Lightolier Edge User manual

Lightolier is a Philips group brand
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • B1208
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Task Lighting Edge
Page 1 of 1 LED Task Light
Features
Lamp: 8x1w LEDs (4800K). LEDs included.
Electrical: Wired for 120V 60Hz operation.
Transformer: In-line 370 ma transformer with quick connect cord. Primary input:
120V. Secondary output: 12V.
Power Cord: Quick connect. Minimum 6ft (182mm) long.
Arm: Formed steel, 34" spring-balanced double arm and 17" single arm versions
are available.
Shade: Heavy-duty cast aluminum shade with internal reflector and
prismatic lens.
Finish: Matte black or silver enamel.
Listing: UL/cUL listed.
2 1/4" (57mm)
5 1/2" (140mm)
8 3/8" (213mm)
17" (432mm) 17" (432mm) 17" (432mm)
Series Lamps Arm Color Mounting
EG = Edge L = LED 8x1w S = 17" Single Arm B = Black E = Edge Clamp
L = 34" Double Arm S= Silver P = Panel Bracket
S = Slat Wall Bracket
T = Table Base
Z = Zero Clearance
Bracket
EG L
Example = EGL–SBE
Ordering Information
Edge Clamp (E):
Clamps onto edge
of desk or table.
Table Base Heavy (T):
9" diameter weighted base for
desktop use.
Panel Bracket (P):
Attaches to 1" slotted panel
standard. Consult factory for
furniture compatibility.
Slat Wall Bracket (S):
Attaches to many furniture slat
wall systems. Consult factory for
furniture compatibility.
Zero Clearance Bracket (Z):
Two-piece edge clamp for tight
spaces. Clamps onto edge of desk
or table.
Mounting Options
