Tangent®Track Lighting System FXS99
Page 1 of 1 Power Trip Kit
Lightolier is a Philips group brand
Features
1. Wire Cover: Plastic Polycarbonate
2. Mounting Plate: .060 thick galvanized steel.
3. Round Knock Out: 7/8 dia. knockouts for electrical feed. Circuit can be fed
into connector. Offset to accommodate grid ceiling runners.
4. Ground Terminals: (3) ground terminals.
5. Circular Knock Out: Allows feeding from j-box with proper UL area for
splice inspection without removing connector from j-box.
6. Mounting Holes: (4) holes on 3.5 in. centers secure connector to j-box or
mounting surface.
7. Tangent Track Connector: (2) assemblies keyed to maintain proper polarity
with track. Installs into track providing electrical and mechanical connection.
8. Circuit Breaker Opening: One can be installed. Limits the amount of
electrical load that can be placed on the circuit. Can be used as standard On/
Off switch.
9. Electrical Wires: Three 12ga wires in metal sheathing at a 10' length.
10.Tamperproof Locking Screw: (2) Mechanically secures connector into
track. Color matches fixture color.
Finish
All Painted finishes are baked enamel.
Electrical
Capacity is 120 volts, 60Hz. All Tangent Track luminaires are polarized and
continuously grounded throughout. Electrical conductors are concealed in an
insulating liner. Intended for wiring to branch circuit building wire with ground.
All wiring must be in accordance with National and Local Codes.
Labels
U.L. listed. Note: to assure full compliance with local energy codes and regula-
tions check with your local code official
Ordering Information
Catalog No. Finish Mountings Compatible Plug in Breakers
FXS99 Silver Drywall and J-box mount only. Connects to Tangent Suspended
Track units.
Compatible with PLD Plug in Breakers. Refer to
Spec Sheet PLD120 for complete offering.
6.15
1.01
10' length
0.28
1.32
2.61
2.91
1
7
6
2
5
3
4
10
9
8
