Light Efficient Design Remphos Outdoor Series User manual

INSTALLATION MANUAL
Outdoor Series
RP-SAL-8W-50K-SF-GY-G1, RP-SAL-30W-50K-SF-GY-G1
MODEL
WATT
LUMEN
NET WEIGHT
DIMMING
RP-SAL-8W-50K-SF-GY-G1
8W
1600LM
11.61 lbs.
Use the remote control to
adjust
RP-SAL-30W-50K-SF-GY-G1
30W
6000LM
29.76 lbs.
Use the remote control to
adjust
Installation:
1. Take out the fixture and the tools from the package.
2. Remove the small plastic on the bottom of the remote and press the power
button on the remote.
3. Cover up the solar panel (you can use the package to cover up the solar
panel entirely or flip the fixture, so the solar panel is facing the ground) and
check if the light module turns on once power is pressed on the remote. When
the light is on a green light will be displayed either flashing or still depending
on its charge state. If the fixture does not turn on, please place it under
sunlight, as the battery may need to charge. For the light to charge, it
needs to be ON. Please wait a few minutes with the light under the sun
and then press the power button on the remote. Make sure the red light
is blinking which indicates that it is on and charging properly.
4. Use the remote control to power up and set up the necessary mode. The light
module will flash twice when receive the signal from remote control (The default
setting is motion sensor mode 40%-100%). Please refer to page 2 for the different
mode options. Pay special attention to your local sunshine and refer to the Best
Practices Solar Guide for additional understanding. The document can be found here
under the documents section and inside the box: https://www.led-llc.com/sal
5. Using the dedicated tool to assemble the light body and the mounting accessories,
adjust the light fixture and LED module to the suitable angle.
6. Install the light to the round pole, square pole or wall, tighten the screws and the
nuts when fixed

Light last 35 hours
Light last 55 hours
Light last 25 hours
Light last 28 hours
Light last 14 hours
Light last 20 hours
Light last 35 hours
Introduction of Remote-Control button
Note: Remote control included.
Red and green indicator
Microwave and PIR receiver
Light-Emitting Module
ON/ OFF Working/Standby Key
Time Control Mode
Constant Brightness
Mode
***Test mode: Please do not select this button, if you do it will reset the mode you selected to
default (40%-100% motion when sensed, and you will need to select the mode you had selected
before to set right.
Select the 4 hr option or 8 hr option to set to a predetermined run time instead of running from
dusk til dawn. These buttons only apply to the constant brightness mode.
Cancels preset time modes that were selected, either 4 or 8 hrs. If no hour
mode is selected, it will try and run from dusk ‘til dawn at the constant level
selected.
Motion Sensing
Mode
Green indicator：
1. Battery power more than 10%, the green light will stay lit
2. Battery power less than 10%, the green light flash will slowly
Suitable for areas and seasons with less sunlight time
Suitable for areas and seasons with average sunlight time
Suitable for areas and seasons with more sunlight time
Red indicator:
1. When charging, the red light will be flashing slowly
2. When fully charged, the red light will stay lit
3. When the red light is blinking fast, this indicates that the battery is not charging
*(Flashing quicker than a second)
4.
Mode switching indication of remote control:
The light module will flash twice when the light fixture receives the signal from remote control

Item
Fixed arm
mounting
Slip fitter
mounting
U-Trunnion
mounting
Square-Hoop
Mounting
Round -Hoop
Mounting
8W Solar
Streetlight
1.Wall mounted
2.Square pole above
3.94 in
1.Round pole:
1.96 in - 3.54 in
2.Square pole：1.96
in - 3.54 in
Round pole:
1.96 in - 4.33 in
30W Solar
Streetlight
Wall mount or
Square pole wider
than 4.75 in
1. Round pole:
2.36 in -3.94 in or
Square pole: 1.97 in
-3.94 in
Round pole:
1.97 in - 4.72 in
Warning and Attention:
1. The average sunshine in the installation area should be above 3.5h/day in order to ensure full function
of the lighting fixture.
2. Before installation, please ensure the light pole foundation is solid enough to withstand lighting fixture.
3. Position the lighting fixture to optimize its exposure to sunlight. Always face the equator (solar panel to
face south if in northern hemisphere for example).
4. In order to allow self-cleaning, please have a minimum angle of 15 degrees.
5. For best results install on a day with full sunlight. If the battery is totally dead, please allow the battery
to charge under sun before programming it accordingly. (Please remove small plastic from remote)
6. Adjust the angle of the fixture to optimize its exposure to sunlight. Adjust the LED module angle toward
the area to be illuminated.
7. The fixture is on once the power button on the remote is pressed and aimed at the fixture. Please
make sure the panel is installed under direct sunlight. The red light should be flashing, indicating that it is
charging. You can also hit the test button on the remote to ensure that it is on and will receive 2 flashes
back from the LED light.
8. Select the necessary operation mode with the remote control. Please refer to the instruction manual of
the remote
control for further information. Note: The remote has a range of 30ft
9. Use the dedicated tool to disassemble the anti-theft screws. Note: Dedicated tool is included in the
box of each lamp.
Installation Accessories:
1.77 – 2.63 in
1.77 – 2.63 in
EPA RATING

10. The lighting fixture will automatically turn on at night and turn off during daylight.
11. Please select the right operating mode according to the local legislation needs and the local sunshine co
nditions.
Modes:
Motion Sensor Mode, Time Control Mode, and Constant Brightness Mode ( See page 2 for details
on mode options)
12. The battery of the LEDSAL solar street light fixture will stop charging when the ambient temperature is
below 32°F or above 149°F. The working temperature of the solar fixture is -4°F (-20°C) to +122°F (+50°C).
When operating in an environment with a temperature lower than 32°F (0°C) or equal to or above 149°F
(65°C) the battery will stop charging, even is there is sunlight. In that temperature range the battery self
protects which will show a flashing red indictor light. This feature helps protect the battery from damage. The
solar area light will still light even in those extreme temperatures until the battery is completely depleted.
13.) The working temperature of the solar fixture is -4°F~+122°F. When operating in an environment
with a temperature lower than 32°F; the battery will stop charging, even if there is sunlight, but the
lighting fixture can still be discharged if you want to use.
14. When the ambient temperature is ≤ 32°F or ≥ 149°F, the battery will turn into self-protection
mode.
a. When the battery charge is only 40%, the luminance will automatically be reduced by half.
b. When the green indicator begins to flicker slowly, it means that there is only 10% battery charge.
c. When there is only 5% battery charge, the luminaire will automatically shut down, then enter the
protection state and not discharge.
10. The lighting fixture will automatically turn on at night and turn off during daylight.
11. Please select the right operating mode according to the local legislation needs and the local sunshine co
nditions.
Modes:
Motion Sensor Mode, Time Control
Battery Replacement
In case of battery failure or end of life, loosen the
screws on the battery cover, disconnect the wire
connectors, replace the whole battery cover kit
(including smart control system, battery, cover) ,
connect the wires and tighten screws.
