Light Emotion FLAT0505R Operator's manual

www.lightemotion.com.au
FLAT0505R
Flat 5x5W 4-in-1 RGBW Wash Fixture with IR Remote
User’s instruction manual
This manual contains important information about the safe installation and use of this product
Please read this instruction manual carefully before installing or operating
Please keep these instructions in a safe place for future reference
V1.01

1
Contents
1. Safety Instructions 2
2. Installation 3
3. Features 3
4. Operation 4
Menu Functions 4
Explanations 5
DMX and DMX Tables 6
5. IR Remote Control 8
6. DMX Connections 9
7. DMX Address Setting 10
8. DMX Terminator 10
9. Cleaning and Maintenance 10
10. Technical Data 11
11. Warranty 11

2
Introduction
Thank you for the purchase of your FLAT0505 5x5W 4-in-1 RGBW Wash Fixture by Light Emotion. We are
confident you will be satisfied with your purchase and enjoy many years of use from this Professional Light
Emotion product. Please read these instructions carefully to ensure the product is well look after and used correctly
to avoid any potential problems.
Please note that as part of our ongoing commitment to continuous improvement and product development, the
specifications in this manual are subject to change without notice. Whilst every care has been taken in the
preparation of this manual we reserve the right to change specifications in the course of product improvement.
What is in the box:
- 1 x FLAT0505 fixture
- Power cable
- IR remote control
- This user manual
1. Safety Instructions:
Please read these instructions carefully. It includes important information about the installation usage and
maintenance of this product.
- Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also
receive this instruction booklet.
- Always make sure that you are connecting to the proper voltage and that the line voltage you are connecting to is
not higher than that stated on the sticker of the fixture.
- This product is intended for indoor use only. To prevent risk of fire or shock, do not expose fixture to rain or
moisture.
- Make sure there are no flammable materials close to the unit while operating.
- The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surface. Be sure that
no ventilation slots are blocked.
- Always disconnect from power source before servicing.
- Secure fixture to stands, trussing and the like using a safety chain.
- Maximum ambient temperature is 40˚C. Do not operate fixture at temperatures higher than this.
- In the event of serious operating problem, stop using the unit immediately. Never try to repair the unit by yourself.
Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized
technical assistance centre.
- Make sure power cord is never crimped or damaged.
- Never disconnect power cord by pulling or tugging on the cord.
- Never carry the fixture directly from the cord. Carry by holding the unit directly or via the hanging bracket.
- Avoid direct eye exposure to the light source while it is on.

3
2. Installation:
Caution: For safe mounting of this product, please read the following carefully.
- Use a suitable clamp to attach to lighting stand, trussing or bar, together with safety chain.
- When mounting the product, do not stand directly underneath the product
- Always use a safety chain when mounting the product on stands, trussing or bars. Make sure the breaking strain
rating of the chain is at least 10 times the weight of the product.
- Make sure there is adequate ventilation around the product.
- Never look directly into the LED light or laser sources of the product.
- For indoor use only – do not use outdoors.
- To avoid electrical shock, keep away from rain and moisture.
3. Features
This product is designed as entertainment effect lighting fixture and is only intended to be used as an effect for
entertainment and production applications. Due to our ongoing commitment to constantly reviewing and improving
products, features and specifications are subject to change without prior notice.
It features 5 x 5W 4-in-1 LEDs which have red, green, blue and white built into each LED lens. Being 4-in-1, the
user has complete control over colours which emit from the one lens reducing any possibility of colour ghosting that
can occur with fixtures that use individual red, green and blue LEDs, and can also do pure white.
- Power input: AC 90V-240V/50HZ-60HZ
- Wattage: 28W
- LEDs: 5 pcs 5W (RGBW 4 in 1)
- Beam angle of LEDs: 40 degree
- 3-pin female XLR socket and 3-pin male XLR socket
- Built-in microphone
- Four button LED digit display
- Fuse: M205 1A slow blow
- Maximum 12 fixtures can be daisy chained together for power (DMX technically unlimited)
- Weight: 2.8 kg
- Size: 240x110x265mm

