Light Emotion Z10 Operator's manual

1of 5 pages
BUBBLE MACHINE
Z10/Z30
User’s instruction manual
This manual contains important information about the safe installation and use of this product Please read this
instruction manual carefully before installing or operating Please keep these instructions in a safe place for future
reference

2 of 5 pages
Congratulations on the purchase of your Z10/Z30 bubble machine.
With its one liter tank capacity and built-in fan, The Light Emotion Z10 will pump out enough
bubbles to make magic happen, impressing all - particularly the children. Perfect for all kinds of
functions including birthday parties, play rooms, school plays and much more.
The Z30 is a monster bubble maker. Integrated high-power fans blow bubbles over 10 meters,
making this unit especially suited for outdoor use* and highly recommended for installation or hire
for that big event on your calendar. The extra-size 3L tank and the large output of the Z30 make it
extremely suited to parades and festivals.
With the specially formulated fluid* which produces bubbles with a long hang-time - the room will
be floating along on literally hundreds those little spheres of magic. It's an effect that never stops
causing awe and delight. The bubble machines are supplied with a hanging bracket and remote
control which will even let you control constant or timed bursts of bubbling fun.
*(Note: requires Bubble fluid to operate, available separately, Unit may be suitable for outdoor use
but is not IP rated and cannot be left in the rain or be subjected to moisture.)
CONTENTS
SECTION Page
WHATISINCLUDED 2
SAFETY INSTRUCIONTS, POWER 3
OPERATIONINSTRUCTIONS 4
SPECIFICATIONS 5
Please note that as part of out ongoing commitment to continuous improvement and product
development, the specifications in this manual are subject to change without notice. Whilst every
care has been taken in the preparation of this manual we reserve the right to change specifications in
the course of product improvement.
WHAT IS INCLUDED:
•1x Bubble Machine
•1x Power Cord
•1x User Manual and Warranty Card
•1x Remote control

3 of 5 pages
SAFETY INSTRUCTIONS:
Please read these instructions carefully. It includes important information about the installation
usage and maintenance of this product.
•Do not overfill your bubble machine. Overfilling will cause the unit to leak.
Danger of electric shock
•Switch off from mains when refilling the liquid or cleaning the system.
•Do not transport with liquid. If the machine get wet, do not use until it is completely dry.
•Keep this device dry.
•Keep the bubble machine upright.
•Turn off or unplug when not in use.
•This machine is not water-proof or splash-proof. If moisture, water, or any liquid gets inside
the housing, immediately unplug the unit and contact your Light Emotion dealer before using
it again.
•No user serviceable parts inside. Refer to your Light Emotion dealer.
•For indoor use only. Not designed for outdoor use.
•This appliance must be earthed.
•For adult use only. The bubble machine must be installed out of the reach of children. Never
leave the unit running unattended.
•Never aim the output at open flames.
•Extended use will make all surfaces slippery.
•Position output of bubbles away from persons.
•Regular cleaning of the bubble wheel is required.
•Bubble liquid may leave permanent marks on clothing.
•Bubbles and fluid can leave a slippery surface.
POWER:
CAUTION: This light emotion is designed to operate on 240VAC
Power Consumption: max 40W
Fuse: M205 1A fast blow

4 of 5 pages
OPEARATION INSTRUCTIONS
SET UP
•Remove all packing materials from the bubble machine.
•Place bubble machine on flat surface.
•Loosen the side screws and lift the housing upwards. You will see a liquid tank.
•Pour bubble liquid into the liquid tank, being careful not to exceed the maximum fluid level as
specified by the specifications. DO NOT OVERFILL.
•When the container is full, lower the housing and tighten the screws.
FILL THE LIQUID
1. Ensure your bubble machine is unplugged from the mains electrical supply before attempting to
open the housing. We take Z10 as an example.
2. To help avoid accidental exposure to dangerous live AC
mains voltage, two safety screws are fitted that require a
screwdriver to remove. Once these are removed, the finger
screws can be undone by hand.
3. Once the screws are removes, the lid of the housing can be
carefully swung upwards, as shown above. Take care not to spill
any of the bubble fluid inside the unit.
4. The fluid tank is designed to fit only one way around. Make
sure you insert it correctly, as shown above, with the lower edge
facing into the machine.

5 of 5 pages
OPERATION:
Connect power cable to the unit.
Press the [POWER] button on the controller, both the Red LED and Green LED will illuminate,
indicating that is ready for use.
LED Function
Hold [ON/OFF] Button The Greed LED on
the top of ON/OFF
button is turn off.
You will notice that the internal
bubble drum and fan are activated.
Bubbles are produced.
Switch [DURATION]
Pot
Adjust the duration of bubble
drum operate every time. (short
to long)
Push [TIMER]
Button
Switch [INTERVAL]
Pot
The Amber LED on
the top of TIMER
button is turn on.
Adjust the interval of bubble
drum operate. (short to long)
SPECIFICATIONS:
Z10 Z30
Weight 4.5Kg 8.5Kg
Size L370 x W200 x H200mm L370 x W280 x H200mm
Power input 240VAC 50Hz 240VAC 50Hz
Max Power consumption 40W 40W
Fuse Fast blow 1AM205 Fast blow 1A M205
Input connection Power - Male IEC Power - Male IEC
Colour Silver and black Silver and black
Tank Capacity 1L 3L
Fluid Consumption 600mL/hr 1.2L/hr
Hanging Bracket Yes Yes
Lead Fixed remote 2m Fixed remote 2m
Construction Metal casing Metal casing
