Lightolier Calculite Compact Fluorescent Downlights User manual

Instruction Sheet Number IS:8031
Page 1 of 2 Installation of Calculite®Compact Fluorescent Downlights and Wall Washer Reflector Trims
Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • B0306
Read and understand these instructions before installing fixture.
This fixture is intended for installation in accordance with the National Electrical Code and local regulations. To assure full compliance with local codes and
regulations, check with your local electrical inspector before installation. To prevent electrical shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
Warranty information on back – retain this sheet.
REFLECTOR OR LENS TRIM
1.GIF 2.GIF
Reflector or
Lens Trim
White
Trim
Ring
FIG. 4
FIG. 3
White
Trim
Ring
INSTALLATION OF LENS WALL WASHER
AND OPEN WALL WASHER
required.
REFLECTOR OR LENS TRIM
A. INSTALL WHITE TRIM RING (FIG. 1, 2, 3 & 4)
NOTE: Omit this section if reflector is self-flanged.
1. For overlapping trim installation (Fig 1) slip White Trim Ring
over Reflector, as shown in Fig 2 & 3.
2. For flangless trim installation (Fig 4), White Trim Ring is not required.
B. SNAP-IN (FIG. 5)
Engage Retaining Spring into Slots in Reflector (see FIG. 5)
following chart below. See Frame-in kit for lamp information.
C. PUSH-UP REFLECTOR (FIG. 6 & 7)
Tilt Reflector and insert Socket Cup into ceiling opening on side
opposite Junction Box. Pivot Reflector and push it up into
ceiling (FIG 6).
NOTE: To remove Reflector, disengage the Socket Cup by
depressing the Retaining Spring (FIG. 5). Turn Reflector
counterclockwise while pulling downward. After starting,
use both hands to remove, see FIG 7.
D. LAMPING (FIG. 8)
NOTE: See Socket Cup Label for lamping information.
Line up Lamp Pins with Socket, tilt lamp base to engage, then bring
lamp to horizontal position and push into Socket (FIG. 8). To relamp,
CAREFULLY PULL STRAIGHT OUT OF SOCKET WITH ONE FINGER
PLACED ON THE TOP OF THE LAMP.
CARE AND MAINTENANCE OF ALZAK REFLECTOR
If you must handle the anodized or Alzak reflectors, we recommend using
clean white or plastic film gloves to avoid fingerprints.
Anodized or Alzak surfaces can be cleaned by the following methods:
1. Wipe off with a soft, clean, dry, lint-free cloth.
2. Wipe off with a soft clean cloth dampened in mild detergent.
3. Wipe off with a clean cloth dampened with a solution of wetting
agent and water (such as 2 oz. per gallon “Pluronic L62-LF” by
Wyandotte Products); then wipe dry.
4. Or use a liquid wash such as Glass Wax®. Avoid gritty cleaning agents.
Socket
Cup
Reflector
Junction
Box
To Remove
FIG. 8
FIG. 5
Reflector
Retaining Spring
Socket Cup
Slot
Fig. 1 Fig. 2
Fig. 3 Fig. 4
Fig. 5
Fig. 6 Fig. 7
Fig. 8

Instruction Sheet Number IS:8031
Page 2 of 2 Installation of Calculite®Compact Fluorescent Downlights and Wall Washer Reflector Trims
Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • B0306
Wall to be Illuminated
Lens Wall Washer
Junction Box
(positioned away
from wall)
Open Wall Washer
FIG. 9A
Wall to be Illuminated
Junction Box
(positioned away
from wall)
Retaining Spring
Removed
FIG. 10AFIG. 10
Junction
Box
Mounting
Frame
Fig. 9
Fig. 9A
Lensed Wall Washer
Junction Box
(Positioned Away
From Wall)
Open Wall Washer
Fig. 10 Fig. 10A
Mounting
Frame
Junction
Box
Retaining Spring
Removed
Junction Box
(Positioned Away
From Wall)
Junction Box
(positioned away
from wall)
Lens Trim
w/ Torsiontite
Spring
Wall to be Illuminated
Leave approx.
1" exposed
Socket Cup
Slot
Reflector
Fig. 11
Junction Box
(Positioned Away
From Wall)
FIG. 12
Fig. 12
INSTALLATION OF LENS WALL WASHER AND OPEN
WALL WASHER
Note: Before installing Reflector, make sure the Mounting Frame is
installed with the Junction Box away from the wall to be illuminated
(FIG. 9 & 9A).
FOR OPEN WALL WASHER (6132 Series Only)
1. Remove two Retaining Springs that are near the Junction Box
from the Mounting Frame (FIG 10).
2. Insert two new Retaining Springs (that are provided with the
reflector trim) into pockets on the Mounting Frame (FIG. 10A).
3. Squeeze Retaining Spring into position with pliers (FIG. 10A)
FOR OPEN WALL WASHER (N/S 6132 Series)
1. By hand, bend the 2 retaining springs that are near the junction box
as far back as possible pushing toward J Box.
A. INSTALL WHITE TRIM RING (FIG. 1, 2, 3 & 4)
NOTE: Omit this section if reflector is self-flanged.
1. For overlapping trim installation (FIG. 1) slip White Trim Ring
over Reflector, as shown in Fig 2 & 3.
2. For flangless trim installation (FIG. 4), White Trim Ring is
not required.
B. SNAP-IN (FIG. 5)
Engage Retaining Spring into Slots in Reflector (see FIG. 5) following
chart below. See Frame-in kit for lamp information.
C. PUSH-UP REFLECTOR (N/S 6132 Series)
1. Tilt Reflector so only (1) Retaining Spring (retaining spring closest to
junction box) touches the Kick Reflector. Push reflector up to clear larger
portion of Kick Reflector past the retaining springs and twist into positon.
LENS WALL WASHER
1. Tilt Reflector and insert Socket Cup into ceiling opening on side
opposite Junction Box. Push Reflector up leaving approximately one
inch of the Reflector exposed below the Ceiling Line (FIG. 11).
2. Compress Torsiontite Springs on Lens Trim by squeezing with
fingers. Insert into Slots in Reflector and push up until flush with
ceiling (FIG. 11).
NOTE: To remove Reflector, lift Lens and pull Lens Trim down
(FIG. 12). Disengage the Socket Cup by depressing the Retaining
Spring (FIG. 5). Turn Reflector counterclockwise while pulling
downward. After starting, use both hands to remove (FIG. 7)
OPEN WALL WASHER
1. Tilt Reflector and insert Socket Cup into ceiling opening on side
opposite Junction Box. Pivot Reflector and push it up into ceiling
(FIG 6).
NOTE: To remove Reflector, disengage the Socket Cup by depressing
the Retaining Spring (FIG. 5). Turn Reflector counterclockwise while
pulling downward. After starting, use both hands to remove, see FIG 7.
D. LAMPING (FIG. 8)
NOTE: See Socket Cup Label for lamping information.
Line up Lamp Pins with Socket, tilt lamp base to engage, then bring
Lamp to horizontal position and push into Socket (FIG. 8). To relamp,
CAREFULLY PULL STRAIGHT OUT OF SOCKET WITH ONE FINGER
PLACED ON THE TOP OF THE LAMP.
CARE AND MAINTENANCE OF ALZAK REFLECTOR
See page. 1