4
4. Operation.
The FLAT0505 has eight kinds of operation mode, they are as follows:
Static color select mode, Manual dimmer color mode, Colour jumping mode, Colour
dreaming mode, Auto-run program mode, Sound active mode, Slave mode, DMX mode
Here above eight kinds running mode are selected by MODE button. Press MODE and UP button
at the same time, when it is on, you can initialize it at extra factory setting, running on the auto-run
program mode.
Press the MODE and down buttons at the same time to select LED digital display on/off .When the
display shows means that the display will stay on all the time, when the display
shows means that the display will turn off after 20 seconds.
MODE
manual
SET UP
manual
UP/DOWN manual instruction
STATIC
COLOR
SELECT
MODE
Color select ~ Select the 15 static colors
Flash ~ Adjust the auto run flash speed, is
flash off, is slowest, is fastest
DIMMER
MODE
White dimmer ~ Adjust the intensity of the white color
Red dimmer ~ Adjust the intensity of the red color
Green dimmer ~ Adjust the intensity of the green color
Blue dimmer ~ Adjust the intensity of the blue color
Flash ~ Adjust the flash speed, is flash
off, is slowest, is fastest
COLOR
JUMPING
MODE
Jumping speed
set
~ Adjust the speed of color jumping
mode, is slowest, is fastest
Flash ~ Adjust the color jumping flash speed,
is flash off, is slowest, is fastest
COLOR
DREAMING
MODE
Dreaming
speed set
~ Adjust the speed of color dreaming
mode, is slowest, is fastest
Flash ~ Adjust the color dreaming flash speed,
is flash off, is slowest, is fastest
AUTO
RUN
MODE
Auto run mode
set
Set the unit into auto run mode
Flash ~ Adjust the auto run flash speed, is
flash off, is slowest, is fastest
SOUND
MODE
Sensitivity
select
~ Adjust the sensitivity of the sound-
active,
is sound-active off, is the
lowest level, is the highest level
Slave mode Slave mode Set the unit into slave mode
DMX MODE Address set ~ Sets the DMX starting address

5
A. Static color select mode
Press "MODE" button, select the static color select mode. There are two modes in the static color
select mode. You can select them by pressing the "SET UP" button.
1) Static color select
Press "SET UP" button until the four digital tube displays" ~ ",then press "UP" or
"DOWN" to select static color 0-15 under this mode.
2) Flash speed select
Press "SET UP" button until the four digital tube displays" ~ ",then press "UP" or
"DOWN" button to select the static colour flash speed 00-99 ,00 is flash off,01 is the slowest flash
speed,99 is the fastest flash speed.
B. Manual dimmer colour mode
1) Manual dimmer colour select
Press "MODE" button, select the manual dimmer colour select mode .At this time, the four digital
tube displays white " ~ ", press the "SET UP" to choose different colour, red
" ~ ", green " ~ ", blue " ~ ", then press "UP" or
"DOWN" button to set the dimming rate 0-255.
2) Flash speed select
Press "SET UP" button until the four digital tube displays " ~ ", then press "UP" or
"DOWN" button to select colour dimmer flash speed 00-99, 00 is flash off, 01 is the slowest flash
speed, 99 is the fastest flash speed.
C. Colour jumping mode
Press "MODE" button, select the color jumping mode. There are two modes in the color jumping
mode. You can select them by pressing the "SET UP" button.
1) Colour jumping speed set
Press "SET UP" button until the four digital tube displays" ~ ". Press "UP" or
"DOWN" button to select the color jumping speed 01-99, 01 is the slowest speed, 99 is the fastest
speed.
2) Flash speed select
Press "SET UP" button until the four digital tube displays " ~ ",then press "UP" or
"DOWN" button to select the color jumping flash speed 00-99, 00 is flash off,01 is the slowest
flash speed, 99 is the fastest flash speed.
D. Colour dreaming (fading) mode
Press "MODE" button, select the colour dreaming mode. There are two modes in the colour
dreaming mode. You can select them by pressing the "SET UP" button.
1) Colour dreaming speed set

