Lighting Systems LSB-9
1BHFPG -ZUFTQSFBEÜ-4#1BSBCPMJD-PVWFS-JHIU51FS'PPU/PNJOBM4FDUJPO
#
Features
1. Housing: Extruded aluminum. Die-cast end cap mechanically attached with
no exposed fasteners or hardware.
2. Lamping: One T5, 28 or 54 watt (as specified) fluorescent lamp per 4-foot
nominal section. Provided by others.
3. Reflector: Precision die-formed semi-specular aluminum.
Electrical
Ballast is <10% THD, .98 ballast factor, pre-heat start. 18 gauge wire. Color-
coded quick connectors allow ease of connection for joiner modules. Power feed
is 18 gauge white SJT. For special circuiting consult factory. Factory installed
ballast disconnect allows the ballast to be disconnected fromand reconnected to
incoming power under load without turning the entire circuit off.
Dimming: 120/277 VAC 1% dimming level, 4 wire feed required.
Emergency Battery Pack: 28 watt: 520 lumens @ 90 minutes, 54 watt: 700
lumens @ 90 minutes, 4 wire feed required.
Mountings
Finish
Powder coated baked white or aluminumfinish. Customcolors available, consult
factory.
Labels
UL, cUL and I.B.E.W.
Ordering Instructions
Individual Fixtures:
1. Order number of MODULES required.
2. Order one POWER FEED END SET per MODULE.
Continuous Rows:
1. Determine run length.
2. Order the appropriate number of MODULES for the complete run.
3. Order one POWER FEED END SET per run.
4. Order one CABLE ASSEMBLY per MODULE minus one per run.
5. For runs that exceed amperage limits, order the appropriate number of
CABLE/CORD ASSEMBLIES.
Options and Accessories
Emergency Circuiting; special circuiting; X, T & L joiner blocks - consult factory.
Complete ordering instructions below.
Cable suspension (not shown) - 4-1/2" (11.43cm) diameter canopy finished white
enamel, 1/16" (0.16cm) diameter stainless steel aircraft cable adjustable up to 36"
(91.44cm). Dual-screw draw-tight connector to create hairline seambetween joiner
modules.
Ordering Information
Family Lamps Voltage Finish
1= 1-Lamp T5 C= Parabolic Louver AL = Aluminum
WH = White
LSB 1 C
Length Shielding Ballast
1 = 120 volt
2 = 277 volt
28 = 28W T5
54 = 54W T5
5E = 54W T5 Emergency Pack
2E = 28W T5 Emergency Pack
5D = 54W T5 Dimming
4. Louver: Parabolic louver, low-iridescent semi-specular anodized aluminum, 41°
shielding lengthwise, blades are 1-1/3” (3.39cm) high and 2” (5.08cm) O.C.
Louver frame is extruded aluminumand finished to match housing.
4= 4-Foot
8= 8-Foot
3-1/2" (8.89cm)
13 4Fixture Shown Half Scale
2
8-1/2” (21.59cm)
1-3/4" (4.45cm)

Job Information Type:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt
Lighting Systems LSB-9
1BHFPG -ZUFTQSFBEÜ-4#1BSBCPMJD-PVWFS-JHIU51FS'PPU/PNJOBM4FDUJPO
#
Performance
CANDLEPOWER CURVE CANDLEPOWER
ZONE 0 22 45 67 90
DEG.
CANDELAS
180 336 336 336 336 336
175 338 338 338 338 339
165 324 329 336 349 345
155 299 310 332 359 368
145 257 282 325 371 387
135 204 240 308 383 414
125 160 209 318 462 500
115 99 165 361 522 569
105 49 148 341 402 411
95 13 75 55 34 34
90 0 0 0 0 0
85 0 1 1 1 0
75 1 1 1 2 2
65 2 2 2 9 15
55 36 48 56 51 51
45 160 200 304 290 236
35 215 236 379 549 557
25 266 270 315 369 392
15 299 299 309 320 318
5 316 316 318 317 317
0 317 317 317 317 317
REPORT NO: LRL 300-1N
CAT NO: LSB14C28
LAMPS: 1 F28T5
LUMENS: 2900
EFFICIENCY:85%
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY
REFLECTANCE
80 70 50
WALL REFLECTANCE
70 50 30 70 50 30 50 30 10
0878787787878626262
1807774727067555452
2746964676259504845
3696256625651454240
4635549575045413735
5584943524540373330
6544438484135332927
7504034453731302623
8463630413328272321
9423327383025252118
10 39 29 23 35 26 21 22 18 15
20% FLOOR CAVITY REFLECTANCE
DISTRIBUTION
Zone Lumens % Lamp % Luminaire
0-90 754 26.0 30.6
90-180 1713 59.1 69.4
0-180 2466 85.0 100.0
Calculations are for 28 watt T5 lamps, for 54 watt T5 lamps multiply by 1.7
Fixture Lengths & Mounting Locations
48"
(121.92cm)
4' 5-1/8"
(134.94cm)
96" (243.84cm)
8' 5-1/8" (256.86cm)
96" (243.84cm)
96" (243.84cm)
96" (243.84cm)
96" (243.84cm) 96" (243.84cm)
96" (243.84cm) 96" (243.84cm) 96" (243.84cm)
48"
(121.92cm)
48"
(121.92cm)
12' 5-1/8" (378.78cm)
16' 5-1/8" (500.70cm)
20' 5-1/8" (622.62cm)
24' 5-1/8" (744.54cm)
4-Foot 8-Foot
12-Foot
16-Foot
20-Foot
24-Foot
Mounting Accessories
Power Feed End Set
Straight Cord: LSBEC36WH (white)
LSBEC36AL (aluminum)
4 Wire Cord*: LSBEC36WHX4 (white)
LSBEC36ALX4 (aluminum)
Cable Assembly
Single Cable: LSBC36
Ceiling Grid Kit
CGK
Includes both Standard 1” (2.54cm
)
Tee Bar Clip & Slot Tee Clip
*Use for dimming, switching, and emergency battery packs.
Cable/Cord Assembly
Single Cable & Cord: LSBCC36
Single Cable & 4 Wire Cord*: LSBCC36X4
4-Foot
Module
8-Foot
Module
Cable/
Assembly
Power Feed
End Set
4-Foot Run 11
8-Foot Run 11
12-Foot Run 11 1 1
16-Foot Run 21 1
20-Foot Run 12 2 1
24-Foot Run 32 1
