the
parts out on the oor to become familiar with the components.
Since this desk can be heavy, it is recommended that you use two people during assembly and follow these
assembly instructions to reduce any problems that could occur.
Tandem X Desk:
Assembly Instructions
4
Included in Hardware Bag
Wrench-13mm
Allen Wrench-5mm
3
9
M6*40L Bolt
Allen Wrench-4mm
For Warranty, Limitations and Exclusions please refer to your DT-5 or DT-7 Owner’s Manual.
The Maximum Load Capacity of this desk is 300 lbs. (136 kg)
TANDEM DESK TANDEM X DESK
8
65
7
9

Assembly and Attachment
A. Lay the expansion desk (2) upside down so the frame is facing
up. Attach the leg (3) to the Tandem X Desk using the four
M8*16L bolts (4) pre-installed in the desktop.
NOTE: If assembling this desk to the right side of the DT-5
or DT-7, see instructions for changing to right side desk.
The Tandem X (expansion desk) attaches to the Tandem Desk.
The expansion desk comes from the factory set up to work on
the left side of the DT-5 or DT-7 Desk. If the Tandem desk is set
up on the right side of the DT-5 or DT-7 simply remove the six
screws from the bottom of the desk frame and turn the frame
180 degrees. Reinstall the 6 screws and the expansion desk is
now set up to mount on the left side of the DT-5 or DT-7 desk.
B. Flip the expansion desk upright and line the
mounting holes of the Tandem Desk frame (1)
with the Tandem X frame (2).
C. Install the two M8*70L carriage bolts (6)
through the two frames and install the M8
washer (5) and M8 lock nuts (7). Do not fully
tighten at this time.
D. Install the two M6*40L (8) screws through
the Tandem X frame into the bottom of the
Tandem desktop. Do not fully tighten at this
time.
E. Make sure the top surface of the Tandem and
Tandem X desk are level. There is a locking
screw (9) on the leg that may need to be
loosened to adjust the height of the Tandem
X desk prior to tightening the attaching
hardware.
F. Once everything is level, tighten the two
M8*70L bolts (6) with lock nuts (7) and the
two M6*40L screws (8).
2
4
3
3
7
9
6
assembled for left
side desk
10
58
10
Top surfaces are level
assembled for
right side desk
