Antari PM-1 User manual

Antari PM-1 Pan Motor for S-500 V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 80378P
MANUAL
ENGLISH

1
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................3
Rigging ............................................................................................................................................................................4
Return Procedure..........................................................................................................................................................5
Claims..............................................................................................................................................................................5
Description of the device.................................................................................................................................................6
Front.................................................................................................................................................................................6
Back.................................................................................................................................................................................7
Installation...........................................................................................................................................................................7
Output Nozzle Pan Control .........................................................................................................................................8
Setup and Operation ........................................................................................................................................................9
Control Modes...............................................................................................................................................................9
One PM-1 device (Stand-alone) ............................................................................................................................9
Multiple PM-1 devices (Master/Slave control) .....................................................................................................9
Multiple PM-1 devices (DMX Control) ..................................................................................................................10
Fixture Linking...............................................................................................................................................................11
Data Cabling...............................................................................................................................................................11
Control Panel ...............................................................................................................................................................12
Control Mode ..............................................................................................................................................................12
DMX Addressing ..........................................................................................................................................................12
Menu Overview...........................................................................................................................................................13
Main Menu Options....................................................................................................................................................14
1. DMX Address ........................................................................................................................................................14
2. DMX Channel Mode ...........................................................................................................................................14
3. Pan Mode .............................................................................................................................................................15
4. Pan Speed ............................................................................................................................................................15
5. Master/Slave Mode.............................................................................................................................................15
6. DMX Error ...............................................................................................................................................................16
7. Pan Direction ........................................................................................................................................................16
8. Display Options ....................................................................................................................................................16
9. Display Orientation..............................................................................................................................................17
10. Test Mode............................................................................................................................................................17
11. Total Operation Time ........................................................................................................................................17
12. Software Version ................................................................................................................................................17
13. Factory Reset......................................................................................................................................................17
DMX Channels .............................................................................................................................................................18
1 channel ..................................................................................................................................................................18
2 channels .................................................................................................................................................................18
Maintenance....................................................................................................................................................................19
Replacing the Fuse.....................................................................................................................................................19
Troubleshooting ...............................................................................................................................................................19
No Response to DMX..................................................................................................................................................20
Product Specifications....................................................................................................................................................21

2
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
●Antari PM-1 Pan Motor for S-500
●Schuko to IEC power cable (1,2 m)
●1 x mounting bracket
●1 x safety eye
●User manual
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
●Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
●Never remove warning or informative labels from the unit.

3
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
●Never use anything to cover the ground contact.
●Never leave any cables lying around.
●Do not insert objects into air vents.
●Do not connect this device to a dimmer pack.
●Do not switch the device on and off in short intervals, as this will reduce the device’s life.
●Do not shake the device. Avoid brute force when installing or operating the device.
●Only use the device indoors, avoid contact with water or other liquids.
●Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
●Only operate the device after having familiarized with its functions.
●Avoid flames and do not put close to flammable liquids or gases.
●Always keep the case closed while operating.
●Always allow a free air space of at least 50 cm around the unit for ventilation.
●Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
●Make sure that the device is not exposed to extreme heat, moisture or dust.
●Make sure that the available voltage is not higher than stated on the rear panel.
●Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
●If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
●If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
●If your Antari device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Antari dealer for service.
●For adult use only. The device must be installed beyond the reach of children. Never leave the
device running unattended.
●Never attempt to bypass the thermostatic switch or fuses.
●For replacement use fuses of same type and rating only.
●The user is responsible for correct positioning and operating of the PM-1. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.
●This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
●Repairs, servicing and electric connection must be carried out by a qualified technician.
●WARRANTY: Till one year after date of purchase.
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The maximum ambient temperature ta = 40 °C must never be exceeded.
●In order to eliminate wear and improve the device’s lifespan, during periods of non-use, completely
disconnect from power source via breaker or by unplugging.
●The relative humidity must not exceed 50 % with an ambient temperature of 40 °C.
●If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
Improper installation can cause serious damage to people and property !
You endanger your own safety and the safety of others!

