Lightolier PTS7-2 User manual

"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lighting Systems PTS7-2
1BHFPG 1FSJNFUFS5SPVHI3FDFTTFE%JSFDU-PVWFS-JHIU51FS'PPU4FDUJPO
$
Quarter Scale
6
5
1
2
4
3
Complete ordering instructions on back.
135° Outside
PTS7C1350 Standard
PTS7C1350A Air
8 -1/2” (245.11cm)
135° Inside
PTS7C1351 Standard
PTS7C1351A Air
90° Outside
PTS7C900 Standard
PTS7C900A Air
90° Inside
PTS7C901 Standard
PTS7C901A Air
End Cap Set
PTS7EP Standard
PTS7EPA Air
14” (35.56cm)
Features
1.
2. Lamping: Two T8 fluorescent lamps, as specified. Provided by others.
3. Reflector: Die-formed semi-specular aluminum.
4. Louver: Semi-specular anodized aluminum, 40° lengthwise by 30° minimum
crosswise shielding. Supported along both edges by concealed frame of
extruded aluminum. Bold baffle, prismatic lens, gold anodized louver, open or
egg crate louver available, consult factory.
5. Socket Channels: Die-formed, pre-painted steel held by support brackets and
allows for up to 6” (15.24cm) lamp overlap.
6.
Electrical
Specify 120 volt or 277 volt. 3 conductor, 18 gauge wire. Color-coded quick
connectors allow ease of connection for joiner modules. For special circuiting,
consult factory. Factory installed ballast disconnect allows the ballast to be
disconnected fromand reconnected to incoming power under load without turning
the entire circuit off.
Dimming: Advance Mark X, use Advance compatible two-wire control (no extra
control lead required).
Mountings
Wall Adjustment Bracket - Allows for inconsistencies in wall straightness.
Die-formed steel used to mount systemto the wall.
Finish
Ceiling trimpainted baked enamel semi-gloss white.
Options and Accessories
90° inside, 90° outside, 135° inside, and 135° outside corerns available.
Labels
UL, cUL and I.B.E.W.
11-1/4” (28.58cm)
7 -1/16”
(19.94cm)
1-5/16” (3.33cm)
8-1/4” (20.96cm)
1-1/2”
(3.81cm)
4-3/4” (12.07cm)
Housing: Die-formed steel, slotted for air return. Integral flanges at each end
strengthen the housing and permit housings to be bolted together in continuous
runs and facilitate suspension of fixture. Concealed openings for heat extraction
and air return.
Ceiling Trim: Extruded aluminumwith integral aligner splines.
End Plate and Corner Block Accessories

Job Information Type:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt
Lighting Systems PTS7-2
1BHFPG 1FSJNFUFS5SPVHI3FDFTTFE%JSFDU-PVWFS-JHIU51FS'PPU4FDUJPO
$
Performance
TWO
Cat No. PTS7T242 PTS7T254 PTS7296 PTS7248 PTS7236 PTS7224
Size 27" to 42" 39" to 54" 96" 48" 36" 24"
Lamps 2-2 Foot 2-3 Foot 4-4 Foot 2-4 Foot 2-3 Foot 2-2 Foot
Type Tele Tele Module Module Module Module
2'3"-3'6" 1
3'3"-4'6" 1
4'3"-5'6" 1 1
5'3"-6'6" 1 1
6'3"-7'6" 1 1
7'3"-8'6" 1 1
8'3"-9'6" 1 1 1
9'3"-10'6" 1 2
10'3"-11'6" 1 1 1
11'3"-12'6" 1 1
12'3"-13'6" 1 1 1 1
13'3"-14'6" 1 1 1
14'3"-15'6" 1 1 1
15'3"-16'6" 1 1 1
16'3"-17'6" 1 1 1 1
17'3"-18'6" 1 1 2
18'3"-19'6" 1 1 1 1
19'3"-20'6" 1 2
20'3"-21'6" 1 1 1 1 1
21'3"-22'6" 1 2 1
22'3"-23'6" 1 2 1
