Lightolier Lighting Systems A-10 User manual

Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt
Lighting Systems A-10
1BHFPG "MFSPOÜ4FSJFT-JHIU51FShDN4FDUJPO
$
2-3/16”
(5.56cm)
15
2
3
3-5/16”
(8.41cm)
8-1/16” (20.48cm)
NOT TO SCALE
Features
1. Housing: Extruded aluminumhousing in lengths of 4’ (121.92cm), 8’ (243.84cm)
and 12’ (365.76cm). There are no exposed fasteners. The end caps are die-cast
aluminumsculpted and finished to match the housing.
5. Shielding: Die-formed 20 gauge steel finished to match housing.
2. Reflector: Die-formed high purity anodized specular aluminum.
3. Lamping: One T5 28W or 54W lamp per four-foot nominal length. Provided
by others.
4. Alignment Mechanism: The housing and the end cap each have a draw tight
mechanismthat creates a hairline joint along and at the ends of the run. To
operate the mechanism, the installer tightens two screws.
Labels
UL, cUL and I.B.E.W.
Finish
Powder coated baked white or silver enamel.
Customcolors available, consult factory.
Mountings
All mounting is on 48” (121.92cm), 96” (243.84cm) and 144” (365.76cm) centers.
Cable Suspension (not shown) 4-1/2" (11.43cm) diameter flat canopy finished
white enamel, 1/16" (0.16cm) diameter stainless steel aircraft cable adjustable up
to 36" (91.44cm) and adjustable cable gripper. Cable mounting at the ends of a run
is not available when track is being used. Installing stems at the ends of the run
will prevent the fixture fromhanging off center caused by the weight of the track
fixture. Cable suspension can be used in the center of runs that have track
installed. Consult factory for other options.
Stem Mounting (not shown) - 4-1/2" (11.43cm) diameter flat canopy, 1/4"
(0.64cm) IP (1/2” (1.27cm) OD) stem. The stemcan accommodate up to 2-12 gauge
and 3-18 gauge solid wires. All components have a white finish.
Electrical
Ballast is <10% THD, 1.0 ballast factor, programstart. Color-coded quick
connectors allow ease of connection for joiner modules. For special circuiting
consult factory. Factory installed ballast disconnect allows the ballast to be
disconnected fromand reconnected to incoming power under load without turning
the entire circtuit off.
Dimming: 120/277 VAC 1% dimming level, 4 or 5 wire feed required.
Emergency Battery Pack: 28 watt: 520 lumens @ 90 minutes, 54 watt: 700
lumens @ 90 minutes.
Ordering Instructions
Individual Fixtures:
1. Order number of MODULES required.
2. Order one POWER FEED END SET per MODULE.
Continuous Rows:
1. Determine run length.
2. Order the appropriate number of MODULES for the complete run.
3. Order one POWER FEED END SET per run.
4. Order one INTERMEDIATE SUSPENSION per MODULE minus one per run.
5. For runs that exceed amperage limits, order the appropriate number of
INTERMEDIATE POWER FEEDS.
Module Ordering Information
Family Series Track Length Shielding Lamps Finish Options
A 2 B A
A= Track
B= No Track
4= 4-Foot
8= 8-Foot
12 = 12-Foot
A= Solid
B= Perf
C= Pierce
D= Lens
28 = 28w
54 = 54w
WH = White
AL = Aluminum
D1 = Dimming 120v
D2 = Dimming 277v
X5 = 5 Through Wires
Complete ordering instructions below.
E1 = Emergency Pack, 120v
E2 = Emergency Pack, 277v

Job Information Type:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt
Lighting Systems A-10
1BHFPG "MFSPOÜ4FSJFT-JHIU51FShDN4FDUJPO
$
Fixture Lengths and Mounting Locations
A2EC36ALX4 = Aluminum
A2EC36WHX4 = White
4 Wires 18ga.
Cable Power Feed
A2ES24ALX4 = Aluminum
A2ES24WHX4 = White
AC36
Intermediate
36" (91.44cm) Cable Set
ALS24
Intermediate
24" (60.96cm) White StemSet
ACC36X4
Intermediate 36" (91.44cm)
Cable & 4 Wire 18 ga.
Cord Set for Fluorescent Only
A2LAL= Aluminum
A2LWH = White
"L" Joiner Block
A2TAL = Aluminum
A2TWH = White
"T" Joiner Block
A2XAL = Aluminum
A2XWH = White
"X" Joiner Block
A2ILAL = Aluminum
A2ILWH = White
Inline Joiner Block
Mounting Accessories
End Set 36” (91.44cm) Cables
96” (243.84cm)
144” (365.76cm)
20’ 9-1/4” (633.10cm)
20-Foot
12’ 9-1/4” (389.26cm)
144” (365.76cm)
12-Foot
48” (121.92cm)
4-Foot
4’ 9-1/4” (145.59cm)
8-Foot
8’ 9-1/4” (267.34cm)
96” (243.84cm)
4 Wires 18ga.
StemPower Feed
End Set 24” (60.96cm) Cables
6" (15.24cm)
6"
(15.24cm)
6"
(15.24cm)
6" (15.24cm)
6"
(15.24cm)
4" (10.16cm)
4" (10.16cm)
4"
(10.16cm)
10" (25.40cm)
12”
(30.48cm)
12” (30.48cm)
12”
(30.48cm)
12” (30.48cm)
CANDLEPOWER CURVE CANDLEPOWER
ZONE 0 22 45 67 90
DEG.
CANDELAS
Performance
DISTRIBUTION
Zone Lumens % Lamp % Luminaire
0-90 0 0.0 0.0
90-180 4613 92.3 100.0
0-180 4613 92.3 100.0
1700
1275
850
425
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
ROOM CAVITY RATIO
70 50 30 70 50 30 50 30 10
088 88 88757575 515151
180 76 73686563 454342
273 66 61625753 393634
366 58 52565045 343129
460 51 45514439 302724
555 45 39473933 272321
651 40 34433529 242018
747 36 29403126 221815
843 33 26372823 191613
940 29 23342520 181412
10 37 27 21 31 23 18 16 13 10
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50
WALL REFLECTANCE
20% FLOOR CAVITY REFLECTANCE
180
175
165
155
145
135
125
115
105
95
90
85
75
65
55
45
35
25
15
5
0
616
617
595
553
484
403
307
202
99
17
2
0
0
0
0
0
0
0
0
0
0
616
618
601
564
511
448
388
440
578
338
48
0
0
0
0
0
0
0
0
0
0
616
617
607
591
576
662
979
1174
1066
365
23
0
0
0
0
0
0
0
0
0
0
616
614
614
620
700
1059
1461
1594
1148
388
15
0
0
0
0
0
0
0
0
0
0
616
615
620
636
783
1254
1609
1721
1192
349
0
0
0
0
0
0
0
0
0
0
0
REPORT NO: ITL50919
CAT NO: A2X4A54
LAMPS: 1-F54T5
LUMENS: 5000
EFFICIENCY: 92.3%
4' (121.92cm)
Module
8' (243.84cm)
Module
12' (365.76cm)
Module End Set Suspension
4' (121.92cm) Run 11
8' (243.84cm) Run 11
12' (365.76cm) Run 11
16' (487.68cm) Run 211
20' (609.60cm) Run 1111
24' (731.52cm) Run 211