4
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself!
Always let the installation be carried out by an authorized dealer!
Procedure:
●If the PM-1 is lowered from the ceiling or high joists, professional trussing systems have to be used.
●Use a clamp to mount the PM-1, with the mounting bracket, to the trussing system.
●The PM-1 must never be fixed swinging freely in the room.
●The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
●When rigging, derigging or servicing the PM-1, always make sure, that the area below the installation
site is secured and that there are not any unauthorized people around.
The PM-1 can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property!
Antari excludes liability for unsafe situations, accidents and damage that are the result of:
●disregard for the warnings or regulations as set out on the PM-1 or in this manual.
●use for other purposes or under other circumstances than those set out in this documentation.
●alterations to the PM-1. This also includes the use of replacement parts other than the original ones.
●insufficient maintenance.
●unauthorized removal of safety caps and/or safeguards.
●incompetent operation of the device.
Antari is not liable for any consequential loss in the event of a PM-1 breakdown.
This user manual has been drawn up with the utmost care. Antari cannot be held responsible for any
mistakes made in this publication or for any consequences thereof.

5
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE
GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause for
the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

6
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Description of the device
Features
The PM-1 is an optional pan motor which can be used in combination with the Antari S-500 snow
machine and allows you to control its pan movement. The PM-1 helps you increase the coverage of this
already powerful machine.
●Input voltage: 100–240 V AC, 50/60 Hz
●Power consumption: 12 W
●Pan angle: 60°/90°/120°
●Control protocol: DMX-512
●Onboard: LED display + control buttons
●Control modes: Stand-alone, Master/Slave, DMX-512
●DMX mode: 1, 2 channels
●Color: Black
●Housing: Metal chassis with plastic cover
●Data connection: 3-pin XLR IN/OUT
●Power connection: IEC power connector IN
●IP rating: IP20
●Fuse: T1AL/250 V
●Dimensions: 170 x 152 x 153 mm (LxWxH)
●Weight: 2 kg
Optional accessories:
80378 –Antari S-500 Snow Machine
Front
Fig. 01
01) S-500 output nozzle installation bracket
02) LED display + control buttons

7
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Back
Fig. 02
03) 3-pin DMX signal connector IN
04) Safety eye
05) 3-pin DMX signal connector OUT
06) IEC power connector IN + Fuse T1AL/250V
Installation
Remove all packing materials from the PM-1 Pan Motor for S-500. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.

8
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Output Nozzle Pan Control
You can install the output nozzle of the S-500 Snow Machine on the Antari PM-1. Follow the instructions
below.
01) Put the output nozzle of the S-500 Snow Machine in the installation bracket (01) of the PM-1 (Fig. 03).
Fig. 03
02) Insert and tighten the mounting screws (Fig. 04).
Fig. 04

9
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Setup and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 110 V specification product on 240 V power, or vice versa.
Connect the device to the main power supply.
Control Modes
There are 3 modes:
●Stand-alone
●Master/Slave
●DMX-512 (1CH, 2CH)
One PM-1 device (Stand-alone)
01) Fasten the device to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140/70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the PM-1 is not connected with a DMX cable, it functions as a stand-alone device.
05) See 3. Pan Mode on page 15 for more information about stand-alone mode.
Multiple PM-1 devices (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140/70141).
03) Use a 3-pin XLR cable to connect the PM-1.
The pins:
01) Earth
02) Signal -
03) Signal +
04) Link the units as shown in Fig. 05. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third, and fourth units. You
can use the same functions on the master device as described in 3. Pan Mode on page 15 (Stand-
alone mode). This means that you can set your desired operation mode on the master device and
all slave devices will react the same as the master device.
Multiple PM-1 devices (Master/Slave control)
Fig. 05

10
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Multiple PM-1 devices (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140/70141).
03) Use a 3-pin XLR cable to connect the PM-1 and other devices.
04) Link the units as shown in Fig. 06. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple PM-1 devices DMX Setup
Fig. 06
Note : Link all cables before connecting electric power

11
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller.
The combined number of channels required by all the fixtures on a serial data link determines the number
of fixtures the data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
●DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
●DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
●DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
●DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
●DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
●DAP Audio data cable FL08 DMX/AES-EBU, XLR/M 5-pin > XLR/F 5-pin.Ordercode FL08150 (1,5 m),
FL083 (3 m), FL086 (6 m), FL0810 (10 m), FL0820 (20 m).
●DAP Audio DMX adapter: 5-pin/3-pin. Ordercode FLA29.
●DAP Audio DMX adapter: 3-pin/5-pin. Ordercode FLA30.
●DAP Audio DMX Terminator 3-pin. Ordercode FLA42.
●DAP Audio DMX Terminator 5-pin. Ordercode FLA43.

