Lifely Tate Series User manual

Product Code
Dimensions(W x D x H)
TATE-RODT220-BLACK Dining Table
TATE-RODT220-NATURAL Dining Table
2200x900x750mm
Important
Please read through instruction carefully
Before assembly and keep for future reference.
For our full catalogue of assembly instructions,
Visit: lifely.com.au/assembly.
Assembly Instructions
Tate Series

Important Tips and Maintenance
1.
Keep children and animals
away from working area as
smaller parts may cause chok-
ing if swallowed.
2.
Never place liquids or anything
damp upon furniture as it
will mark. Ensure a coaster or
running is beneath.
Never use ammonia based
3.
cleaning products as it will
damage the finish.
4.
To avoid fading, keep furniture
out of direct sunlight.
5.
Use a soft or damp cloth(dry
cloth)when wiping or cleaning
surfaces.
6.
Two person are required.
7.
Lay a soft matt down to protect
the furniture piece before and
during assembly.
TATE-RODT220-BLACK 2

Designed for everyday
TATE-RODT220-BLACK 3
So your relationship is strong. But is it flat-pack furniture
strong? Unless you're an aerospace engineer, assembling
furniture can be slightly sressful. We recommend
meditating quietly, pouring yourself a herbal tea(or
slightly less herbal wine) and tackling things one step at
a time. If you feel a passive aggressive remark coming
on, try a compliment instead.E.g. "You're so good
looking".
This 7-step assembly should take around 2 hours with
an Allen Key - or 60 minutes with and electric drill.
Godspeed.

TATE-RODT220-BLACK 4
Before Assembly
Tips Before Your Start:
- Remove all wrapping material, including staples & packing straps before you start to assemble.
- DO NOT tighten all screws and bolts until completely assembled.
- Keep all hardware parts out of reach of children.
QUICKFIT
Tighten quickfit until shoulder is flush with panel. Do not overtighten or undertighten.
Panel Panel
Shoulder
CAM LOCK
When fitting cam lock, ensure starting position is correct before you insert connecting quickfit.
Turn cam lock clockwise to tighten.
Quickfit head should be in the centre
of the cam lock when the two panels
are joined.
Cam lock should be inserted before
quickfit.
CORRECT WRONG

Cam Lock Dowel
Screw Washer
Dowel Cam Lock
φ15mm
Allen Key
4#
5#
Component Hardware
Please check you have all the fittings
part or tools are listed in below.
No. F No. G No.H No. I
No. A No. B No. C No. D No. E
Quantity:32Pcs Quantity:64Pcs
8*28mm
Quantity:32Pcs Quantity:32Pcs Quantity:2Pcs
Quantity:8Pcs Quantity:8Pcs Quantity:1Pc Quantity:8Pcs
Screw
M6*50
Screw Allen Key
φ20
Foot Pad
φ18
M8*35mm
8*30mm
TATE-RODT220-BLACK 5

Component Panels part List
Please check you have all the panels are listed below.
1.
2.
3.
4.
1
2
2
4
4
4
4
44
4
45
5
5
5
5
5
3
3
5
5
5.
TATE-RODT220-BLACK 6
Table Top
Top Panel of Base
Bottom Panel of Base
Side Panel of Base
Corner Rail of Base
x1 CTN 2/3
x1 CTN 1/3
x1 CTN 1/3
x4 CTN 1/3
x4 CTN 1/3
2.
3.
4.
5.
Top Panel of Base
Bottom Panel of Base
Side Panel of Base
Corner Rail of Base
x1 CTN 3/3
x1 CTN 3/3
x4 CTN 3/3
x4 CTN 3/3

STEP 1
Cam Lock
No. C
Quantity:16Pcs
STEP 2
Cam Lock Dowel
8*28mm
No. A
Quantity:32 Pcs
5
A
B
B
A
B
A
B
A
B
A
B
Dowel
8*30mm
No. B
Quantity:48 Pcs
5
55
5
4
4
C
C
C
C
C
C
C
C
TATE-RODT220-BLACK 7
x2
x8

STEP 3
STEP 4 D
D
D
D
D
D
D
D
E
3
B
B
C
C
4
4
Cam Lock
No. C
Quantity:16Pc
Dowel
8*30mm
No. B
Quantity:8 Pcs
Screw
M6*50mm
No. D
Quantity:16 Pcs
Allen Key
4#
No. E
Quantity:2 Pcs
TATE-RODT220-BLACK 8
B
x2
x2

STEP 5
STEP 6
F
G
H
1
I
I
I
I
I
I
I
I
D
E
D
D
D
D
D
D
D
2
B
B
Dowel
8*30mm
No. B
Quantity:8 Pcs
Screw
M6*50mm
No. D
Quantity:16 Pcs
Screw
M8*35mm
No. F
Quantity:8 Pcs
Screw Washer
φ18mm
No. G
Quantity:8 Pcs
Allen Key
5#
No. H
Quantity:1 Pc
Foot Pad
No. I
Quantity:8 Pcs
φ20mm
TATE-RODT220-BLACK 9
x2

STEP 7
TATE-RODT220-BLACK 10

lifely.com.au
Great job. You're done!
Don't forget to share how it looks in
your space and tag us on lnstagram.
@lifelyhome#homewithlifely!
