Lighting Systems Lytespread™Alpha Wall Mount LSAW-2
Page 1 of 2 2 Light T5 Per 4’ (Nominal) Section
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
Features
1. Housing: 18 gauge die-formed pierced steel. 1/4" Aluminum end caps with
access for through wiring. No exposed fasteners or hardware.
2. Lamping: 2-T5, 28 or 54 watt fluorescent lamps per 4’ section. By others.
3. Reflector: Precision die-formed, high reflectivity, and low iridescent
aluminum.
4. Diffuser: Opal acrylic.
Electrical
Ballast is electronic, meeting A.N.S.I. starting, end of life protection, T.H.D., A
sound rating, and end-of-life specifications. 3 Conductor 18 gauge wire. Color-
coded quick connectors allow ease of connection for fixture modules. For special
circuitry consult factory.
Dimming: Advance Mark X. Use Advance compatible 2 wire control (no extra
lead required).
Emergency Battery Pack: 54 Watt: 390-700 Lumens @ 90 min.
28 Watt: 370-520 Lumens @ 90 min.
Finish
Powder coated baked white enamel. Custom colors available, consult factory.
Mountings
Luminaires joined at 1 3/4" wide channel only. Housings are not contiguous.
There is a 1" separation between housings on 8’ and 12’ fixtures (see bottom
view drawing above). When fixtures are joined there will be the same 1"
separation between housings as on the 8’ and 12’ luminaires.
Options and Accessories
Dual Switching: Order the DS option for separate row switching. DS option
comes complete with the 4 through wire option.
4 and 5 Wire: Order X4 for EM Battery Pack. For non-standard dimming options;
order X5 option for Osram or DALI 54 Watt dimming and ESI 28 & 54 Watt.
Digital Dimming: Order X4 option for Lutron HiLume or ECO-10 54 Watt
dimming.
Consult Factory for any additional wiring conditions.
Labels
UL, cUL, and I.B.E.W.
Ordering Instructions
Individual Fixtures:
1. Order number of MODULES required.
2. Order one END SET per MODULE.
Continuous Rows:
1. Determine run length
2. Order the appropriate number of MODULES for the complete run.
3. Order one END SET for each run.
7 11/16"
7 7/16"
1 3/4"
3 1/2"
4" Slot
1.0000
0.1250
0.1875
Bottom View Pierce Pattern
Ordering Information
Type Lamps Lamp Type Length Ballast Voltage Options
2 = 2 Lamp T5 28 = 28 Watts 4 = 4 Foot Blank = Static 1 = 120 VAC Blank = No Options
54 = 54 Watts 8 = 8 Foot E = Emergency 2 = 277 VAC X4 = 4 Through Wires
12 = 12 Foot D = Dimming 3 = 347 VAC X5 = 5 Through Wires
(54W only) (Static only)
LSAW 2
Complete ordering instructions below.

Lighting Systems Lytespread™Alpha Wall Mount LSAW-2
Page 2 of 2 2 Light T5 Per 4’ (Nominal) Section
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
Job Information Type:
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50
% WALL REFLECTANCE
50 30 10 50 30 10 50 30 10
076 76 76 65 65 65 45 45 45
166 63 60 57 54 52 39 38 36
257 53 49 49 46 43 34 32 30
350 45 41 43 39 36 30 27 25
444 39 34 38 33 30 27 24 21
539 33 29 34 29 25 24 20 18
635 29 25 30 25 22 21 18 15
731 25 21 27 22 19 19 16 13
828 22 19 24 19 16 17 14 12
925 20 16 22 17 14 15 12 10
10 23 18 14 20 15 12 14 11 9
00
1010
180180
31003100
23252325
15501550
775775
2020
3030
4040
5050
6060
7070
808080
9090
100100100
110110
120120
130130
140140
150150
160160
170170170
Performance
Fixture Lengths & Mounting Locations
Candlepower Curve
Mounting Accessories
Candlepower Summary
ZONE CANDLEPOWER
DEG. 0 22 45 67 90
180 1672 1672 1672 1672 1672
175 1766 1760 1741 1711 1682
165 2143 2090 1940 1763 1623
155 2449 2388 2170 1794 1516
145 2720 2619 2275 1805 1352
135 2886 2739 2336 1738 1140
125 3077 2889 2305 1607 893
115 3004 2894 2293 1405 609
105 2025 2015 1845 1197 327
95 819 819 725 587 73
90 19 15 9 1 0
85 23 20 11 3 1
75 33 31 20 11 6
65 41 39 30 22 16
55 47 45 39 32 26
45 49 49 44 39 35
35 49 50 47 44 40
25 49 51 49 47 45
15 49 50 49 47 45
544 45 4443 43
042 42 4242 42
Report No. ITL52310
Cat No: LSAW254
Lamps: 2-F54T5
Lumens: 5000
Efficiency: 79.2%
ZONAL LUMEN SUMMARY
ZONE LUMENS % BARELAMP % LUMINAIRE
0 - 90 149 1.5 1.9
90 - 180 7774 77.7 98.1
0 - 180 7924 79.2 100.0
Pair of End Caps:
LSAWE
48-1/2" (OAL)
40 "
88 "
96-1/2" (OAL)
68 " 144-1/2" (OAL) 68 "
192-1/2" (OAL)
8" 88 "
88"
68 "
68 "
68 "
68 "
240-1/2" (OAL)
288-1/2" (OAL)
8"
8" 68"
88"
68"
4'
8'