6
Press "SET UP" button until the four digital tube displays " ~ ". Press "UP" or
"DOWN" button to select the color dreaming speed 01-99 ,01 is the slowest speed, 99 is the fastest
speed.
2) Flash speed select
Press "SET UP" button until the four digital tube displays " ~ ",then press "UP" or
"DOWN" button to select the color dreaming flash speed 00-99 ,00 is flash off, 01 is the slowest
flash speed, 99 is the fastest flash speed.
E. Auto-run program mode
Press "MODE" button, select the auto-run program mode. There are two modes in the auto-run
program mode. You can select them by pressing the "SET UP" button.
1) Colour dreaming program mode select
Press "SET UP" button until the four digital tube displays " ", the unit runs into the auto
run program mode, the colour jumping program and color dreaming program run alternatively.
Press UP or DOWN is no use under this mode. Running speed is the current speed of color jumping
program and colour dreaming program.
2) Flash speed select
Press "SET UP" button until the four digital tube displays " ~ ", then press "UP" or
"DOWN" button to select the auto run program flash speed 00-99,00 is flash off, 01 is the slowest
flash speed, 99 is the fastest flash speed.
F. Sound active mode
Press "MODE" button, select the sound active program mode, the four digital tube displays
" ~ ", then press "UP" or "DOWN" to select the sound active the sensitivity 0-31. 0
is off sound-active, 01 is the lowest sensitivity, 31 is the highest sensitivity.
G. Slave mode
Press "MODE" button, select salve mode, the four digital tube displays " ". The unit will be
controlled by the master unit now.
H. DMX mode
Press “ MODE ” button until the display is “ ~ ” , then press UP or DOWN to set
the DMX address 001-512.

7
DMX MODE: 7 DMX channels
CH7 CH6 CH5 CH4 CH3 CH2 CH1
MODE DMX VALUE FUNCTION
1 0-13 No function
0-10=No use
11-255=Flash
(slow→fast)
Dimming
0-255
(dim→
bright)
White
0-255
(dim→
bright)
Blue
0-255
(dim→
bright)
Green
0-255
(dim→
bright)
Red
0-255
(dim→
bright)
2 14-26 Red
No function
No function
No function
No function
3 27-38 Green
4 39-51 Blue
5 52-64 White
6 65-76 R+G
7 77-89 R+B
8 90-102 R+W
9 103-114 G+B
10 115-127 G+W
11 128-140 B+W
12 141-152 R+G+B
13 153-165 R+G+W
14 166-178 R+B+W
15 179-190 G+B+W
16 191-204 R+G+B+W
17 205-217 Color change
Speed
0-255
(slow→
fast)
18 218-230
Color dreaming
19 231-242 Auto run
20 243-255 Sound active
Sensitivity
8-255
(insensitive→
sensitive)
No function
Note: R---red G---green B---blue W---white

8
5.
Operation by IR remote :
You can also operate this product by IR remote, the distance available is at most 10m.
Notice:IR remote can also be used when the unit is in the DMX mode.
The picture of the IR remote:
AUTO RUN mode
Press AUTO RUN button to choose Auto run mode. Press FLASH to turn on the flash of the Auto
Run and then press “+” and “-“ buttons to adjust flash speed. You can also put in two numbers
00-99 to adjust flash speed, 00 is to turn off flash, 01 is the slowest speed, 99 is the fastest speed.
Select program Mode
Press PROG to cycle among the built-in programs, it contains static colour select mode, colour
jumping mode and color dreaming mode. Each press of this button will change to the next mode.
1. When the flat par goes into the static color mode, press “+” and “-” or put in two numbers 00-15
to select the 15 static colours. You can press FLASH to turn on flash and press “+” and “-” or put in
two numbers 00-99 to adjust the flash speed, 00 is to turn off flash, 01 is the slowest speed, 99 is
the fastest speed.
2. When the flat par goes into color jumping mode or color dreaming mode, press “+”and “-” or put
in two numbers 01-99 to adjust the program speed, 01 is slowest, 99 is the fastest. You can press
FLASH to turn on flash and press “+” and “-” or put in two numbers 00-99 to adjust the flash speed,
00 is to turn off flash, 01 is the slowest speed, 99 is the fastest speed.
Sound Active Mode
Press SA to display sound active mode, press “+” and “-” or put in two numbers 00-31 to adjust the
sound active sensitivity level. 00 is sound active off, 01 is the lowest level, 31 is the highest level.
M/S mode
Press SL to display slave mode.

