Lifecycle LC9500 Configuration guide

LifeCycle LC9500 LC95-0000-12
General Assembly S/N CBJ100000
Operation Manual M051-00K63-B043
Manual: Serv; LC95/91/85 M051-00K63-A009
Console
Overlay
Final Frame
Assembly
Alternator
w/Pulley
Crank Shaft
Assembly
Intermediate
Pulley/Shaft
Assembly
Seat Latch
Assembly
Seat Post
Assembly
Seat Post
Shrouds
Idler Bracket
Assembly
Console Support
Assembly
Left Side Shroud
and Crankarm
Right Side Shroud
and Crankarm
PCB Mounting
Bracket Assembly Front Wheels
Resistor
Assembly
Handlebar
Assembly
Belts
Cables
Bottom Sensor
Cover
0K63-01146-0000 Upper Sensor
Cover
0K63-01145-0000
Polar Receiver
SK40-00045-0001
Accessory Tray
0K63-01030-0000
Screws(4)
0017-00101-1253
rev 30 Oct 2008

2
LifeCycle LC9500 LC95-0000-12
Console Overlay Bezel Assembly S/N CBJ100000
Console Assembly Overlay Bezel
AK63-00070-0001 Eng Met AK63-00063-0001 Eng Met
AK63-00070-0003 Ger Met AK63-00063-0003 Ger Met
AK63-00070-0004 Spn Met AK63-00063-0004 Spn Met
AK63-00070-0006 Jap Met AK63-00063-0006 Jap Met
AK63-00070-0007 Frn Met AK63-00063-0007 Frn Met
AK63-00070-0008 Itl Met AK63-00063-0008 Itl Met
AK63-00070-0009 Itl Met AK63-00063-0009 Itl Met
AK63-00070-0010 Por Met AK63-00063-0010 Por Met
Console Board - Upper
A084-92219-A001
Console Case Assembly
AK63-00121-0000
Battery Door
0K63-01029-0000
Phillips Pan Screws(13)
9917-00101-1650
Upper Overlay
Lower Overlay

3
LifeCycle LC9500 LC95-0000-12
Final Frame Assembly S/N CBJ100000
Alternator w/Pulley
AK63-00093-0000
Power Control Board
and Battery Assembly
AK63-00049-0000
Frame Gasket
0K63-01007-0001
Clutch Assembly
AK63-00026-0000
Idler Pulley Assy
AK63-00021-0000
Crank Disc
0K63-01095-0001
Crank Pulley Assy
AK63-00051-0000
Resistor Assy
AK63-00047-0001
Grommet
0017-00042-1134
Seat Latch Assy
AK63-00043-0000
5/16 x 18 x 12 HXW Bolt
0017-00101-1183
Leveler
Ak61-00035-0000
End Cap
0K63-01219-0000

4
LifeCycle LC9500 LC95-0000-12
Alternator w/Pulley - AK63-00093-0000 S/N CBJ100000
A
lternator Pulley
0K61-02500-0001
A
lternator
0017-00009-0841
Locking Nut
0017-00103-0117 Washer
0017-00104-004
4
Bolt
0017-00101-0956

5
Lif LifeCycle LC9500 LC95-0000-12
Crank Shaft & Bearing Assembly S/N CBJ100000
Flywheel Screws (3)
0017-00101-1715
Washers (3)
0017-00104-0458
Pulley Assembly
AK63-00051-0000
Pulley
0K63-01018-0000
Crank Arm Hub
0K63-01095-0001
*Small Thrust Washer (2)
0K63-01129-0000
*Needle Bearing (2)
0K63-01344-0000
*Large Thrust Washer (2)
0K63-01129-0001
*Small Snap Ring (2)
0017-00100-0241
*Bowed Retainer Ring (2)
0017-00100-0243
Washer (2)
0017-00104-040
9
Bolt (2)
0017-00101-1705
*Crankshaft
0K63-01012-0001
*Crankshaft & Bearing Kit
GK63-00002-0077
Crank Arm Hub (2)
0K63-01095-000
1

6
LifeCycle LC9500 LC95-0000-12
Intermediate Shaft & Bearing Assembly – GK63-00002-0007 S/N CBJ100000
Spacer
Clutch Assembly
AK63-00026-0000
DELRIN Washers
0017-00104-0455
Retaining Ring
0017-00100-0242

7
LifeCycle LC9500 LC95-0000-12
Seat Latch Assembly - AK63-00043-0000 S/N CBJ100000
Set Screws (2)
0017-00101-0333
NYLINER
0017-00042-1129
Latch Spring
0K63-01117-000
Latch Bracket
0K63-01064-0000
E-Ring
0017-00100-0050
NYLINER
0017-00042-1129
Latch Rack
0K63-01061-0000
Link Shaft
AK63-00113-0000