23'3"-24'6" 1 2 1
24'3"-25'6" 1 2 1 1
25'3"-26'6" 1 2 2
26'3"-27'6" 1 2 1 1
27'3"-28'6" 1 3
28'3"-29'6" 1 2 1 1 1
29'3"-30'6" 1 3 1
30'3"-31'6" 1 3 1
31'3"-32'6" 1 3 1
32'3"-33'6" 1 3 1 1
33'3"-34'6" 1 3 2
34'3"-35'6" 1 3 1 1
35'3"-36'6" 1 4
36'3"-37'6" 1 3 1 1 1
37'3"-38'6" 1 4 1
38'3"-39'6" 1 4 1
39'3"-40'6" 1 4 1
40'3"-41'6" 1 4 1 1
41'3"-42'6" 1 4 2
42'3"-43'6" 1 4 1 1
43'3"-44'6" 1 5
44'3"-45'6" 1 4 1 1 1
45'3"-46'6" 1 5 1
46'3"-47'6" 1 5 1
47'3"-48'6" 1 5 1
48'3"-49'6" 1 5 1 1
49'3"-50'6" 1 5 2
50'3"-51'6" 1 5 1 1
Quick Calculators
85˚
75˚
65˚
45˚
55˚
0˚ 5˚ 15˚ 25˚ 35˚
1000
1250
750
1500
1750
500
CANDLEPOWER CURVE
REPORT NO: LRL 499-5E
LAMPS: 2-32WT8
LUMENS: 2900
EFFICIENCY: 45.6%
Ordering Information
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50
% WALL REFLECTANCE
50 30 10 50 30 10 50 30 10
0545454 53 5353 515151
1494746 48 4645 464544
2444139 43 4139 413938
3393634 39 3634 373533
4363229 35 3229 343129
5322826 31 2825 302725
6292523 29 2522 282522
7262320 26 2220 252220
8242018 23 2017 232017
9211815 21 1815 211715
10 20 16 14 19 16 14 19 16 14
CANDLEPOWER SUMMARY
ZONE
Deg
0 45 90 135 180
180 00000
175 00000
165 00000
155 00000
145 00000
135 00000
125 00000
115 00000
105 00000
95 00000
90 00000
85 94 37 5 2 2
75 483 132 10 7 7
65 894 298 28 17 21
55 1178 748 168 68 32
45 1387 1118 544 133 65
35 1586 1365 882 206 114
25 1679 1553 1117 502 223
15 1721 1617 1279 851 658
5 1547 1495 1369 1231 1171
0 1382 1382 1382 1382 1382
ONE SIDE MOUNTING
NO OPPOSITE WALL
1.5 112
2.5 57
3.5 38
4.5 30 138 100 65 46 36 30
5.5 26
6.5 24
7.5 23 88 84 69 55 45 38
8.5 22
9.5 21 68 70 62 53 45 39
024681012
DISTANCE FROM WALL, FEET
TWO SIDE MOUNTING
12 FT BETWEEN WALLS
1.5 142 142
2.5 92 92
3.5 77 77
4.5 72 170 144 129 144 170 72
5.5 69 69
6.5 67 67
7.5 65 130 135 134 135 130 65
8.5 63 63
9.5 60 115 124 125 124 115 60
024681012
DISTANCE FROM WALL, FEET
ONE SIDE MOUNTING
6 FT BETWEEN WALLS
1.5 135 78
2.5 80 88
3.5 61 88
4.5 53 155 124 85
5.5 48 78
6.5 45 71
7.5 42 106 104 64
8.5 39 58
9.536878953
0246
DISTANCE FROM WALL, FEET
HORIZONTAL FC
VERTICAL FC
DISTANCE FROM CEILING, FT
0 deg
90 deg
180
deg
0 deg
90 deg
180
deg
NOTE: Add to end of catalog number for desired ballast.
E81 = T8 Electronic 120v
E82 = T8 Electronic 227v
M71 = T8 Electronic Dimming Ballast 120v
M72 = T8 Electronic Dimming Ballast 277v
Ordering Instructions
Individual Fixtures:
1. Order number of FIXTURES.
2. Order one END PLATE SET per fixture.
Continuous Rows:
1. Determine run length.
2. Use chart above to find catalog numbers. Each run ends with a telescoping unit.
3. Order END PLATE SET for each open run.
Square/Rectangle Patterns:
1. Consult plans and mark locations for corners.
2. Calculate net footage of each run.
3. Deduct corner dimension fromeach corner.
4. Determine catalog numbers the same way as a straight run.
ZONAL LUMEN SUMMARY
ZONE LUMENS % BARELAMP % LUMINAIRE
0-90 2644 45.6 100.0
90-180 0 0.0 0.0
0-180 2644 45.6 100.0
ROOM CAVITY RATIO
LIGHT