12
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
The PM-1 can be operated with a controller in control mode or without the controller in stand-alone
mode.
Control Panel
A) LED display
B) ENTER button
C) DOWN button
D) UP button
E) MENU button
Fig. 07
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel allows you to assign DMX fixture addresses, which is the first channel with which the PM-
1 will respond to the controller.
Please note when you use the controller, the device has 2 channels.
When using multiple PM-1 fixtures, make sure that you set the DMX addresses right.
Therefore, the DMX address of the first PM-1 should be 1(001); the DMX address of the second PM-1
should be 1+2=3 (003); the DMX address of the third PM-1 should be 3+2=5 (005), etc.
Please, make sure that you do not have any overlapping channels in order to control each PM-1
correctly. If two or more PM-1 fixtures are addressed similarly, they will work similarly.
Controlling:
After having addressed all PM-1 fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the PM-1 will automatically detect whether DMX 512 data is received or not.
If it does not, the problem may be:
●The XLR cable from the controller is not connected with the input of the PM-1.
●The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 90 seconds
When no button is pressed for 30 seconds, the display will show the DMX starting address and after 60
more seconds the display will turn off.
Press the MENU, ENTER, UP or DOWN button to light up the display. See 8. Display Options on page 16 for
more information.

13
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Menu Overview

14
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Main Menu Options
The main menu has the following options:
1. DMX address
8. Display options
2. DMX channel mode
9. Display orientation
3. Pan mode
10. Test mode
4. Pan speed
11. Total operation time
5. Master/Slave mode
12. Software version
6. DMX error
13. Factory reset
7. Pan direction
01) Press the MENU button to navigate through the main menu.
02) Press the ENTER button to open the submenus.
1. DMX Address
In this menu you can set the DMX starting address of the device.
01) Press the MENU button until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to select the DMX starting address. The selection range is
.
04) Press the ENTER button to confirm the selection.
2. DMX Channel Mode
In this menu you can select the DMX channel mode.
01) Press the MENU button until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to select one of the 2 DMX channel modes:
1 channel
2 channels
04) Press the ENTER button to confirm the selection.

15
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
3. Pan Mode
In this menu you can set the pan range and run the auto program.
01) Press the MENU button until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to select one of the 3 options:
60 degrees
90 degrees
120 degrees
04) Press the ENTER button to confirm the selection. The device will automatically start rotating at the set
range.
Note: The device must be set as a master for this operation mode to be functional. See 5. Master/Slave
Mode on page 15 for more information.
4. Pan Speed
In this menu you can set the pan movement speed.
01) Press the MENU button until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to set the pan movement speed. The adjustment range is
, from slow to fast.
04) Press the ENTER button to confirm the selection.
5. Master/Slave Mode
In this menu you can set the device as a master or a slave device in master/slave control mode.
01) Press the MENU button until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to select one of the 3 options:
Master: The device operates as a master and sends DMX
signals to other devices.
Slave 1: The device operates as a slave and copies the
behavior of the master device.
Slave 2: The device operates as a slave and mirrors the
behavior of the master device.
04) Press the ENTER button to confirm the selection.
05) Press and hold down the MENU button for 2 seconds until the display shows the currently selected
master/slave control mode, in order to activate it.