8
LifeCycle LC9500 LC95-0000-12
Seat Post Assembly - AK63-00232-0000 S/N CBJ100000
Seat-Deluxe
AK63-00229-0001
Lock Washer(4)
0017-00104-0064
Hex Bolt(4)
0017-00101-1121
Extrusion
Guide Cap
0K63-01044-0000
Seat Post Assembly
AK63-00099-0001
Spring Support Bracket
0K63-01210-0000
Guide Base
0K63-01045-0000
Polylastomer Bumper
0017-00042-1131
Pan Screws(3)
0017-00101-1614
Seat Adjustment Rack
0K63-01049-0000
Screw
0017-00101-1623
Seat Post Decal
0K63-01151-0000

9
LifeCycle LC9500 LC95-0000-12
Seat Post Shrouds S/N CBJ100000
Left Seat Post Shroud
0K63-01092-0001
Right Seat Post Shroud
0K63-01092-000
2
Screw
0017-00101-0991

10
LifeCycle LC9500 LC95-0000-12
Idler Bracket Assembly - AK63-00021-0000 S/N CBJ100000
Idler Bracket
0K63-01050-0000
Idler Bearing
AK63-00008-0000
Lock Nut
0017-00103-0218

11
LifeCycle LC9500 LC95-0000-12
Console Support Assembly - AK63-00065-0000 S/N CBJ100000
Console Cable
HR Electrode Cable
Console Support
Weldment Assy
AK63-00089-0000
End Cap
0017-00042-1132
Support Screws (4)
0017-00101-1736
Pan Screws(4)
0017-00101-1721
Handlebar Cover-RT
0k63-01192-0001
I-Beam Joint
0K63-01178-0002
Handlebar Cover-LT
0k63-01192-0002
Polar Bracket
0K63-01113-0000
Nut(2)
0017-00103-0318
Screws
0017-00101-1710
Cable Assy: Jack/Hr

12
LifeCycle LC9500 LC95-0000-12
Left Side Shroud and Crankarm S/N CBJ100000
Crank Arm Screws(3)
0017-00101-1702
Shroud Screws(3)
0017-00101-0991 Left Side Shroud
AK63-00058-0002
Shroud Plug
0K63-01084-0000 Left Pedal
AK63-00263-0002
Left Strap
0K63-01238-0002
Crank Arm, LT
OK39-1042-0006
Washer(2)
0017-00104-0280
Decal
0K63-01153-0000

13
LifeCycle LC9500 LC95-0000-12
Right Side Shroud and Crankarm S/N CBJ100000
Crank Arm Screws(3)
0017-00101-1702
Right Side Shroud Screws(8)
0017-00101-0991
Right Side Shroud
AK63-00058-0001
Right Pedal
AK63-00263-0001
Right Strap
0K63-01238-0001
Crank Arm, RT
OK39-1042-0005
Decal
0K63-01153-0000

14
LifeCycle LC9500 LC95-0000-12
PCB Mounting Bracket Assembly – AK63-00049-0000 S/N CBJ100000
Plastic Grommet(4)
0017-00042-0821
Battery - 6V
0017-00003-0685
Battery Screws(2)
0017-00101-0975
Cable-Insulated Clamp
0017-00009-0915
Positive
Terminal
Battery Mounting
Bracket
0K63-01211-0000
Pan Screws(4)
0017-00101-0823
PCB Circuit Board
B084-92218-D002

15
LifeCycle LC9500 LC95-0000-12
Front Wheels – AK63-00017-0000 S/N CBJ100000
Wheel/Bearing Assembly
A
K63-00016-0000
Wheel Screw
0017-00101-1611
Flat Washer
0K63-01041-0000
Pan Screw(2)
0017-00101-1611
Wheel Insert
0K63-01039-0000

16
LifeCycle LC9500 LC95-0000-12
Resistor Assembly - AK63-00047-0001 S/N CBJ100000
Resistor Bracket(2)
0K63-01165-0000
Resistor Mounting Rod
0K63-01166-0000
Resistor
.5 OHM 240 Watt
100E-00002-0084
Nut(3)
0017-00103-0081
Retainer
0K63-01215-0000
Power Control
Cable Assembly
TORX Screw(20)
0017-00101-1282

17
LifeCycle LC9500 LC95-0000-12
Handlebar Assembly - AK63-00091-0000 S/N CBJ100000
Handlebar
End Cap(2)
0K63-01114-0000
Insulated Plug(4)
0K63-01167-0000
Phillips Screw(4)
0017-00101-1720
Electrode Cable
Assembly
Electrode
Molded Insert(4)
AK63-00014-0002
Molder Grip
Handlebar
AK63-00083-0000

18
LifeCycle LC9500 LC95-0000-12
Belts S/N CBJ100000
Alternator Belt
0K63-01065-0000
Intermediate Belt
0K63-01066-0001

19
LifeCycle LC9500 LC95-0000-12
Cables S/N CBJ100000