9
Select light program mode
Press R/G/B to choose the three different colours, and "0" is to choose the white colour, then press
“+” and “-” or put in three numbers 000-255 to adjust the intensity of the light. You can press
FLASH to turn on flash and press “+”and “-” or put in two numbers 00-99 to adjust the flash speed,
00 is to turn off flash, 01 is the slowest speed, 99 is the fastest speed.
DMX MODE
Press D to display DMX mode.
Set ADDR
Press this button to set the DMX address or initialize the program, then the red, green, blue and
white lights will flash 2~3 times. Please put in 3 number, for example, 1 2 3. After the red light is
on, please put in the first number. After the first number is accessed the green light will be on, then
put in the second number. When the blue light will be on, please put in the third number. After all
the three number are put in, the red, green and blue lights will flash 2~3 times, which indicate that
the DMX address is right and it go in to the DMX MODE automatically. If the address is wrong the
red light will be on. New DMX address should be put in.
If the 951 are put in, red and green lights will be on. Put “0” to initialize the program. If the wrong
address is put in, the red light will be on, indicating new address should be put in. Then the system
will run in the auto run mode.
Black Out mode
Press “BLACK OUT” to set the LED lights power on or power off by pressing this button.
6. DMX-512 Control Connection
Using a 3 pin XLR cable, you can connect the product to a DMX controller and then to other fixtures
with 3 pin XLR inputs and outputs. When not using DMX, multiple fixtures can be connected together
and operate under master/slave control. The signal cable should have two core with shielded cable, the
signal connectors are XLR input and output connectors. Please refer to the below diagram:

10
7. DMX Address Setting
When being used in conjunction with a DMX controller, each fixture must be set a specific starting
address. When receiving signal, fixture will receive channel control signals of this address from the
DMX controller.
For simplicity, the user can use the same address for multiple fixtures but this will result in each fixture
providing exactly the same output and fixtures with the same DMX address cannot be individually
controlled.
To control each fixture individually via DMX, each fixture must have its own unique DMX address. If
this fixture is in 7 channel DMX mode then each address must be 7 channels apart. For example, if the
first unit is on DMX channel 1, the 2
nd
must be on DMX channel 8, the 3
rd
on channel 15 and so on.
Some DMX controllers may group fixtures in lots of 16 channels – so in that case, fixture 1 on channel 1,
fixture 2 on channel 17, 3 on 33, and so on. Refer to your DMX controllers’ instruction manual on how
best to manage your DMX channel allocation.
8. DMX-512 connection with DMX terminator
A DMX terminator helps to reduce ‘noise’ on the DMX chain, and makes the light respond to control
more accurately. It should be plugged in to the last fixture in any chain. For Terminator connections
please see below:
9. Cleaning and Maintenance
From time to time it is recommended the product is cleaned to ensure maximum light output and
performance. Use a wet cloth to clean the housing as well as the lenses. Please note that alcohol based
cleaners and solvents cannot be used as they will cause damage to the product.
When used in a fixed long term installation such as a venue or club, the unit should be periodically taken
down from the installation and professionally cleaned. Dust build-up within the unit can cause damage
and ultimately failure of components.

11
10. Technical Data
- Power input: AC 90V-240V/50HZ-60HZ
- Wattage: 28W
- LEDs: 5 pcs 5W (RGBW 4 in 1)
- Beam angle of LEDs: 40 degree
- 3-pin female XLR socket and 3-pin male XLR socket
- Built-in microphone
- Four button LED digit display
- Fuse: M205 1A slow blow
- Maximum 12 fixtures can be daisy chained together for power (DMX technically unlimited)
- Weight: 2.8 kg
- Size: 240x110x265mm
11. Warranty
This product is warranted for 2 years from your purchase date. We are confident that this product will
give many years of trouble-free operation but should an unlikely problem arise, warranty claims must be
via the original place of purchase, together with the original purchase receipt. Please keep both your
original purchase receipt and this instruction manual together and in a safe place for future reference.
Should the product be sold within the warranty period, be sure to pass on both to the new purchaser so
they are able to claim warranty should they need to. We recommend you register your warranty online at
www.industrygear.com.au.
Purchased from:_________________________________________
Contact Details:_________________________________________
Date Purchased:_________________________________________
Invoice/Receipt Number:__________________________________
Copyright Light Emotion 2017. E&OE
Exclusively imported by LSW Imports and Distribution
PO Box 887, Kingsgrove, NSW, 2208
[email protected]
www.lightemotion.com.au
1800 643 111 (within Australia)
[phone] (outside of Australia)