16
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
6. DMX Error
In this menu you can determine the device’s behavior in case of a DMX signal error.
01) Press the MENU button until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to select one of the 3 options:
The device will operate in Pan mode.
The device will stop working.
The device will use last working DMX signal, to ensure undisrupted performance.
04) Press the ENTER button to confirm the selection.
7. Pan Direction
In this menu you can reverse the pan movement direction.
01) Press the MENU button until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to select one of the 2 options:
Pan reverse off
Pan reverse on
04) When the display shows , each pressing of the ENTER button will reverse the device’s
current movement direction.
8. Display Options
In this menu you can select whether the display will remain on or will turn off after 90 seconds of inactivity.
01) Press the MENU button until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to select one of the 2 options:
The LED display remains on
When no button is pressed for 30 seconds, the display will show the DMX starting
address and after 60 more seconds the display will turn off. Press any button to turn
the display on.
04) Press the ENTER button to confirm the selection.

17
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
9. Display Orientation
In this menu you can select the orientation of the display.
01) Press the MENU button until the display shows .
02) Repeatedly press the ENTER button to choose one of the 2 display orientations:
Normal display
Inverted display
10. Test Mode
In this menu you can test the device’s functions.
01) Press the MENU button until the display shows .
02) Press the ENTER button to test the device’s functions.
11. Total Operation Time
In this menu you can view the device’s total operation time.
01) Press the MENU button until the display shows .
02) Press the ENTER button to view the device’s total operation time (hours).
12. Software Version
In this menu you can view the device’s currently installed software version.
01) Press the MENU button until the display shows .
02) Repeatedly press the ENTER button to toggle between the 2 screens displaying the software version.
The currently installed software version is .
13. Factory Reset
In this menu you can reset the pan to home position.
01) Press the MENU button until the display shows .
02) Press the ENTER button to reset the pan.

18
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
DMX Channels
1 channel
Channel 1 –Horizontal movement (Pan)
Move the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0–255, 127-center).
The head can be turned by 120° and stopped at any position you wish.
2 channels
Channel 1 –Horizontal movement (Pan) CH2 must be set between 0–15
Move the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0–255, 127-center).
The head can be turned by 120° and stopped at any position you wish.
Channel 2 –Built-in programs
0–15
Manual pan
16–31
Pan 60°, Speed 1
32–47
Pan 60°, Speed 2
48–63
Pan 60°, Speed 3
64–79
Pan 60°, Speed 4
80–95
Pan 60°, Speed 5
96–111
Pan 90°, Speed 1
112–127
Pan 90°, Speed 2
128–143
Pan 90°, Speed 3
144–159
Pan 90°, Speed 4
160–175
Pan 90°, Speed 5
176–191
Pan 120°, Speed 1
192–207
Pan 120°, Speed 2
208–223
Pan 120°, Speed 3
224–239
Pan 120°, Speed 4
240–255
Pan 120°, Speed 5

19
Ordercode: 80378P
Antari PM-1 Pan Motor for S-500
Maintenance
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and
must not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
04) The electric power supply cables must not show any damages or material fatigue.
The PM-1 requires almost no maintenance. However, you should keep the unit clean. Disconnect the
mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use
alcohol or solvents.
Keep connections clean. Disconnect electric power, and then wipe the DMX connections with a damp
cloth. Make sure connections are thoroughly dry before linking equipment or supplying electric power.
Replacing the Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out. If the
fuse burns out, the product will not function whatsoever. If this happens, follow the directions below.
01) Unplug the unit from electric power source.
02) Insert a screwdriver into the slot in the fuse cover. Gently pry up the fuse cover. The fuse will come
out.
03) Remove the used fuse. If brown or unclear, it is burned out.
04) Insert the replacement fuse into the holder where the old fuse was. Reinsert the fuse cover. Be sure to
use a fuse of the same type and specification. See the product specification label for details.
Troubleshooting
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit
operates properly, do not carry out following steps.
If the device does not operate properly, refer servicing to a technician.
Suspect two potential problem areas as: the power supply and the fuse.
01) Power supply. Check if the unit is plugged into an appropriate power supply.
02) The fuse. Replace the fuse. See page 19 for replacing the fuse.
03) If all of the above appears to be O.K., plug the unit in again.
04) If you are unable to determine the cause of the problem, do not open the PM-1, as this may
damage the unit and the warranty will become void.
05) Return the device to your Antari dealer.
