BluDot Chicago 8 Box Quick start guide

Chicago 8 Box
DESIGNED IN 1997
ASSEMBLY NOTES | REV 04
@BLUDOT
We design all our pieces in our Minneapolis studio. Follow
along on Instagram for some sneak peeks into the process.
NEED A HAND?
Contact us at [email protected] or
844.425.8368 for assistance.

1 | 8 4 4 . 4 2 5 . 8 3 6 8 CHICAGO 8 BOX
Pt. 5001
64QTY
Pt. 1001
QTY
Pt. 8036
4QTY
64
Back Panel
8QTY
Horizontal Panel
16QTY
Side Panel
16QTY
Pt. 1218
4QTY
Pt. 8042
2QTY
3 Hole Post
QTY
5 Hole Post
4QTY4
Pt. 5005
64QTY
Pt. 5002
64QTY
Pt. 1217
QTY
Pt. 8041
4QTY4
8042
Anti-tip Strap
8041
An�-�p Bracket
Parts & Hardware

[e-mail] | 2ASSEMBLY NOTES
354
1 2
How to use the cam lock system
Note direction of cam arrow. Turn cam clockwise 1/2 turn or until tight. Note direction of cam arrow.

3 | 8 4 4 . 4 2 5 . 8 3 6 8 CHICAGO 8 BOX
PT. 5001 X 4 PT. 5005 X 4 PT. 5002 X 4
Side Panel
Horizontal Panel
Side Panel
Step 01
BEGIN ASSEMBLING CASE.
Attach side panels to horizontal panel as shown
using the provided hardware. Be sure to align
grooves on horizontal panel and side panels.
Refer to page 2 on how to use the cam lock system.

[e-mail] | 4ASSEMBLY NOTES
PT. 5001 X 4 PT. 5005 X 4 PT. 5002 X 4
Horizontal Panel
Step 03
FINISH ASSEMBLING CASE.
Finish assembling the case as shown. Repeat
steps 01-03 for remaining cases. Refer to page
2 on how to use the cam lock system.
Step 02
INSERT BACK PANEL.
Insert back panel into grooves in case.

5 | 8 4 4 . 4 2 5 . 8 3 6 8 CHICAGO 8 BOX
PT. 1001 X 16
5 Hole Post
3 Hole Post
Step 04
ASSEMBLING THE POSTS.
Assemble the posts as shown using the
provided hardware. Repeat step 04 for
remaining posts.

[e-mail] | 6ASSEMBLY NOTES
5 Hole Posts
3 Hole Posts
3 Hole Posts
Turn to level
Step 06
LEVEL THE CASES.
Level the cases as shown.
Step 05
INSTALLING THE POSTS.
Insert post as shown.
After the posts have
been installed, have
a second person help
lift and bring the cases
upright.

7 | 8 4 4 . 4 2 5 . 8 3 6 8 CHICAGO 8 BOX
PT. 1001 X 8
Step 07
ATTACHING THE CASES.
Attach the cases to the posts as shown
using the provided hardware.

[e-mail] | 8ASSEMBLY NOTES
PT. 1001 X 16
Step 08
ATTACHING THE CASES.
Attach the cases to the posts as shown
using the provided hardware.

9 | 8 4 4 . 4 2 5 . 8 3 6 8 CHICAGO 8 BOX
PT. 1001 X 8
Step 09
ATTACHING THE CASES.
Attach the cases to the posts as shown
using the provided hardware.

[e-mail] | 10ASSEMBLY NOTES
PT. 1001 X 16
Step 10
ATTACHING THE CASES.
Attach the cases to the posts as shown
using the provided hardware.

11 | 8 4 4 . 4 2 5 . 8 3 6 8 CHICAGO 8 BOX
Back
Panel
Top
8041
An�-�p Bracket
PT. 8041 x 2PT. 1217 x 4
Step 11
INSTALL ANTI-TIP BRACKETS TO CASE.
Brackets must be installed to top panel
of case. In order to prevent damage, it is
recommended that 7/64” pilot holes be drilled
prior to installation.

[e-mail] | 12ASSEMBLY NOTES
Side Panel
1” lower than
case top
PT. 8036 x 4*
8041
An�-�p Bracket
PT. 8041 x 2PT. 1218 x 4
Wall
Step 12
ATTACH ANTI-TIP BRACKETS TO THE WALL.
Wall anchors and fasteners are included for installation into
drywall. Please consult your local hardware professional to
determine the hardware best suited for your wall type.
Position the anti-tip brackets onto the wall 1” below case top
panel height as shown and mark hole locations with a pencil.
If the mounting locations are not positioned on a stud, drill 5/16”
clearance holes in the hole locations. Press wall anchors into
drilled holes.
If the hole locations are positioned on a stud, this step of
installing wall anchors may be skipped. Instead, drill 7/64” pilot
holes for the fasteners.
Secure anti-tip brackets in place using fasteners as shown.

13 | 8 4 4 . 4 2 5 . 8 3 6 8 CHICAGO 8 BOX
PT. 8042 X 2
8042
Anti-tip Strap
Step 13
SECURE THE CASE.
Install and tighten the
strap prior to using the
product.

BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
Additional Information
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt
and fingerprints, use a quality cleaner formulated for
wood furniture. Wipe completely dry with a soft cloth
in the direction of the wood grain.

BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
